Photo sensor - receiver O200.ER-PV1Z.72CV/H006, through-beam 5m, 10-30VDC, PNP NO/NC, 2m cable, IP67

O200.ER-PV1Z.72CV/H006 is the receiver half of a Baumer O200 miniature through-beam pair with a 6 m nominal range. It carries no sensitivity adjustment - the switching threshold is preset at the factory, so the pair is aligned and left alone.

• Range: actual 5 m, nominal 6 m; smallest detectable object 5 mm (0.5 mm with aperture)
• Output: PNP complementary, light/dark operate, < 50 mA
• Supply: 10...30 VDC, typ. 16 mA at 24 VDC
• Response time: < 0.5 ms
• Housing: rectangular 8 x 25.1 x 14.1 mm, ASA plastic, PMMA optics, M3 stainless steel threaded sleeves
• Environment: IP 67, -25...+50 °C
• Connection: 2 m PVC cable, 4-wire

The fixed threshold suits series machines where the same gap is checked on every unit and commissioning should not include a sensitivity setting that can drift or be turned. A flashing output indicator reports weak signal margin or a soiled lens, and reciprocal influence is suppressed so several pairs can work side by side.
