SG-TL70B-Y is a Banner TL70B series yellow 70 mm light module for a modular tower light. When off the segment looks gray, so ambient light does not make it appear lit.

• Color: yellow, 590 nm, 55 lm
• Mode: steady or flashing 1.5 Hz / 3 Hz
• Supply: 12...30 V DC, 141 mA at 12 V, 71 mA at 24 V
• Housing: polycarbonate, Ø70 x 50 mm
• Environment: IP65, IP66, -40...+50 °C

The module twist-locks onto a TL70B series base. Unlike the TL70 series, the module has no settings of its own: it is driven by the base input that matches its position in the tower, and flashing is switched on with DIP switches in the base.

CE, UKCA and UL compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

Power supply: 11...30 VDC Range 0...100% LEL (0...5 %vol) CH4 Resolution 0,1 %LEL (50 ppm) CH4 Default alarm set-points 20 / 50 %LEL 2 × 4-20 mA / 0-10 V, RS485

Receiver SMR3215TBJ

WLS15PXRGB0500DSKQP is a Banner WLS15 Pro series 500 mm RGB strip light controlled over IO-Link. Besides color, flashing and intensity it has level, gauge and segment modes, so the strip can show a fill level or up to 10 separate status zones.

• Light: RGB, 19 color options, each LED individually controllable
• Communication: IO-Link, input response time max. 45 ms
• Supply: 18...30 V DC, typical 0.18 A at 24 V, max. 0.255 A
• Housing: polycarbonate with aluminum frame, polyamide end caps, 500 x 30.6 x 15.5 mm, lighted length 426.4 mm
• Environment: IP66, IP67, -40...+50 °C
• Connection: 150 mm PVC cable with 4-pin M12 male connector

Requires an IO-Link master port. If the master cannot supply the required current, Banner specifies a splitter cable and an external power supply.

CE compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

SG-TL70-AP is a Banner TL70 series 70 mm audible module that plays a user-loaded MP3 or WAV file instead of a fixed tone. It fits on top of a TL70 modular tower light base.

• Audio: MP3 or WAV files, 4 MB flash memory; ships with a 2.5 kHz steady tone
• Trigger: input channel selected with DIP switches; playback repeats while the input is active
• Supply: 12...30 V DC via DC base (330 mA at 12 V), or 100...240 V AC via B-TL70-Z base
• Housing: black polycarbonate, Ø70 x 79.6 mm
• Environment: IP50, -20...+50 °C

Files are loaded over the USB-USBM-1 cable: the module appears on the PC as a USB drive and files are copied onto it. A spoken message or a custom tone can then mark a specific machine state.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

SG-TL70-RGB14 is a Banner TL70 series RGB light module that shows one of 14 colors, chosen with DIP switches. One stocked module can stand in for several single-color segments.

• Colors: 14, including red, green, yellow, blue, white, cyan, magenta and orange
• Mode: steady, flashing or strobe 0.5 / 1.5 / 3 Hz, intensity sweep; high or low intensity
• Supply: 12...30 V DC, high intensity max. 350 mA at 12 V, typical 170 mA at 24 V
• Housing: black polycarbonate, Ø70 x 50 mm
• Environment: IP65, -40...+50 °C

The module twist-locks onto a B-TL70 series base. The black DIP switches set color and mode, the white ones the module's position in the tower (1...6).

CE and UKCA compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

B-TL70PK-QP is the IO-Link base module of the Banner TL70 Pro modular tower light. It carries up to six RGB segments, or five segments plus an audible, and every segment's color, flashing and animation is set over IO-Link.

