RKC5.501T-30/TXL is a TURCK connection cable with a straight M12 female connector (4-pin) on one end and open cores on the other. The PUR jacket is rated for moving installation, including drag chains.

• Connector: M12 x 1, female, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 30 m, PUR, black, shielded, Ø 5.3 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

RKS4.4T-40/TXL is a TURCK shielded connection cable with a straight M12 female connector (4-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 40 m, PUR, black, Ø 5.3 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

RKS4.4T-50/TXL is a TURCK shielded connection cable with a straight M12 female connector (4-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 50 m, PUR, black, Ø 5.3 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

VBRS4.4-2RKC4T-2/2/TXL is a TURCK Y-splitter with a straight M12 male connector (4-pin) and two straight M12 female connectors (3-pin) on 2 m PUR cable branches. Pin 4 of the male connector is wired to pin 4 of the first branch (BK1), pin 2 to pin 4 of the second branch (BK2), and the supply (pin 1 +, pin 3 -) is shared by both branches.

• Connectors: M12 x 1 male, 4-pin / 2 x M12 x 1 female, 3-pin, all straight, gold-plated brass (CuZn) contacts
• Cable: 2 x 2 m, PUR, black, Ø 4.3 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nuts, FPM/FKM seal; tightening torque 0.8...1 Nm
• Environment: IP67 (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

Two sensors switching on pin 4 therefore share one two-channel M12 port.

The PUR jacket is rated for drag chains: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m. It resists chemicals, UV radiation, oils and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

RoHS compliant.

VBRS4.4-2WKC4.324T-5/5/TXL is a TURCK Y-splitter with a straight M12 male connector and two angled M12 female connectors on 5 m PUR cable branches. Pin 4 of the male connector is wired to pins 2 and 4 of the first branch, pin 2 to pins 2 and 4 of the second branch, and the supply (pin 1 +, pin 3 -) is shared by both branches.

• Connectors: M12 x 1 male, straight / 2 x M12 x 1 female, angled; all 4-pin, gold-plated brass (CuZn) contacts
• Cable: 2 x 5 m, PUR, black, Ø 4.3 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nuts, FPM/FKM seal; tightening torque 0.8...1 Nm
• Environment: IP67 (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

Two sensors therefore share one two-channel M12 port. The PUR jacket resists chemicals, UV radiation, oils and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

RoHS compliant.

950551020 Pastiprinātājs šķiedru optikai S7-5-E-N

S18UIAQ is a Banner U-GAGE S18U ultrasonic sensor in a straight M18 housing with a 4-20 mA output scaled across a taught window. Its 30 mm near limit lets it measure close to the sensor face, and temperature compensation is built in.

• Accuracy: linearity ±1 mm (2.5 ms) or ±0.5 mm (30 ms); resolution 1 mm or 0.5 mm; 50 x 50 mm aluminium target, 22 °C
• Measuring range: 30...300 mm, 300 kHz; minimum window 5 mm
• Output: analog 4-20 mA; response 2.5 ms or 30 ms, selected on the black wire
• Supply: 10...30 V DC, 40 mA typical at 25 V
• Housing: M18 straight, thermoplastic polyester
• Environment: IP67, NEMA 6P, -20...+60 °C
• Connection: integral M12 5-pin male

Window limits are taught with the push button or the remote wire.

Vibration per MIL-STD-202F method 201A, shock per IEC 60947-5-2 (30 g, 11 ms).

WLS15XDW0360DSC2 is a Banner WLS15 series 360 mm daylight white strip light in a sealed polycarbonate shell with an aluminum frame. The same model runs on 12 V DC or 24 V DC.

• Light: daylight white 5000 K, 350 lm, lighted length 286.4 mm
• Supply: 12 or 24 V DC, typical 0.38 A at 12 V, 0.20 A at 24 V
• Dimming: PWM 25...100 %, up to 1000 Hz
• Housing: polycarbonate, aluminum frame, polyamide end caps, 360 x 30.6 x 15.5 mm
• Environment: IP66, IP67, -40...+60 °C
• Connection: 2 m PVC cable, 2 wires, stand-alone (non-cascade) model

The light is fixed with M4 screws through the integral slots (max. 0.56 N·m) or with snap clips. The cable must not be exposed to a high-pressure jet.

