RKS4.4T-30/TXL is a TURCK shielded connection cable with a straight M12 female connector (4-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 30 m, PUR, black, Ø 5.3 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

RKC4T-2/TEL is a TURCK connection cable with a straight M12 female connector (3-pin) on one end and open cores on the other.

• Connector: M12 x 1, female, straight, A-coded, 3-pin, gold-plated brass (CuZn) contacts
• Cable: 2 m, PVC, black, Ø 4.3 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

WKC4T-2/TEL is a TURCK connection cable with an angled M12 female connector (3-pin) on one end and open cores on the other.

• Connector: M12 x 1, female, angled, A-coded, 3-pin, gold-plated brass (CuZn) contacts
• Cable: 2 m, PVC, black, Ø 4.3 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The PVC jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

BS5231-0 is a TURCK field-wireable M8 male connector, angled, 3-pin, for 3.5...5 mm cable with solder contacts.

• Connector: M8, male, angled, 3-pin, gold-plated brass (CuZn) contacts, more than 100 mating cycles
• Ratings: 4 A, 60 V, contact resistance ≤3 mΩ
• Connection: solder contacts, conductors up to 0.25 mm², cable diameter 3.5...5 mm, M11 x 0.75 screw-in thread
• Housing: black PBT body, PA 66 contact carrier, nickel-plated die-cast zinc (GD-Zn) coupling nut, FPM/FKM seal
• Environment: IP67 (screwed together); -40...+85°C fixed

Approval: cULus recognized.

VB2-FSM5-2FKM4.4 is a TURCK Y-splitter without cable with one M12 male connector (5-pin) and two M12 female connectors (4-pin).

• Connectors: M12 male, 5-pin / 2 x M12 female, 4-pin, straight, gold-plated brass (CuZn) contacts, more than 100 mating cycles
• Ratings: 4 A, 60 V, contact resistance ≤5 mΩ, insulation resistance ≥10⁸ Ω
• Housing: black TPU, nickel-plated brass coupling nuts
• Environment: IP67 (only when screwed in); -30...+90°C

RoHS compliant.

SG-TL70B-A is a Banner TL70B series 70 mm audible module that twist-locks on top of a TL70B modular tower light. It sounds when the base input for its position is switched.

• Audible: 2.7 kHz, up to 104 dB at 1 m, 13 dB adjustment with the rotating baffle
• Mode: continuous or pulsed at 1.5 Hz / 3 Hz, set with DIP switches in the base
• Supply: 12...30 V DC, 33 mA at 12 V, 17 mA at 24 V
• Housing: polycarbonate, Ø70 x 72 mm
• Environment: IP65, IP66, -40...+50 °C

Works only with TL70B series bases and always sits at the top of the tower.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

SA-M30TE12 is a Banner tapered adapter that joins a light with a 30 mm base to the top of a ½" stand-off pipe and covers the joint. It is typically used with CL50 column lights, TL50 tower lights and K50 indicators.

• Connection: 30 mm light base to ½" NPSM/DN15 pipe
• Material: black acetal
• Included: mounting hardware

SOP-E12-150SS is a Banner 150 mm stand-off pipe in 304 stainless steel for mounting an indicator, tower light or sensor raised above the mounting surface.

• Length: 150 mm
• Thread: ½" NPT at both ends (NPSM/DN15 system)
• Material: 304 stainless steel

The lower end needs a mounting base and the upper end an adapter for the device base.

S15S-TH-MQ is a Banner temperature and humidity sensor in an overmolded M12 housing that reports relative humidity, temperature and dew point as Modbus RTU registers over RS-485. It ships with an aluminium grill filter cap.

• Accuracy: humidity ±2 % RH at 25 °C, ±3 % RH at 0...+70 °C and 10...90 % RH, ±7 % RH below 10 % or above 90 % RH; temperature ±0.8 °C (-40...0 °C), ±0.7 °C (0...+60 °C), ±1.3 °C (+60...+85 °C)
• Measuring range: humidity 0...100 % RH, resolution 0.1 % RH; temperature -40...+85 °C, resolution 0.1 °C; sample rate 3 s
• Output: RS-485, Modbus RTU, 9.6/19.2/38.4 kbaud, address 1...254
• Supply: 10...30 V DC, max. 50 mA; protected against reverse polarity
• Environment: IP65, IP67, IP68 at the M12 connection; operating -40...+70 °C, up to 90 % RH non-condensing
• Connection: integral 4-pin M12 male and female connectors

Baud rate, parity and address are set with the SNAP SIGNAL software through the BWA-UCT-900 USB adapter cable. An optional 10 µm sintered stainless steel filter is available separately.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 g, 11 ms). FCC Part 15 Class B, ICES-003(B).

