BK7-0 is a TURCK field-wireable M16 x 0.75 female connector, straight, 7-pin, for 6...8 mm cable.

• Connector: M16 x 0.75, female, straight, 7-pin, silver-plated bronze (CuSn) contacts, more than 500 mating cycles
• Ratings: 5 A, 60 V
• Connection: conductors up to 0.75 mm², cable diameter 6...8 mm, PG9 screw-in thread
• Housing: black PA body, PBT (UL 94 V0) contact carrier, nickel-plated die-cast zinc (GD-Zn) coupling nut
• Environment: -40...+95°C fixed

HT-WWAK4-2/S2430 is a TURCK high-temperature connection cable with an angled M12 female connector (4-pin) on one end and open cores on the other.

• Connector: M12 x 1, female, angled, 4-pin, gold-plated brass (CuZn) contacts, more than 100 mating cycles
• Cable: 2 m, PTFE, white, Ø 3.8 mm, 4 x 0.34 mm², PTFE core insulation, core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V
• Housing: black glass-fibre reinforced PBT, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP65 (only when screwed in); -20...+150°C fixed

The PTFE cable itself is rated for -190...+260°C. The jacket stays flexible in cold and heat, resists welding sparks, chemicals, UV radiation, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and LABS free. RoHS compliant.

VC-AC21-11.024-K is a TURCK field-wireable design A valve connector, 2+PE, with screw-clamp terminals for 6...8 mm cable, a yellow switching-state LED and varistor protective circuitry.

• Connector: valve connector design A, 2+PE, metal contacts, more than 50 plug cycles
• Ratings: 10 A, 24 V
• Connection: screw-clamp terminals, conductors up to 1 mm² (3 x 1 mm²), cable diameter 6...8 mm, M20 x 1.5 screw-in thread, M3 x 33.5 central screw
• Housing: transparent PA6-I body, black PA6 GF30 contact carrier, NBR seal
• Environment: IP65 (mounted); -25...+80°C fixed

Supplied with the central screw, pressure screw, seal, sealing ring and pressure ring.

VB2-FSM5-2FKM5 is a TURCK Y-splitter without cable with one M12 male connector (5-pin) and two M12 female connectors (5-pin). The two female connectors are wired in parallel.

• Connectors: M12 male, 5-pin / 2 x M12 female, 5-pin, straight, gold-plated brass (CuZn) contacts, more than 100 mating cycles
• Ratings: 4 A, 60 V, contact resistance ≤5 mΩ, insulation resistance ≥10⁸ Ω
• Housing: black TPU, nickel-plated brass coupling nuts
• Environment: IP67 (only when screwed in); -30...+90°C

RoHS compliant.

PT250R-2004-U1-H1141 is a TURCK PT-2000 series relative pressure transmitter with a fully welded metal measuring cell and a 0...10 V voltage output in 3-wire technology. It has no display: the measured value goes straight to the analogue input of a PLC or controller.

• Accuracy: ±0.3 % FS typical, max. 0.5 % FS (linearity, hysteresis, repeatability); temperature coefficient ±0.2 % FS/10 K; long-term stability 0.25 % FS per IEC EN 60770-1; reference conditions 15...25°C, 24 VDC
• Measuring range: 0...250 bar relative (0...25 MPa); overpressure ≤ 750 bar, burst pressure ≥ 1500 bar; resolution ±0.1 % FS
• Output: analogue 0...10 V, 3-wire, load ≤ 100 nF / > 10 kΩ; response time < 2 ms, typ. 1 ms
• Supply: 12...33 VDC, consumption ≤ 7 mA; protected against short circuit, wire break and reverse polarity
• Housing: stainless steel 1.4404 (AISI 316L) and polyarylamide 50 % GF (UL 94 V-0), stainless steel 1.4435 (AISI 316L) cell; G 1/4" male thread, back sealing per DIN EN ISO 1179-2 with FPM profile seal; wrench size 24, nut torque max. 20 Nm
• Environment: IP67, ambient -30...+85°C, medium -40...+135°C
• Connection: M12 x 1 connector

One FKM profile seal is included in the delivery.