CE compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

[M23F12PIN-5.0-1032081] Konektora kabelis enkoderiem UTD-IPH00-XXXXX-L10S-PRL M23, 5m ekranēts, 10x0,34mm²

Pos.10 - Type: [A] NG 8100 Pos.20 - Certificate: [0] CE / UKCA / TR-CU Pos.30 - Process temperature / insulator: [F] -40°C..+150°C (-40°F..302°F) FKM Single line of defense, PEEK Pos.40 - Electronic module: [A] 2-wire 4..20 mA, HART (9.6..35 V DC) Pos.50 - Process connection: [0A] Thread ¾" NPT PN40 taper, ANSI/ ASME B1.20.1 Pos.80 - Version of Probe L: [E] Rod ø8 mm (0.31") Pos.90 - Display and adjustment module: [A] with display and adjustment module, with inspection window in lid Pos.100 - Rigid part L1: [0] without (rod version) Pos.130 - Cable entry: [D] 1x M20x1.5 screwed cable gland PA (ø5-9 mm [0.20-0.35"]) 1x blind plug Pos.140 - Language manual: [2] EN - English Pos.160 - Housing: [A] aluminium single chamber Pos.190 - Dimensions centering weight (diameter / height): [0] without

PFM43-2211.A1421.0 is a Baumer electromagnetic insertion flow meter for pipes from DN 80 to DN 500. It is inserted into the pipe through a G 1 A threaded connection, so a large line does not need a full-bore flow meter. It passes flow velocity on as a pulse or frequency signal, and it is configured with Baumer BCP software.

• Measuring range: flow velocity 0.4...10 m/s, pipes DN 80...DN 500
• Accuracy: ±2 % at ≥ 0.5 m/s, repeatability ±0.5 %
• Output: 2 x pulse/frequency/alarm; analogue 0...20 mA or 4...20 mA output - optional
• Supply: 10...30 V DC, ≤ 1 W
• Housing: AISI 316, L=176 mm; G 1 A connection in AISI 304, Hastelloy C electrodes, PEEK and PTFE seals
• Environment: IP67; process -10...100 °C, up to 100 bar; ambient -10...60 °C
• Connection: M12-A, 5-pin, stainless steel

The medium must have a conductivity above 20 µS/cm, so the meter is not suitable for demineralised water or oils. After power-up it is operational within 30 s, but calibration needs a warm-up of up to 15 min.

PFM43-2211.A2421.0 is a Baumer electromagnetic insertion flow meter for pipes from DN 80 to DN 1000. It is inserted into the pipe through a G 1 A threaded connection, so a large line does not need a full-bore flow meter. It passes flow velocity on as a pulse or frequency signal, and it is configured with Baumer BCP software.

• Measuring range: flow velocity 0.4...10 m/s, pipes DN 80...DN 1000
• Accuracy: ±2 % at ≥ 0.5 m/s, repeatability ±0.5 %
• Output: 2 x pulse/frequency/alarm; analogue 0...20 mA or 4...20 mA output - optional
• Supply: 10...30 V DC, ≤ 1 W
• Housing: AISI 316, L=244 mm; G 1 A connection in AISI 304, Hastelloy C electrodes, PEEK and PTFE seals
• Environment: IP67; process -10...100 °C, up to 100 bar; ambient -10...60 °C
• Connection: M12-A, 5-pin, stainless steel

The medium must have a conductivity above 20 µS/cm, so the meter is not suitable for demineralised water or oils. After power-up it is operational within 30 s, but calibration needs a warm-up of up to 15 min.

PFM43-2211.A3421.0 is a Baumer electromagnetic insertion flow meter for pipes from DN 80 to DN 2000. It is inserted into the pipe through a G 1 A threaded connection, so a large line does not need a full-bore flow meter. It passes flow velocity on as a pulse or frequency signal, and it is configured with Baumer BCP software.

• Measuring range: flow velocity 0.4...10 m/s, pipes DN 80...DN 2000
• Accuracy: ±2 % at ≥ 0.5 m/s, repeatability ±0.5 %
• Output: 2 x pulse/frequency/alarm; analogue 0...20 mA or 4...20 mA output - optional
• Supply: 10...30 V DC, ≤ 1 W
• Housing: AISI 316, L=462 mm; G 1 A connection in AISI 304, Hastelloy C electrodes, PEEK and PTFE seals
• Environment: IP67; process -10...100 °C, up to 100 bar; ambient -10...60 °C
• Connection: M12-A, 5-pin, stainless steel

The medium must have a conductivity above 20 µS/cm, so the meter is not suitable for demineralised water or oils. After power-up it is operational within 30 s, but calibration needs a warm-up of up to 15 min.

