PT40R-2004-U1-H1141/X is a TURCK PT-2000 series relative pressure transmitter with a fully welded metal measuring cell and a 0...10 V voltage output in 3-wire technology. It has no display: the measured value goes straight to the analogue input of a PLC or controller.

• Accuracy: ±0.3 % FS typical, max. 0.5 % FS (linearity, hysteresis, repeatability); temperature coefficient ±0.2 % FS/10 K; long-term stability 0.25 % FS per IEC EN 60770-1; reference conditions 15...25°C, 24 VDC
• Measuring range: 0...40 bar relative (0...4 MPa); overpressure ≤ 120 bar, burst pressure ≥ 240 bar; resolution ±0.1 % FS
• Output: analogue 0...10 V, 3-wire, load ≤ 100 nF / > 10 kΩ; response time < 2 ms, typ. 1 ms
• Supply: 12...33 VDC, consumption ≤ 7 mA; protected against short circuit, wire break and reverse polarity
• Housing: stainless steel 1.4404 (AISI 316L) and polyarylamide 50 % GF (UL 94 V-0), stainless steel 1.4016 (AISI 430) cell; G 1/4" male thread, back sealing per DIN EN ISO 1179-2 with FPM profile seal; wrench size 24, nut torque max. 20 Nm
• Environment: IP67, ambient -30...+85°C, medium -40...+135°C
• Connection: M12 x 1 connector

A pressure peak orifice is built into the process connection. One FKM profile seal is included in the delivery.

Approval: cULus (UL E302799). Shock 100 g (11 ms) per IEC 68-2-27, vibration 20 g (15...2000 Hz) per IEC 68-2-6. MTTF 1238 years per SN 29500 (40°C).

DXMR90-X1E is a Banner DXMR90 series industrial controller with four independent Modbus RTU client ports and two M12 D-coded Ethernet ports. It collects data from Modbus server devices, processes it in the internal logic controller and passes it to EtherNet/IP, Modbus TCP or PROFINET networks.

• Ports: 4x Modbus RTU client (M12 female), Port 0 male and female for power and Modbus trunk pass-through
• Communication: 2x Ethernet 100 Mbps (M12 D-coded) with in-line switch; Modbus TCP, EtherNet/IP, PROFINET, MQTT, MQTT Sparkplug B, RESTful API
• RS-485: 2-wire half-duplex, 1.2...115.2 kbit/s, default 19.2 kbit/s, baud rate and parity set per port
• Configuration: action rules, ScriptBasic and MicroPython; DXM Configuration Software v4
• Supply: 12...30 VDC, max. 120 mA at 12 VDC; total current through the ports max. 3.5 A
• Environment: IP65, IP67, indoor use, -40...+70 °C

Four Modbus networks with different baud rates and parity run side by side, so devices sharing one server address can sit on separate ports. Several DXMR90-X1E units can be chained through the Port 0 power and Ethernet pass-through. Modbus devices connect with M12 cordsets ordered separately.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (30 G, 11 ms).

SD50P300WSR2QP is a Banner SD50 status display with a built-in 2.4 GHz serial data radio, a 300 mm white LED text line and RGB indicator LEDs. Text, colours and animations arrive as Modbus RTU commands over the radio, so only power is wired to the display.

• Display: 8x96 pixel white LED text line, 300 mm long, RGB indicator LEDs in 14 colours, legible from 10 m
• Communication: 2.4 GHz serial data radio, conducted < 18 dBm (65 mW), Modbus RTU
• Supply: 12...30 VDC, max. 570 mA at 12 VDC, 230 mA at 30 VDC
• Housing: black polycarbonate, smoky polycarbonate window, 325x50x28 mm
• Environment: IP65, -20...+50 °C
• Connection: 150 mm PVC cable with 4-pin M12 male connector (power)

Suited to positions where a data cable is hard to run, such as moving equipment or the far end of a line. It needs a Banner 2.4 GHz radio with Modbus control - a DXM controller or an R70SR serial data radio; that and the M12 power cordset are ordered separately. End caps take M5 and 1/4-20 fasteners (screws not included); clip brackets are available as accessories.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms). Suitable for damp locations per UL 2108.

SD50P300WKQP is a Banner SD50 status display with a 300 mm white LED text line and RGB indicator LEDs, controlled over IO-Link. Text, colours and animations are written from the PLC through the IO-Link master as process data.

