Q5XKILAF3000-Q8 is a Banner Q5X series Class 2 laser triangulation sensor that outputs distance over 95...3000 mm as a 4...20 mA signal and has a second channel for switching or IO-Link. It detects black targets below 6 % reflectance and shows the distance on its display.

• Repeatability (switching output): ±0.5 mm at 95...300 mm, ±0.25 % at 300...1000 mm, ±0.5 % at 1000...2000 mm, ±1 % at 2000...3000 mm
• Measuring range: 95...3000 mm
• Output 1: analog 4...20 mA, max. load 300 Ω; response time 0.5...2270 ms depending on measurement rate and averaging
• Output 2: PNP/NPN switching or IO-Link push/pull, 50 mA; IO-Link v1.1, 38.4 kbit/s, Smart Sensor Profile
• Supply: 12...30 V DC, < 1 W; protected against reverse polarity and transient overvoltage
• Housing: ABS, PMMA lens cover, polycarbonate display window; side mounting
• Environment: IP67, -10...+50 °C
• Connection: integral M12 male connector, 5-pin, rotatable through 270°

The analog span and the switch point are taught separately, so one sensor can feed a continuous distance value to the controller and signal a limit at the same time. The sensor reaches full performance after 10 minutes of warm-up.

Vibration per MIL-STD-202G method 201A, shock per method 213B condition I (100 g).

CL50GRYPQ is a Banner CL50 series 50 mm LED column light with green, red and yellow segments. Each colour is switched by its own PNP input, one colour at a time.

• Colours: green 525 nm (72 lm), red 625 nm (38 lm), yellow 590 nm (30 lm)
• Inputs: PNP, one per colour, response 10 ms
• Supply: 18-30 V DC, up to 100 mA per colour
• Housing: Ø50 x 114.2 mm, ABS/polycarbonate, black, M30x1.5 base mount
• Environment: IP67, -40...+50 °C
• Connection: integral M12 male connector, 4-pin

The light connects through a separately ordered 4-pin M12 female cordset. UL and CE approved.

DMP 457 is a stainless steel pressure transmitter designed for harsh marine, shipbuilding and offshore environments. It provides high accuracy and long-term stability for media compatible with 316L stainless steel, such as fuels, oils and water. With marine approvals (LR, DNV, GL, CCS), it is well suited for mechanical and plant engineering, the oil & gas sector and marine applications.

The industrial pressure transmitter DMP 335 is based on a stainless steel welded pressure sensor without fluid. This characteristic has a special advantage with applications where silicon oil or elastomeric seals cannot be used.

The industrial pressure transmitter DMP 335 is based on a stainless steel welded pressure sensor without fluid. This characteristic has a special advantage with applications where silicon oil or elastomeric seals cannot be used.

RKC4.4T-3/TEL is a TURCK connection cable with a straight M12 female connector (4-pin) on one end and open cores on the other.

• Connector: M12 x 1, female, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 3 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

WLS15XDW0640DSQP is a Banner WLS15 series 640 mm daylight white strip light in a sealed polycarbonate shell with an aluminum frame. The same model runs on 12 V DC or 24 V DC.

• Light: daylight white 5000 K, 700 lm, lighted length 566.4 mm
• Supply: 12 or 24 V DC, typical 0.76 A at 12 V, 0.40 A at 24 V
• Dimming: PWM 25...100 %, up to 1000 Hz
• Housing: polycarbonate, aluminum frame, polyamide end caps, 640 x 30.6 x 15.5 mm
• Environment: IP66, IP67, -40...+60 °C
• Connection: 150 mm PVC cable with 4-pin M12 male connector, stand-alone (non-cascade) model

The light is fixed with M4 screws through the integral slots (max. 0.56 N·m) or with snap clips. The cable must not be exposed to a high-pressure jet.

CE compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

EA5R1050PIXMODQ is the receiver of a Banner EZ-ARRAY measuring light curtain with a 1050 mm array of 210 beams at 5 mm spacing. The controller is built into the receiver: it evaluates the beam pattern and reports object position, height, width or count through two analog outputs, two discrete outputs and Modbus RTU.

• Resolution: 5 mm straight scan, 2.5 mm edge scan; minimum object 5 mm (low-contrast mode)
• Range: 400 mm...4 m between emitter and receiver
• Outputs: 2x analog 4-20 mA, 2x PNP 100 mA, Modbus RTU over RS485 (up to 15 nodes)
• Supply: 12-30 V DC, 105 mA at 24 V
• Housing: clear-anodised aluminium, acrylic lens cover; end-cap brackets and centre bracket included
• Environment: IP65, -40...+70 °C
• Connection: M12, 8-pin; cordset ordered separately

The receiver is configured with its six-position DIP switch or with the supplied PC software; a straight scan takes 2.8...26.5 ms depending on array length. It works with the EZ-ARRAY emitter of the same length, and each unit needs its own 8-pin M12 cordset.

