R45C-K-IQ is a Banner R45C series in-line converter that turns an IO-Link process data value from the master into an analog current output. It lets an IO-Link master drive a valve, positioner or other device with a mA input.

• Precision: accuracy 0.5 %, resolution 14 bit
• Output: analog current, process data range 0...24000 µA; out-of-range level selectable Low 3.5 mA, High 20.5 mA or Hold
• Communication: IO-Link device (male side)
• Supply: 18...30 VDC, max. 50 mA; pass-through current max. 4 A
• Housing: over-moulded PVC body, nickel-plated brass coupling nuts
• Environment: IP65, IP67, IP68, -40...+70 °C
• Connection: integral 4-pin M12 male and female

If the process data value leaves the valid range, the output moves to the selected level after 2 s. It needs an IO-Link master port.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

R90C-4B21-KQ is a Banner R90C series IO-Link hub with four M12 ports, each carrying two discrete channels that can be set as NPN or PNP input or output. It brings non-IO-Link sensors and actuators onto one IO-Link master port.

• Ports: 4x M12 female, 2 discrete channels per port, NPN or PNP set per channel; output load 100 mA
• Functions: ON/OFF delay, one-shot, retriggerable one-shot, pulse stretcher, totaliser; count, events per minute and duration per channel
• Communication: IO-Link device; any port signal can be mirrored to another port or to the host pin 2
• Supply: 18...30 VDC, max. 100 mA; pass-through current max. 1 A per port
• Housing: over-moulded PVC body, nickel-plated brass coupling nuts, 50x90 mm
• Environment: IP65, IP67, IP68, -40...+70 °C
• Connection: 4x 4-pin M12 female, 1x 4-pin M12 male to the master

Mounts on the machine next to the sensors, so one cable runs back to the IO-Link master instead of eight. It needs an IO-Link master port and M12 cordsets, ordered separately.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

! Without packaging!
Capacitive Sensor

Rated switching distance 10 mm

Flush; Cable length 2 m; Rectangular, height 5.5 mm; Large active face, marked for correct installation; Plastic, PP; Fixed settings; DC 3-wire, 10…30 VDC; NO contact, NPN output; Cable connection

T18GRBP is a Banner EZ-LIGHT T18 series three-color indicator in a right-angle housing with an M18x1 threaded base. Green, red and blue each have their own input wire.

• Colors: green, red, blue
• Inputs: PNP, response time max. 1 ms
• Supply: 10...30 V DC, max. 25 mA per color
• Housing: yellow thermoplastic polyester, M18x1 thread, 41 x 30.1 x 32.4 mm
• Environment: IP67, -40...+50 °C
• Connection: 2 m cable, 4 wires

Supplied without original packaging.

Q20PDL is a Banner Q20 series long-range diffuse photo sensor with a visible red 624 nm beam. It detects an object by the light the object reflects back to the sensor, so no reflector or separate receiver is needed.

• Sensing range: 800 mm on a 90 % white test card
• Output: PNP, complementary Light Operate and Dark Operate outputs, 100 mA
• Response: 850 µs ON/OFF; repeatability 90 µs
• Supply: 10-30 V DC, < 18 mA
• Housing: ABS, PMMA lenses
• Environment: IP67, -20...+60 °C
• Connection: 2 m PVC cable, 4 wires

A green LED indicator shows power; the amber one shows the output state and flashes at marginal excess gain. Sensitivity is set with a single-turn potentiometer.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

Without packaging

!Without packaging!

K30 Series: 2-Color Touch Sensor; Latching Output

Voltage: 12-30 V dc; Housing: Polycarbonate; IP67 IP69K

Output: Bipolar (NO); Colors: Yellow - Not Activated, Red - Activated

5-pin M12 Integral QD

PKW4M-5/TEL is a TURCK connection cable with an angled M8 female connector (4-pin) on one end and open cores on the other.

• Connector: M8 x 1, female, angled, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 50 VAC / 60 VDC, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

RKS4.4T-0.3-PSGS4M/TXL is a TURCK shielded connection cable with a straight M12 female connector on one end and a straight M8 male connector on the other (4-pin). The cable shield is connected to the M12 coupling nut.

• Connectors: M12 x 1 female, A-coded / M8 x 1 male, both straight, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 0.3 m, PUR, black, Ø 5.3 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 50 VAC/60 VDC, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nuts, FPM/FKM seal; M8 tightening torque 0.5...0.6 Nm
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

M12, female, straight, 3 poles, sensor-/actuator cable

BS5143-0 is a TURCK field-wireable M8 male connector, straight, 4-pin, for 3.5...5 mm cable with screw-clamp terminals.