• Display: 8x96 pixel white LED text line, 300 mm long, RGB indicator LEDs in 14 colours, legible from 10 m
• Communication: IO-Link V1.1, COM2 (38.4 kbit/s); text up to 29 characters in Run mode
• Configuration: IODD parameters via the IO-Link master
• Supply: 18...30 VDC, max. 350 mA at 18 VDC, 260 mA at 24 VDC
• Housing: black polycarbonate, smoky polycarbonate window, 325x50x28 mm
• Environment: IP65, -20...+50 °C
• Connection: 150 mm PVC cable with 4-pin M12 male connector

Shows counts, measurements, takt time or fault text at the machine without a separate HMI. It needs an IO-Link master port and an M12 cordset, both ordered separately. End caps take M5 and 1/4-20 fasteners (screws not included); clip brackets are available as accessories.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms). Suitable for damp locations per UL 2108.

SD50P300WD15QP is a Banner SD50 Pro status display with a 300 mm white LED text line and RGB indicator LEDs, controlled by four discrete inputs. Each binary combination of the inputs calls one of up to 15 stored states, each with its own text, colour and animation.

• Display: 8x96 pixel white LED text line, 300 mm long, RGB indicator LEDs in 14 colours, legible from 10 m
• Inputs: 4 discrete inputs, up to 15 states; text up to 29 characters in discrete control
• Configuration: Banner Pro Editor software via Pro Converter Cable MQDC-506-USB
• Supply: 12...30 VDC, max. 550 mA at 12 VDC, 260 mA at 24 VDC
• Housing: black polycarbonate, smoky polycarbonate window, 325x50x28 mm
• Environment: IP65, -40...+50 °C
• Connection: 150 mm PVC cable with 5-pin M12 male connector

Used next to a workstation or machine to show takt time, equipment status or assembly steps straight from PLC outputs. States, text and animations are set up in Pro Editor; the mating M12 cordset is ordered separately. End caps take M5 and 1/4-20 fasteners (screws not included); clip brackets are available as accessories.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

SD50P300WSQP is a Banner SD50 status display with a 300 mm white LED text line and RGB indicator LEDs, controlled over Modbus RTU on RS-485. Text, colours and animations are written to Modbus registers by a PLC or a DXM controller.

• Display: 8x96 pixel white LED text line, 300 mm long, RGB indicator LEDs in 14 colours, legible from 10 m
• Communication: Modbus RTU server, RS-485, default 19.2 kbit/s; text up to 29 characters in Run mode
• Supply: 12...30 VDC, max. 550 mA at 12 VDC, 260 mA at 24 VDC
• Housing: black polycarbonate, smoky polycarbonate window, 325x50x28 mm
• Environment: IP65, -20...+50 °C
• Connection: 150 mm PVC cable with 4-pin M12 male connector

Several displays can share one RS-485 line, each with its own Modbus address, to show counts, takt time or fault text along a line. The M12 cordset is ordered separately. End caps take M5 and 1/4-20 fasteners (screws not included); clip brackets are available as accessories.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms). Suitable for damp locations per UL 2108.

LBFS-2.01K21.0 is a capacitive point level switch from the Baumer CleverLevel series with a G 1/2" A hygienic process connection and an 82 mm probe. The extended probe places the switching point further from the tank wall, and this build is rated to 100 bar process pressure rather than the 10 bar of the standard hygienic connection.

• Immersion length: 82 mm
• Switching: point level detection, Single Point, Two Point and Window trigger modes, hysteresis < ±1 mm, repeatability < ±1 mm
• Output: two PNP outputs (SW1, SW2), each separately High-Active or Low-Active, 50 mA, step response T90 0.1 s, adjustable damping 0...60 s
• Supply: 8.5...35 V DC, current consumption < 8 mA (typ.)
• Housing: stainless steel; wetted parts PEEK Natura and AISI 316L (1.4404), Ra ≤ 0.8 µm
• Environment: process temperature -40...115 °C (135 °C temporarily), process pressure -1...100 bar (-1...80 bar temporarily), IP67 and IP69K with a matching mating connector
• Connection: M12-A, 4-pin, polycarbonate connector with status LED indicators

The extended build is intended for tanks with a thick wall or insulation, and for plant where the probe has to reach through a nozzle to the medium itself. The Ra ≤ 0.8 µm surface finish allows CIP cleaning. Mounting position is free - top, bottom or side.

Complies with EN 1935/2004, EN 10/2011 and EN 2023/2006, and FDA. The PEEK material complies with USP Class VI. cULus listed, E365692. Marine approvals: DNV, Lloyd's Register and CCS.