QS18VP6LP is a Banner QS18 series polarised retroreflective photo sensor with a visible red 630 nm beam and a range of 3.5 m to a reflector. The polarising filter rejects light returned by shiny objects, so they break the beam instead of acting as a reflector.

• Sensing range: 3.5 m with a reflector
• Output: complementary PNP, Light Operate and Dark Operate
• Response: 0.6 ms; repeatability 150 µs
• Supply: 10-30 V DC
• Housing: rectangular with M18 threaded nose, ABS, acrylic lens
• Environment: IP67, NEMA 4X, -20...+70 °C
• Connection: 2 m PVC cable, 4 wires

Needs a reflector, ordered separately. Sensitivity is set with a potentiometer. UL and CE approved.

RSSD-RJ45S-4414-0.5M is a TURCK Industrial Ethernet cable with a straight M12 male connector on one end and a straight RJ45 male connector on the other (4-pin). The 4-wire CAT 5e cable is built to ISO/IEC 11801 and EN 50173 for 100 Mbit/s Ethernet.

• Connectors: M12 x 1 male, straight, D-coded / RJ45 male, straight; 4-pin
• Cable: 0.5 m, PUR, green, Ø 4.8 mm, 4 x 0.15 mm², core colours WHOG, WHBU, BU, OG, overall shield of aluminium foil and tinned copper braid
• Ratings: 3 A, 42 V; CAT 5e, impedance 100 Ω, capacitance 51 pF/m
• Housing: TPU, nickel-plated zinc die-cast (GD-Zn) coupling nut
• Environment: M12 IP67 (only when screwed in), RJ45 IP20; -40...+80°C fixed, -25...+80°C mobile
• Drag chain: at least 5 million bending cycles, bending radius ≥15 x Ø, torsion ±30°/m

The green PUR jacket is UV and oil resistant (IEC 60811-2-1), flame retardant (IEC 60332-1-2), resistant to weld spatter and free from halogen, silicone, PVC and LABS; RoHS compliant. Approval: cULus.

K30APT2FGRYF2QP is a Banner K30 FDA series 30 mm capacitive touch button with a three-colour indicator, in FDA-grade materials for food and washdown areas. It switches when touched with a bare or gloved hand, without mechanical force, and the green, red and yellow light are controlled by separate PNP inputs.

• Colours: green, red, yellow; colour 3 overrides 1 and 2, colour 2 overrides 1
• Inputs: PNP, one per colour, response 300 ms
• Output: PNP, normally open, momentary, 150 mA max, response 150 ms
• Supply: 12-30 V DC, 55 mA max
• Housing: Ø30 x 41 mm, FDA-grade copolyester, grey, M22x1.5 base mount
• Environment: IP67, IP69K, -40...+50 °C
• Connection: 150 mm PVC cable with M12 male connector, 8-pin, stainless steel

The button is immune to false triggering by water spray, detergents and oils, and needs a separately ordered 8-pin M12 female cordset.

Vibration tested to IEC 60068-2-6, shock to IEC 60068-2-27 (30 g, 11 ms). UL, CE and UKCA approved.

WLS15XDW0920DSQP is a Banner WLS15 series 920 mm daylight white strip light in a sealed polycarbonate shell with an aluminum frame. The same model runs on 12 V DC or 24 V DC.

• Light: daylight white 5000 K, 1050 lm, lighted length 846.4 mm
• Supply: 12 or 24 V DC, typical 1.14 A at 12 V, 0.60 A at 24 V
• Dimming: PWM 25...100 %, up to 1000 Hz
• Housing: polycarbonate, aluminum frame, polyamide end caps, 920 x 30.6 x 15.5 mm
• Environment: IP66, IP67, -40...+60 °C
• Connection: 150 mm PVC cable with 4-pin M12 male connector, stand-alone (non-cascade) model

The light is fixed with M4 screws through the integral slots (max. 0.56 N·m) or with snap clips. The cable must not be exposed to a high-pressure jet.