• Connector: M8, male, straight, 4-pin, gold-plated brass (CuZn) contacts, more than 100 mating cycles
• Ratings: 4 A, 30 V, contact resistance ≤3 mΩ
• Connection: screw-clamp terminals, conductors up to 0.5 mm², cable diameter 3.5...5 mm, M11 x 0.75 screw-in thread
• Housing: black PBT body, PA 66 contact carrier, nickel-plated die-cast zinc (GD-Zn) coupling nut, FPM/FKM seal
• Environment: IP67 (screwed together); -40...+85°C fixed

Approval: cULus recognized.

WKS4.4T-5/TXL is a TURCK shielded connection cable with an angled M12 female connector (4-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, angled, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PUR, black, Ø 5.3 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

WKS4.4T-10/TEL is a TURCK shielded connection cable with an angled M12 female connector (4-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, angled, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 10 m, PVC, black, Ø 5.4 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, 0...+80°C mobile

The PVC jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS.

Approval: cULus.

RSSD-RJ45S-4422-25M is a TURCK Industrial Ethernet cable with a straight M12 male connector on one end and a straight RJ45 male connector on the other (4-pin). The 4-wire CAT 5e cable carries 100 Mbit/s Ethernet and PROFINET.

• Connectors: M12 x 1 male, straight, D-coded / RJ45 male, straight; 4-pin
• Cable: 25 m, PUR, green, Ø 6.5 mm, 4 x 0.32 mm², core colours WH, YE, BU, OG, overall shield of aluminium foil and tinned copper braid
• Ratings: 1.5 A, 42 V DC; CAT 5e, impedance 100 Ω, capacitance 50 pF/m
• Housing: TPU, nickel-plated brass coupling nut
• Environment: M12 IP67 (only when screwed in), RJ45 IP20; -40...+80°C fixed, -30...+80°C mobile
• Drag chain: at least 5 million bending cycles, bending radius ≥15 x Ø, torsion ±180°/m

The green PUR jacket is halogen free (IEC 60754), oil resistant (IEC 60811-2-1) and flame retardant (IEC 60332-1-2); the cable is RoHS compliant and PNO compliant for PROFINET. Approval: UL Listed.

WKH4.5-20/TFE is a TURCK hygienic connection cable with an angled M12 female connector (5-pin) on one end and open cores on the other, for sensors and actuators in food and beverage plants.

• Connector: M12 female, angled, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 20 m, PVC, grey RAL 7040, Ø 4.9 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: grey PP, stainless steel (V4A) coupling nut, FPM/FKM seal
• Environment: IP65, IP67, IP68, IP69 (only when screwed in); -25...+80°C fixed, 0...+80°C mobile

Designed for food and beverage areas: the grey PVC jacket (RAL 7040) resists acids, alkalis, oils and chemicals and is flame retardant per DIN EN 60332-1-2 and 60332-2-2. RoHS and REACH compliant. Approvals: GOST, Ecolab.

WKH4.5-5/TFE is a TURCK hygienic connection cable with an angled M12 female connector (5-pin) on one end and open cores on the other, for sensors and actuators in food and beverage plants.

• Connector: M12 female, angled, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PVC, grey RAL 7040, Ø 4.9 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: grey PP, stainless steel (V4A) coupling nut, FPM/FKM seal
• Environment: IP65, IP67, IP68, IP69 (only when screwed in); -25...+80°C fixed, 0...+80°C mobile

Designed for food and beverage areas: the grey PVC jacket (RAL 7040) resists acids, alkalis, oils and chemicals and is flame retardant per DIN EN 60332-1-2 and 60332-2-2. RoHS and REACH compliant. Approvals: GOST, Ecolab.

RKH4.5-5/TFE is a TURCK hygienic-design connection cable for food and beverage production, with a straight M12 female connector (5-pin) on one end and open cores on the other.

• Connector: M12 x 1, female, straight, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PVC, grey (RAL 7040), Ø 4.9 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: grey PP, stainless steel (V4A) coupling nut, FPM/FKM seal
• Environment: IP65, IP67, IP68, IP69 (only when screwed in); -25...+80°C fixed, 0...+80°C mobile

The jacket resists acids, alkalis, oils and chemicals and is flame retardant per DIN EN 60332-1-2 and DIN EN 60332-2-2. RoHS and REACH compliant, approvals: Ecolab, GOST.

RKH4.5-10/TFE is a TURCK hygienic-design connection cable for food and beverage production, with a straight M12 female connector (5-pin) on one end and open cores on the other.

• Connector: M12 x 1, female, straight, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 10 m, PVC, grey (RAL 7040), Ø 4.9 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: grey PP, stainless steel (V4A) coupling nut, FPM/FKM seal
• Environment: IP65, IP67, IP68, IP69 (only when screwed in); -25...+80°C fixed, 0...+80°C mobile

The jacket resists acids, alkalis, oils and chemicals and is flame retardant per DIN EN 60332-1-2 and DIN EN 60332-2-2. RoHS and REACH compliant, approvals: Ecolab, GOST.

