The BL20-PG-EN-V3 is a TURCK BL20 series programmable gateway with an integrated CODESYS V3 PLC environment. It works as the head module of a BL20 station and, at the same time, as a controller that processes I/O data and communicates with higher system levels.

• Configuration: CODESYS V3 PLC environment, OPC UA server/client
• Communication: Modbus TCP, EtherNet/IP, PROFINET, integrated 10/100 Mbps switch (switched or dual-MAC mode), 2x RJ45
• Power: 24 VDC (18...30 VDC), module bus current ≤200 mA, field supply current up to 8 A, system supply current up to 1.3 A
• Indication: LEDs for PLC status, supply and fault signalling
• Environment: IP20, 0...+55°C

The gateway replaces a separate PLC in the control cabinet, since it processes the BL20 station's I/O data itself according to a CODESYS V3 program and simultaneously connects the station to the plant Ethernet network, including TURCK Cloud IIoT connectivity. The station additionally requires matching BL20-E series I/O modules, ordered separately.

The BL20-E-2CNT-2PWM is a TURCK BL20-E series economy module with 2 counter/encoder input channels and 2 PWM outputs. Electronics and connection technology are combined in one housing, so no separate base module is needed.

• Inputs: 2 counter/encoder channels up to 200 kHz, thresholds parametrizable 0...1 V/0...4.5 V (low) and 2.5...30 V/7.5...30 V (high)
• Outputs: 2 PWM outputs 20 kHz / 0.5 A, 2 digital outputs 20 kHz / 0.5 A, output voltage 24 VDC
• Power: 24 VDC (18...30 VDC), field supply current ≈20 mA, module bus current ≈50 mA
• Connection: push-in terminals
• Environment: IP20, 0...+55°C

The module operates as part of a BL20-E station together with a BL20-E-GW gateway and other BL20-E modules, and is suited for reading encoders and driving motors or valves with a PWM signal.

Complies with cULus requirements.

The BL20-2AI-I(0/4...20MA) is a TURCK BL20 series electronic module with 2 analogue current inputs. The module mounts on a separate BL20 base, and the field signal is galvanically isolated from the module bus via an optocoupler.

• Inputs: 2 analogue current inputs, signal 0/4...20 mA
• Accuracy: input resistance <0.125 kΩ, maximum input current 50 mA
• Power: 24 VDC, field supply current ≤12 mA, module bus current ≤35 mA
• Connection: screw or tension-spring terminals (depending on the base)
• Environment: IP20, 0...+55°C

The module requires a separately ordered BL20 base (S3 or S4 series, with screw or tension-spring terminals) — it cannot be used without one. The electronics can be replaced without disconnecting the field wiring, since the connections stay on the base.

Complies with cULus requirements.

GSM datalogger is designed to record 3 current inputs and 1 binary input. In case of exceeded set limits, SMS and JSON messages can be sent via GPRS data connection. Measured values can be sent to the internet storage COMET Cloud, which is a complete monitoring, alarm and analysis system.

It is also possible to set the regular sending of JSON messages to COMET Database, the sending interval is adjustable. Alarms are also indicated locally by LED, LCD and acoustically by built-in beeper.

The recording is performed in a non-volatile electronic memory. The data can be transferred to a PC via included USB-C cable.

GSM recorder includes Traceable calibration certificate with declared metrological traceability of etalons is based on requirements of EN ISO/IEC 17025 standard.

Radio Transmission System Point-to-point
Node

• • External antenna (RG58 RP-SMA connection)
  • Integrated signal strength indicator
  • Configuration via DIP switch
  • Deterministic data transmission
  • Frequency hopping FHSS
  • Time Division Multiplex Access TDMA
  • Transmission power: 63 mW, 18 dBm conducted, ≤ 20 dBm EIRP
  • Inputs: 4 x PNP, 2 x 0…20 mA
  • Outputs: 4 x PNP, 2 x 0…20 mA
  • Power consumption: < 60 mA at 24 VDC

The BL20-PG-EN-V3-WV is a variant of the BL20-PG-EN-V3 programmable gateway with a CODESYS WebVisu license included. The gateway works as the head module and controller of a BL20 station, and WebVisu lets a process visualisation be opened directly in a browser without extra SCADA software.

• Configuration: CODESYS V3 PLC environment with WebVisu license included, OPC UA server/client
• Communication: Modbus TCP, EtherNet/IP, PROFINET, integrated 10/100 Mbps switch (switched or dual-MAC mode), 2x RJ45
• Power: 24 VDC (18...30 VDC), module bus current ≤200 mA, field supply current up to 8 A, system supply current up to 1.3 A
• Indication: LEDs for PLC status, supply and fault signalling
• Environment: IP20, 0...+55°C

The gateway fits where an operator needs to view or control the BL20 station's process from any device with a browser, without installing a separate visualisation server. The station additionally requires matching BL20-E series I/O modules, ordered separately.

Complies with FM ATEX, IECEx and FM Class I Div. 2 (US and Canada) requirements, and carries an EU Declaration of Conformity.
