PKG3M-15/TXL is a TURCK connection cable with a straight M8 female connector (3-pin) on one end and open cores on the other. The PUR jacket is rated for moving installation, including drag chains.

• Connector: M8 x 1, female, straight, 3-pin, gold-plated brass (CuZn) contacts
• Cable: 15 m, PUR, black, Ø 4.1 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 50 VAC / 60 VDC, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

PKG3M-20/TEL is a TURCK connection cable with a straight M8 female connector (3-pin) on one end and open cores on the other.

• Connector: M8 x 1, female, straight, 3-pin, gold-plated brass (CuZn) contacts
• Cable: 20 m, PVC, black, Ø 4.3 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 50 VAC / 60 VDC, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

BS 4151-0/16 is a TURCK field-wireable 7/8" male connector, straight, 5-pin, for 12...14 mm cable with screw-clamp terminals.

• Connector: 7/8", male, straight, 5-pin, gold-plated brass (CuZn) contacts, more than 50 mating cycles
• Ratings: 9 A, 600 V
• Connection: screw-clamp terminals, conductors 16 AWG, cable diameter 12...14 mm
• Housing: black PBT body, nylon or TPU contact carrier, nickel-plated metal coupling nut
• Environment: IP67; -25...+85°C fixed

Approval: UL.

RKC4.4T-1-RSC4.4T/TEL is a TURCK extension cable with a straight M12 female connector on one end and a straight M12 male connector on the other (4-pin). The cable has a black PVC jacket.

• Connectors: M12 x 1 female and M12 x 1 male, both straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 1 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

PKG3M-5-RSC4T/TEL is a TURCK adapter cable from a straight M8 female connector to a straight M12 male connector (A-coded), 3-pin, with a black PVC jacket. It connects an M8 sensor to an M12 port.

• Connectors: M8 x 1 female, straight, and M12 x 1 male, straight, A-coded, 3-pin each, gold-plated brass (CuZn) contacts, more than 100 mating cycles
• Cable: 5 m, PVC, black, Ø 4.3 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 50 V AC/60 V DC
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

S18-2VNDS-Q8 is a Banner S18-2 series diffuse photo sensor in an 18 mm plastic barrel. It detects objects by the visible red light they reflect back, up to 300 mm from the sensor.

• Sensing range: 300 mm on a 90 % white test card
• Output: complementary NPN, Light Operate (black) and Dark Operate (white), 100 mA total
• Response: 1.5 ms ON, 0.75 ms OFF; repeatability 100 µs
• Supply: 10-30 V DC (10-24 V DC above +55 °C), 16 mA
• Housing: ABS, PMMA window, M18x1 threaded barrel, PBT nuts included
• Environment: IP67, -40...+70 °C
• Connection: integral M12 4-pin male connector

The range applies to a white card; darker objects are detected at a shorter distance. Sensitivity is set with a single-turn potentiometer. A green LED shows power and flashes at a marginal signal; the amber LED shows that the black-wire (Light Operate) output is on.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B (75 g operating).

EIL580P-SC10.7BF.01024.B is a Baumer optoPulse programmable incremental encoder with optical sensing. Pulse count from 1 to 65536, TTL or HTL output level, zero pulse width and position and signal sequence are set on site, so one encoder replaces several fixed-resolution models.

• Resolution: 1...65536 pulses per revolution, factory setting 1024
• Output: TTL/RS422 (factory setting) or HTL/push-pull, 6 channels, up to 300 kHz (TTL)
• Supply: 4.75-30 V DC, no-load consumption ≤70 mA
• Housing: Ø58 mm, clamping flange, Ø10 x 20 mm shaft with flat
• Environment: IP67 (with shaft seal), -40...+100 °C, up to 6000 rpm
• Connection: M12 8-pin radial connector

Parameters are set with the Baumer Z-PA-EI-H or Z-PA-EI-P programming tool and an M12/D-SUB connection cable. Unprogrammed, the encoder runs at 1024 pulses with a 5 V TTL output.

UL 508 / CSA 22.2 approved. EMC to EN 61000-6-2 and EN 61000-6-3; vibration (30 g, 10-2000 Hz) and shock (300 g, 6 ms) resistance to EN 60068-2-6 and EN 60068-2-27.

PKG3M-40/TXL is a TURCK connection cable with a straight M8 female connector (3-pin) on one end and open cores on the other. The PUR jacket is rated for moving installation, including drag chains.

• Connector: M8 x 1, female, straight, 3-pin, gold-plated brass (CuZn) contacts
• Cable: 40 m, PUR, black, Ø 4.1 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 50 VAC / 60 VDC, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

T30UDPAQ is a Banner T30U series ultrasonic proximity sensor with two PNP outputs, each with its own taught switching window. The outputs can be taught together or separately and set as identical, independent, overlapping or complementary windows.