• Modules: up to 6 SG-TL70P-RGB segments, or 5 segments plus SG-TL70-A, -AL or -AP audible in position 6
• Communication: IO-Link; Basic, Advanced, Run, Level and Gauge modes
• Supply: 18...30 V DC; RGB segment max. 156 mA at 24 V
• Housing: polycarbonate, M30x1.5 thread with nut, 1/2-14 NPT internal, max. 2.25 Nm
• Environment: IP65, UL Type 1, -40...+50 °C
• Connection: 150 mm PVC cable with 4-pin M12 male connector

Light and audible modules are ordered separately and the base needs an IO-Link master port. In Level and Gauge modes the tower shows a process value as a bar of lit segments.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

LMB30LP is a Banner low-profile flat bracket with a 30 mm mounting hole.

• Mounting hole: Ø30.5 mm
• Mounting: 2x Ø5.5 mm holes
• Dimensions: 65 x 50 mm
• Material: 300 series stainless steel

TLF100P3QP is a Banner TLF100 Pro series 100 mm tower light with three RGB segments in a flat housing that mounts flush on a machine surface. Each segment is switched by its own bimodal PNP or NPN input wire.

• Segments: 3, RGB multicolor, default green/yellow/red from the bottom; e.g. green 7.5 lm, yellow 9.8 lm, red 3.7 lm per segment
• Inputs: bimodal PNP/NPN, one wire per segment, response max. 250 ms; advanced mode adds PWM/PFM (100...5000 Hz), counter and timer inputs
• Supply: 12...30 V DC, typ. 59 mA per segment at 24 V
• Housing: black polycarbonate, 100 x 190 x 42.2 mm, flush mounting; supplied screws for surfaces up to 8 mm
• Environment: IP65, IP69K, UL Type 4X, -40...+50 °C
• Connection: 150 mm PVC cable with 5-pin M12 male connector

Colors, flash patterns, animations and the level, counter and timer modes are set with Banner's free Pro Editor software, which needs the Pro Converter Cable. The cable must not be cleaned with a high-pressure jet.

CE, UKCA and UL marked. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

TLF100P3KQP is a Banner TLF100 Pro series 100 mm tower light with three RGB segments in a flat housing that mounts flush on a machine surface. It is controlled entirely over IO-Link: color, flashing, dimming and animations are set from the controller.

• Segments: 3, RGB multicolor, default green/yellow/red from the bottom; e.g. green 7.5 lm, yellow 9.8 lm, red 3.7 lm per segment
• Communication: IO-Link, response max. 20 ms; basic segment, advanced segment, run, level and gauge modes
• Supply: 18...30 V DC, typ. 59 mA per segment at 24 V, device max. 560 mA
• Housing: black polycarbonate, 100 x 190 x 42.2 mm, flush mounting; supplied screws for surfaces up to 8 mm
• Environment: IP65, IP69K, UL Type 4X, -40...+50 °C
• Connection: 150 mm PVC cable with 4-pin M12 male connector

Needs an IO-Link master port; there are no discrete inputs, so the tower cannot be switched directly from a PLC output. The cable must not be cleaned with a high-pressure jet.

CE, UKCA and UL marked. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

TL15GYRAQ is a Banner TL15 series kit of four 15 mm in-line segments - green, yellow, red and an audible - that screw together on M12 connectors into an ultra-small tower light. Each segment responds to one pin, so a single 5-pin cable drives all four.

• Segments: green 535 nm (18 lm, pin 4), yellow 590 nm (22 lm, pin 1), red 620 nm (10 lm, pin 2), audible (pin 5)
• Audible: 2.9 kHz, 79 dB at 1 m
• Input: lights bimodal PNP/NPN, audible PNP
• Supply: lights 12 V DC (80 mA) or 24 V DC (40 mA) ±10 %; audible 12...30 V DC
• Environment: lights IP65, IP67, IP68; audible IP60; -40...+50 °C
• Connection: 5-pin M12 male/female on light segments, M12 male on audible

The kit can stand alone or be added in-line to a sensor or an existing tower light; the segments are packed separately and assembled on site.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

LMBS15SP is a Banner snap clip that holds a device in the S15 housing. It is fixed with the supplied thread-forming screws or with M5 or No. 10 hardware.

