DF-G1-NS-Q5 is a Banner DF-G1 Expert amplifier for plastic and glass fibre optic assemblies, with a single NPN output. Two 4-digit displays show the signal level in red and the threshold in green at the same time, so the margin is visible without a menu.

• Output: 1x NPN, 100 mA; response 200 µs, 500 µs, 2 ms or 5 ms by mode
• Light source: visible red, 660 nm
• Supply: 10-30 V DC, < 40 mA at 24 V (< 30 mA in ECO display mode)
• Housing: 10 mm wide, ABS/polycarbonate, for 35 mm DIN rail
• Environment: IP50, -10...+55 °C
• Connection: 150 mm PVC cable with M12 male connector, 4-pin

Teach methods are two-point, dynamic, and Light, Dark, Window or Calibration SET; Light Operate or Dark Operate is chosen with a switch on the front, and ON/OFF delays and one-shot timers are set from the menu or the remote teach wire. A 4-pin M12 cordset is needed.

1-channel

• • Input circuits monitored for wire break and short circuit
  • Complete galvanic isolation
  • HART transparent
  • Removable cage clamp terminals
  • ATEX, IECEx, cULus
  • Use in zone 2
  • SIL 2

S4BR30-300-S is the receiver of a Banner EZ-SCREEN S4B Type 4 safety light curtain with a 300 mm defined area and 30 mm resolution (hand detection). When any beam is interrupted, both OSSD safety outputs switch off; the lighted end cap shows clear, weak beam, blocked beam or fault from a distance.

• Defined area: 300 mm; resolution 30 mm; response time 7.5 ms
• Operating range: 0.1...12 m
• Outputs: two redundant PNP OSSD safety outputs, 24 V DC, max 0.5 A each; configurable pin for weak beam output or IO-Link (COM2)
• Supply: +24 V DC ±15 %, 96 mA typical without load
• Housing: anodised aluminium, 38 x 40 mm, glass-filled polycarbonate end caps
• Environment: IP65, -20...+55 °C, indoor use
• Connection: RD (removable disconnect) socket; 5-pin or 8-pin RD cordset with M12 ordered separately

With the 8-pin RD cordset the receiver monitors the contactors itself (EDM) and needs no external safety module; with the 5-pin cordset it is wired to a safety relay, safety controller or safety PLC. Reduced resolution can be switched on to ignore one blocked beam, and up to four pairs can be cascaded.

Type 4 per IEC 61496-1 and -2, Category 4 PL e per EN ISO 13849-1, SIL3 per IEC 61508. MTTFd 287 years, PFHd 3.08 × 10⁻⁹ (single pair).

S4BE30-300-S is the emitter of a Banner EZ-SCREEN S4B Type 4 safety light curtain with a 300 mm defined area and 30 mm resolution (hand detection). It projects a row of synchronised, modulated infrared beams (860 nm) from end to end of the housing, so there is no dead zone at either end.

• Defined area: 300 mm; resolution 30 mm; system response time 7.5 ms
• Operating range: 0.1...12 m
• Indicators: bi-colour status indicator, two tri-colour scan code indicators
• Supply: +24 V DC ±15 %, 33 mA typical
• Housing: anodised aluminium, 38 x 40 mm, glass-filled polycarbonate end caps
• Environment: IP65, -20...+55 °C, indoor use
• Connection: RD (removable disconnect) socket; RD cordset with M12 ordered separately

The emitter works only as a pair with an S4B receiver of the same length and resolution. The scan code (1 or 2) is set with switches in the RD cordset, so that two pairs mounted close to each other do not interfere.

Type 4 per IEC 61496-1 and -2, Category 4 PL e per EN ISO 13849-1, SIL3 per IEC 61508. MTTFd 287 years, PFHd 3.08 × 10⁻⁹ (single pair).

S4BA-MBK-11 is an end mount bracket kit for Banner EZ-SCREEN S4B safety light curtains: two L-brackets with a glass-filled polycarbonate adapter that lets the sensor rotate ±15°.

• Fits: S4B emitters and receivers with FID 3 or older
• Included: 2 brackets and mounting hardware
• Material: 8-gauge cold-rolled steel, black zinc finish; glass-filled polycarbonate adapter
• Adjustment: ±15° rotation

Not for FID 4 and later S4B units (the models with the lighted end cap). Light curtains longer than 900 mm also need a side mount bracket.