Approval: cULus (UL E302799). Shock 100 g (11 ms) per IEC 68-2-27, vibration 20 g (15...2000 Hz) per IEC 68-2-6. MTTF 1238 years per SN 29500 (40°C).

• For effective, permanent control of water and process quality
• Compact, high-quality sensor design prevents failures and unplanned downtime
• Simplify your installation and commissioning processes

Humidity-Sensor for operating temperatures -80...200°C transmitter box from aluminium-die casting no display sensor tube high-grade steel 1.4301/special plastics, Ø 15mm length: aprox. 243 mm duct mounting Output 1: relative humidity Output range 1: 0...100 % rh Output signal 1: 4...20 mA Output 2: not Supply voltage: 10...30 VDC outputs digital adjustable with push-buttons operation temperature range transmitter: -40...85°C operation temperature range sensor tube: -80...200°C please note the assembly instructions! Filter: : sintered filter made of high-grade steel, ZE13

PKW4M-P7X2-10/TEL is a TURCK connection cable with an angled M8 female connector (4-pin) on one end and open cores on the other. A two-colour LED is built into the connector.

• Connector: M8 x 1, female, angled, 4-pin, gold-plated brass (CuZn) contacts
• Indication: two-colour LED (PNP) – green shows supply, yellow shows switching state
• Cable: 10 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 30 VDC, more than 100 mating cycles
• Housing: translucent TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

RKC4.5T-20/TXL is a TURCK connection cable with a straight M12 female connector (5-pin) on one end and open cores on the other. The PUR jacket is rated for moving installation, including drag chains.

• Connector: M12 x 1, female, straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 20 m, PUR, black, Ø 4.8 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

WL50SWSSL5Q is a Banner WL50S series LED spotlight with a 316 stainless steel housing and a ±5° lens, giving the smallest, most focused spot in the series. The light comes from three high-intensity white LEDs.

• Light: white 5000...8300 K, 295 lm; 13,780 lx at 0.5 m and 3,445 lx at 1 m
• Supply: 12...30 V DC, up to 400 mA
• Housing: 316 stainless steel, polycarbonate window with Viton seal, M30x1.5 base with stainless steel nut, Ø56 mm
• Environment: IP67, IP69K, -20...+50 °C
• Connection: integral 5-pin M12 male connector, only 2 wires used
• Useful life: light output drops by less than 30% after 50,000 hours

The narrow beam lights a specific work area on a machine, and the housing is chemically resistant and built for washdown machinery. The base gasket is FDA-grade silicone. The cable must not be hit with a high-pressure spray.

Vibration per MIL-STD-202F (Method 201A), shock per IEC 60947-5-2 (30 G, 11 ms).

T18-2VPDLIR-Q8 is a Banner T18-2 series diffuse photo sensor with an infrared 850 nm beam, in a right-angle 18 mm housing for washdown areas. It detects objects by the light they reflect back, up to 750 mm from the sensor.

• Sensing range: 750 mm, adjustable
• Output: complementary PNP, Light Operate (black wire) and Dark Operate (white wire), 100 mA total (50 mA above +55 °C)
• Response: 1.5 ms ON, 0.75 ms OFF; repeatability 100 µs
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, M18x1 thread, PBT polyester, PMMA window, epoxy-encapsulated electronics
• Environment: IP67, IP68, IP69K, -40...+70 °C
• Connection: integral M12 4-pin male connector

Sensitivity is set with a single-turn potentiometer. A green LED shows power and flashes at a marginal signal; the amber LED shows that the black-wire output is on.

ECOLAB certified chemical compatibility. Vibration tested to MIL-STD-202G, method 201A; shock to method 213B (75 g operating).

