Ultrasonic sensor U500.DA5.2-UAMJ.72F, 20...1500 mm, 0-10V, IO-Link, M12 5-pin

U500.DA5.2-UAMJ.72F is a Baumer U500 series ultrasonic distance sensor with a 20...1500 mm measuring range, a 0...10 V analog output and an IO-Link interface. It has two IO-Link channels (dual channel) and a multiplex version, so several sensors can run side by side without mutual interference.

• Accuracy: repeatability 0.5 mm; resolution < 0.3 mm; temperature drift < 2 % of object distance (> 50 mm); power-up drift compensated after 15 min
• Measuring range: 20...1500 mm, start and end point adjustable; response time < 70 ms; sonic frequency 200 kHz
• Outputs: analog 0...10 V / 10...0 V, up to 100 mA; IO-Link V1.1, COM 2 (38.4 kBaud), cycle time ≥ 12 ms, port type Class A, 48-bit process data (distance, 2 switching channels, quality, alarm, counter)
• Supply: 12...30 V DC, average consumption 35 mA; short-circuit and reverse-polarity protected
• Housing: rectangular, ASA/PMMA plastic, PEEK-coated sensor face, 18 x 45 x 32 mm
• Environment: IP67, operating temperature -25...+65 °C
• Connection: M12 connector, 5-pin

Suited to level measurement in tanks and distance measurement up to 1.5 m, where object colour, transparency or dust disturbs an optical measurement. The range is set by qTeach, Line-Teach or over IO-Link, which also configures filtering, the output characteristic, the sonic beam width and the function of pin 5.