R95C-4B4UI-MQ is a Banner R95C series Modbus hub with eight M12 ports: four with two discrete channels each and four analog ports for voltage or current, each usable as input or output. All values are read and written through Modbus registers over RS-485.

• Discrete: ports 1-4, 2 channels each, NPN or PNP set per channel, output load 200 mA; delay modes, counters, PFM output 0...600 Hz
• Analog: ports 5-8, input 0...11000 mV or 0...24000 µA, output 0...10000 mV or 4000...20000 µA
• Communication: Modbus RTU server, RS-485
• Supply: 12...30 VDC, max. 400 mA without load; total pass-through current max. 4 A
• Housing: over-moulded PVC body, nickel-plated brass coupling nuts, 50x95 mm
• Environment: IP65, IP67, IP68, -40...+70 °C
• Connection: 8x 4-pin M12 female, 1x 5-pin M12 male to the Modbus line

Any analog input can be mirrored to an analog output port or as a PFM signal to a discrete port without PLC logic. Settings are made with Banner SNAP SIGNAL Configuration Software; M12 cordsets are ordered separately.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

R45C-MUU-UUQ is a Banner R45C series in-line converter with two analog analog voltage ports, each usable as input or output, and a Modbus RTU connection. Input values are written to Modbus registers, and values written to the output registers are produced as analog voltage.

• Precision: accuracy 0.5 %, resolution 14 bit
• Inputs and outputs: 2 ports, analog voltage in and out, range 0...11000 mV; input impedance approx. 14.3 kΩ; output load min. 2.5 kΩ
• Communication: Modbus RTU server, RS-485, default 19.2 kbit/s
• Supply: 12...30 VDC, max. 50 mA; pass-through current max. 4 A
• Housing: over-moulded PVC body, nickel-plated brass coupling nuts
• Environment: IP65, IP67, IP68, -40...+60 °C
• Connection: 5-pin M12 male (Modbus), 2x 4-pin M12 female (analog)

Out-of-range output values go to a selectable level after 2 s: Low (0 V or 3.5 mA), High (10.5 V or 20.5 mA) or Hold. Modbus settings are made with Banner SNAP SIGNAL Configuration Software.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

R95C-8B21-MQ is a Banner R95C series Modbus hub with eight M12 ports, each carrying two discrete channels that can be set as NPN or PNP input or output. Channel states are read and written through Modbus registers over RS-485.

• Ports: 8x M12 female, 2 discrete channels per port, NPN or PNP set per channel; output load 100 mA
• Functions: ON/OFF delay, one-shot, retriggerable one-shot, pulse stretcher, totaliser; count, events per minute and duration per channel
• Communication: Modbus RTU server, RS-485; any port signal can be mirrored to another port or to the host pin 5
• Supply: 12...30 VDC, max. 400 mA; pass-through current max. 500 mA per port
• Housing: over-moulded PVC body, nickel-plated brass coupling nuts, 50x95 mm
• Environment: IP65, IP67, IP68, -40...+70 °C
• Connection: 8x 4-pin M12 female, 1x 5-pin M12 male to the Modbus line

Collects up to 16 discrete signals at the machine onto one Modbus line, for example to a DXMR90 controller. Settings are made with Banner SNAP SIGNAL Configuration Software; M12 cordsets are ordered separately.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

R95C-8UI-MQ is a Banner R95C series Modbus hub with eight M12 ports for analog voltage or current inputs. Each measured value is placed in its own Modbus register and read over RS-485.