• Fits: Banner S15 housing
• Material: white polypropylene
• Mounting: clearance for M5 or No. 10 hardware
• Included: pack of 5, with thread-forming hardware

LC15T-127AL2RGQP is a Banner LC15T series capacitive touch switch that sits in an M12 line between the supply and a DC device. A single touch switches the output on (green) or off (red).

• Function: on/off, red = off, green = on
• Pass-through current: max. 4 A
• Supply: 12...30 V DC, 11 mA typical at 24 V
• Housing: polycarbonate, polyamide end caps, Ø15 x 126.9 mm, slots for M4 screws
• Environment: IP66, IP67, IK06, -40...+60 °C
• Connection: 150 mm PVC cables with 4-pin M12 male (input) and female (output)

Switches any DC device that takes constant power on pins 1 and 3, such as a Banner LED work light, without a separate switch box.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

S22AMTSGRHQP is a Banner S22 Pro series 22 mm touch button with a momentary output. With power applied it glows green; a touch switches the output and turns it red.

• Colors: green 527 nm, red 625 nm (touched)
• Output: bipolar, normally open, momentary, max. 150 mA; input response 20 ms, output 300 ms
• Supply: 10...30 V DC, 45 mA at 24 V
• Housing: polycarbonate base, dome and nut, M22x1.5 thread, max. 2.25 Nm
• Environment: IP66, IP67, IP69K, -40...+50 °C
• Connection: 150 mm PVC cable with 5-pin M12 male connector

Fits a standard 22 mm push-button hole in a panel and is configurable with Pro Editor.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (30 G, 11 ms).

S22ALTSGRHQ is a Banner S22 Pro series 22 mm touch button with a latching output. With power applied it glows green; a touch switches the output and turns it red.

• Colors: green 527 nm, red 625 nm (touched)
• Output: bipolar, normally open, latching, max. 150 mA; input response 20 ms, output 300 ms
• Supply: 10...30 V DC, 45 mA at 24 V
• Housing: polycarbonate base, dome and nut, M22x1.5 thread, max. 2.25 Nm
• Environment: IP66, IP67, IP69K, -40...+50 °C
• Connection: integral 5-pin M12 male connector

Fits a standard 22 mm push-button hole in a panel and is configurable with Pro Editor.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (30 G, 11 ms).

K30PAF100AMGRY3Q is a Banner K30 Pro series 30 mm touchless button: an infrared adjustable-field sensor behind an RGB dome that switches when a hand or object comes within the taught distance, up to 100 mm, and ignores what lies beyond it.

• Sensing: adjustable field up to 100 mm, infrared 940 nm; object, background or window teach
• Output: bipolar, normally open, momentary, max. 150 mA, response 120 ms
• Indicator: green (5.8 lm), yellow (7.9 lm), red (3.2 lm) by default; 14 colors via Pro Editor
• Supply: 10...30 V DC, 30 mA typical at 24 V
• Housing: polycarbonate base, dome and nut, M22x1.5 thread
• Environment: IP65, -20...+50 °C
• Connection: integral 5-pin M12 male connector

The switch point is taught over the remote input wire or the Pro Converter Cable button; the dome shows signal strength in green, yellow or red during teach. Allow 5 minutes warm-up for best repeatability.

Vibration per MIL-STD-202F method 201A, shock per method 213B (75 G operating).

K30PTALGRY3Q is a Banner K30 Pro series 30 mm touch button with an RGB indicator and a latching output. Two inputs select green, yellow or red; colors, animation, output logic and touch sensitivity are changed with Pro Editor software.

• Colors (default): green 522 nm (7.7 lm), yellow 576 nm (7.8 lm), red 620 nm (3.1 lm); up to 14 colors via Pro Editor
• Output: bipolar, normally open, latching, max. 100 mA; input response 40 ms, output 300 ms
• Supply: 12...30 V DC, 80 mA at 12 V, 40 mA at 24 V
• Housing: polycarbonate base, dome and nut, M22x1.5 thread, Ø30 x 54.5 mm
• Environment: IP67, IP69K, -40...+50 °C
• Connection: integral 5-pin M12 male connector

Programming needs the Pro Converter Cable and Pro Editor. The M22 base fits a standard 22 mm push-button hole.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (30 G, 11 ms).

