PIT46U is a Banner pair of individual plastic fibres for opposed mode, one for the emitter and one for the receiver. The tip has an M4 thread stepping down to M2.5.

• Range: DF-G1 820 mm, D10D 1200 mm, D10B 320 mm, D10A 300 mm
• Fibre: Ø1 mm, length 2 m, unterminated; supplied as a pair
• Tip: M2.5 and M4 threaded
• Material: acrylic (PMMA) core, black polyethylene jacket, nickel-plated brass tip
• Bend radius: at least 25 mm
• Temperature: -30...+70 °C

The control ends are unterminated and are cut to length with the PFC-4 cutter supplied with the fibre. The acrylic core is damaged by acids, strong alkalis and solvents; Banner recommends plastic fibres for visible-light sensors only.

K50LGRALSYPQP is a Banner K50L series sealed 50 mm dome indicator with three LED colors and a loud audible alarm. Each color and the audible have their own PNP input, so they can be switched independently from controller outputs.

• Colors: green, red, yellow; one color on at a time
• Audible: continuous tone 2.9 kHz, up to 94 dB at 1 m, adjustable volume
• Input: PNP, response time 1 ms (LED) and 10 ms (audible)
• Supply: 12...30 V DC, up to 35 mA per color at 30 V (65 mA at 12 V), audible 35 mA
• Housing: polycarbonate, M30x1.5 threaded base, 50 x 62 mm
• Environment: IP67, NEMA/UL 4X and 13, -20...+50 °C
• Connection: 150 mm PVC cable with 5-pin M12 male connector

Volume is set by rotating the front cover, so one model suits both a quiet room and a noisy machine. The supply circuit is protected against reverse polarity and transient voltages.

CE and UL compliant. Vibration per MIL-STD-202F (Method 201A), shock per IEC 60947-5-2 (30 G, 11 ms).

BWA-QM30-FMSS is a Banner magnetic bracket for attaching a QM30 vibration sensor to a flat steel surface without drilling. The sensor is screwed to the bracket and the NdFeB magnet holds the assembly on the machine.

• Fits: Banner QM30 vibration sensors, aluminium and stainless steel versions
• Surface: flat
• Material: 410 stainless steel body with NdFeB magnet insert
• Size: 30 x 30 mm
• Included: bracket and two sets of 304 stainless steel screws

QM30VT2 is a Banner 2-axis vibration and temperature sensor for condition monitoring of rotating machines. It works as a Modbus slave on RS-485 and delivers values pre-processed in the sensor, such as RMS velocity, peak acceleration and high-frequency RMS acceleration for the X and Z axes.

• Accuracy: vibration ±10 % at 25 °C; temperature ±3 °C
• Measuring range: vibration 0...46 mm/s RMS, 10 Hz...4 kHz; temperature -40...+105 °C, resolution 1 °C
• Output: RS-485, Modbus RTU, 9.6/19.2/38.4 kbaud
• Supply: 10...30 V DC, 9 mA at 30 V DC
• Housing: aluminium, 30 mm; mounting by M4 screw, epoxy, thermal tape or magnet
• Environment: IP67, -40...+105 °C
• Connection: 2.09 m cable with M12 5-pin male connector

Mount the X axis in line with the motor shaft and as close to the bearing as possible; a cover shroud or other flexible surface reduces accuracy. Configuration is done with the Banner software and the BWA-UCT-900 USB adapter cable.

Shock per MIL-STD-202G, method 213B (100 g). CE and UKCA declaration of conformity.

BRT-51X51BM is a Banner square acrylic retroreflector with micro-prism geometry, for photo sensors working in retroreflective mode. Two slots let it be screwed on, and optional brackets are available.

• Reflector size: 51 x 51 mm
• Overall size: 51 x 61 x 6.2 mm
• Reflectivity factor: 1.5
• Mounting: 2 slots, Ø4.6 mm
• Temperature: -20...+50 °C

RKSV4.4T-15/TXL is a TURCK shielded connection cable with a straight M12 female connector (4-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 15 m, PUR, black, Ø 5.3 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, stainless steel (V4A) coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

TX715-P3CV01 is a 15.6" touch display from the TURCK TX700 series with a built-in CODESYS V3 PLC, TARGET and WEB VISU visualisation. The PLC program and the screens are built in CODESYS V3 and loaded into the device over Ethernet.