EIL580-SY06.5EQ.01000.A is a Baumer optoPulse incremental encoder with optical sensing, 1000 pulses per revolution and synchro flange mounting. The HTL output level follows the supply (Vout = Vin), so on a 24 V system the signal is at 24 V and goes straight to a PLC high-speed counter input.

• Resolution: 1000 pulses per revolution, zero pulse
• Output: HTL/push-pull, 6 channels (A+, B+, R+, A-, B-, R-), up to 160 kHz
• Supply: 4.75-30 V DC, no-load consumption ≤70 mA
• Housing: Ø58 mm, synchro flange with Ø50 mm centring collar, Ø6 x 10 mm shaft with flat
• Environment: IP65, -40...+85 °C, up to 12000 rpm

The synchro flange lets the encoder be held with clamps and rotated around its shaft before tightening. The shaft needs a flexible coupling.

UL 508 / CSA 22.2 approved. EMC to EN 61000-6-2 and EN 61000-6-3; vibration (30 g, 10-2000 Hz) and shock (300 g, 6 ms) resistance to EN 60068-2-6 and EN 60068-2-27.

WKC4.4T-15/TEL is a TURCK connection cable with an angled M12 female connector (4-pin) on one end and open cores on the other.

• Connector: M12 x 1, female, angled, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 15 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The PVC jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

PKG4MS-4.6-22 is a Banner single-ended cordset with a straight 4-pin M8 female connector and flying leads. The cable shield is tied to the coupling nut.

• Connector: M8, female, straight, 4 pins; nickel-plated brass coupling nut, black PVC overmold
• Cable: 4.6 m, black PVC, Ø 5.21 mm, 4 x 22 AWG, shielded
• Ratings: 4 A, 30 V DC
• Environment: IP66, IP67, IP68, -40...+70 °C

CE marked.

STP-M8MRJ45-415 is a Banner Ethernet cordset with a straight 4-pin M8 male connector at one end and an RJ45 plug at the other. The twisted pairs are individually shielded with an overall shield, rated Cat5e.

• Connectors: M8, male, straight, 4 pins, nickel-plated brass nut, black PUR body / RJ45 plug, polycarbonate housing, gold-plated contacts
• Cable: 4.57 m, black PVC, Ø 5 mm, 26 AWG, shield on the M8 nut and RJ45 shell
• Ratings: 0.5 A, 42 V DC
• Environment: IP66, IP67 (M8 end only), -40...+70 °C

Pressure switch with intuitive switch point setting PK6522 PK-100-SFG14-HCPKG/US/ /W

Pressure switch with intuitive switch point setting PK6520 PK-400-SFG14-HCPKG/US/ /W

SMBZMXMP is a Banner stainless steel plate for flush mounting a sensor of the 3DTOF series. Besides the M4 holes for the sensor it carries a 1/4-20 thread, so the plate can also be fixed to an articulated (Bogen-type) arm.

• Fits: Banner 3DTOF series
• Material: stainless steel
• Hardware: M4 x 0.7 screws included
• Extra mounting: 1/4-20 thread

WLF12PXRGB1200SQP is a Banner WLF12 Pro series flexible RGB LED strip with a 1200 mm lit length for status indication on machines, AGVs and workstations. Color, flashing, intensity and animations are set through an LC25 LED controller, which can be driven by discrete signals, IO-Link or Modbus.

• Colors: RGB, programmable through the LC25 controller
• Supply: 12 V DC ±10% without controller, 12...30 V DC with LC25 controller; current 0.78 A at 12 V
• Housing: clear silicone, 1225 x 12.8 x 6.4 mm, adhesive tape on the back, minimum bend radius 15 mm
• Environment: IP66, IP67, IP69K, -20...+45 °C
• Connection: 150 mm PVC cable with 4-pin M12 male connector

The strip needs an LC25 LED controller mounted no more than 3.05 m away. A supply above 12 V DC applied directly to the strip damages it permanently. The strip can be shortened at the cut lines every 50 mm, sealing the end with the supplied cap and silicone, but cutting voids the warranty. Not for applications with repeated flexing.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms). Suitable for damp locations per UL 2108.

