Ultrasonic sensor S18UIAQ, 30...300 mm, 4-20mA, 10-30VDC, M18, M12 5-pin

S18UIAQ is a Banner U-GAGE S18U ultrasonic sensor in a straight M18 housing with a 4-20 mA output scaled across a taught window. Its 30 mm near limit lets it measure close to the sensor face, and temperature compensation is built in.

• Accuracy: linearity ±1 mm (2.5 ms) or ±0.5 mm (30 ms); resolution 1 mm or 0.5 mm; 50 x 50 mm aluminium target, 22 °C
• Measuring range: 30...300 mm, 300 kHz; minimum window 5 mm
• Output: analog 4-20 mA; response 2.5 ms or 30 ms, selected on the black wire
• Supply: 10...30 V DC, 40 mA typical at 25 V
• Housing: M18 straight, thermoplastic polyester
• Environment: IP67, NEMA 6P, -20...+60 °C
• Connection: integral M12 5-pin male

Window limits are taught with the push button or the remote wire.

Vibration per MIL-STD-202F method 201A, shock per IEC 60947-5-2 (30 g, 11 ms).