• Display: 15.6" TFT, 1366 x 768 (HD), 16:9, 16M colours, 400 cd/m², capacitive glass front, dimmable to 0 %
• Communication: 3 x RJ45 Ethernet 10/100 Mbit, 1 x RS232/RS485/RS422, 2 x USB host (v2.0, max. 500 mA), SD card slot
• Expansion: 2 slots for up to 4 plug-in modules (I/O, CANopen, PROFIBUS DP, RS485, RS232, LTE/Wi-Fi)
• PLC: CODESYS V3.5.12.10, IEC 61131-3 (IL, LD, FBD, SFC, ST), 20000 kB program memory, 63 kB retain memory; ARM Cortex A9, Quad core 800 MHz, 2048 MB RAM, 8 GB Flash, battery-backed clock
• Supply: 24 VDC (10...32 VDC), max. 1.2 A
• Housing: metal, front 422 x 267 x 56 mm, cut-out 411 x 256 mm, mounting depth 56+8 mm
• Environment: IP66 front, IP20 rear, NEMA 12/4X; -20...+60 °C, 5...85 % RH non-condensing

Built into a cabinet door or control desk. Mounting brackets and the power connector come in the 15.6" TX700 mounting kit, available as an accessory; I/O and fieldbus modules plug into the expansion slots and are ordered separately.

7” Display - CODESYS V3 PLC with TARGET and WEB VISU

High-Quality Metal Housing with a Resistive Touch Screen

• • 7" TFT wide screen color display
  • LED backlight
  • 800 x 480 pixel resolution
  • 64 K colors
  • Resistive touch screen
  • 2 RJ45 Ethernet ports with integrated switch
  • 1 serial interface (RS232, RS485, RS422)
  • 2 USB host ports
  • 1 SD card slot

M18-4NAES-Q8 is the emitter of a Banner M18-4 series opposed-mode pair in an M18 stainless steel barrel, with a visible red beam and a 25 m range with an M18-4 receiver. Emitter power is set with a 250° potentiometer.

• Range: 25 m with an M18-4 receiver, effective beam 15.2 mm
• Supply: 10-30 V DC up to +55 °C, 10-24 V DC above; 17 mA
• Housing: M18 316L stainless steel barrel, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C
• Connection: integral M12 4-pin male connector

A green LED indicator shows power.

Vibration and shock per MIL-STD-202F, methods 201A and 213B. ECOLAB chemical compatibility certified.

M18-4VPRS-Q8 is the receiver of a Banner M18-4 series opposed-mode pair in an M18 stainless steel barrel, with a 25 m range with an M18-4 emitter. Sensitivity is set with a 250° potentiometer.

• Sensing range: 25 m with an M18-4 emitter, effective beam 15.2 mm
• Output: complementary PNP, one NO and one NC, 100 mA total (50 mA above +55 °C)
• Response: 1.5 ms ON, 1.0 ms OFF; repeatability 170 µs
• Supply: 10-30 V DC up to +55 °C, 10-24 V DC above; 8 mA
• Housing: M18 316L stainless steel barrel, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C
• Connection: integral M12 4-pin male connector

A green LED indicator shows power and flashes at a marginal signal; amber LED indicators show the output is conducting.

Vibration and shock per MIL-STD-202F, methods 201A and 213B. ECOLAB chemical compatibility certified.

• Relay is designed to control the level of conductive liquids in wells, tanks, pools, tankers, reservoirs,... (replacement HRH-1).
• Galvanically isolated supply and guard circuits.
• Within one device, the following confi gurations can be selected:
  - 2x one-level monitoring (in separate tanks)
  - 1x two-level monitoring (in one tank) - pumping from one tank to another.
• DIP switch selection on the front panel (8 functions).
• Adjustable probe sensitivity (for each probe separately).
• Adjustable relay switching delay (for each probe separately).
• 10 Hz watch frequency prevents polarization of the liquid and increases resistance to interference by network frequency

QS18VP6DVSQ8 is a Banner QS18 series diffuse photo sensor with a small visible red 630 nm light spot. It detects an object by the light the object reflects back to the sensor, and the visible spot shows exactly where it is aimed.