• Inputs: 8 ports, analog voltage 0...11000 mV or current 0...24000 µA; impedance approx. 14.3 kΩ (voltage) or 250 Ω (current)
• Communication: Modbus RTU server, RS-485, default 19.2 kbit/s
• Supply: 12...30 VDC, max. 400 mA; pass-through current max. 500 mA per port
• Housing: over-moulded PVC body, nickel-plated brass coupling nuts, 50x95 mm
• Environment: IP65, IP67, IP68, -40...+70 °C
• Connection: 8x 4-pin M12 female, 1x 5-pin M12 male to the Modbus line

Brings eight analog transmitters onto one Modbus line at the machine instead of wiring each back to an analog input card. Settings are made with Banner SNAP SIGNAL Configuration Software; M12 cordsets are ordered separately.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

R45C-MII-IIQ is a Banner R45C series in-line converter with two analog analog current ports, each usable as input or output, and a Modbus RTU connection. Input values are written to Modbus registers, and values written to the output registers are produced as analog current.

• Precision: accuracy 0.5 %, resolution 14 bit
• Inputs and outputs: 2 ports, analog current in and out, range 0...24000 µA; input impedance approx. 250 Ω; output load max. 1 kΩ at 24 VDC
• Communication: Modbus RTU server, RS-485, default 19.2 kbit/s
• Supply: 12...30 VDC, max. 50 mA; pass-through current max. 4 A
• Housing: over-moulded PVC body, nickel-plated brass coupling nuts
• Environment: IP65, IP67, IP68, -40...+60 °C
• Connection: 5-pin M12 male (Modbus), 2x 4-pin M12 female (analog)

Out-of-range output values go to a selectable level after 2 s: Low (0 V or 3.5 mA), High (10.5 V or 20.5 mA) or Hold. Modbus settings are made with Banner SNAP SIGNAL Configuration Software.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

UWT NivoRadar NR 7200 is an 80 GHz FMCW radar level sensor for continuous, non-contact measurement of liquids up to 15 m. The narrow 8° beam avoids reflections from tank walls and internal fittings, and only the PVDF antenna is in contact with the medium.

• Warranty: extended to 6 years
• Measuring range: 0...15 m, accuracy ±2 mm
• Output: 2-wire 4...20 mA with HART
• Supply: 15...35 V DC, loop-powered
• Housing: PBT, G 1 1/2" thread (DIN ISO 228-1), PVDF wetted parts
• Environment: IP66/IP67, process temperature -40...+80 °C, pressure -1...+3 bar
• Connection: M20x1.5 cable gland
• Setup: display with push buttons under a transparent lid, or UWT LevelApp via Bluetooth

Used for level in storage and process tanks, IBCs and wastewater sumps, including many acids. Measures liquids with a dielectric constant from 1.1 - oils and solvents as well as water-based media.

CE, UKCA and cFMus approved for general-purpose (non-Ex) areas.

RKC4T-2-RSC4T/TXL is a TURCK extension cable with a straight M12 female connector on one end and a straight M12 male connector on the other (3-pin). The PUR jacket is rated for moving installation, including drag chains.

• Connectors: M12 x 1 female and M12 x 1 male, both straight, A-coded, 3-pin, gold-plated brass (CuZn) contacts
• Cable: 2 m, PUR, black, Ø 4.1 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

K50L2RGBKQ is a Banner K50 Pro series 50 mm RGB dome indicator controlled over IO-Link. Color, flashing, intensity and animations are set from the IO-Link master, so one indicator on one 4-pin cable can show many machine states.

• Colors: RGB, predefined and custom colors via IO-Link
• Animations: flashing, two-color flashing, strobe, half/half, half/half rotate
• Communication: IO-Link, input response time max. 30 ms
• Supply: 18...30 V DC, typical 115 mA at 24 V
• Housing: polycarbonate, M30x1.5 threaded base, Ø50 x 69 mm
• Environment: IP66, IP67, IP69K, UL 4X and 13, -40...+50 °C
• Connection: integral 4-pin M12 male connector

Requires an IO-Link master port; the IODD file is on the Banner website. The base is fixed with the included M30 nut, max. torque 4.5 N·m.

CE compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (30 G, 11 ms).

OT200.DN-GLZZJ.72CV is a distance sensor from the Baumer OT200 series, measuring by time of flight over a 0...2000 mm range. It reports the measured distance over IO-Link and at the same time switches two freely set switching points.