EIL580-SC10.5FH.01024.A is a Baumer optoPulse incremental encoder with optical sensing and 1024 pulses per revolution. It runs on an 8-30 V DC supply while the output stays at 5 V TTL/RS422 level, so it connects to an RS422 input on a machine that only has 24 V available.

• Resolution: 1024 pulses per revolution, zero pulse
• Output: TTL/RS422, 6 channels (A+, B+, R+, A-, B-, R-), up to 300 kHz
• Supply: 8-30 V DC, no-load consumption ≤70 mA
• Housing: Ø58 mm, clamping flange with Ø36 mm centring collar, Ø10 x 20 mm shaft with flat
• Environment: IP65, -40...+85 °C, up to 12000 rpm
• Connection: M23 12-pin radial connector

Used for motor speed and position feedback where the controller or frequency converter has an RS422 input. Permitted shaft load is 40 N axial and 80 N radial, so the shaft needs a flexible coupling.

UL 508 / CSA 22.2 approved. EMC to EN 61000-6-2 and EN 61000-6-3; vibration (30 g, 10-2000 Hz) and shock (300 g, 6 ms) resistance to EN 60068-2-6 and EN 60068-2-27.

O200.EL-PV1T.72NV/FREC_H006 is the receiver half of a Baumer O200 miniature through-beam pair, working with a pulsed red laser emitter over a 6 m nominal range. Sensitivity is set with qTeach - a ferromagnetic tool held against the housing instead of a potentiometer - so once the machine runs there is no adjustment on the sensor for anyone to turn.

• Range: actual 5 m, nominal 6 m; smallest detectable object 3 mm (0.5 mm with aperture)
• Output: PNP complementary, light/dark operate, 50 mA
• Supply: 10...30 VDC, typ. 10 mA at 24 VDC
• Response time: < 0.1 ms, jitter < 0.03 ms
• Housing: rectangular 8 x 25.1 x 14.1 mm, ASA plastic, PMMA optics, M3 stainless steel threaded sleeves
• Environment: IP 67, -25...+50 °C
• Connection: M8 4-pin flylead connector, 200 mm

Typical positions are counting and presence checks on packaging and assembly lines, where the aperture accessory brings 0.5 mm parts and gaps within reach. A flashing output indicator reports weak signal margin or a soiled lens, so alignment is checked without instruments. Reciprocal influence is suppressed, so several pairs can work side by side.

O200.TL-GZZY.72NV/FIN2_H006 is the emitter half of a Baumer O200 miniature through-beam pair, with a parallel red laser beam rather than a diverging one, so detection stays even across the whole 6 m nominal range. The emitter diode is switched off either through the test input or over IO-Link, letting a controller verify the receiver channel without anyone breaking the beam by hand.

• Range: actual 5 m, nominal 6 m; parallel beam
• Light source: pulsed red laser diode, 680 nm, laser class 1
• Communication: IO-Link V1.1, port class A, 230.4 kBaud, cycle ≥ 0.6 ms
• Supply: 10...30 VDC, typ. 10 mA at 24 VDC
• Housing: rectangular 8 x 25.1 x 15.8 mm, ASA plastic, PMMA optics, M3 stainless steel threaded sleeves
• Environment: IP 67, -20...+50 °C
• Connection: M8 4-pin flylead connector, 200 mm

A parallel beam pays off where the pair sits at an awkward distance or the object passes close to one side: the spot does not grow with range, so the smallest detectable object and the alignment tolerance are the same at 0.5 m as at 5 m. The emitter is used with an O200 through-beam receiver, which carries the switching output - the emitter has none of its own.

RKC4.5T-15-RSC4.5T/TXL is a TURCK extension cable with a straight M12 female connector on one end and a straight M12 male connector on the other (5-pin). The PUR jacket is rated for moving installation, including drag chains.

• Connectors: M12 x 1 female and M12 x 1 male, both straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 15 m, PUR, black, Ø 4.8 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

RKS8T-25-RSS8T/TXL is a TURCK shielded M12 connection cable with a straight female connector on one end and a straight male connector on the other (8-pin, A-coded). The cable shield is connected to the coupling nuts.

• Connectors: M12 x 1 female / male, straight, A-coded, 8-pin, gold-plated brass (CuZn) contacts
• Cable: 25 m, PUR, black, Ø 6.3 mm, 8 x 0.25 mm², core colours BN, WH, BU, BK, GY, PK, VT, OG
• Shield: aluminium foil and tinned copper wire
• Ratings: 2 A, 30 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nuts, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

TL50HGYRAOS4Q is a Banner TL50H series high-brightness 50 mm tower light with green, yellow and red segments and an omni-directional sealed audible with a staccato tone. It comes assembled; each color and the audible have their own bimodal input.