• Sensing range: 250 mm
• Output: complementary PNP, Light Operate and Dark Operate, 100 mA each
• Response: 850 µs ON/OFF; repeatability 90 µs
• Supply: 10-30 V DC, < 25 mA
• Housing: ABS, 18 mm threaded nose or side mounting, 3 mm hardware included
• Environment: IP67, -20...+70 °C
• Connection: integral M12 4-pin male connector

A green LED indicator shows power; the amber one shows light sensed and flashes at marginal excess gain. Sensitivity is set with a single-turn potentiometer.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

PKG4M-15/TXL is a TURCK connection cable with a straight M8 female connector (4-pin) on one end and open cores on the other. The PUR jacket is rated for moving installation, including drag chains.

• Connector: M8 x 1, female, straight, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 15 m, PUR, black, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 50 VAC / 60 VDC, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

RKC5701-5M is a TURCK shielded CAN bus cable (DeviceNet, CANopen) with a straight M12 female connector (5-pin, A-coded) on one end and open cores on the other. The cable carries a separate power pair and a data pair with 120 Ω impedance.

• Connector: M12 x 1, female, straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PUR, anthracite, Ø 6.7 mm, shielded; power pair AWG 22 (RD, BK), data pair AWG 24 (WH, BU)
• Electrical: 4 A, 60 V, impedance 120 Ω (1 MHz), capacitance 37 pF/m, loop resistance 82 Ω/km
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+80°C fixed, -25...+60°C mobile

The cable is rated for drag chains (at least 5 million bending cycles, up to 3 m/s, bending radius ≥10 x Ø). It is oil resistant per VDE 0472-803, flame retardant per VDE 0472-804/B, UV resistant and free from halogen and LABS.

Approval: UL.

• 8 Universal Analog Input Channels: Supports multiple sensor types, including thermocouples, Pt100, Pt1000, voltage signals (V, mV), and current (mA). With reading and recording rates of up to 1000 readings per second and 24-bit A/D conversion resolution, it guarantees precise and detailed monitoring.
 • 8 Configurable Digital I/Os and 2 Relay Outputs: The digital I/Os can be individually configured as inputs or outputs, and the relay outputs (NO, NC, common) allow local control of devices or alarms.
 • High-Performance Storage and Logging: The FieldLogger has memory to store up to 512k of data, with the possibility of expansion via an SD card, allowing the logging of up to 100 channels at configurable rates. Data can be downloaded through software or via a USB-host interface using a flash drive.

The N321R is a temperature controller dedicated to applications in refrigeration. The defrost cycle is accomplished by turning off the compressor at time intervals chosen by the user. Pt100 and thermistor sensors inputs available. Adjust for ON and OFF durations. Auto defrost at programmable intervals. Manual Defrost key in the front pannel.

3G/2G Multi Channel Data Logger

LogBox 3G is an IoT device with integrated data logger and 3G / 2G connectivity which allows remote telemetry or mobile monitoring solution. Data can be accessed remotely and centralized via NXperience software for Windows or via NOVUS Cloud IoT platform. Moreover, NOVUS may provide access to LogBox 3G for SCADA system or proprietary application through specific communication driver, upon request. Secure, real-time information accessed quickly and easily.

The device has two universal analog inputs that accept a wide range of sensors. It also has internal sensors for measuring temperature, battery voltage and external sources. In addition, LogBox 3G has SMS commands and alarm alerts.

3G/2G Multi Channel Data Logger

LogBox 3G is an IoT device with integrated data logger and 3G / 2G connectivity which allows remote telemetry or mobile monitoring solution. Data can be accessed remotely and centralized via NXperience software for Windows or via NOVUS Cloud IoT platform. Moreover, NOVUS may provide access to LogBox 3G for SCADA system or proprietary application through specific communication driver, upon request. Secure, real-time information accessed quickly and easily.