DES4-M51-D is the RD (removable disconnect) cordset that plugs directly into an S4B safety light curtain housing and brings the connection out to a 5-pin M12 male connector. It fits S4B units with FID 2 or later; the scan code switches sit in its housing-side connector.

• Connector: S4B RD female, straight / M12x1 male, straight, A-coded, 5-pin
• Cable: 0.4 m, black PVC, Ø 5.46 mm, 22 AWG
• Rating: 2 A, 60 V AC / 75 V DC
• Body: black PUR overmould, nickel-plated brass coupling nut
• Environment: IP65, -40...+70 °C

With the 5-pin cordset the S4B receiver is wired to a safety relay, safety controller or safety PLC.

LBFS-2.01111.0 is a capacitive point level switch from the Baumer CleverLevel series with a G 1/2" A ISO 228-1 BSC process thread. The Frequency Sweep measuring principle sets the switching point from the dielectric constant of the medium (DC > 1.5), and the device carries two independent outputs, SW1 and SW2, each set separately to High-Active or Low-Active logic.

• Switching: point level detection, Single Point, Two Point and Window trigger modes, hysteresis < ±1 mm, repeatability < ±1 mm
• Output: two PNP outputs (SW1, SW2), each separately High-Active or Low-Active, 50 mA, step response T90 0.1 s, adjustable damping 0...60 s
• Supply: 8.5...35 V DC, current consumption < 8 mA (typ.)
• Housing: stainless steel; wetted parts PEEK Natura and AISI 304 (1.4301), Ra ≤ 0.8 µm
• Environment: process temperature -40...115 °C (135 °C temporarily), process pressure -1...100 bar (-1...80 bar temporarily), IP67 and IP69K with a matching mating connector
• Connection: M12-A, 4-pin, polycarbonate connector with status LED indicators

The switch is intended for tanks and pipework in industrial plant with a G 1/2" internal thread and pressures up to 100 bar. Mounting position is free - top, bottom or side. Damping of up to 60 s is set so that surface movement or splashing does not cause false switching.

The PEEK material complies with USP Class VI. cULus listed, E365692. Marine approvals: DNV, Lloyd's Register and CCS. EMC compliance to EN 61326-1 and EN 50121-3-2.

LBFS-2.01421.0 is a capacitive point level switch from the Baumer CleverLevel series with a G 1/2" A hygienic process connection. The Frequency Sweep measuring principle sets the switching point from the dielectric constant of the medium (DC > 1.5), and the device carries two independent outputs, SW1 and SW2, each set separately to High-Active or Low-Active logic.

• Switching: point level detection, Single Point, Two Point and Window trigger modes, hysteresis < ±1 mm, repeatability < ±1 mm
• Output: two PNP outputs (SW1, SW2), each separately High-Active or Low-Active, 50 mA, step response T90 0.1 s, adjustable damping 0...60 s
• Supply: 8.5...35 V DC, current consumption < 8 mA (typ.)
• Housing: stainless steel; wetted parts PEEK Natura and AISI 316L (1.4404), Ra ≤ 0.8 µm
• Environment: process temperature -40...115 °C (135 °C temporarily), process pressure -1...10 bar, IP67 and IP69K with a matching mating connector
• Connection: M12-A, 4-pin, polycarbonate connector with status LED indicators

The switch is intended for tanks and pipework in food, beverage and pharmaceutical plant, where the Ra ≤ 0.8 µm surface finish and the hygienic connection allow CIP cleaning without removing the sensor. The hygienic connection limits process pressure to 10 bar. Mounting position is free - top, bottom or side.

Complies with EN 1935/2004, EN 10/2011 and EN 2023/2006, FDA, 3-A (74-07) and EHEDG EL Class I. The PEEK material complies with USP Class VI. cULus listed, E365692. Marine approvals: DNV, Lloyd's Register and CCS.

LBFS-2.01511.0 is a capacitive point level switch from the Baumer CleverLevel series with a G 1/2" A ISO 228-1 process connection for reverse assembly - the thread sits inside the body, so the sensor screws onto a nozzle projecting from the tank. Gasket ZPX3-14B0 (glass and aramide fibre with NBR) is included.