• Colors (bottom to top): green 525 nm (60 lm), yellow 590 nm (23 lm), red 625 nm (32 lm)
• Audible: omni-directional sealed, staccato, 2.1 kHz, 99 dB at 1 m, not adjustable
• Input: bimodal PNP/NPN, response 10 ms
• Supply: 18...30 V DC or 24 V AC; per color 100 mA at 18 V, audible 45 mA
• Housing: ABS base and covers, polycarbonate segments, M30x1.5 thread; IP67, UL Type 4X Indoor and 13
• Connection: integral 5-pin M12 male connector

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (30 G, 11 ms).

WLS27CW285DSQ is a Banner WLS27 series 285 mm cool white strip light in an FDA-grade copolyester shell rated up to IP69K. It is a cascade model with a male M12 connector at one end and a female one at the other.

• Light: cool white 6500 K, 800 lm, CRI 85
• Dimming: black wire to supply - 50 % intensity, open or to common - 100 %
• Supply: 12...30 V DC, typical 0.30 A at 24 V, max. 0.8 A
• Housing: anodized aluminum frame, diffused FDA copolyester shell, Ø27 x 360 mm, brackets included
• Environment: IP66, IP67, IP69K, -40...+70 °C, the light dims above +50 °C
• Connection: integral 4-pin M12 male connector

In a cascade at 100 % intensity the total length must not exceed 1.4 m at 12 V DC, 3.0 m at 24 V DC and 3.1 m at 30 V DC; at 50 % intensity the lengths double. Clean only with mild detergent and warm water.

CE compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

Supplied without original packaging.

WLS28-2CW145XPBQ is a Banner WLS28-2 series 145 mm cool white work light with a High/Low/Off switch on the housing. It is a cascade model: further lights connect to it with double-ended cordsets, and the switch controls them too.

• Light: cool white 6500 K, 400 lm, CRI 85
• Switch: II - 100 %, I - 50 %, 0 - off
• Supply: 12...30 V DC, typical 0.15 A at 24 V
• Housing: anodized aluminum, clear polycarbonate window, 224 x 28 x 25 mm, two swivel brackets included
• Environment: IP50, -40...+70 °C, light output decreases above +50 °C
• Connection: integral 4-pin M12 male connector

In a cascade at 100 % intensity the total light length must not exceed 1.4 m at 12 V DC and 3.0 m at 24 V DC; at 50 % intensity the lengths double. LED lifetime L70 - 75,000 hours.

CE compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

BRT-84 is a Banner round acrylic retroreflector with a centre mounting hole, for photo sensors working in retroreflective mode.

• Diameter: 84 mm
• Reflectivity factor: 1.4
• Mounting: centre hole, Ø4.5 mm
• Temperature: -20...+60 °C

Supplied without individual packaging.

R58ECRGB1Q8 is a Banner R58E Expert registration mark sensor with a red, green and blue LED light source. During TEACH it picks the colour that gives the most contrast between the mark and its background and detects 16 levels of grey scale; the switching frequency is 10 kHz.

• Sensing: fixed focus 10 mm ±3 mm, image 1.2 x 3.8 mm, parallel to sensor length
• Light source: red 636 nm, green 525 nm, blue 472 nm, selected automatically during TEACH
• Outputs: bipolar, 1x PNP and 1x NPN, 100 mA each; response 50 µs, repeatability 15 µs
• Supply: 10-30VDC, max 75 mA at 10 VDC
• Housing: zinc alloy die-cast, acrylic lens
• Environment: IP67, -10...+55 °C
• Connection: integral M12 5-pin connector

Static and Dynamic TEACH by push button or the gray remote wire; in Dynamic TEACH the shorter event becomes Output ON, so Light/Dark Operate is set automatically. Mount at about 15° to shiny surfaces. A 30 ms OFF-delay or ON-delay can be enabled.

Vibration and shock per IEC 60068-2-6 and IEC 60068-2-27.

DF-G1-NS-Q3 is a Banner DF-G1 Expert amplifier for plastic and glass fibre optic assemblies, with a single NPN output. Two 4-digit displays show the signal level in red and the threshold in green at the same time, so the margin is visible without a menu.