CE compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

Measurement range: -55°C to +125°C; Accuracy up to 0.5°C in the -10°C to +85°C range and up to 2°C in the -55°C to -125°C range; default probe length: 2x 1m- different probe lengh on request; IP67

LMK 809 is a plastic submersible level probe with a Ø45 mm housing and a flush ceramic sensor, designed for continuous level measurement in wastewater and aggressive media. The flush-mounted ceramic element simplifies cleaning when solids or sludge build up on the probe. Different cable and sealing materials are available to ensure maximum compatibility with the process environment, making LMK 809 well suited for sewage water, sludge and aggressive media.

Q12AB6FF30 is a Banner Q12 series miniature fixed-field photo sensor with a 30 mm cutoff and a small visible red spot focused at 16 mm. It detects objects closer than the cutoff and ignores the background beyond it.

• Sensing range: 30 mm cutoff, fixed
• Output: bipolar, 1 PNP and 1 NPN, Light Operate
• Response: 0.85 ms ON/OFF; repeatability 175 µs
• Supply: 10-30 V DC
• Housing: miniature rectangular, thermoplastic, polycarbonate lens
• Environment: IP67, -20...+55 °C
• Connection: 2 m PVC cable

The small housing fits where there is no room for an 18 mm sensor; there is no sensitivity adjustment. UL, CE and UKCA approved.

PFS4F-0.2 is a TURCK M8 male flange connector, 4-pin, for rear mounting, with 0.2 m PVC-insulated stranded wires.

• Connector: M8 x 1, male, straight, 4-pin, gold-plated bronze (CuSn) contacts, more than 100 mating cycles
• Wires: 0.2 m, PVC insulation, colours BK, WH, BU, BN
• Ratings: 4 A, 50 VAC / 60 VDC, contact resistance ≤5 mΩ
• Housing: nickel-plated brass (CuZn) flange, black TPU contact carrier, NBR seal, M8 x 1 thread
• Environment: IP65, IP67, IP68 (screwed together); -30...+90°C fixed

CE marked.

Q20-2KLAF3-Q is a Banner Q20-2 time-of-flight laser sensor with an adjustable cut-off up to 3 m. It ignores objects beyond the taught distance regardless of their colour, and IO-Link gives access to the measured distance, delay timers and diagnostics.

• Accuracy: 35 mm typical (mean of 256 samples); minimum object separation 50 mm
• Sensing range: 20...3000 mm on 90 % white card
• Outputs: channel 1 PNP and IO-Link V1.1 (Smart Sensor Profile, 38.4 kbaud); channel 2 PNP, PFM Pulse Pro or remote input; 50 mA total
• Supply: 10...30 V DC, < 35 mA; protected against reverse polarity
• Housing: compact ABS, 25.4 mm mounting hole spacing; Class 1 infrared laser 940 nm
• Environment: IP67, -20...+50 °C
• Connection: 150 mm PVC cable with M8 4-pin male connector

Four teach modes are selected with the button or remote wire: two-point background suppression (default), one-point object, one-point window (foreground suppression) and dual mode (intensity + distance). The visible red alignment LED can be switched off.

UL, CE and UKCA; FCC Part 15 Class B, ICES-003(B). Laser per IEC 60825-1:2014.

Q20-2KLAF2-Q is a Banner Q20-2 time-of-flight laser sensor with an adjustable cut-off up to 2 m. It ignores objects beyond the taught distance regardless of their colour, and IO-Link gives access to the measured distance, delay timers and diagnostics.

• Accuracy: 35 mm typical (mean of 256 samples); minimum object separation 50 mm
• Sensing range: 20...2000 mm on 90 % white card
• Outputs: channel 1 PNP and IO-Link V1.1 (Smart Sensor Profile, 38.4 kbaud); channel 2 PNP, PFM Pulse Pro or remote input; 50 mA total
• Supply: 10...30 V DC, < 35 mA; protected against reverse polarity
• Housing: compact ABS, 25.4 mm mounting hole spacing; Class 1 infrared laser 940 nm
• Environment: IP67, -20...+50 °C
• Connection: 150 mm PVC cable with M8 4-pin male connector

Four teach modes are selected with the button or remote wire: two-point background suppression (default), one-point object, one-point window (foreground suppression) and dual mode (intensity + distance). The visible red alignment LED can be switched off.

UL, CE and UKCA; FCC Part 15 Class B, ICES-003(B). Laser per IEC 60825-1:2014.

Q20-2KLAF2-Q5 is a Banner Q20-2 time-of-flight laser sensor with an adjustable cut-off up to 2 m. It ignores objects beyond the taught distance regardless of their colour, and IO-Link gives access to the measured distance, delay timers and diagnostics.

