Level sensor LMP 331 0-10m H2O Art: 430-1001-1-1-1-1-100-3-000

CO2: 400 ppm – 5000 ppm, accuracy ±(40 ppm + 5 % of reading)
Temperature / humidity / air pressure range: -15°C to 70°C, 0 to 100% RH, 300 to 1100 hPa
IP30 protection

Min duration pulse: 5 millisecond. Max duration pulse: 500 millisecond. Supported counters: NO (Pull-up 3.6V). Default 3 active channles, (more/less chanles on request). IP30 protection.

- Connectivity for 5 years - 60 Mb/5 years

Weight 80 g excluding batteries / 120 g including batteries Dimensions 86 x 86 x 27 mm Enclosure Plastic, PC/ABS Operating conditions Temperature 0 to 50 °C Humidity 0 to 85% RH (non-condensing) Device Power Supply Battery Type 2 x 3.6V AA Lithium Batteries Expected Battery Life <10 years (Depending on configurations and environment) Device Logging Function Sampling Interval Configurable via NFC and downlink configuration Temperature Resolution: 0.1 °C Accuracy: ±0.2 °C Humidity Resolution: 0.1 % RH Accuracy at 25 °C: ± 2 % RH CO2 • Range, calibrated: 0 – 2000 ppm • Range, extended: 0 – 10000ppm • Accuracy, calibrated: ± 50 ppm / ± 3% of reading • Accuracy, extended: ± 10% of reading

Compatible with LoRaWAN® specification 1.0.3 • Analog 0 – 10 V input • Digital input • Pulse counter • Direct connection to various external sensors and equipment • Easy installation • Easy configuration • IP67 Classified • Battery-powered • Long-range communication • Configurable over NFC • Configurable over the air • Ten years of battery life* • Supported channel plans: US902-928, EU863-870, AS923, AU915- 928, KR920-923, RU864, IN865 & HK923 • CE Approved and RoHS compliant

With Switching Outputs; Operating voltage 12…30 VDC; Max. range 2500 mm; Aluminum housing; IP65; Connection: 1 × M8 male connector, 4-pin; 1 × M8 female connector, 4-pin; Field of view: 60 × 45° (3104 × 2374 mm at max. range); Resolution: 272 × 208 pixels; Operating voltage: 12…30 VDC; Output 1: PNP/NPN switching output, Pulse Pro, switchable; Output 2: PNP/NPN switching output, Pulse Pro, switchable; Ethernet interface (M8 × 1 female connector, 4-pin); Supports Modbus TCP and EtherNet/IP

7” Display for F&B — CODESYS V3 PLC with TARGET and WEB VISU

High-Quality Metal Housing and Glass Front with a Capacitive Touch

• • 7" TFT wide screen color display
  • LED backlight
  • 800 x 480 pixel resolution
  • 16 M colors
  • Capacitive touchscreen with glass front and polyester coating
  • Stainless steel frame and food-grade seal
  • IP69 degree of protection, high-pressure watertight up to 80 °C
  • Acid- and chemical-resistant
  • 3 RJ45 Ethernet ports with 10/100 Mbit
  • 1 serial interface (RS232, RS485, RS422)
  • 2 USB host ports
  • 1 SD card slot

DIN Rail Device for the Control Cabinet; Operating voltage; 2 separated RJ45 Ethernet ports with 10/100 Mbit; 1 serial interface (RS232, RS485, RS422); 1 USB host port; 1 SD card slot

Temperature ranges Operational: 0 to 50° C (32-122° F) Storage: -40 to 80° C (-40 to 176° F) Calibrated: 0 to 50° C (32 to 122° F) Diameter 2.62 cm (1.03 in.) Length 14.43 cm (5.68 in.) Weight 137 g (0.30 lb) Materials Titanium, Acetal, FKM Fluoroelastomer, Ceramic Output options Rugged TROLL 100: USB or RS232 via docking station Battery type & life 3.6 V lithium; 10 years or 2M readings Memory 2.0 MB Data records 120,000 (data record = date/time plus 2 parameters logged (no wrapping) from device within the factory-calibrated temperature range) Accuracy (FS) ±0.1% Resolution ±0.01% FS or better Units of measure Pressure: psi, kPa, bar, mbar, mmHg, inHg Level: in, ft, mm, cm, m Temperature Sensor Accuracy ±0.3° C Resolution 0.01° C or better Units of measure Celsius or Fahrenheit

Temperature ranges Operational: 0-50° C (32-122° F) Storage: -40-80° C (-40-176° F) Calibrated: 0-50° C (32-122° F) Diameter 2.62 cm (1.03 in.) Length 14.43 cm (5.68 in.) Weight 137 g (0.30 lb) Materials Titanium body; Delrin nose cone, hanger, backend Output options USB or RS232 via docking station; Modbus/RS485 or SDI-12 via Rugged TROLL 200 Cable Battery type & life 3.6 V lithium; 10 years or 2M readings External power 8-36 VDC Memory 2.0 MB Data records 120,000 Fastest logging rate 1 per minute Fastest output rate Modbus & SDI-12: 1 per second Log types Linear Sensor Type/Material Piezoresistive; Ceramic Range 7.0 to 30.0 psi; 0.5 to 2 bar Accuracy (FS) ±0.1% Resolution ±0.01% FS or better Units of measure Pressure: psi, kPa, bar, mbar, mmHg, inHg Temperature Sensor Accuracy ±0.3° C Resolution 0.01° C or better Units of measure Celsius or Fahrenheit

Temperature ranges1 Operational: 0 to 50° C (32-122° F) Storage: -40 to 80° C (-40 to 176° F) Calibrated: 0 to 50° C (32 to 122° F) Diameter 2.62 cm (1.03 in.) Length 14.43 cm (5.68 in.) Weight 137 g (0.30 lb) Materials Titanium, Acetal, FKM Fluoroelastomer, Ceramic Output options Rugged TROLL 200: USB or RS232 via docking station; Modbus/RS485 or SDI-12 via Rugged TROLL 200 Cable; Wireless TROLL Com Battery type & life 3.6 V lithium; 10 years or 2M readings Memory 2.0 MB Data records 120,000 (data record = date/time plus 2 parameters logged (no wrapping) from device within the factory-calibrated temperature range) Accuracy (FS) ±0.1% Resolution ±0.01% FS or better Units of measure Pressure: psi, kPa, bar, mbar, mmHg, inHg Level: in, ft, mm, cm, m Temperature Sensor Accuracy ±0.3° C Resolution 0.01° C or better Units of measure Celsius or Fahrenheit

0052000NV- 0052000-03 15meters meters