K50PTVKQ is a Banner K50 Pro series 50 mm touch button with an RGB indicator, vibration feedback on touch and IO-Link control. The touch state is reported to the controller, which also sets color, animation and output logic.

• Indicator: 14 default colors plus custom colors
• Vibration feedback: steady or pattern, max. 3 s per touch, 500 000 cycles
• Communication: IO-Link COM2 (38.4 kbps), process data 2 bytes in, 10 bytes out
• Function: NO or NC, momentary or latching, on/off delay 0...60 000 ms
• Supply: 18...30 V DC, 93 mA typical at 24 V
• Housing: polycarbonate, M30x1.5 thread, Ø50 x 66 mm; IP67, IP69K, -40...+50 °C
• Connection: integral 4-pin M12 male connector

Needs an IO-Link master port. The vibration gives the operator a confirmation that can be felt through gloves.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (30 G, 11 ms).

K50PCLRGB7KAQP is a Banner K50 Pro series compact 50 mm RGB indicator with a built-in audible, controlled entirely over IO-Link. Color, flashing, dimming, animation and the audible tone are set from the controller.

• Indicator: RGB multicolor, e.g. green 8.9 lm, yellow 11.6 lm, red 3.9 lm
• Audible: 14 tones, 2.9 kHz continuous tone at 83 / 88 / 92 dB (1 m)
• Communication: IO-Link, input response 250 ms
• Supply: 18...30 V DC, 83 mA at 24 V, max. 145 mA
• Housing: polycarbonate base, dome and nut, M30x1.5 thread, Ø50 x 69.6 mm
• Environment: IP67, IP69K, UL Type 4X, -40...+50 °C
• Connection: 150 mm PVC cable with 4-pin M12 male connector

Needs an IO-Link master port; there are no discrete inputs, so it cannot be driven directly from a PLC output.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (30 G, 11 ms).

WC-K50C is a Banner silicone cover that protects K50 compact indicators and touch buttons in washdown areas.

• Fits: Banner K50 compact indicators and touch buttons
• Material: FDA-grade silicone
• Protection rating: IP67 and IP69K

SMB30SC is a Banner swivel bracket for sensors with a 30 mm housing. Once the orientation is set, the swivel is locked with the included screw.

• Sensor hole: Ø30.0 mm
• Mounting: Ø7.0 mm holes on a Ø50.8 mm circle
• Material: black reinforced thermoplastic polyester
• Included: stainless steel mounting and swivel locking hardware

TX107-00VPST is a 7" touch display from the TURCK TX100 series with TX VisuPro runtime, a plastic housing and a resistive touchscreen behind a plastic front film. It works as an operator panel only and has no built-in PLC.

• Display: 7" TFT, 800 x 480 (WVGA), 16:9, 64K colours, 200 cd/m², resistive, dimmable
• Communication: 1 x RJ45 Ethernet 10/100 Mbit, 1 x RS232/RS485/RS422, 1 x USB host
• Software: TX VisuPro runtime; ARM Cortex A8, 1 GHz, 512 MB RAM, 4 GB Flash
• Supply: 24 VDC (10...32 VDC), max. 0.3 A
• Housing: plastic, front 187 x 147 x 34 mm, cut-out 176 x 136 mm, mounting depth 29+5 mm
• Environment: IP66 front, IP20 rear, NEMA 2/4X; 0...+50 °C, 5...85 % RH non-condensing

Built into a cabinet door or control desk. Mounting brackets and the power connector come in the TX100 mounting kit, available as an accessory. There are no expansion slots.

Approvals: Haz. Loc. Class I, Division 2, Groups A, B, C and D.