• Accuracy: 35 mm typical (mean of 256 samples); minimum object separation 50 mm
• Sensing range: 20...2000 mm on 90 % white card
• Outputs: channel 1 PNP and IO-Link V1.1 (Smart Sensor Profile, 38.4 kbaud); channel 2 PNP, PFM Pulse Pro or remote input; 50 mA total
• Supply: 10...30 V DC, < 35 mA; protected against reverse polarity
• Housing: compact ABS, 25.4 mm mounting hole spacing; Class 1 infrared laser 940 nm
• Environment: IP67, -20...+50 °C
• Connection: 150 mm PVC cable with M12 4-pin male connector

Four teach modes are selected with the button or remote wire: two-point background suppression (default), one-point object, one-point window (foreground suppression) and dual mode (intensity + distance). The visible red alignment LED can be switched off.

UL, CE and UKCA; FCC Part 15 Class B, ICES-003(B). Laser per IEC 60825-1:2014.

Q20-2KLAF3-Q5 is a Banner Q20-2 time-of-flight laser sensor with an adjustable cut-off up to 3 m. It ignores objects beyond the taught distance regardless of their colour, and IO-Link gives access to the measured distance, delay timers and diagnostics.

• Accuracy: 35 mm typical (mean of 256 samples); minimum object separation 50 mm
• Sensing range: 20...3000 mm on 90 % white card
• Outputs: channel 1 PNP and IO-Link V1.1 (Smart Sensor Profile, 38.4 kbaud); channel 2 PNP, PFM Pulse Pro or remote input; 50 mA total
• Supply: 10...30 V DC, < 35 mA; protected against reverse polarity
• Housing: compact ABS, 25.4 mm mounting hole spacing; Class 1 infrared laser 940 nm
• Environment: IP67, -20...+50 °C
• Connection: 150 mm PVC cable with M12 4-pin male connector

Four teach modes are selected with the button or remote wire: two-point background suppression (default), one-point object, one-point window (foreground suppression) and dual mode (intensity + distance). The visible red alignment LED can be switched off.

UL, CE and UKCA; FCC Part 15 Class B, ICES-003(B). Laser per IEC 60825-1:2014.

RSSD-4422-5M is a TURCK Industrial Ethernet cable with a straight M12 male connector (4-pin) on one end and open cores on the other. The 4-wire CAT 5e cable carries 100 Mbit/s Ethernet and PROFINET.

• Connector: M12 x 1 male, straight, D-coded, 4-pin
• Cable: 5 m, PUR, green, Ø 6.5 mm, 4 x 0.32 mm², core colours WH, YE, BU, OG, overall shield of aluminium foil and tinned copper braid
• Ratings: 4 A, 30 V; CAT 5e, impedance 100 Ω, capacitance 50 pF/m
• Housing: TPU, nickel-plated brass coupling nut
• Environment: IP67 (only when screwed in); -40...+80°C fixed, -30...+80°C mobile
• Drag chain: at least 5 million bending cycles, bending radius ≥15 x Ø, torsion ±180°/m

The green PUR jacket is halogen free (IEC 60754), oil resistant (IEC 60811-2-1) and flame retardant (IEC 60332-1-2); the cable is RoHS compliant and PNO compliant for PROFINET. Approval: UL Listed.

Q20-2PLP-Q5 is a Banner Q20-2 series polarized retroreflective photo sensor with a visible red 645 nm beam and a 5 m range with a BRT-92X92C reflector. The polarizing filter lets it detect dark and shiny objects.

• Sensing range: 5 m with BRT-92X92C reflector
• Output: PNP, Light or Dark Operate selected by switch, 100 mA
• Response: 600 µs; repeatability 144 µs
• Supply: 10-30 V DC, < 20 mA
• Housing: ABS, acrylic lens, 3 mm mounting holes at 25.4 mm spacing
• Environment: IP67, -25...+70 °C
• Connection: 150 mm PVC cable with M12 4-pin male connector

A green LED indicator shows power; the amber one shows light sensed and flashes at a marginal sensing condition. Sensitivity is set with a single-turn potentiometer. Default mode is Dark Operate.

Q20-2PLP-Q3 is a Banner Q20-2 series polarized retroreflective photo sensor with a visible red 645 nm beam and a 5 m range with a BRT-92X92C reflector. The polarizing filter lets it detect dark and shiny objects.