• Switching: point level detection from the dielectric constant of the medium (DC > 1.5), Single Point, Two Point and Window trigger modes, hysteresis < ±1 mm
• Output: two PNP outputs (SW1, SW2), each separately High-Active or Low-Active, 50 mA, step response T90 0.1 s, adjustable damping 0...60 s
• Supply: 8.5...35 V DC, current consumption < 8 mA (typ.)
• Housing: stainless steel; wetted parts PEEK Natura and AISI 304 (1.4301), Ra ≤ 0.8 µm
• Environment: process temperature -40...85 °C, process pressure -1...100 bar, IP67 and IP69K with a matching mating connector
• Connection: M12-A, 4-pin, polycarbonate connector with status LED indicators

The reverse-assembly build covers the case where the tank wall carries no internal thread and only a male-threaded nozzle is available. On this build the process temperature is limited to 85 °C and no temporary excursion above it is permitted. Mounting position is free - top, bottom or side.

The PEEK material complies with USP Class VI. cULus listed, E365692. Marine approvals: DNV, Lloyd's Register and CCS. EMC compliance to EN 61326-1 and EN 50121-3-2.

DES4-M81-D is the RD (removable disconnect) cordset that plugs directly into an S4B safety light curtain housing and brings the connection out to a 8-pin M12 male connector. It fits S4B units with FID 2 or later; the scan code switches sit in its housing-side connector.

• Connector: S4B RD female, straight / M12x1 male, straight, A-coded, 8-pin
• Cable: 0.4 m, black PVC, Ø 5.92 mm, 22 AWG
• Rating: 2 A, 60 V AC / 75 V DC
• Body: black PUR overmould, nickel-plated brass coupling nut
• Environment: IP65, -40...+70 °C

With the 8-pin cordset the S4B receiver provides EDM monitoring and can drive the contactors directly, without a separate safety module.

CSB-M1281M1281B is a Banner Y splitter with an 8-pin M12 male trunk and two 8-pin M12 female branches. All eight conductors are wired in parallel from the trunk to both branches.

• Connectors: trunk M12x1 male, 8-pin; branches 2x M12x1 female, 8-pin
• Cable lengths: trunk 0.3 m, each branch 0.3 m
• Wiring: pins 1-8 in parallel (brown, orange/black, orange, white, black, blue, green/yellow, violet)
• Junction: 35 x 17 mm, with a mounting hole

BC-M12F8-24-1 is a Banner single-ended cordset with a straight 8-pin M12 female connector and flying leads, unshielded.

• Connector: M12x1, female, straight, A-coded, 8 pins; nickel-plated brass coupling nut, black TPU body
• Cable: 1 m, black PVC, Ø 5.92 mm, 8 x 24 AWG; wire colours white, brown, green, yellow, gray, pink, blue, red
• Ratings: 2 A, 30 V; bend radius > 10x the outer diameter
• Environment: IP66, IP67, IP68, -40...+70 °C

UL and CE marked.

FW-ERKSM0516-PL-I-0613 is a TURCK field-wireable M12 Power female connector with L-coding (4+FE) for power connections up to 12 A and 63 VDC. The cores are terminated in IDC quick-connect terminals without stripping.

• Connector: M12 x 1 female, straight, L-coded, 4+FE, gold-plated brass (CuZn) contacts, more than 500 mating cycles
• Ratings: 12 A, 63 VDC
• Connection: IDC terminals for 0.75...1.5 mm² cores, cable outer diameter 6...13 mm
• Housing: black GD-Zn die-cast zinc, nickel-plated GD-Zn coupling nut, FPM/FKM seal; shieldable
• Environment: IP65, IP67 (assembled and screwed in); -40...+85°C

Approval: cULus.

S4BE14-300-S is the emitter of a Banner EZ-SCREEN S4B Type 4 safety light curtain with a 300 mm defined area and 14 mm resolution (finger detection). It projects a row of synchronised, modulated infrared beams (860 nm) from end to end of the housing, so there is no dead zone at either end.

• Defined area: 300 mm; resolution 14 mm; system response time 11.5 ms
• Operating range: 0.1...12 m
• Indicators: bi-colour status indicator, two tri-colour scan code indicators
• Supply: +24 V DC ±15 %, 33 mA typical
• Housing: anodised aluminium, 38 x 40 mm, glass-filled polycarbonate end caps
• Environment: IP65, -20...+55 °C, indoor use
• Connection: RD (removable disconnect) socket; RD cordset with M12 ordered separately

The emitter works only as a pair with an S4B receiver of the same length and resolution. The scan code (1 or 2) is set with switches in the RD cordset, so that two pairs mounted close to each other do not interfere.