Sn = 3 mm, M8×1 metal thread (nickel-plated brass), flush, short barrel, with cable connection (3 m), 10–30V DC, PNP NO (operable as 2-wire PNP/NPN NO), IP67

RKSV8T-25/TEG1023 is a TURCK shielded connection cable with a straight M12 female connector (8-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 8-pin, gold-plated brass (CuZn) contacts
• Cable: 25 m, grey (RAL 7035), Ø 6.4 mm, 8 x 0.25 mm², core colours BN, WH, BU, BK, GY, PK, VT, OG
• Shield: aluminium foil and tinned copper wire
• Ratings: 2 A, 30 V, more than 100 mating cycles
• Housing: TPU, grey, stainless steel (V4A) coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -40...+80°C mobile

The cable jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS.

Approval: cULus.

WKC4.4T-30/TEL is a TURCK connection cable with an angled M12 female connector (4-pin) on one end and open cores on the other.

• Connector: M12 x 1, female, angled, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 30 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The PVC jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

WKC4.4T-25/TXL is a TURCK connection cable with an angled M12 female connector (4-pin) on one end and open cores on the other.

• Connector: M12 x 1, female, angled, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 25 m, PUR, black, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The PUR jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

TC42HLRRVJ is an Ascon Tecnologic TC42 timer, counter and power limiter in a 48 x 48 mm (1/16 DIN) case with a white and orange dual display. The CNT (count enable) and RST (reset) inputs take volt-free contacts or NPN/PNP signals. This version is set up from the keyboard: it has no NFC programming, internal buzzer or battery.

• Inputs: 2 digital inputs (CNT, RST) for volt-free contacts or NPN/PNP logic
• Outputs: OUT1 and OUT2 relay SPDT 8 A resistive, 1/2 HP 250 V, 100 000 operations
• Timer: 4 scales - 9999 h, 99 h 59 min, 99 min 59 s, 99.99 s; accuracy ±0.1% fs
• Counter: up to 9999, counting frequency up to 200 Hz
• Supply: 100...240 Vac/Vdc ±10%, approx. 3 VA
• Case: 48 x 48 mm, depth 62.3 mm, panel cut-out 45 x 45 mm, screw terminals 0.2...2.5 mm²; IP65 front with gasket, 0...50 °C

Conforms to low voltage directive 2014/35/EU (EN 60730-1, EN 60730-2-7, EN 61812-1, UL 508) and EMC directive 2014/30/EU (EN 55011 class B).

TC42LLRRVJ is an Ascon Tecnologic TC42 timer, counter and power limiter in a 48 x 48 mm (1/16 DIN) case with a white and orange dual display. The CNT (count enable) and RST (reset) inputs take volt-free contacts or NPN/PNP signals. This version is set up from the keyboard: it has no NFC programming, internal buzzer or battery.

• Inputs: 2 digital inputs (CNT, RST) for volt-free contacts or NPN/PNP logic
• Outputs: OUT1 and OUT2 relay SPDT 8 A resistive, 1/2 HP 250 V, 100 000 operations
• Timer: 4 scales - 9999 h, 99 h 59 min, 99 min 59 s, 99.99 s; accuracy ±0.1% fs
• Counter: up to 9999, counting frequency up to 200 Hz
• Supply: 24 Vac/Vdc ±10%, approx. 3 VA
• Case: 48 x 48 mm, depth 62.3 mm, panel cut-out 45 x 45 mm, screw terminals 0.2...2.5 mm²; IP65 front with gasket, 0...50 °C

Conforms to low voltage directive 2014/35/EU (EN 60730-1, EN 60730-2-7, EN 61812-1, UL 508) and EMC directive 2014/30/EU (EN 55011 class B).

XX4CHXX-5905309602250 Efento HC5 NB-IoT Leakage detector/customer Resistance defined, IP67 sensor with U.FL antenna, 4 channel

The secure, connected mailbox that lets you receive and return all your parcels and letters, even when you're not available.

The automatic parcel locker dedicated to receiving even the largest everyday parcels for private or professional customers.