• Sensing range: 5 m with BRT-92X92C reflector
• Output: PNP, Light or Dark Operate selected by switch, 100 mA
• Response: 600 µs; repeatability 144 µs
• Supply: 10-30 V DC, < 20 mA
• Housing: ABS, acrylic lens, 3 mm mounting holes at 25.4 mm spacing
• Environment: IP67, -25...+70 °C
• Connection: 150 mm PVC cable with M8 3-pin male connector

A green LED indicator shows power; the amber one shows light sensed and flashes at a marginal sensing condition. Sensitivity is set with a single-turn potentiometer. Default mode is Dark Operate.

Q20-2PLP-2M is a Banner Q20-2 series polarized retroreflective photo sensor with a visible red 645 nm beam and a 5 m range with a BRT-92X92C reflector. The polarizing filter lets it detect dark and shiny objects.

• Sensing range: 5 m with BRT-92X92C reflector
• Output: PNP, Light or Dark Operate selected by switch, 100 mA
• Response: 600 µs; repeatability 144 µs
• Supply: 10-30 V DC, < 20 mA
• Housing: ABS, acrylic lens, 3 mm mounting holes at 25.4 mm spacing
• Environment: IP67, -25...+70 °C
• Connection: 2 m PVC cable, 3 wires

A green LED indicator shows power; the amber one shows light sensed and flashes at a marginal sensing condition. Sensitivity is set with a single-turn potentiometer. Default mode is Dark Operate.

Q20-2NLP-Q is a Banner Q20-2 series polarized retroreflective photo sensor with a visible red 645 nm beam and a 5 m range with a BRT-92X92C reflector. The polarizing filter lets it detect dark and shiny objects.

• Sensing range: 5 m with BRT-92X92C reflector
• Output: NPN, Light or Dark Operate selected by switch, 100 mA
• Response: 600 µs; repeatability 144 µs
• Supply: 10-30 V DC, < 20 mA
• Housing: ABS, acrylic lens, 3 mm mounting holes at 25.4 mm spacing
• Environment: IP67, -25...+70 °C
• Connection: 150 mm PVC cable with M8 4-pin male connector (3-wire sensor)

A green LED indicator shows power; the amber one shows light sensed and flashes at a marginal sensing condition. Sensitivity is set with a single-turn potentiometer. Default mode is Dark Operate.

Q20-2NLP-Q3 is a Banner Q20-2 series polarized retroreflective photo sensor with a visible red 645 nm beam and a 5 m range with a BRT-92X92C reflector. The polarizing filter lets it detect dark and shiny objects.

• Sensing range: 5 m with BRT-92X92C reflector
• Output: NPN, Light or Dark Operate selected by switch, 100 mA
• Response: 600 µs; repeatability 144 µs
• Supply: 10-30 V DC, < 20 mA
• Housing: ABS, acrylic lens, 3 mm mounting holes at 25.4 mm spacing
• Environment: IP67, -25...+70 °C
• Connection: 150 mm PVC cable with M8 3-pin male connector

A green LED indicator shows power; the amber one shows light sensed and flashes at a marginal sensing condition. Sensitivity is set with a single-turn potentiometer. Default mode is Dark Operate.

Q20-2PLP-Q is a Banner Q20-2 series polarized retroreflective photo sensor with a visible red 645 nm beam and a 5 m range with a BRT-92X92C reflector. The polarizing filter lets it detect dark and shiny objects.

• Sensing range: 5 m with BRT-92X92C reflector
• Output: PNP, Light or Dark Operate selected by switch, 100 mA
• Response: 600 µs; repeatability 144 µs
• Supply: 10-30 V DC, < 20 mA
• Housing: ABS, acrylic lens, 3 mm mounting holes at 25.4 mm spacing
• Environment: IP67, -25...+70 °C
• Connection: 150 mm PVC cable with M8 4-pin male connector (3-wire sensor)

A green LED indicator shows power; the amber one shows light sensed and flashes at a marginal sensing condition. Sensitivity is set with a single-turn potentiometer. Default mode is Dark Operate.

Q20-2VNLP-2M is a Banner Q20-2 series polarized retroreflective photo sensor with a visible red 645 nm beam and a 5 m range with a BRT-92X92C reflector. The polarizing filter lets it detect dark and shiny objects.

• Sensing range: 5 m with BRT-92X92C reflector
• Output: two NPN, one Light Operate and one Dark Operate (complementary), 100 mA total
• Response: 600 µs; repeatability 144 µs
• Supply: 10-30 V DC, < 20 mA
• Housing: ABS, acrylic lens, 3 mm mounting holes at 25.4 mm spacing
• Environment: IP67, -25...+70 °C
• Connection: 2 m PVC cable, 4 wires

A green LED indicator shows power; the amber one shows light sensed and flashes at a marginal sensing condition. Sensitivity is set with a single-turn potentiometer.