Type 4 per IEC 61496-1 and -2, Category 4 PL e per EN ISO 13849-1, SIL3 per IEC 61508. MTTFd 289 years, PFHd 3.05 × 10⁻⁹ (single pair).

S4BR14-300-S is the receiver of a Banner EZ-SCREEN S4B Type 4 safety light curtain with a 300 mm defined area and 14 mm resolution (finger detection). When any beam is interrupted, both OSSD safety outputs switch off; the lighted end cap shows clear, weak beam, blocked beam or fault from a distance.

• Defined area: 300 mm; resolution 14 mm; response time 11.5 ms
• Operating range: 0.1...12 m
• Outputs: two redundant PNP OSSD safety outputs, 24 V DC, max 0.5 A each; configurable pin for weak beam output or IO-Link (COM2)
• Supply: +24 V DC ±15 %, 96 mA typical without load
• Housing: anodised aluminium, 38 x 40 mm, glass-filled polycarbonate end caps
• Environment: IP65, -20...+55 °C, indoor use
• Connection: RD (removable disconnect) socket; 5-pin or 8-pin RD cordset with M12 ordered separately

With the 8-pin RD cordset the receiver monitors the contactors itself (EDM) and needs no external safety module; with the 5-pin cordset it is wired to a safety relay, safety controller or safety PLC. Reduced resolution can be switched on to ignore one blocked beam, and up to four pairs can be cascaded.

Type 4 per IEC 61496-1 and -2, Category 4 PL e per EN ISO 13849-1, SIL3 per IEC 61508. MTTFd 289 years, PFHd 3.05 × 10⁻⁹ (single pair).

R58ECRGB1Q is a Banner R58E Expert registration mark sensor with a red, green and blue LED light source. During TEACH it picks the colour that gives the most contrast between the mark and its background and detects 16 levels of grey scale; the switching frequency is 10 kHz.

• Sensing: fixed focus 10 mm ±3 mm, image 1.2 x 3.8 mm, parallel to sensor length
• Light source: red 636 nm, green 525 nm, blue 472 nm, selected automatically during TEACH
• Outputs: bipolar, 1x PNP and 1x NPN, 100 mA each; response 50 µs, repeatability 15 µs
• Supply: 10-30VDC, max 75 mA at 10 VDC
• Housing: zinc alloy die-cast, acrylic lens
• Environment: IP67, -10...+55 °C
• Connection: 150 mm PVC pigtail with M12 5-pin connector

Static and Dynamic TEACH by push button or the gray remote wire; in Dynamic TEACH the shorter event becomes Output ON, so Light/Dark Operate is set automatically. Mount at about 15° to shiny surfaces. A 30 ms OFF-delay or ON-delay can be enabled.

Vibration and shock per IEC 60068-2-6 and IEC 60068-2-27.

QS186EQ8 is the emitter of a Banner QS18 series opposed-mode photo sensor pair. Its infrared beam reaches a QS18 receiver up to 20 m away; the emitter itself has no output.

• Sensing range: 20 m with a QS18 receiver
• Output: none (emitter)
• Supply: 10-30 V DC
• Housing: rectangular with M18 threaded nose, ABS, acrylic lens
• Environment: IP67, NEMA 6, -20...+70 °C
• Connection: integral M12 male connector, 4-pin

Needs a QS18 receiver, ordered separately. UL and CE approved.

PKG3M-0.6-PSW3M/TXL is a TURCK connection cable with a black PUR jacket rated for drag chains. The female end is straight and the male end is angled, which saves space where the cable leaves the device at a right angle.

• Connectors: M8 x 1 female, straight, and M8 x 1 male, angled, 3-pin each, gold-plated brass (CuZn) contacts, more than 100 mating cycles
• Cable: 0.6 m, PUR, black, Ø 4.1 mm, 3 x 0.34 mm², PP core insulation, core colours BN, BU, BK
• Ratings: 4 A, 50 V AC/60 V DC
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

SX5-B6 is the stand-alone model of the Banner SX5 Type 3 safety laser scanner, with its own OSSD pair and 6 switchable zone sets. Protective fields reach 5.5 m and warning fields 40 m over a 275° scan.