FW-EWKSM0426-FD-P-0408 is a TURCK field-wireable M12 female connector, angled, with D-coding (4-pin) for Industrial Ethernet. The cores are connected in push-in terminals and the cable shield is picked up by an iris spring onto the metal housing.

• Connector: M12 x 1 female, angled, D-coded, 4-pin, gold-coated bronze (CuSn) contacts with nickel sublayer, more than 100 mating cycles
• Ratings: 48 VAC / 60 VDC, insulation resistance ≥10⁸ Ω
• Connection: push-in terminals for 0.14...0.75 mm² cores (0.08...0.5 mm² with ferrules), cable outer diameter 4...8 mm
• Housing: nickel-plated GD-Zn die-cast zinc body and coupling nut, NBR seal, black PA 6.6 contact carrier
• Environment: IP65, IP67 (assembled and screwed in); -40...+85°C

Approval: cULus. Flammability class UL 94 V0, RoHS compliant.

SR-IM-9A is a Banner interface module with three 6 A safety output channels. Each NO channel is built from contacts of two force-guided relays in series, and the NC feedback contacts Y1-Y4 go to the EDM input of the light curtain or safety module that drives it - that is how the combination reaches Category 4 and PL e.

• Outputs: 3 NO safety channels, 6 A each; max. 250 V AC / 24 V DC
• Switching capacity: AC-15 250 V AC 3 A; DC-13 24 V DC 2 A; contacts AgNi + 0.2 µm gold
• Input: 24 V DC ±15 %, no polarity, 50 mA per channel, from OSSD or hard-contact outputs
• Response and life: 20 ms max.; mechanical 20 million operations; electrical 1,000,000 cycles at 450 VA
• Housing: polycarbonate, 22.5 mm wide, 35 mm DIN rail, push-in spring clamp terminals 0.2...2.08 mm²
• Environment: IP20 (install in an IP54 enclosure), 0...+50 °C, 90 % RH at +50 °C

For inductive loads, fit suppressors across the load, never across the output contacts. Each spring clamp terminal takes one wire only.

Up to SIL 3 (IEC 61508, IEC 62061), Category 4 and PL e (EN ISO 13849-1) with EDM; PFHd 2.1 × 10-10. CE, UKCA, UL.

SR-IM-11A is a Banner interface module with two 6 A safety output channels and one 6 A NC auxiliary channel. Each NO channel is built from contacts of two force-guided relays in series, and the NC feedback contacts Y1-Y4 go to the EDM input of the light curtain or safety module that drives it - that is how the combination reaches Category 4 and PL e.

• Outputs: 2 NO safety channels + 1 NC auxiliary channel, 6 A each; max. 250 V AC / 24 V DC
• Switching capacity: AC-15 NO 250 V AC 3 A, NC 250 V AC 2 A; DC-13 24 V DC 2 A; contacts AgNi + 0.2 µm gold
• Input: 24 V DC ±15 %, no polarity, 50 mA per channel, from OSSD or hard-contact outputs
• Response and life: 20 ms max.; mechanical 20 million operations; electrical 1,000,000 cycles at 450 VA
• Housing: polycarbonate, 22.5 mm wide, 35 mm DIN rail, push-in spring clamp terminals 0.2...2.08 mm²
• Environment: IP20 (install in an IP54 enclosure), 0...+50 °C, 90 % RH at +50 °C

For inductive loads, fit suppressors across the load, never across the output contacts. Each spring clamp terminal takes one wire only.

Up to SIL 3 (IEC 61508, IEC 62061), Category 4 and PL e (EN ISO 13849-1) with EDM; PFHd 2.1 × 10-10. CE, UKCA, UL.

For T-groove cylinders

FW-D9TLEDKU9PG-W-FC-ME-SH-8.5 is a TURCK field-wireable 9-pin Sub-D male connector for PROFIBUS-DP, with a 90° cable outlet and IDC terminals for 6...8 mm cable.