• Output: 1x NPN, 100 mA; response 200 µs, 500 µs, 2 ms or 5 ms by mode
• Light source: visible red, 660 nm
• Supply: 10-30 V DC, < 40 mA at 24 V (< 30 mA in ECO display mode)
• Housing: ABS/polycarbonate, for 35 mm DIN rail
• Environment: IP50, -10...+55 °C
• Connection: 150 mm PVC cable with M8 male connector, 4-pin

Teach methods are two-point, dynamic, and Light, Dark, Window or Calibration SET; Light Operate or Dark Operate is chosen with a switch on the front, and ON/OFF delays and one-shot timers are set from the menu or the remote teach wire. A 4-pin M8 cordset is needed.

SOP-E12-300SS is a Banner 300 mm stand-off pipe in 304 stainless steel for mounting an indicator, tower light or sensor raised above the mounting surface.

• Length: 300 mm
• Thread: ½" NPT at both ends (NPSM/DN15 system)
• Material: 304 stainless steel

The lower end needs a mounting base and the upper end an adapter for the device base.

EA5E1200Q is the emitter of a Banner EZ-ARRAY measuring light curtain, with a 1200 mm array of 240 infrared beams at 5 mm spacing. It is synchronised with the receiver over the cable, and all evaluation and outputs are in the receiver.

• Array: 1200 mm, 240 beams, 5 mm spacing, infrared LED
• Range: 400 mm...4 m between emitter and receiver
• Supply: 12-30 V DC, 80 mA at 24 V
• Housing: clear-anodised aluminium, acrylic lens cover; end-cap brackets and centre bracket included
• Environment: IP65, -40...+70 °C
• Connection: M12, 8-pin; cordset ordered separately

It works with an EZ-ARRAY receiver of the same length, which sets the outputs and the Modbus interface.

EA5R1200PIXMODQ is the receiver of a Banner EZ-ARRAY measuring light curtain with a 1200 mm array of 240 beams at 5 mm spacing. The controller is built into the receiver: it evaluates the beam pattern and reports object position, height, width or count through two analog outputs, two discrete outputs and Modbus RTU.

• Resolution: 5 mm straight scan, 2.5 mm edge scan; minimum object 5 mm (low-contrast mode)
• Range: 400 mm...4 m between emitter and receiver
• Outputs: 2x analog 4-20 mA, 2x PNP 100 mA, Modbus RTU over RS485 (up to 15 nodes)
• Supply: 12-30 V DC, 120 mA at 24 V
• Housing: clear-anodised aluminium, acrylic lens cover; end-cap brackets and centre bracket included
• Environment: IP65, -40...+70 °C
• Connection: M12, 8-pin; cordset ordered separately

The receiver is configured with its six-position DIP switch or with the supplied PC software; a straight scan takes 2.8...26.5 ms depending on array length. It works with the EZ-ARRAY emitter of the same length, and each unit needs its own 8-pin M12 cordset.

Measurement range: -15°C to 70°C and 0 to 100% RH; Accuracy: up to 0.4°C in the 0°C to +70°C range, and 0.5°C in the -35°C to 0°C; Accuracy up to 3% in the range of 0 to 90% and up to 4% in the range above 90%; IP30 protection

Q12RP6RQ3 is the receiver of a Banner Q12 series miniature opposed-mode photo sensor pair. Its PNP output switches on when an object breaks the beam from a Q12 emitter up to 2 m away.

• Sensing range: 2 m with a Q12 emitter
• Output: 1 PNP, Dark Operate
• Response: 1.3 ms ON, 0.9 ms OFF; repeatability 175 µs
• Supply: 10-30 V DC
• Housing: miniature rectangular, thermoplastic, polycarbonate lens
• Environment: IP67, -20...+55 °C
• Connection: 150 mm cable with M8 male connector, 3-pin

Needs a Q12 emitter, ordered separately. UL, CE and UKCA approved.

Q126EQ3 is the emitter of a Banner Q12 series miniature opposed-mode photo sensor pair. Its visible red 640 nm beam reaches a Q12 receiver up to 2 m away; the emitter itself has no output.

• Sensing range: 2 m with a Q12 receiver
• Output: none (emitter)
• Supply: 10-30 V DC
• Housing: miniature rectangular, thermoplastic, polycarbonate lens
• Environment: IP67, -20...+55 °C
• Connection: 150 mm cable with M8 male connector, 3-pin

Needs a Q12 receiver, ordered separately. UL, CE and UKCA approved.