RKS4.5T-30/TXL is a TURCK shielded connection cable with a straight M12 female connector (5-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 30 m, PUR, black, Ø 5.7 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

Measurement range: -55°C to +125°C; Accuracy up to 0.5°C in the -10°C to +85°C range and up to 2°C in the -55°C to -125°C range; default probe length: 1m- different probe lengh on request; different probe tip- on request; default IP30 protection; IP67 on request

Measurement range: - 200 °C to +200 °C; Accuracy: up to 0.5 °C in the +200 °C and 1,3°C in the -200°C; default probe length: 1m- different probe lengh on request; IP30 protection; IP67 on request

Temperature: -55 to +125°C, accuracy: up to 0.5°C in the range from -10°C to +85°C and up to 2°C in the range -55 to -125°C. 1 m long external probe. Battery ensures up to 5 years. Measurement period: 1 minute – 10 days (configurable by the user) User configurable alarm thresholds. The device stores 40,000 measurements in its memory, when the memory is full, the oldest measurements are overwritten Sensor's configuration can be changed remotely from the cloud or with a mobile application over Bluetooth Low Energy.

Temperature: -55 to +125°C, accuracy: up to 0.5°C in the range from -10°C to +85°C and up to 2°C in the range -55 to -125°C. 1 m long external probe. Battery ensures up to 5 years. Measurement period: 1 minute – 10 days (configurable by the user) User configurable alarm thresholds. The device stores 40,000 measurements in its memory, when the memory is full, the oldest measurements are overwritten Sensor's configuration can be changed remotely from the cloud or with a mobile application over Bluetooth Low Energy.

Temperature: -55 to +125°C, accuracy: up to 0.5°C in the range from -10°C to +85°C and up to 2°C in the range -55 to -125°C. 1 m long external probe. Battery ensures up to 5 years. Measurement period: 1 minute – 10 days (configurable by the user) User configurable alarm thresholds. The device stores 40,000 measurements in its memory, when the memory is full, the oldest measurements are overwritten Sensor's configuration can be changed remotely from the cloud or with a mobile application over Bluetooth Low Energy.

Temperature: -55 to +125°C, accuracy: up to 0.5°C in the range from -10°C to +85°C and up to 2°C in the range -55 to -125°C. 1 m long external probe. Battery ensures up to 5 years. Measurement period: 1 minute – 10 days (configurable by the user) User configurable alarm thresholds. The device stores 40,000 measurements in its memory, when the memory is full, the oldest measurements are overwritten Sensor's configuration can be changed remotely from the cloud or with a mobile application over Bluetooth Low Energy.

Temperature: -55 to +125°C, accuracy: up to 0.5°C in the range from -10°C to +85°C and up to 2°C in the range -55 to -125°C. 1 m long external probe. Battery ensures up to 5 years. Measurement period: 1 minute – 10 days (configurable by the user) User configurable alarm thresholds. The device stores 40,000 measurements in its memory, when the memory is full, the oldest measurements are overwritten Sensor's configuration can be changed remotely from the cloud or with a mobile application over Bluetooth Low Energy.

- IP30 protection

Temperature: -55 to +125°C, accuracy: up to 0.5°C in the range from -10°C to +85°C and up to 2°C in the range -55 to -125°C. 1 m long external probe. Battery ensures up to 5 years. Measurement period: 1 minute – 10 days (configurable by the user) User configurable alarm thresholds. The device stores 40,000 measurements in its memory, when the memory is full, the oldest measurements are overwritten Sensor's configuration can be changed remotely from the cloud or with a mobile application over Bluetooth Low Energy.

Temperature: -55 to +125°C, accuracy: up to 0.5°C in the range from -10°C to +85°C and up to 2°C in the range -55 to -125°C. 1 m long external probe. Battery ensures up to 5 years. Measurement period: 1 minute – 10 days (configurable by the user), storeable 40,000 measurements.