• Protective field: up to 5.5 m (70/150 mm resolution), 4 m (50 mm), 3 m (40 mm), 2.5 m (30 mm); warning field up to 40 m (90 % white)
• Outputs: 1 OSSD pair, 250 mA at 24 V DC, push-pull; 2 auxiliary outputs, 250 mA
• Scanning: 275°, angular resolution 0.1°, scan cycle 30 ms, response time programmable 62...1202 ms; 905 nm Class 1 laser
• Connection: I/O and power M12 A-coded 8-pin; Ethernet M12 D-coded 4-pin for the configuration software
• Supply: 24 V DC (19.2...30 V DC) SELV/PELV, 0.3 A without load
• Housing: aluminium alloy, yellow RAL 1003, replaceable PC window, 102 x 152 x 112.5 mm, 1.5 kg
• Environment: IP65, -10...+50 °C, 95 % RH non-condensing

The scanner is for indoor industrial use only - not outdoors, not through a window or other transparent material, and not where heavy vapour, smoke or dust is in the air. Commissioning needs the Banner SX5 configuration software and the machine interface and M12 Ethernet cables, ordered separately.

Type 3 (EN 61496-1), PL d and Category 3 (EN ISO 13849-1), SIL 2 (IEC 61508), SIL CL 2 (EN 62061), PFHd 6.38 × 10-8. CE and cULus.

SX5-M10 is a Master model of the Banner SX5 Type 3 safety laser scanner, with 2 OSSD pairs and up to 10 zone sets (12-pin connection). Remote SX5-R scanners can be added, and the configuration is held in a removable memory.

• Protective field: up to 5.5 m (70/150 mm resolution), 4 m (50 mm), 3 m (40 mm), 2.5 m (30 mm); warning field up to 40 m (90 % white)
• Outputs: 2 OSSD pairs, 250 mA at 24 V DC, push-pull; 2 auxiliary outputs, 250 mA
• Scanning: 275°, angular resolution 0.1°, scan cycle 30 ms, response time programmable 62...1202 ms; 905 nm Class 1 laser
• Connection: I/O and power M12 A-coded 12-pin or 8-pin; Ethernet M12 D-coded 4-pin; M12 8-pin port for remote scanners; removable memory in the system plug
• Supply: 24 V DC (19.2...30 V DC) SELV/PELV, 0.3 A without load
• Housing: aluminium alloy, yellow RAL 1003, replaceable PC window, 102 x 152 x 112.5 mm, 1.5 kg
• Environment: IP65, -10...+50 °C, 95 % RH non-condensing

The scanner is for indoor industrial use only - not outdoors, not through a window or other transparent material, and not where heavy vapour, smoke or dust is in the air. Commissioning needs the Banner SX5 configuration software and the machine interface and M12 Ethernet cables, ordered separately.

Type 3 (EN 61496-1), PL d and Category 3 (EN ISO 13849-1), SIL 2 (IEC 61508), SIL CL 2 (EN 62061), PFHd 6.38 × 10-8. CE and cULus.

SX5-M70 is a Master model of the Banner SX5 Type 3 safety laser scanner, with 3 OSSD pairs and up to 70 zone sets over its 17-pin and 8-pin connections. Remote SX5-R scanners can be added, and the configuration is held in a removable memory.

• Protective field: up to 5.5 m (70/150 mm resolution), 4 m (50 mm), 3 m (40 mm), 2.5 m (30 mm); warning field up to 40 m (90 % white)
• Outputs: 3 OSSD pairs, 250 mA at 24 V DC, push-pull; 2 auxiliary outputs, 250 mA
• Scanning: 275°, angular resolution 0.1°, scan cycle 30 ms, response time programmable 62...1202 ms; 905 nm Class 1 laser
• Connection: I/O and power M12 A-coded 17-pin + 8-pin; Ethernet M12 D-coded 4-pin; M12 8-pin port for remote scanners; removable memory in the system plug
• Supply: 24 V DC (19.2...30 V DC) SELV/PELV, 0.3 A without load
• Housing: aluminium alloy, yellow RAL 1003, replaceable PC window, 102 x 152 x 112.5 mm, 1.5 kg
• Environment: IP65, -10...+50 °C, 95 % RH non-condensing

The scanner is for indoor industrial use only - not outdoors, not through a window or other transparent material, and not where heavy vapour, smoke or dust is in the air. Commissioning needs the Banner SX5 configuration software and the machine interface and M12 Ethernet cables, ordered separately.