• Measuring range: 0...2000 mm (Sd), repeat accuracy ≤ 1.25...1.5 mm
• Output: push-pull (PNP/NPN) and IO-Link V1.1.4, Class A
• Linearity error: ± 10 mm
• Supply: 10...30 V DC, consumption max. 55 mA
• Housing: plastic (ASA, PMMA), 8 x 25.1 x 15.8 mm, smooth stainless steel mounting sleeve
• Environment: IP 67, -25...+50 °C
• Connection: 2 m cable, 4 cores

The infrared laser diode (940 nm, laser class 1) also works in dusty and smoky environments, while a visible red Alignment Guide beam is used for alignment. Response time is selected over IO-Link: < 25 ms in High Speed, < 50 ms in Standard and < 200 ms in High Accuracy mode. Suppression of reciprocal influence allows several sensors to be mounted side by side.

Vibration and shock resistance tested to IEC 60068-2-6:2008 (10 g, 10...2000 Hz) and IEC 60068-2-27:2009 (50 g / 11 ms).

OT200.GN-GLZZJ.72CV is a background suppression photo sensor from the Baumer OT200 series, measuring by time of flight over a 0...2000 mm switching range. It measures distance directly instead of judging the amount of reflected light, so dark and shiny objects are detected at the same point. The measured distance value is additionally available over IO-Link.

• Switching range: 0...2000 mm (Tw), set by qTeach or IO-Link
• Output: push-pull (PNP/NPN) and IO-Link V1.1.4, Class A, Light operate, switchable
• Repeat accuracy: ≤ 1.25...1.5 mm
• Supply: 10...30 V DC, consumption typically 25 mA (24 V DC)
• Housing: plastic (ASA, PMMA), 8 x 25.1 x 15.8 mm, smooth stainless steel mounting sleeve
• Environment: IP 67, -25...+50 °C
• Connection: 2 m PVC cable, 4 x 0.08 mm²

The infrared laser diode (940 nm, laser class 1) also works in dusty and smoky environments, while a visible red Alignment Guide beam is used for alignment. qTeach setup needs no button, so the switching point cannot be changed by accident during production. Suppression of reciprocal influence allows several sensors to be mounted side by side.

Vibration and shock resistance tested to IEC 60068-2-6:2008 (10 g, 10...2000 Hz) and IEC 60068-2-27:2009 (50 g / 11 ms).

OT200.SN-GDZZJ.72CV is a SmartReflect light barrier from the Baumer OT200 series - it forms the beam between the sensor and a fixed background instead of a separate reflector. The background position Sde is set anywhere between 300 and 2000 mm, and an object is detected as soon as it enters the beam ahead of the background. The measured distance value is additionally available over IO-Link.

• Background position: 300...2000 mm (Sde), scanning range 90...94 % Sde
• Output: push-pull (PNP/NPN) and IO-Link V1.1.4, Class A, Light operate, switchable
• Output current: 100 mA
• Supply: 10...30 V DC, consumption typically 25 mA (24 V DC)
• Housing: plastic (ASA, PMMA), 8 x 25.1 x 15.8 mm, smooth stainless steel mounting sleeve
• Environment: IP 67, -25...+50 °C
• Connection: 2 m PVC cable, 4 x 0.08 mm²

The reflector-free barrier principle suits positions where a reflector has nowhere to mount or soils quickly - the conveyor belt, machine frame or wall serves as the background. The infrared laser diode (940 nm, laser class 1) also works in dusty and smoky environments, while a visible red Alignment Guide beam is used for alignment.

Vibration and shock resistance tested to IEC 60068-2-6:2008 (10 g, 10...2000 Hz) and IEC 60068-2-27:2009 (50 g / 11 ms).

K50RF-4030-LKDQ is a Banner K50R series 60 GHz pulsed coherent radar sensor with a 40 x 30° beam in a flush-mount housing. It detects metal, water and organic materials at up to 5 m and works either with background suppression or against a taught reference point (retroreflective mode).

• Accuracy: linearity < ±5 mm (RCS 1 m² reference target); repeatability 10 mm
• Range: 0.05...5 m
• Outputs: output 1 IO-Link or push/pull, PNP/NPN; output 2 PNP/NPN or PFM; 50 mA each; response 80 ms
• Supply: 10...30 V DC, < 35 mA at 24 V
• Housing: polycarbonate, flush mount
• Environment: IP67, -40...+60 °C
• Connection: integral M12 5-pin male

Detection is unaffected by wind, fog, steam and temperature changes and resists rain and snow. Settings are made over IO-Link, with Banner Measurement Sensor Software or with the remote input wire.