RKC4T-0.3-PSG3M/TXL is a TURCK connection cable with a straight M12 female connector on one end and a straight M8 male connector on the other (3-pin).

• Connectors: M12 x 1 female, A-coded / M8 x 1 male, both straight, 3-pin, gold-plated brass (CuZn) contacts
• Cable: 0.3 m, PUR, black, Ø 4.1 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 50 VAC/60 VDC, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nuts, FPM/FKM seal; M8 tightening torque 0.5...0.6 Nm
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

Q20NDXL is a Banner Q20 series long-range diffuse photo sensor with an infrared beam. It detects objects by the light they reflect back, up to 1.5 m from the sensor, and has both a Light Operate and a Dark Operate NPN output.

• Sensing range: 1500 mm, adjustable
• Output: complementary NPN, Light Operate and Dark Operate
• Response: 0.8 ms; repeatability 155 µs
• Supply: 10-30 V DC
• Housing: compact rectangular, thermoplastic, acrylic lens
• Environment: IP67, NEMA 4X, -20...+60 °C
• Connection: 2 m PVC cable, 4 wires

Sensitivity is set with a potentiometer.

UL and CE approved.

K30APT2FXRF2 is a Banner K30 FDA series 30 mm capacitive touch button in FDA-grade materials for food and washdown areas. It switches when touched with a bare or gloved hand, without mechanical force; the button stays dark with power applied and lights red when its input is active.

• Colour: red when the input is active, off with power only
• Input: PNP, response 300 ms
• Output: PNP, normally open, momentary, 150 mA max, response 150 ms
• Supply: 12-30 V DC, 55 mA max
• Housing: Ø30 x 41 mm, FDA-grade copolyester, grey, M22x1.5 base mount
• Environment: IP67, IP69K, -40...+50 °C
• Connection: 2 m PVC cable, 4 wires

The button is immune to false triggering by water spray, detergents and oils.

Vibration tested to IEC 60068-2-6, shock to IEC 60068-2-27 (30 g, 11 ms). UL, CE and UKCA approved.

TX715FB-P3CV01 is a 7" touch display from the TURCK TX700 series with a built-in CODESYS V3 PLC, TARGET and WEB VISU visualisation. The FB version for the food industry has a stainless steel AISI 316L frame, a food-grade seal and an IP69 front that withstands high-pressure water up to 80 °C, acids and chemicals.

• Display: 7" TFT, 1366 x 768 (HD), 16:9, 16M colours, 400 cd/m², capacitive glass front with polyester coating, dimmable to 0 %
• Communication: 3 x RJ45 Ethernet 10/100 Mbit, 1 x RS232/RS485/RS422, 2 x USB host (v2.0, max. 500 mA), SD card slot
• Expansion: 2 slots for up to 4 plug-in modules (I/O, CANopen, PROFIBUS DP, RS485, RS232, LTE/Wi-Fi)
• PLC: CODESYS V3.5.12.10, IEC 61131-3 (IL, LD, FBD, SFC, ST), 20000 kB program memory, 63 kB retain memory; ARM Cortex A9, Quad core 800 MHz, 2048 MB RAM, 8 GB Flash, battery-backed clock
• Supply: 24 VDC (10...32 VDC), max. 1.2 A
• Housing: die-cast aluminium, stainless steel AISI 316L frame, polyester front foil, mounting depth 56+8 mm
• Environment: IP69 front, IP20 rear, NEMA 12/4X; -20...+60 °C, 5...85 % RH non-condensing

Intended for operator stations in food and beverage production. Built into a cabinet door or control desk. Mounting brackets and the power connector come in the 7" TX700 mounting kit, available as an accessory; I/O and fieldbus modules plug into the expansion slots and are ordered separately.

BWS8151-0 is a TURCK field-wireable M12 female connector, straight, 5-pin, B-coded, for 4...6 mm cable with screw-clamp terminals.

• Connector: M12, female, straight, B-coded, 5-pin, CuZn contacts with Optalloy coating, more than 500 mating cycles
• Ratings: 4 A, 60 V, contact resistance ≤8 mΩ
• Connection: screw-clamp terminals, conductors up to 0.75 mm², cable diameter 4...6 mm, PG7 screw-in thread
• Housing: black PA body, contact carrier and coupling nut, FPM/FKM seal
• Environment: IP67 (screwed together); -25...+85°C fixed

Approval: cULus recognized.

WKC4.4T-P7X2-5-RSC4.4T/TXL is a TURCK extension cable with an angled M12 female connector on one end and a straight M12 male connector on the other (4-pin). The female connector has two built-in LED indicators: green shows the supply, yellow the PNP signal on pin 4.

• Connectors: M12 x 1 female, angled / M12 x 1 male, straight; A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PUR, black, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 30 V DC, more than 100 mating cycles
• Housing: female translucent TPU, male black TPU; nickel-plated brass coupling nuts, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The PUR jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.