Type 3 (EN 61496-1), PL d and Category 3 (EN ISO 13849-1), SIL 2 (IEC 61508), SIL CL 2 (EN 62061), PFHd 6.38 × 10-8. CE and cULus.

SX5-ME70 is the Master model of the Banner SX5 Type 3 safety laser scanner with encoder inputs, so zone sets on an AGV can be selected by its speed, measured by two independent encoders. It has 3 OSSD pairs, up to 70 zone sets and a removable configuration memory.

• Protective field: up to 5.5 m (70/150 mm resolution), 4 m (50 mm), 3 m (40 mm), 2.5 m (30 mm); warning field up to 40 m (90 % white)
• Outputs: 3 OSSD pairs, 250 mA at 24 V DC, push-pull; 2 auxiliary outputs, 250 mA
• Scanning: 275°, angular resolution 0.1°, scan cycle 30 ms, response time programmable 62...1202 ms; 905 nm Class 1 laser
• Connection: I/O and power M12 A-coded 17-pin + 8-pin; Ethernet M12 D-coded 4-pin; M12 8-pin port for remote scanners; removable memory in the system plug
• Supply: 24 V DC (19.2...30 V DC) SELV/PELV, 0.3 A without load
• Housing: aluminium alloy, yellow RAL 1003, replaceable PC window, 102 x 152 x 112.5 mm, 1.5 kg
• Environment: IP65, -10...+50 °C, 95 % RH non-condensing

The scanner is for indoor industrial use only - not outdoors, not through a window or other transparent material, and not where heavy vapour, smoke or dust is in the air. Commissioning needs the Banner SX5 configuration software and the machine interface and M12 Ethernet cables, ordered separately.

Type 3 (EN 61496-1), PL d and Category 3 (EN ISO 13849-1), SIL 2 (IEC 61508), SIL CL 2 (EN 62061), PFHd 6.38 × 10-8. CE and cULus.

SX5-R is the Remote model of the Banner SX5 Type 3 safety laser scanner. It has no safety outputs of its own: it connects to an SX5 Master over an 8-pin M12 cable and switches the Master's OSSDs.

• Protective field: up to 5.5 m (70/150 mm resolution), 4 m (50 mm), 3 m (40 mm), 2.5 m (30 mm); warning field up to 40 m (90 % white)
• Outputs: none of its own - uses the OSSD pairs of the SX5 Master; each Remote adds 10 ms to the response time
• Scanning: 275°, angular resolution 0.1°, scan cycle 30 ms, response time programmable 62...1202 ms; 905 nm Class 1 laser
• Connection: M12 A-coded 8-pin to the Master or the next Remote
• Supply: 24 V DC (19.2...30 V DC) SELV/PELV, 0.3 A without load
• Housing: aluminium alloy, yellow RAL 1003, replaceable PC window, 102 x 152 x 112.5 mm, 1.5 kg
• Environment: IP65, -10...+50 °C, 95 % RH non-condensing

It works only with an SX5-M10, SX5-M70 or SX5-ME70 Master, ordered separately. The scanner is for indoor industrial use only - not outdoors, not through a window or other transparent material, and not where heavy vapour, smoke or dust is in the air.

Type 3 (EN 61496-1), PL d and Category 3 (EN ISO 13849-1), SIL 2 (IEC 61508), SIL CL 2 (EN 62061), PFHd 6.38 × 10-8. CE and cULus.

WKS4.5T-50/TXL is a TURCK shielded connection cable with an angled M12 female connector (5-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, angled, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 50 m, PUR, black, Ø 5.7 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

T18-2NAELIR-Q8 is a Banner T18-2 series opposed-mode emitter with infrared, 850 nm light, used with a T18-2 receiver. The right-angle 18 mm threaded housing has epoxy-encapsulated electronics and food-grade plastics, for wet and washdown areas.

• Sensing range: 25 m with a T18-2 receiver
• Light source: infrared, 850 nm LED
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, 18 mm thread, PBT polyester, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C; ECOLAB chemical compatibility
• Connection: M12 male connector, 4-pin

Vibration per MIL-STD-202G method 201A, shock per method 213B (75 g operating).