• Accuracy: repeatability ±0.25 % of distance; hysteresis 2.5 mm; minimum window 10 mm
• Sensing range: 150 mm...1 m, 228 kHz
• Outputs: 2x PNP, 100 mA total; response 48 ms
• Supply: 12...24 V DC, 90 mA
• Housing: M30 thread, reinforced thermoplastic polyester (PBT)
• Environment: IP67, -20...+70 °C
• Connection: integral M12 5-pin male

Window limits are taught with the push buttons on the sensor or through the remote teach wire, with no potentiometers to adjust. Objects closer than 150 mm can cause a false response.

Vibration per MIL-STD-202F method 201A, shock per IEC 60947-5-2 (30 g, 11 ms). CE and UKCA.

T30R-1515-CKIQP is a Banner T30R series 122 GHz FMCW radar sensor in an M30 housing with a 15 x 15° beam. It outputs the measured distance as 4-20 mA and has one configurable PNP/NPN discrete output that also carries IO-Link.

• Accuracy: linearity < ±4 mm (RCS 1 m² reference target); repeatability < 1 mm; temperature effect < ±10 mm
• Range: detection 0.1...6 m, measurement 0.1...6 m
• Outputs: analog 4-20 mA (white wire); discrete PNP/NPN or IO-Link push/pull (black wire), 50 mA; analog update 2 ms, discrete response 6 ms
• Supply: 10...30 V DC, < 100 mA at 24 V
• Housing: PBT, M30 x 1.5 thread, COP window
• Environment: IP67, -40...+65 °C
• Connection: 150 mm PUR cable with M12 5-pin male connector

The C version sweeps a wider bandwidth than the standard T30R-1515, giving a smaller dead zone and the same linearity across the whole 0.1...6 m range, for measurement close to the sensor. Settings are made over IO-Link, with Banner Measurement Sensor Configuration Software or with the remote input wire.

Radio approval for this model: US, Canada and Korea only - it is not listed as approved for Europe. Vibration per MIL-STD-202F method 201A, shock per method 213B (75 g operating).

ESG 34FH0500G is a Baumer shielded M12 female cordset, 8-pin, straight, with the cable shield connected to the coupling nut.

• Connector: M12 female, straight, 8-pin, shield on coupling nut
• Cable: PUR, Ø approx. 5.9 mm, shielded, halogen-free, 5 m, suitable for drag chains
• Wire colours, pins 1-8: WH, BN, GN, YE, GY, PK, BU, RD
• Temperature: -25...+80 °C moving, -40...+80 °C fixed

UL listed, file number E315836.

Humidity, temperature transmitter. T+RH probe from hard anodized duralumin for compressed air up to 25 bars on the cable. Outdoor, indoor use.

Relative humidity, temperature sensors at probe on the cable. Measured values are also converted to other humidity interpretation: dew point temperature, absolute humidity, specific humidity, mixing ratio, specific enthalpy.

The device is supplied with T+RH probe with 1 meter cable.

3MP HD Resolution People/Vehicle/Animal Detection Spotlight Night Vision

EIL580-S1B1.7FE.01024.A is a Baumer optoPulse incremental encoder with optical sensing, 1024 pulses per revolution and a EURO flange B10. The flange, with a Ø85 mm centring collar and six Ø6.6 mm holes on a Ø100 mm pitch circle, matches EURO B10 motor and gearbox mounting.

• Resolution: 1024 pulses per revolution, zero pulse
• Output: TTL/RS422, 6 channels (A+, B+, R+, A-, B-, R-), up to 300 kHz
• Supply: 5 V DC ±5 %, no-load consumption ≤70 mA
• Housing: EURO flange B10 (Ø115 mm), Ø11 x 30 mm shaft with Woodruff key
• Environment: IP67 (with shaft seal), -40...+85 °C, up to 6000 rpm
• Connection: M23 12-pin radial connector

The encoder needs a regulated 5 V supply and cannot be connected directly to a 24 V circuit. The shaft needs a flexible coupling, as permitted load is 40 N axial and 80 N radial.

UL 508 / CSA 22.2 approved. EMC to EN 61000-6-2 and EN 61000-6-3; vibration (30 g, 10-2000 Hz) and shock (300 g, 6 ms) resistance to EN 60068-2-6 and EN 60068-2-27.