IA23S is a Banner individual glass fibre for opposed mode with a right-angled probe tip. It is supplied as one fibre: an opposed setup uses one on the emitter and one on the receiver.

• Type: opposed, individual fibre, supplied as 1 piece
• Length: 914 mm, bundle Ø3.2 mm
• Tip: right-angled probe, Ø4.8 mm
• Sheath: stainless steel monocoil
• Bend radius: at least 25 mm
• Temperature: -140...+249 °C

The fibre ends are ground and polished, so the assembly cannot be shortened or spliced. Glass fibres carry infrared as well as visible light; Banner recommends them for IR sensors.

LPA-MBK-12 is a Banner side-mount bracket for EZ-SCREEN Low Profile emitters and receivers. The sensor can be rotated +10° / -30° in the bracket.

• Fits: Banner EZ-SCREEN Low Profile
• Type: side mount, right-angle
• Rotation: +10° / -30°
• Included: 1 bracket with hardware

Measurement range: -15°C to 70°C and 0 to 100% RH; Accuracy: up to 0.4°C in the 0°C to +70°C range, and 0.5°C in the -35°C to 0°C; Accuracy up to 3% in the range of 0 to 90% and up to 4% in the range above 90%; IP30 protection

QS18VP6LV W/30 is a Banner QS18 series non-polarised retroreflective photo sensor with a visible red 630 nm beam, a range of 6.5 m to a reflector and a 9 m cable. It switches when an object breaks the beam between the sensor and the reflector.

• Sensing range: 6.5 m with a reflector
• Output: complementary PNP, Light Operate and Dark Operate
• Response: 0.6 ms; repeatability 150 µs
• Supply: 10-30 V DC
• Housing: rectangular with M18 threaded nose, ABS, acrylic lens
• Environment: IP67, NEMA 4X, -20...+70 °C
• Connection: 9 m PVC cable, 4 wires

Needs a reflector, ordered separately. Being non-polarised, it can be fooled by shiny targets; sensitivity is set with a potentiometer. UL and CE approved.

EN380.IL-SMA6.5C1H1.00250.H is a Baumer EN380 series incremental encoder with optical sensing, a synchro flange and a solid shaft. Every channel also carries an inverted signal, so the encoder can be wired to a differential input and use a longer cable in electrically noisy surroundings.

• Resolution: 250 pulses per revolution
• Output: HTL/push-pull, channels A, B and reference R with inverted signals, up to 160 kHz
• Supply: 8...30 VDC, 30 mA (24 VDC) without load
• Housing: aluminium, synchro flange, stainless steel shaft ø6 x 12 mm
• Environment: IP 65, -25...+85 °C, vibration 10 g (10-2000 Hz), shock 100 g (2 ms)
• Connection: 1 m radial cable, 8 x 0.14 mm², open cable end

The encoder mounts on a motor or gearbox shaft end through a flexible coupling, and the synchro flange fits it into a tight installation without a separate mounting plate. Permissible speed is 8000 rpm.

EMC compliance to EN 61000-6-2 and EN 61000-6-4. UL-Listing E217823.

EN380.IL-SMA5.5C1T1.01024.H is a Baumer EN380 series incremental encoder with optical sensing, a synchro flange and a solid shaft. Every channel also carries an inverted signal, so the encoder can be wired to a differential input and use a longer cable in electrically noisy surroundings.

• Resolution: 1024 pulses per revolution
• Output: TTL/RS422, channels A, B and reference R with inverted signals, up to 300 kHz
• Supply: 5 VDC ±5 %, 60 mA without load
• Housing: aluminium, synchro flange, stainless steel shaft ø5 x 12 mm
• Environment: IP 65, -25...+85 °C, vibration 10 g (10-2000 Hz), shock 100 g (2 ms)
• Connection: 1 m radial cable, 8 x 0.14 mm², open cable end

The encoder mounts on a motor or gearbox shaft end through a flexible coupling, and the synchro flange fits it into a tight installation without a separate mounting plate. Permissible speed is 8000 rpm.

EMC compliance to EN 61000-6-2 and EN 61000-6-4. UL-Listing E217823.

EN380.IL-SMA5.5C1T1.00500.H is a Baumer EN380 series incremental encoder with optical sensing, a synchro flange and a solid shaft. Every channel also carries an inverted signal, so the encoder can be wired to a differential input and use a longer cable in electrically noisy surroundings.