Radio approval: US, Europe, UK; ETSI EN 305 550. Impact code IK07 per IEC 61010-1.

Q90R2-12040-6KDQ is a Banner Q90R2 series 60 GHz FMCW radar sensor with a ±60° horizontal and ±20° vertical field of view. It measures distance and speed of objects up to 20 m and can be set to detect within a distance or area, ignoring everything beyond, or against a taught reference.

• Accuracy: distance linearity ±10 mm above 200 mm, repeatability 10 mm, resolution 0.2 m; velocity linearity ±0.01 m/s
• Range: 0.15...20 m; velocity up to ±9 m/s
• Outputs: output 1 IO-Link or push/pull, PNP/NPN; output 2 PNP/NPN or PFM; 50 mA each; response 50/150/250 ms
• Supply: 10...30 V DC, < 100 mA at 24 V
• Housing: aluminium, polycarbonate window
• Environment: IP67, IP69K, -40...+65 °C
• Connection: integral M12 male

Besides distance, the sensor measures target velocity. Detection is unaffected by wind, fog, steam and temperature changes and resists rain and snow. Configuration is done over IO-Link, with Banner Measurement Sensor Software or with the remote input wire.

Radio approval: US, Canada, Europe, Australia, New Zealand; ETSI EN 305 550. Impact IK08 per IEC 62262.

DX80N2Q45THA NB is a Banner Sure Cross Q45 wireless node with a built-in temperature and relative humidity sensor, powered by its own lithium AA cells. It sends relative humidity, °C and °F to a DXM controller or DX80 Performance gateway, so no sensor or supply cable runs to the measuring point.

• Accuracy: temperature ±0.4 °C (0...+60 °C), ±0.6 °C (-40...0 °C), ±1.2 °C (+60...+85 °C); humidity ±2 % RH at 25 °C, ±3 % RH (0...70 °C, 10...90 % RH), ±7 % RH (0...70 °C, 0...10 % or 90...100 % RH)
• Measuring range: -40...+85 °C, 0...100 % RH; resolution 0.1 °C and 0.1 % RH
• Outputs: 2.4 GHz FHSS radio; registers 1-3 hold RH, °C and °F; default sensing interval 5 min
• Supply: 3.6 V lithium AA cells, not included (NB model)
• Housing: reinforced thermoplastic polyester, transparent Lexan cover, stainless steel hardware
• Environment: IP67, NEMA 6P; -40...+70 °C, 90 % RH at +50 °C non-condensing

Typical positions are refrigerators and chillers, warehouses, storage rooms, cleanrooms and incubators. The temperature is the register value divided by 20; humidity needs no scaling.

CE and UKCA (2.4 GHz models), RED 2014/53/EU; FCC ID UE3SX243, IC 7044A-SX243.

OT330.GN-GLZZJ.72OV/0030 is a background suppression photo sensor from the Baumer OT330 series in a miniature housing, measuring by time of flight over a 0...2500 mm switching range. Distance is measured directly, so a black and a white object are detected at the same point (black/white shift 0 %). The measured distance value is available over IO-Link.

• Switching range: 0...2500 mm (Tw), set by qTeach or IO-Link
• Output: push-pull (PNP/NPN) and IO-Link V1.1.4, Class A, Light operate
• Output current: 100 mA, repeat accuracy < 2...1.5 mm
• Supply: 10...30 V DC, consumption typically 25 mA (24 V DC)
• Housing: plastic (ABS, ASA, PMMA), 11 x 32 x 21 mm, smooth brass mounting sleeve
• Environment: IP 67, -25...+55 °C
• Connection: M12 flylead connector, 300 mm

The infrared laser diode (940 nm, laser class 1) also works in dusty and smoky environments, while a visible red Alignment Guide beam is used for alignment. Response time is selected over IO-Link: < 25 ms in High Speed, < 50 ms in Standard and < 200 ms in High Accuracy mode. Suppression of reciprocal influence allows several sensors to be mounted side by side.

Vibration and shock resistance tested to IEC 60068-2-6:2008 (10 g, 10...2000 Hz) and IEC 60068-2-27:2009 (50 g / 11 ms resp. 100 g / 6 ms).