- Equipped with an external Watermark soil moisture probe 3 m long and a temperature probe – 3 m (to correct the results depending on the soil temperature). - Measurement range: 0 - 200 Centibar (kPa) - Accuracy: up to 0.5°C in the range from -10°C to +85°C - Default IP67 protection (old no: 5906660327783)

- Min duration pulse: 5 millisecond - Max duration pulse: 500 millisecond - Supported counters: NO (Pull-up 3.6V) - default 3 active channles, (more/less chanles on request) - default IP30 protection-

TX-RS485 is a plug-in module for TURCK TX700 HMI/PLC devices that adds a galvanically isolated RS485/RS422 interface on a 9-pin SUB-D female connector.

• Interface: RS485/RS422, 9.6...115.2 kbps, galvanically isolated
• Connector: 1 x 9-pin SUB-D, female
• Supply: from the HMI
• Housing: metal, 41.2 x 90.3 x 23.8 mm
• Environment: IP20, -20...+60 °C, 5...85 % RH non-condensing

Fits the expansion slots of TX700 HMI/PLC devices and the TX700S gateway; powered from the HMI, no separate supply. The module has a plug-in extension port.

Approvals: CE.

Measurement range: -55°C to +125°C; Accuracy up to 0.5°C in the -10°C to +85°C range and up to 2°C in the -55°C to -125°C range; default probe length: 2x 1m- different probe lengh on request; IP30 protection; IP67 on request

ABR72L16-RDE2 is a Banner ABR 7000 imager-based barcode reader for 1D and 2D codes, including direct part marked (DPM) codes. It has a 2 MP global-shutter sensor, a 16 mm liquid-lens autofocus and red diffused lighting in two software-configurable sectors.

• Imager: 1600 x 1200 px CMOS, global shutter, 45 fps; 16 mm liquid lens autofocus
• Lighting: red diffused DPM, central/peripheral sectors; working distance 40...450 mm
• Inputs and outputs: 2 opto-isolated inputs; 3 outputs NPN/PNP/push-pull, 100 mA
• Communication: RS232 or RS422 main + RS232 auxiliary; Ethernet 10/100 with TCP/IP, EtherNet/IP, Modbus TCP, SLMP, PROFINET-compatible
• Configuration: Barcode Manager software, Smart Teach button, embedded web server
• Supply: 10-30VDC, 0.7 A at 10 VDC to 0.2 A at 30 VDC
• Housing and environment: aluminium, 238 g, IP67 with sealed cables, 0...+45 °C; M12 17-pin male + M12 D-coded 4-pin female

Factory focus is 240 mm with a horizontal field of view of 112 mm; other distances are set with the autofocus. Power and I/O need a 17-pin M12 cordset, and the Ethernet port a D-coded M12 cable. Two class 2 laser pointers aim the reader, and green/red spots and a beeper show good read and no read.

Vibration per EN 60068-2-6, shock per EN 60068-2-27, bump per EN 60068-2-29. Laser class 2 per IEC 60825-1.

This soft-sided case is ideal for carrying your Multiparameter Sonde and accessories. It includes space for: Aqua TROLL 700 or Aqua TROLL 800 Multiparameter Sonde Aqua TROLL Sensors Rugged Android Tablet Wireless TROLL Com Accessories Two 1L bottles of calibration solution in outside mesh holders.

RKS4.5T-20/TEL is a TURCK shielded connection cable with a straight M12 female connector (5-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 20 m, PVC, black, Ø 6.1 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, 0...+80°C mobile

The PVC jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS.

Approval: cULus.

 Sn = 3 mm, M8×1 metal thread (nickel-plated brass), flush, extended barrel, with connector M8 (4-pin), 10–30V DC, PNP NO/NC (changeover), with increased switching distance

PKW4M-10/TEL is a TURCK connection cable with an angled M8 female connector (4-pin) on one end and open cores on the other.

• Connector: M8 x 1, female, angled, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 10 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 50 VAC / 60 VDC, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

RSC4.4T-1/TXL is a TURCK connection cable with a straight M12 male connector (A-coded, 4-pin) on one end and open cores on the other.

• Connector: M12 x 1, male, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 1 m, PUR, black, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, test voltage 2000 V, more than 100 mating cycles
• Housing: black TPU, nickel-plated brass coupling nut
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The PUR jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.