• Connector: Sub-D, male, 90° cable outlet, 9-pin, gold-plated CuZn contacts, more than 200 mating cycles
• Ratings: 4 A, 12 V
• Bus functions: integrated controller for clock rates up to 12 Mbit/s, switchable terminating resistor, LEDs for bus cable functions, integrated PG diagnostic socket
• Connection: IDC terminals, cable diameter 6...8 mm, shieldable
• Housing: die-cast zinc (GD-Zn) body, black PA contact carrier
• Environment: IP20, pollution degree 1; -20...+75°C fixed

Approval: UL.

PBMN-24B22RA14471212000 is a Baumer PBMN series relative pressure sensor with a flush membrane, a 0...10 bar measuring range and a 4...20 mA two-wire output. The cooling neck allows permanent operation at process temperatures up to 200 °C.

• Accuracy: max. measuring error ±0.25 % FSR, including zero-point and span error, non-linearity and hysteresis (EN 61298-2); long-term stability ≤ 0.1 % FSR per year
• Measuring range: 0...10 bar, relative pressure; temperature coefficient ≤ 0.03 % FSR/10 K (zero point and span), compensated range -40...+85 °C
• Output: 4...20 mA, 2-wire, response time ≤ 5 ms; zero point and span adjustable with FlexProgrammer 9701
• Supply: 8...30 V DC
• Protection: short-circuit protected
• Housing: AISI 316L (1.4404); process connection G 1/2 A DIN EN ISO 1179-2 (3852-E) with cooling neck, AISI 316L (1.4404); membrane AISI 316L (1.4435), Ra ≤ 0.4 µm; NBR gasket; NSF H1 oil filling
• Environment: IP65; ambient temperature -40...+85 °C; process temperature -40...+200 °C
• Connection: DIN EN 175301-803 A (DIN 43650 A) connector, 4-pin

Suited to pressure measurement in high-temperature processes, including permanent SIP/CIP cycles up to 200 °C. The oil filling is NSF H1 listed (FDA approved), so it can be used on food production equipment.

EMC to EN 61000-6-3. Shock to EN 60068-2-27 (50 g / 11 ms, 100 g / 6 ms), vibration to EN 60068-2-6 (1.5 mm p-p 10...58 Hz, 10 g 58 Hz...2 kHz).

Duct mount CO2 concentration t-line WebSensor.

Transmitter with built-in concentration CO2, temperature, relative humidity sensor for duct mount.

A multiple point CO2 and temperature adjustment procedure leads to excellent CO2 measurement accuracy over the entire temperature working range; this is a must for process control and outdoor applications. The dual wavelength NDIR CO2 sensing procedure compensates automatically for ageing effects. The CO2 module is highly resistant to pollution and offers maintenance free operation and outstanding long term stability.

Green LED shines - CO2 concentration 0 to 1000 ppm

Yellow LED shines - CO2 concentration 1001 to 1200 ppm

Red LED shines - CO2 concentration 1201 ppm and more

Extended measuring range available for an additional charge

• Measuring range: 0 to 10 000 ppm
• Accuracy: 100 ppm + 5% of the measured value at 25 °C and 1013 hPa

RKC5T-10/TXL is a TURCK connection cable with a straight M12 female connector (4-pin + PE) on one end and open cores on the other. Pin 5 is the protective earth (PE). The PUR jacket is rated for moving installation, including drag chains.

• Connector: M12 x 1, female, straight, A-coded, 4-pin + PE, gold-plated brass (CuZn) contacts
• Cable: 10 m, PUR, black, Ø 4.8 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GNYE
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

Kontaktors DILM15-01-230AC-E EATON Piegāde 1 nedēļa

Kontaktors DILEM-10 (230VAC) (XTMC6A10) EATON Piegāde 1 nedēļa

Motora aizsardzība PKZM0-6.3 Eaton Piegāde 1 nedēļa

Motora aizsardzība PKZM0-1.6 Eaton Piegāde 1 nedēļa