RKS4.5T-5/TXL is a TURCK shielded connection cable with a straight M12 female connector (5-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PUR, black, Ø 5.7 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

Temperatūras sensors TE2-1.4.7020.0080.0 Art: 11180504 G 1/2 A hygienic (A03) L=80mm D=6mm

LC25C-WLF12-RGB7Q is a Banner LC25 in-line controller that sits between a PLC and a WLF12 Pro flexible multicolor strip light. It converts discrete, PWM or PFM signals into colors, animations, levels or counters on the strip.

• Inputs: 3 discrete inputs, 12...30 V DC; PWM 0...100 % or PFM 100...10 000 Hz
• Modes: machine status, tower light, timer, counter, distance, gauge - set in Pro Editor
• Supply: 12...30 V DC, max. 30 mA (strip supplied separately)
• Housing: translucent black PVC, nickel-plated brass coupling, 25 x 85 mm
• Environment: IP65, IP67, IP68, -40...+50 °C
• Connection: integral 4-pin M12 male and female connectors

Required for WLF12 Pro: the strip must be no more than 3.05 m from the controller, and 24 V applied directly to the strip destroys it. The strip length is taught once by remote input or in Pro Editor.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

RKC4.4T-1.5-RSC4.4T/TEL is a TURCK extension cable with a straight M12 female connector on one end and a straight M12 male connector on the other (4-pin). The cable has a black PVC jacket.

• Connectors: M12 x 1 female and M12 x 1 male, both straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 1.5 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

Konektors ar kabeli MSUD valve plug A-18mm with cable PUR 3x0.75 bk UL/CSA+drag ch. 2m Art: 7000-18021-6360200

Konektors ar kabeli MSUD valve plug A-18mm with cable PUR 3x0.75 bk UL/CSA+drag ch. 5m Art: 7000-18021-6360500

U500.DA5.2-UAMJ.72F is a Baumer U500 series ultrasonic distance sensor with a 20...1500 mm measuring range, a 0...10 V analog output and an IO-Link interface. It has two IO-Link channels (dual channel) and a multiplex version, so several sensors can run side by side without mutual interference.

• Accuracy: repeatability 0.5 mm; resolution < 0.3 mm; temperature drift < 2 % of object distance (> 50 mm); power-up drift compensated after 15 min
• Measuring range: 20...1500 mm, start and end point adjustable; response time < 70 ms; sonic frequency 200 kHz
• Outputs: analog 0...10 V / 10...0 V, up to 100 mA; IO-Link V1.1, COM 2 (38.4 kBaud), cycle time ≥ 12 ms, port type Class A, 48-bit process data (distance, 2 switching channels, quality, alarm, counter)
• Supply: 12...30 V DC, average consumption 35 mA; short-circuit and reverse-polarity protected
• Housing: rectangular, ASA/PMMA plastic, PEEK-coated sensor face, 18 x 45 x 32 mm
• Environment: IP67, operating temperature -25...+65 °C
• Connection: M12 connector, 5-pin

Suited to level measurement in tanks and distance measurement up to 1.5 m, where object colour, transparency or dust disturbs an optical measurement. The range is set by qTeach, Line-Teach or over IO-Link, which also configures filtering, the output characteristic, the sonic beam width and the function of pin 5.

Q4XTULAF500-Q8 is a Banner Q4X series laser distance sensor with a Class 1 visible red 655 nm laser and a 0-10 V analog output over 25-500 mm. It measures dark and shiny targets alike and shows the reading in volts or millimetres on its four-digit display.

• Resolution: < 0.3 mm at 25-100 mm, < 1 mm at 100-300 mm, < 1.75 mm at 300-500 mm; linearity follows the accuracy curve in the manual
• Measuring range: 25-500 mm
• Output: analog 0-10 V, min. load 2.5 kOhm; response 0.5...2560 ms depending on averaging
• Supply: 12-30 V DC, < 675 mW
• Housing: 316L stainless steel, M18 threaded barrel, PMMA lens cover
• Environment: IP67, IP68, IP69K, -10...+50 °C, ECOLAB certified
• Connection: integral M12 5-pin male connector

The analog span is taught with the push buttons or the remote input, with one-point and two-point teach. The housing withstands aggressive cleaning and typical cutting and lubricating fluids, so it fits washdown food lines and machining centres. Allow 10 minutes of warm-up for best accuracy.

Shock to MIL-STD-202G, method 213B; vibration to MIL-STD-202G, method 201A. Class 1 laser product.