Q20-2NLP-2M is a Banner Q20-2 series polarized retroreflective photo sensor with a visible red 645 nm beam and a 5 m range with a BRT-92X92C reflector. The polarizing filter lets it detect dark and shiny objects.

• Sensing range: 5 m with BRT-92X92C reflector
• Output: NPN, Light or Dark Operate selected by switch, 100 mA
• Response: 600 µs; repeatability 144 µs
• Supply: 10-30 V DC
• Housing: ABS, acrylic lens, 3 mm mounting holes at 25.4 mm spacing
• Environment: IP67, -25...+70 °C
• Connection: 2 m PVC cable, 3 wires

A green LED indicator shows power; the amber one shows light sensed and flashes at a marginal sensing condition. Default mode is Dark Operate.

Q20-2VPLP-Q5 is a Banner Q20-2 series polarized retroreflective photo sensor with a visible red 645 nm beam and a 5 m range with a BRT-92X92C reflector. The polarizing filter lets it detect dark and shiny objects.

• Sensing range: 5 m with BRT-92X92C reflector
• Output: two PNP, one Light Operate and one Dark Operate (complementary), 100 mA total
• Response: 600 µs; repeatability 144 µs
• Supply: 10-30 V DC, < 20 mA
• Housing: ABS, acrylic lens, 3 mm mounting holes at 25.4 mm spacing
• Environment: IP67, -25...+70 °C
• Connection: 150 mm PVC cable with M12 4-pin male connector

A green LED indicator shows power; the amber one shows light sensed and flashes at a marginal sensing condition. Sensitivity is set with a single-turn potentiometer.

Q20-2NLP-Q5 is a Banner Q20-2 series polarized retroreflective photo sensor with a visible red 645 nm beam and a 5 m range with a BRT-92X92C reflector. The polarizing filter lets it detect dark and shiny objects.

• Sensing range: 5 m with BRT-92X92C reflector
• Output: NPN, Light or Dark Operate selected by switch, 100 mA
• Response: 600 µs; repeatability 144 µs
• Supply: 10-30 V DC, < 20 mA
• Housing: ABS, acrylic lens, 3 mm mounting holes at 25.4 mm spacing
• Environment: IP67, -25...+70 °C
• Connection: 150 mm PVC cable with M12 4-pin male connector

A green LED indicator shows power; the amber one shows light sensed and flashes at a marginal sensing condition. Sensitivity is set with a single-turn potentiometer. Default mode is Dark Operate.

M18TIP6EQ is a Banner M18T series non-contact infrared temperature sensor with a 6:1 distance-to-spot ratio and a sealed plastic face for food industry use. A thermopile detector measures the infrared energy an object emits and gives a 4-20 mA output proportional to its temperature, plus a PNP alarm.

• Accuracy: linearity ±2 °C at 0...+50 °C, ±1 °C or ±1 % above +50 °C; repeatability ±1 % or ±1 °C, whichever is greater
• Measuring range: -20...+300 °C; spectral range 8-14 µm; D:S 6:1; minimum taught span 10 °C
• Outputs: analog 4-20 mA, slope set by teach order; PNP alarm; response 75 ms (95 % step)
• Supply: 12-30 V DC, < 35 mA
• Protection: output short circuit
• Housing: M18 threaded barrel, 304 stainless steel, encapsulated
• Environment: IP67, -20...+70 °C; 5 min warm-up
• Connection: integral M12 male connector, 5-pin

The measuring window is taught with the push button or by remote teach, without potentiometers, and the target does not need to move. Linearity is specified for 0...+300 °C.

UL, CE and UKCA approved.

RKC4.4T-15-RSC4.4T/TXL is a TURCK extension cable with a straight M12 female connector on one end and a straight M12 male connector on the other (4-pin). The PUR jacket is rated for moving installation, including drag chains.

• Connectors: M12 x 1 female and M12 x 1 male, both straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 15 m, PUR, black, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

SOK-TL50-150A is a complete Banner elevated mounting kit that raises a TL50 tower light 150 mm above the surface. The pipe passes through a 30 mm drilled hole and the adapter on top gives a tapered transition to the light base.