T18-2VPRL-Q8 is a Banner T18-2 series opposed-mode receiver, used with a T18-2 emitter. The right-angle 18 mm threaded housing has epoxy-encapsulated electronics and food-grade plastics, for wet and washdown areas.

• Sensing range: 25 m with a T18-2 emitter
• Output: complementary PNP (NO and NC), 100 mA total up to +55 °C; response 1.5 ms ON / 1 ms OFF
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, 18 mm thread, PBT polyester, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C; ECOLAB chemical compatibility
• Connection: M12 male connector, 4-pin

Vibration per MIL-STD-202G method 201A, shock per method 213B (75 g operating).

IM12-DI01-2S-2T-PR/24VDC is a 2-channel TURCK isolating switching amplifier in a 12.5 mm housing with two potential-free transistor outputs up to 10 kHz. It can be powered through a Power bridge, which also carries a collective fault signal; the connector for the bridge is included.

• Channels: 2 inputs for NAMUR sensors (EN 60947-5-6) or potential-free contacts
• Outputs: 2 potential-free, short-circuit-proof transistors, ≤30 V DC, 0.1 A, ≤10 kHz
• Supply: 10...30 V DC via terminals or Power bridge, ≤0.8 W
• Housing: polycarbonate/ABS, 120 x 12.5 x 117 mm, DIN rail (NS35)
• Connection: removable screw terminals, 0.2...2.5 mm²
• Environment: IP20, -25...+70 °C

DIP switches on the front set the output mode, input circuit monitoring and the operating mode. An input fault makes the red LED flash according to NE44 and blocks the transistor of that channel. Mechanical contacts need either monitoring switched off or the resistor wiring shown in the datasheet.

Approvals: ATEX, cULus; for use in ATEX Zone 2. Usable in safety circuits up to SIL 2 (IEC 61508).

PIRS1X326T5AL47 is a Banner plastic fibre-optic array for opposed-mode sensing: the 47 mm sensing end carries 32 fibre cores of Ø 0.25 mm side by side, so a small object anywhere along the array interrupts the light. The beam exits from the side of the flat sensing head.

• Array: 47 mm, 32 cores Ø 0.25 mm; side-view sensing head 55.2 x 20.2 x 8.7 mm
• Fibre: plastic, polyethylene jacket, length 2 m, T5 termination with stainless steel ferrule
• Bend radius: minimum 60 mm
• Temperature: -55...+70 °C

Supplied as a pair for emitter and receiver. The drawing states that it is not for use with D10 amplifiers; Banner gives a range of 438 mm with a DF-G1 amplifier.

PBCT23TMB5M4 is a Banner coaxial plastic fibre for diffuse mode: a 0.5 mm central core is surrounded by 9 cores of 0.25 mm in an M4 threaded stainless steel tip. The fibre is sheathed in SteelSkin, a stainless steel braid over a monocoil.

• Range: DF-G1 80 mm
• Fibre: 0.5 mm + 9 x 0.25 mm cores, length 1 m, TMB5 terminated sensor ends
• Tip: M4 x 0.7 stainless steel, 2 jam nuts and 1 lock washer included
• Sheath: SteelSkin stainless steel braid, Ø3.6 mm; branches Ø2.9 mm
• Bend radius: at least 12 mm; max +70 °C

PVD100Q is a Banner PVD series parts verification sensor for pick-to-light bin picking: four visible red beams across a 100 mm array, with green and red job lights on both sides of the housing. It works in diffuse mode, or in retroreflective mode when a reflector is mounted opposite, and adjusts itself without user setup.

• Sensing range: diffuse up to 400 mm (18 % grey card), retroreflective up to 2 m with 25 mm reflective tape
• Output: PNP or NPN and NO or NC selected by DIP switch, 150 mA
• Response: 400 ms, including 100 ms ON- and OFF-delay
• Supply: 12-30 V DC, < 75 mA at 24 V DC
• Housing: black painted aluminium, 30 x 15 mm cross-section, acrylic lenses
• Environment: IP62, NEMA 2, 0...+50 °C
• Connection: 2 m PVC cable with M12 5-pin male connector

The controller switches the green job light through the white wire to show which bin to pick from; a reach into the wrong bin turns the light red and switches the output. DIP switches behind the rubber cover also set steady or flashing job light and the job-light input polarity.

SMBAMS30RA is a Banner SMBAMS series right-angle bracket for sensors with a 30 mm housing. Its slots let the sensor be turned through more than 90°.