• Resolution: 500 pulses per revolution
• Output: TTL/RS422, channels A, B and reference R with inverted signals, up to 300 kHz
• Supply: 5 VDC ±5 %, 60 mA without load
• Housing: aluminium, synchro flange, stainless steel shaft ø5 x 12 mm
• Environment: IP 65, -25...+85 °C, vibration 10 g (10-2000 Hz), shock 100 g (2 ms)
• Connection: 1 m radial cable, 8 x 0.14 mm², open cable end

The encoder mounts on a motor or gearbox shaft end through a flexible coupling, and the synchro flange fits it into a tight installation without a separate mounting plate. Permissible speed is 8000 rpm.

EMC compliance to EN 61000-6-2 and EN 61000-6-4. UL-Listing E217823.

EN380.IL-SMA5.5C1T1.00360.H is a Baumer EN380 series incremental encoder with optical sensing, a synchro flange and a solid shaft. Every channel also carries an inverted signal, so the encoder can be wired to a differential input and use a longer cable in electrically noisy surroundings.

• Resolution: 360 pulses per revolution
• Output: TTL/RS422, channels A, B and reference R with inverted signals, up to 300 kHz
• Supply: 5 VDC ±5 %, 60 mA without load
• Housing: aluminium, synchro flange, stainless steel shaft ø5 x 12 mm
• Environment: IP 65, -25...+85 °C, vibration 10 g (10-2000 Hz), shock 100 g (2 ms)
• Connection: 1 m radial cable, 8 x 0.14 mm², open cable end

The encoder mounts on a motor or gearbox shaft end through a flexible coupling, and the synchro flange fits it into a tight installation without a separate mounting plate. Permissible speed is 8000 rpm.

EMC compliance to EN 61000-6-2 and EN 61000-6-4. UL-Listing E217823.

EN380.IL-SMA5.5C1H1.00500.H is a Baumer EN380 series incremental encoder with optical sensing, a synchro flange and a solid shaft. Every channel also carries an inverted signal, so the encoder can be wired to a differential input and use a longer cable in electrically noisy surroundings.

• Resolution: 500 pulses per revolution
• Output: HTL/push-pull, channels A, B and reference R with inverted signals, up to 160 kHz
• Supply: 8...30 VDC, 30 mA (24 VDC) without load
• Housing: aluminium, synchro flange, stainless steel shaft ø5 x 12 mm
• Environment: IP 65, -25...+85 °C, vibration 10 g (10-2000 Hz), shock 100 g (2 ms)
• Connection: 1 m radial cable, 8 x 0.14 mm², open cable end

The encoder mounts on a motor or gearbox shaft end through a flexible coupling, and the synchro flange fits it into a tight installation without a separate mounting plate. Permissible speed is 8000 rpm.

EMC compliance to EN 61000-6-2 and EN 61000-6-4. UL-Listing E217823.

EN380.IL-SMA5.5C1H1.00360.H is a Baumer EN380 series incremental encoder with optical sensing, a synchro flange and a solid shaft. Every channel also carries an inverted signal, so the encoder can be wired to a differential input and use a longer cable in electrically noisy surroundings.

• Resolution: 360 pulses per revolution
• Output: HTL/push-pull, channels A, B and reference R with inverted signals, up to 160 kHz
• Supply: 8...30 VDC, 30 mA (24 VDC) without load
• Housing: aluminium, synchro flange, stainless steel shaft ø5 x 12 mm
• Environment: IP 65, -25...+85 °C, vibration 10 g (10-2000 Hz), shock 100 g (2 ms)
• Connection: 1 m radial cable, 8 x 0.14 mm², open cable end

The encoder mounts on a motor or gearbox shaft end through a flexible coupling, and the synchro flange fits it into a tight installation without a separate mounting plate. Permissible speed is 8000 rpm.

EMC compliance to EN 61000-6-2 and EN 61000-6-4. UL-Listing E217823.

EN380.IL-SMA5.5C1H1.00100.H is a Baumer EN380 series incremental encoder with optical sensing, a synchro flange and a solid shaft. Every channel also carries an inverted signal, so the encoder can be wired to a differential input and use a longer cable in electrically noisy surroundings.

• Resolution: 100 pulses per revolution
• Output: HTL/push-pull, channels A, B and reference R with inverted signals, up to 160 kHz
• Supply: 8...30 VDC, 30 mA (24 VDC) without load
• Housing: aluminium, synchro flange, stainless steel shaft ø5 x 12 mm
• Environment: IP 65, -25...+85 °C, vibration 10 g (10-2000 Hz), shock 100 g (2 ms)
• Connection: 1 m radial cable, 8 x 0.14 mm², open cable end

The encoder mounts on a motor or gearbox shaft end through a flexible coupling, and the synchro flange fits it into a tight installation without a separate mounting plate. Permissible speed is 8000 rpm.

