Pressure sensor PBMN-24B22RA14471212000, 0...10 bar, 4-20mA, G 1/2" flush, DIN 43650 A

PBMN-24B22RA14471212000 is a Baumer PBMN series relative pressure sensor with a flush membrane, a 0...10 bar measuring range and a 4...20 mA two-wire output. The cooling neck allows permanent operation at process temperatures up to 200 °C.

• Accuracy: max. measuring error ±0.25 % FSR, including zero-point and span error, non-linearity and hysteresis (EN 61298-2); long-term stability ≤ 0.1 % FSR per year
• Measuring range: 0...10 bar, relative pressure; temperature coefficient ≤ 0.03 % FSR/10 K (zero point and span), compensated range -40...+85 °C
• Output: 4...20 mA, 2-wire, response time ≤ 5 ms; zero point and span adjustable with FlexProgrammer 9701
• Supply: 8...30 V DC
• Protection: short-circuit protected
• Housing: AISI 316L (1.4404); process connection G 1/2 A DIN EN ISO 1179-2 (3852-E) with cooling neck, AISI 316L (1.4404); membrane AISI 316L (1.4435), Ra ≤ 0.4 µm; NBR gasket; NSF H1 oil filling
• Environment: IP65; ambient temperature -40...+85 °C; process temperature -40...+200 °C
• Connection: DIN EN 175301-803 A (DIN 43650 A) connector, 4-pin

Suited to pressure measurement in high-temperature processes, including permanent SIP/CIP cycles up to 200 °C. The oil filling is NSF H1 listed (FDA approved), so it can be used on food production equipment.

EMC to EN 61000-6-3. Shock to EN 60068-2-27 (50 g / 11 ms, 100 g / 6 ms), vibration to EN 60068-2-6 (1.5 mm p-p 10...58 Hz, 10 g 58 Hz...2 kHz).