• Sensor hole: Ø31.0 mm
• Mounting: Ø6.5 mm hole and 26.8 × 7.0 mm slot
• Material: 2.6 mm (12-gauge) cold-rolled steel

BC-M12F5A-22-2 is a Banner single-ended cordset with a right-angle 5-pin M12 female connector and flying leads. The cable is UL listed as ITC and PLTC tray cable, sunlight resistant and rated Oil Res I and II.

• Connector: M12x1, female, right-angle, A-coded, 5 pins; nickel-plated brass coupling nut, black TPU body
• Cable: 2 m, black PVC, Ø 5.59 mm, 5 x 22 AWG; wire colours brown, white, blue, black, gray
• Ratings: 4 A, 30 V
• Bend radius: static ≥ 4x, dynamic ≥ 15x the outer diameter
• Environment: IP66, IP67, IP68, -40...+105 °C

UL 2250 ITC, UL 13 PLTC, UL 758 AWM 2517, CSA FT4 flame rating. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (50 G, 11 ms).

BC-M12F8A-24-2-SF is a Banner single-ended cordset with a right-angle 8-pin M12 female connector and flying leads. The cable has an aluminium foil shield with full coverage and an unterminated drain wire, so the shield is grounded at the cabinet end only.

• Connector: M12x1, female, right-angle, A-coded, 8 pins; nickel-plated brass coupling nut, black TPU body
• Cable: 2 m, black PVC, Ø 5.6 mm, 8 x 24 AWG, foil shield 100 % with drain wire
• Ratings: 2 A, 30 V; bend radius static 10x, dynamic 15x the outer diameter
• Environment: IP66, IP67, IP68, operating -40...+50 °C

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (50 G, 11 ms).

PSW3M-2/TEL is a TURCK sensor and actuator cable with a angled M8 male connector (3-pin) on one end and open cores on the other, for connecting sensors and actuators with an M8 female socket to a terminal box or controller.

• Connector: M8 x 1 male, angled, 3-pin, gold-plated brass (CuZn) contacts, black TPU body, nickel-plated brass coupling nut
• Cable: 2 m, PVC, black, Ø 4.3 mm, 3 x 0.34 mm², PVC core insulation, core colours BN, BU, BK
• Ratings: 4 A, 50 VAC / 60 VDC, test voltage 2000 V, more than 100 mating cycles
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The black PVC jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and LABS free.

Approval: cULus.

PSG3M-2/TEL is a TURCK sensor and actuator cable with a straight M8 male connector (3-pin) on one end and open cores on the other, for connecting sensors and actuators with an M8 female socket to a terminal box or controller.

• Connector: M8 x 1 male, straight, 3-pin, gold-plated brass (CuZn) contacts, black TPU body, nickel-plated brass coupling nut
• Cable: 2 m, PVC, black, Ø 4.3 mm, 3 x 0.34 mm², PVC core insulation, core colours BN, BU, BK
• Ratings: 4 A, 50 VAC / 60 VDC, test voltage 2000 V, more than 100 mating cycles
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The black PVC jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and LABS free.

Approval: cULus.

HA8141-16 is a TURCK field-wireable M12 female connector, straight, 4-pin, A-coded, for 6...8 mm cable with IDC terminals.

• Connector: M12, female, straight, A-coded, 4-pin, gold-plated CuZn contacts
• Ratings: 6 A, 50 V
• Connection: IDC terminals, conductors up to 0.75 mm², cable diameter 6...8 mm, M12 x 1 screw-in thread
• Housing: black PA body and contact carrier, nickel-plated brass (CuZn) coupling nut, FPM/FKM seal
• Environment: IP67 (screwed together); -5...+50°C fixed

HAS8141-16 is a TURCK field-wireable M12 male connector, straight, 4-pin, A-coded, for 6...8 mm cable with IDC terminals.

• Connector: M12, male, straight, A-coded, 4-pin, gold-plated CuZn contacts
• Ratings: 6 A, 50 V
• Connection: IDC terminals, conductors up to 0.75 mm², cable diameter 6...8 mm, M12 x 1 screw-in thread
• Housing: black PA body and contact carrier, nickel-plated brass (CuZn) coupling nut, FPM/FKM seal
• Environment: IP67 (screwed together); -5...+50°C fixed