EMC compliance to EN 61000-6-2 and EN 61000-6-4. UL-Listing E217823.

EN380.IL-BH12.5C1H1.01000.H is a Baumer EN380 series incremental encoder with optical sensing, a blind hollow shaft and a torque pin. Every channel also carries an inverted signal, so the encoder can be wired to a differential input and use a longer cable in electrically noisy surroundings.

• Resolution: 1000 pulses per revolution
• Output: HTL/push-pull, channels A, B and reference R with inverted signals, up to 160 kHz
• Supply: 8...30 VDC, 30 mA (24 VDC) without load
• Housing: aluminium, blind hollow shaft ø12 mm
• Environment: IP 65, -25...+85 °C, vibration 10 g (10-2000 Hz), shock 100 g (2 ms)
• Connection: 1 m radial cable, 8 x 0.14 mm², open cable end

The encoder slides onto a motor or gearbox shaft end and the torque pin holds the housing against rotation, so neither a coupling nor a separate bracket is needed. Permissible speed is 6000 rpm up to +75 °C.

EMC compliance to EN 61000-6-2 and EN 61000-6-4. UL-Listing E217823.

EN380.IL-BG12.5C2T1.02000.H is a Baumer EN380 series incremental encoder with optical sensing, a blind hollow shaft and a torque pin. Every channel also carries an inverted signal, so the encoder can be wired to a differential input and use a longer cable in electrically noisy surroundings.

• Resolution: 2000 pulses per revolution
• Output: TTL/RS422, channels A, B and reference R with inverted signals, up to 300 kHz
• Supply: 5 VDC ±5 %, 60 mA without load
• Housing: aluminium, blind hollow shaft ø12 mm
• Environment: IP 65, -25...+85 °C, vibration 10 g (10-2000 Hz), shock 100 g (2 ms)
• Connection: 2 m radial cable, 8 x 0.14 mm², open cable end

The encoder slides onto a motor or gearbox shaft end and the torque pin holds the housing against rotation, so neither a coupling nor a separate bracket is needed. Permissible speed is 6000 rpm up to +75 °C.

EMC compliance to EN 61000-6-2 and EN 61000-6-4. UL-Listing E217823.

EN380.IL-BF12.5C1T1.01000.H is a Baumer EN380 series incremental encoder with optical sensing, a blind hollow shaft and a stator coupling. Every channel also carries an inverted signal, so the encoder can be wired to a differential input and use a longer cable in electrically noisy surroundings.

• Resolution: 1000 pulses per revolution
• Output: TTL/RS422, channels A, B and reference R with inverted signals, up to 300 kHz
• Supply: 5 VDC ±5 %, 60 mA without load
• Housing: aluminium, blind hollow shaft ø12 mm
• Environment: IP 65, -25...+85 °C, vibration 10 g (10-2000 Hz), shock 100 g (2 ms)
• Connection: 1 m radial cable, 8 x 0.14 mm², open cable end

The encoder slides onto a motor or gearbox shaft end and the stator coupling holds the housing against rotation, so neither a coupling nor a separate bracket is needed. Permissible speed is 6000 rpm up to +75 °C.

EMC compliance to EN 61000-6-2 and EN 61000-6-4. UL-Listing E217823.

EN380.IL-BF12.5C1T1.00250.H is a Baumer EN380 series incremental encoder with optical sensing, a blind hollow shaft and a stator coupling. Every channel also carries an inverted signal, so the encoder can be wired to a differential input and use a longer cable in electrically noisy surroundings.

• Resolution: 250 pulses per revolution
• Output: TTL/RS422, channels A, B and reference R with inverted signals, up to 300 kHz
• Supply: 5 VDC ±5 %, 60 mA without load
• Housing: aluminium, blind hollow shaft ø12 mm
• Environment: IP 65, -25...+85 °C, vibration 10 g (10-2000 Hz), shock 100 g (2 ms)
• Connection: 1 m radial cable, 8 x 0.14 mm², open cable end

The encoder slides onto a motor or gearbox shaft end and the stator coupling holds the housing against rotation, so neither a coupling nor a separate bracket is needed. Permissible speed is 6000 rpm up to +75 °C.

EMC compliance to EN 61000-6-2 and EN 61000-6-4. UL-Listing E217823.