• Fits: Banner TL50 tower lights
• Included: SA-M30TE12 adapter, SOP-E12-150A pipe, SA-E12M30 base cover
• Pipe: 150 mm, black anodised aluminium, ½" NPT

RSSD-4422-10M is a TURCK Industrial Ethernet cable with a straight M12 male connector (4-pin) on one end and open cores on the other. The 4-wire CAT 5e cable carries 100 Mbit/s Ethernet and PROFINET.

• Connector: M12 x 1 male, straight, D-coded, 4-pin
• Cable: 10 m, PUR, green, Ø 6.5 mm, 4 x 0.32 mm², core colours WH, YE, BU, OG, overall shield of aluminium foil and tinned copper braid
• Ratings: 4 A, 30 V; CAT 5e, impedance 100 Ω, capacitance 50 pF/m
• Housing: TPU, nickel-plated brass coupling nut
• Environment: IP67 (only when screwed in); -40...+80°C fixed, -30...+80°C mobile
• Drag chain: at least 5 million bending cycles, bending radius ≥15 x Ø, torsion ±180°/m

The green PUR jacket is halogen free (IEC 60754), oil resistant (IEC 60811-2-1) and flame retardant (IEC 60332-1-2); the cable is RoHS compliant and PNO compliant for PROFINET. Approval: UL Listed.

S4BE30-600-S is the emitter of a Banner EZ-SCREEN S4B Type 4 safety light curtain with a 600 mm defined area and 30 mm resolution (hand detection). It projects a row of synchronised, modulated infrared beams (860 nm) from end to end of the housing, so there is no dead zone at either end.

• Defined area: 600 mm; resolution 30 mm; system response time 10.0 ms
• Operating range: 0.1...12 m
• Indicators: bi-colour status indicator, two tri-colour scan code indicators
• Supply: +24 V DC ±15 %, 33 mA typical
• Housing: anodised aluminium, 38 x 40 mm, glass-filled polycarbonate end caps
• Environment: IP65, -20...+55 °C, indoor use
• Connection: RD (removable disconnect) socket; RD cordset with M12 ordered separately

The emitter works only as a pair with an S4B receiver of the same length and resolution. The scan code (1 or 2) is set with switches in the RD cordset, so that two pairs mounted close to each other do not interfere.

Type 4 per IEC 61496-1 and -2, Category 4 PL e per EN ISO 13849-1, SIL3 per IEC 61508. MTTFd 287 years, PFHd 3.08 × 10⁻⁹ (single pair).

S4BR30-600-S is the receiver of a Banner EZ-SCREEN S4B Type 4 safety light curtain with a 600 mm defined area and 30 mm resolution (hand detection). When any beam is interrupted, both OSSD safety outputs switch off; the lighted end cap shows clear, weak beam, blocked beam or fault from a distance.

• Defined area: 600 mm; resolution 30 mm; response time 10.0 ms
• Operating range: 0.1...12 m
• Outputs: two redundant PNP OSSD safety outputs, 24 V DC, max 0.5 A each; configurable pin for weak beam output or IO-Link (COM2)
• Supply: +24 V DC ±15 %, 96 mA typical without load
• Housing: anodised aluminium, 38 x 40 mm, glass-filled polycarbonate end caps
• Environment: IP65, -20...+55 °C, indoor use
• Connection: RD (removable disconnect) socket; 5-pin or 8-pin RD cordset with M12 ordered separately

With the 8-pin RD cordset the receiver monitors the contactors itself (EDM) and needs no external safety module; with the 5-pin cordset it is wired to a safety relay, safety controller or safety PLC. Reduced resolution can be switched on to ignore one blocked beam, and up to four pairs can be cascaded.

Type 4 per IEC 61496-1 and -2, Category 4 PL e per EN ISO 13849-1, SIL3 per IEC 61508. MTTFd 287 years, PFHd 3.08 × 10⁻⁹ (single pair).

TL50GYRAQ is a Banner TL50 series 50 mm LED tower light with 3 colour segments: green, yellow, red, from the bottom up, topped by a audible alarm. Each colour has its own input wire and the inputs are bimodal, so the tower can be driven from either PNP or NPN controller outputs.

• Colours: green 528 nm, yellow 590 nm, red 625 nm
• Audible: continuous tone, 2.7 kHz, up to 92 dB at 1 m, adjustable down to 62 dB
• Inputs: bimodal (PNP or NPN), one per colour, response 10 ms
• Supply: 18-30 V DC or 24 V AC 50/60 Hz, up to 45 mA per colour, alarm 25 mA
• Housing: Ø50 x 200.8 mm, ABS base and covers, polycarbonate light segments, black, M30x1.5 base mount
• Environment: IP50, -20...+50 °C
• Connection: integral M12 male connector, 5-pin

The tower connects through a separately ordered 5-pin M12 female cordset. Audible intensity is adjusted by unscrewing the top cover by up to 1.5 turns.