FHDK 10P5101 is a Baumer miniature photo sensor with background suppression. It compares where the reflected beam lands on its internal detector, so an object is detected regardless of its colour or surface reflectivity while everything beyond the set distance is ignored. A 35...45 mm focus zone with a 4 mm beam diameter allows small objects to be detected.

• Switching distance: 20...120 mm, adjustable by a 5-turn mechanical potentiometer
• Output: PNP, Light/Dark Operate, < 100 mA
• Supply: 10...30 V DC, typical consumption 20 mA
• Housing: rectangular, 10.4 x 27 x 14 mm, plastic (ASA), PMMA optics
• Environment: IP 65, -25...+65 °C
• Connection: cable 2 m, 4-wire

The sensor suits presence and position control in packaging, assembly and sorting machines where the background sits close to the object and dark or glossy surfaces give a standard diffuse sensor a false reading. A flashing light indicator shows insufficient signal margin or a soiled lens, so alignment and maintenance need no instruments. Reciprocal influence is suppressed, so several sensors can be mounted side by side.

SG-TL70-W is a Banner TL70 series white 70 mm light module for a modular tower light. When off the segment looks gray, so ambient light does not make it appear lit.

• Color: daylight white, 5000 K, 125 lm
• Mode: steady or flashing 1.5 Hz / 3 Hz, selected with DIP switches
• Supply: 12...30 V DC, 420 mA at 12 V, 200 mA at 24 V
• Housing: black polycarbonate, Ø70 x 50 mm
• Environment: IP65, -40...+50 °C

The module twist-locks onto a B-TL70 series base, which carries the electrical connection. The DIP switches set the module's position in the tower (1...6), so it can be moved to another position without rewiring.

CE and UKCA compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

SG-TL70B-R is a Banner TL70B series red 70 mm light module for a modular tower light. When off the segment looks gray, so ambient light does not make it appear lit.

• Color: red, 625 nm, 24 lm
• Mode: steady or flashing 1.5 Hz / 3 Hz
• Supply: 12...30 V DC, 141 mA at 12 V, 71 mA at 24 V
• Housing: polycarbonate, Ø70 x 50 mm
• Environment: IP65, IP66, -40...+50 °C

The module twist-locks onto a TL70B series base. Unlike the TL70 series, the module has no settings of its own: it is driven by the base input that matches its position in the tower, and flashing is switched on with DIP switches in the base.

CE, UKCA and UL compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

SG-TL70B-G is a Banner TL70B series green 70 mm light module for a modular tower light. When off the segment looks gray, so ambient light does not make it appear lit.

• Color: green, 525 nm, 67 lm
• Mode: steady or flashing 1.5 Hz / 3 Hz
• Supply: 12...30 V DC, 141 mA at 12 V, 71 mA at 24 V
• Housing: polycarbonate, Ø70 x 50 mm
• Environment: IP65, IP66, -40...+50 °C

The module twist-locks onto a TL70B series base. Unlike the TL70 series, the module has no settings of its own: it is driven by the base input that matches its position in the tower, and flashing is switched on with DIP switches in the base.

CE, UKCA and UL compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

SG-TL70B-B is a Banner TL70B series blue 70 mm light module for a modular tower light. When off the segment looks gray, so ambient light does not make it appear lit.

• Color: blue, 475 nm, 25 lm
• Mode: steady or flashing 1.5 Hz / 3 Hz
• Supply: 12...30 V DC, 204 mA at 12 V, 102 mA at 24 V
• Housing: polycarbonate, Ø70 x 50 mm
• Environment: IP65, IP66, -40...+50 °C

The module twist-locks onto a TL70B series base. Unlike the TL70 series, the module has no settings of its own: it is driven by the base input that matches its position in the tower, and flashing is switched on with DIP switches in the base.

CE, UKCA and UL compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).

SG-TL70B-W is a Banner TL70B series white 70 mm light module for a modular tower light. When off the segment looks gray, so ambient light does not make it appear lit.

• Color: white, 5000 K, 107 lm
• Mode: steady or flashing 1.5 Hz / 3 Hz
• Supply: 12...30 V DC, 204 mA at 12 V, 102 mA at 24 V
• Housing: polycarbonate, Ø70 x 50 mm
• Environment: IP65, IP66, -40...+50 °C

The module twist-locks onto a TL70B series base. Unlike the TL70 series, the module has no settings of its own: it is driven by the base input that matches its position in the tower, and flashing is switched on with DIP switches in the base.

CE, UKCA and UL compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (15 G, 11 ms).