Weight 80 g excluding batteries / 120 g including batteries Dimensions 86 x 86 x 27 mm Enclosure Plastic, PC/ABS Operating conditions Temperature 0 to 50 °C Humidity 0 to 85% RH (non-condensing) Device Power Supply Battery Type 2 x 3.6V AA Lithium Batteries Expected Battery Life <10 years (Depending on configurations and environment) Device Logging Function Sampling Interval Configurable via NFC and downlink configuration Temperature Resolution: 0.1 °C Accuracy: ±0.2 °C Humidity Resolution: 0.1 % RH Accuracy at 25 °C: ± 2 % RH CO2 • Range, calibrated: 0 – 2000 ppm • Range, extended: 0 – 10000ppm • Accuracy, calibrated: ± 50 ppm / ± 3% of reading • Accuracy, extended: ± 10% of reading

E2630-LEL-C3H8-230-A Gāzes detektors E2630-LEL-230VAC, 2 x parslēdzošie releji 250VAC/30VDC 6A, skaņas signāls 85dB un LED indikācija, IP65, sensora pašdiagnostika ieslēdzoties un atsevišķi aktivizējot slēdzi, reakcijas laiks 1 sekunde, vides temperatūra -40/+70C

RKC4.4T-20/TXL is a TURCK connection cable with a straight M12 female connector (4-pin) on one end and open cores on the other. The PUR jacket is rated for moving installation, including drag chains.

• Connector: M12 x 1, female, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 20 m, PUR, black, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

RKC4.4T-25/TXL is a TURCK connection cable with a straight M12 female connector (4-pin) on one end and open cores on the other. The PUR jacket is rated for moving installation, including drag chains.

• Connector: M12 x 1, female, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 25 m, PUR, black, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

WSC4.4T-5/TXL is a TURCK connection cable with an angled M12 male connector (4-pin) on one end and open cores on the other.

• Connector: M12 x 1, male, angled, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PUR, black, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The PUR jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

QS186EQ5 is the emitter of a Banner QS18 series opposed-mode photo sensor pair. It sends an infrared 940 nm beam to a separate QS18 receiver up to 20 m away; an object is detected when it breaks the beam.

• Sensing range: 20 m with a QS18 receiver, effective beam 13 mm
• Output: none (emitter)
• Supply: 10-30 V DC, < 25 mA
• Housing: ABS, 18 mm threaded nose or side mounting, 3 mm hardware included
• Environment: IP67, -20...+70 °C
• Connection: 150 mm PVC cable with M12 4-pin male connector

The emitter has no output and works only with a QS18VP6R or QS18VN6R receiver, ordered separately. A green LED indicator shows power.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

QS18VN6RQ5 is the receiver of a Banner QS18 series opposed-mode photo sensor pair. It switches when an object breaks the beam from a separate QS186E emitter up to 20 m away.

• Sensing range: 20 m with a QS186E emitter, effective beam 13 mm
• Output: complementary NPN, Light Operate and Dark Operate, 100 mA each
• Response: 750 µs ON, 375 µs OFF; repeatability 100 µs
• Supply: 10-30 V DC, < 25 mA
• Housing: ABS, 18 mm threaded nose or side mounting, 3 mm hardware included
• Environment: IP67, -20...+70 °C
• Connection: 150 mm PVC cable with M12 4-pin male connector

Works with a QS186E emitter, ordered separately. A green LED indicator shows power; the amber one shows light sensed and flashes at marginal excess gain.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

T30R-4545-KIQ is a Banner T30R series 122 GHz FMCW radar sensor in an M30 housing with a 45 x 45° beam. It outputs the measured distance as 4-20 mA and has one configurable PNP/NPN discrete output that also carries IO-Link.

• Accuracy: linearity < ±20 mm below 500 mm, < ±4 mm above 500 mm (RCS 1 m² reference target); repeatability < 1 mm; temperature effect < ±10 mm
• Range: detection 0.3...10 m
• Outputs: analog 4-20 mA (white wire); discrete PNP/NPN or IO-Link push/pull (black wire), 50 mA; analog update 2 ms, discrete response 6 ms
• Supply: 10...30 V DC, < 100 mA at 24 V
• Housing: PBT, M30 x 1.5 thread, COP window
• Environment: IP67, -40...+65 °C
• Connection: integral M12 5-pin male

The flat lens gives a much wider 45 x 45° beam than the T30R-1515. Detection is unaffected by wind, fog, steam and temperature changes and resists rain and snow. Settings are made over IO-Link, with Banner Measurement Sensor Configuration Software or with the remote input wire.

Radio approval: US, Canada, Europe, UK, Australia, New Zealand, India, Singapore, Malaysia, Korea; ETSI EN 305 550-1 and -2. Vibration per MIL-STD-202F method 201A, shock per method 213B (75 g operating).

RSS4.4T-2/TXL is a TURCK shielded connection cable with a straight M12 male connector (4-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, male, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 2 m, PUR, black, Ø 5.3 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.