Vibration tested to IEC 60068-2-6, shock to IEC 60068-2-27 (30 g, 11 ms).

UWT NivoRadar NR 7200 is an 80 GHz FMCW radar level sensor for continuous, non-contact measurement of liquids up to 20 m. The narrow 8° beam avoids reflections from tank walls and internal fittings, and only the PVDF antenna is in contact with the medium.

• Warranty: extended to 6 years
• Measuring range: 0...20 m, accuracy ±2 mm
• Output: 2-wire 4...20 mA with HART
• Supply: 15...35 V DC, loop-powered
• Housing: PBT, G 1 1/2" thread (DIN ISO 228-1), PVDF wetted parts
• Environment: IP66/IP67, process temperature -40...+80 °C, pressure -1...+3 bar
• Connection: M20x1.5 cable gland
• Setup: display with push buttons under a transparent lid, or UWT LevelApp via Bluetooth

Used for level in storage and process tanks, IBCs and wastewater sumps, including many acids. Measures liquids with a dielectric constant from 1.1 - oils and solvents as well as water-based media.

CE, UKCA and cFMus approved for general-purpose (non-Ex) areas.

WKS4.5T-5/TXL is a TURCK shielded connection cable with an angled M12 female connector (5-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, angled, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PUR, black, Ø 5.7 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

RKH4.4-2/TFE is a TURCK hygienic-design connection cable for food and beverage production, with a straight M12 female connector (4-pin) on one end and open cores on the other.

• Connector: M12 x 1, female, straight, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 2 m, PVC, grey (RAL 7040), Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: grey PP, stainless steel (V4A) coupling nut, FPM/FKM seal
• Environment: IP65, IP67, IP68, IP69 (only when screwed in); -25...+80°C fixed, 0...+80°C mobile

The jacket resists acids, alkalis, oils and chemicals and is flame retardant per DIN EN 60332-1-2 and DIN EN 60332-2-2. RoHS and REACH compliant, approvals: Ecolab, GOST.

LBFS-2.01422.0 is a capacitive point level switch from the Baumer CleverLevel series with a G 1/2" A hygienic process connection and NPN outputs. The Frequency Sweep measuring principle sets the switching point from the dielectric constant of the medium (DC > 1.5), and the device carries two independent outputs, SW1 and SW2, each set separately to High-Active or Low-Active logic.

• Switching: point level detection, Single Point, Two Point and Window trigger modes, hysteresis < ±1 mm, repeatability < ±1 mm
• Output: two NPN outputs (SW1, SW2), each separately High-Active or Low-Active, 50 mA, step response T90 0.1 s, adjustable damping 0...60 s
• Supply: 8.5...35 V DC, current consumption < 8 mA (typ.)
• Housing: stainless steel; wetted parts PEEK Natura and AISI 316L (1.4404), Ra ≤ 0.8 µm
• Environment: process temperature -40...115 °C (135 °C temporarily), process pressure -1...10 bar, IP67 and IP69K with a matching mating connector
• Connection: M12-A, 4-pin, polycarbonate connector with status LED indicators

The NPN version is for control systems with a common positive potential, where inputs are switched to 0 V. In all other respects the switch matches the hygienic build for food, beverage and pharmaceutical plant: the Ra ≤ 0.8 µm surface finish allows CIP cleaning, and the hygienic connection limits process pressure to 10 bar.

Complies with EN 1935/2004, EN 10/2011 and EN 2023/2006, FDA, 3-A (74-07) and EHEDG EL Class I. The PEEK material complies with USP Class VI. cULus listed, E365692. Marine approvals: DNV, Lloyd's Register and CCS.

SA-F12 is a Banner flange base that fixes a ½" stand-off pipe to a flat surface. It is die-cast zinc, painted black.

• Fits: ½" NPSM/DN15 stand-off pipes
• Material: die-cast zinc, black paint
• Included: M5 mounting hardware and nitrile gasket

WKC4.4T-P7X2-30/TEL is a TURCK connection cable with an angled M12 female connector (4-pin) on one end and open cores on the other. The connector has two built-in LED indicators: green shows the supply, yellow the PNP signal on pin 4.

• Connector: M12 x 1, female, angled, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 30 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 30 V DC, more than 100 mating cycles
• Housing: translucent TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The PVC jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.