The device has two universal analog inputs that accept a wide range of sensors. It also has internal sensors for measuring temperature, battery voltage and external sources. In addition, LogBox 3G has SMS commands and alarm alerts.

BK14-0 is a TURCK field-wireable M16 x 0.75 female connector, straight, 14-pin, for 6...8 mm cable.

• Connector: M16 x 0.75, female, straight, 14-pin, gold-plated bronze (CuSn) contacts, more than 500 mating cycles
• Ratings: 3 A, 60 V
• Connection: conductors up to 0.25 mm², cable diameter 6...8 mm, PG9 screw-in thread
• Housing: black PA body, PBT (UL 94 V0) contact carrier, nickel-plated die-cast zinc (GD-Zn) coupling nut
• Environment: -40...+95°C fixed

RKS8T-5/TXL is a TURCK shielded connection cable with a straight M12 female connector (8-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 8-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PUR, black, Ø 6.3 mm, 8 x 0.25 mm², core colours BN, WH, BU, BK, GY, PK, VT, OG
• Shield: aluminium foil and tinned copper wire
• Ratings: 2 A, 30 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

Q76E-VP-ZLVC-Q8 is a Banner Q76 series wide-beam retroreflective photo sensor with a visible red 620 nm light band and a 0.4-4 m range. The wide band detects the leading edge of irregular objects and pallets that a single-spot beam could miss.

• Sensing range: 0.4-4 m with a 100 x 100 mm BRT-92X92CB reflector; 3 m with a 40 x 60 mm reflector
• Smallest object: 19 mm standard, 12 mm increased, 8 mm fine-adjusted sensitivity
• Output: complementary PNP, Light Operate and Dark Operate; response 2 ms, 250 Hz
• Supply: 10-30 V DC
• Housing: PC-PBT, PMMA lens cover
• Environment: IP67, IP69, -40...+60 °C, ECOLAB certified
• Connection: integral M12 4-pin male connector

Standard sensitivity switches when 28 % of the band is covered and suits opaque objects; increased sensitivity switches at 18 % for containers with openings, film and transparent objects. Sensitivity and Light/Dark Operate are set with the single teach button. The reflector must be at least 50 mm wide and 30 mm tall.

WKC4.4T-P7X2-25/TEL is a TURCK connection cable with an angled M12 female connector (4-pin) on one end and open cores on the other. The connector has two built-in LED indicators: green shows the supply, yellow the PNP signal on pin 4.

• Connector: M12 x 1, female, angled, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 25 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 30 V DC, more than 100 mating cycles
• Housing: translucent TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The PVC jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

VT2-FKM4.4-FSM4.4-FSM4.4 is a TURCK T-splitter without cable with two M12 male connectors (4-pin) and one M12 female connector (4-pin), all A-coded.

• Connectors: 2 x M12 male, 4-pin / M12 female, 4-pin, straight, A-coded, gold-plated brass (CuZn) contacts, more than 100 mating cycles
• Ratings: 4 A, 48 V, contact resistance ≤5 mΩ, insulation resistance ≥10⁸ Ω
• Housing: black TPU, nickel-plated brass coupling nuts
• Environment: IP65, IP67, IP68 (only when screwed in); -30...+90°C

RoHS compliant.

PSG4M-0.2-PSG4M/TXN is a TURCK bridge cable with a straight M8 male connector (4-pin) on each end, used to link TBEN-S modules to each other.

• Connectors: M8 male, straight / M8 male, straight; 4-pin, gold-plated brass (CuZn) contacts
• Cable: 0.2 m, PUR, green, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 30 V, more than 100 mating cycles
• Housing: black TPU, nickel-plated brass coupling nuts; M8 tightening torque 0.5...0.6 Nm
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The PUR jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant and free from halogen, silicone, PVC and LABS. CE, UKCA and RoHS compliant.
