PRO-KIT is a Banner kit for configuring Pro series lights and selected sensors from a PC with the Pro Editor software. It is needed for initial configuration only, not for the device's operation in the machine.

• Included: converter cable, splitter and power supply
• Software: Banner Pro Editor
• Fits: Banner Pro series lights and selected sensors

CE and UKCA compliant.

OT300.GL-GLZZJ.72N is a background suppression photo sensor from the Baumer OT300 series in a miniature housing, measuring by time of flight over a 100...1800 mm switching range. A red laser diode (680 nm, laser class 1) focused at 700 mm forms a narrow point beam, and the measured distance value is available over IO-Link.

• Switching range: 100...1800 mm (Tw), set by teach-in or IO-Link
• Output: push-pull (PNP/NPN) and IO-Link V1.1.3, Class A, Light operate, switchable
• Repeat accuracy: ≤ 1400...5500 µm, linearity error ± 10 mm
• Supply: 12...30 V DC, consumption max. 60 mA
• Housing: plastic (ASA, PMMA), 12.9 x 32.3 x 23 mm
• Environment: IP 67, -20...+50 °C
• Connection: M8 connector, 4 pin

Response time is selected over IO-Link: < 4 ms in High Speed, < 8 ms in Standard and < 50 ms in Long Range mode, so the same sensor suits both a fast sorting line and a longer distance with weak remission. Operating hours, operating cycles, supply voltage and device temperature are also readable over IO-Link.

Vibration and shock resistance tested to IEC 60068-2-6:2008 (10 g, 10...2000 Hz) and IEC 60068-2-27:2009 (50 g / 11 ms).

O200.SL.T-GW1J.72NV/F160_H006 is a Baumer O200 miniature SmartReflect light barrier tuned for transparent objects. It forms the barrier between itself and a fixed machine surface, so no reflector is mounted opposite, and an object is detected by the 5% signal attenuation that even a clear bottle or film produces.

• Background position Sde: 15...180 mm, teachable; scanning range 90%...85% Sde
• Detection: minimum signal attenuation 5%, focus at 160 mm
• Output: push-pull, light/dark operate, 50 mA
• Communication: IO-Link V1.1, port class A, 230.4 kBaud, cycle ≥ 0.6 ms
• Supply: 10...30 VDC, typ. 10 mA at 24 VDC; response time < 0.25 ms in High Speed mode
• Housing: rectangular 8 x 25.1 x 15.8 mm, ASA plastic, PMMA optics, M3 stainless steel threaded sleeves; laser class 1, 680 nm
• Environment: IP 67, -20...+50 °C; connection M8 4-pin flylead connector, 200 mm

It is used on filling and labelling lines for PET bottles, glass containers, clear film and blister packs, and wherever there is no room or no mounting point for a reflector on the far side. Background tracking compensates for lens contamination and slow changes in the reference surface, so the threshold stays usable between cleaning intervals; the compensation and the switching point are also readable and settable over IO-Link.

O200.GL-GW1J.72NV/F040_H006 is a Baumer O200 miniature background suppression sensor with a focused laser beam converging at 40 mm, where it resolves objects down to 0.05 mm. Switching point, hysteresis, time filters and counter are set by qTeach, line teach or over IO-Link V1.1, and the same interface returns a 16-bit distance measurement, excess gain, quality and alarm bits.

• Sensing distance Tw: 20...120 mm, teachable; sensing range Tb 3...132 mm
• Output: push-pull, light/dark operate, 50 mA
• Communication: IO-Link V1.1, port class A, 230.4 kBaud, cycle ≥ 0.6 ms
• Supply: 10...30 VDC, typ. 10 mA at 24 VDC
• Response time: ≤ 0.25 ms in High Speed mode, jitter ≤ 0.06 ms
• Housing: rectangular 8 x 25.1 x 15.8 mm, ASA plastic, PMMA optics, M3 stainless steel threaded sleeves; laser class 1, 680 nm
• Environment: IP 67, -20...+50 °C; connection M8 4-pin flylead connector, 200 mm

The focused beam suits small targets and narrow gaps - wire ends, thin edges, holes in a moving strip, or the boundary between stacked sheets. The distance value returned over IO-Link lets a controller follow signal drift long before the switching output starts to fail.

O200.GR.F-PV1Z.72NV/H006_BX15 is a Baumer O200 miniature background suppression sensor with a fixed 15 mm switching distance and V-optics, in which the emitted and received beams cross on the object itself. That geometry gives a repeatable switching point on shiny and transparent surfaces, where coaxial optics read the specular reflection instead of the object.

• Sensing distance Tw: 15 mm, fixed, no adjustment; sensing range Tb 3...15 mm
• Detection: smallest object typ. 0.05 mm at 10 mm
• Output: PNP complementary, light/dark operate, 50 mA
• Supply: 10...30 VDC, typ. 16 mA at 24 VDC; response time < 1 ms
• Housing: rectangular 8 x 25.1 x 14.1 mm, ASA plastic, PMMA optics, M3 stainless steel threaded sleeves; red LED 644 nm
• Environment: IP 67, -30...+50 °C
• Connection: M8 4-pin flylead connector, 200 mm

The fixed preset means commissioning is mounting and wiring only - there is nothing to teach and nothing that can be turned later. It is used at short fixed distances against glass, film, foil and polished metal: edge detection on packaging film, presence of a vial or ampoule, label and blister checks.

O200.GP-GW1J.72NV/E022_H006 is a Baumer O200 miniature background suppression sensor whose PinPoint LED light is shaped into a line beam. The line covers the full width of an irregular or perforated object, so a part with holes, slots or a ragged edge gives one switching signal instead of a burst of short pulses.

• Sensing distance Tw: 20...120 mm, teachable; sensing range Tb 3...132 mm
• Detection: line beam, smallest object typ. 8 mm at 60 mm
• Output: push-pull, light/dark operate, 50 mA
• Communication: IO-Link V1.1, port class A, 230.4 kBaud, cycle ≥ 0.6 ms
• Supply: 10...30 VDC, typ. 16 mA at 24 VDC; response time < 0.25 ms in High Speed mode
• Housing: rectangular 8 x 25.1 x 15.8 mm, ASA plastic, PMMA optics, M3 stainless steel threaded sleeves; 644 nm
• Environment: IP 67, -30...+50 °C; connection M8 4-pin flylead connector, 200 mm

Typical positions are perforated trays, mesh baskets, crates with gaps and bottle cases on a conveyor, where a point beam would drop out each time it passes an opening. Teach-in is by qTeach or line teach and every parameter is also reachable over IO-Link, so a format change can be loaded from the controller instead of being set by hand at the machine.

U500.PA0.2-GP1J.72F is a Baumer U500 series ultrasonic proximity sensor with a 20...1000 mm operating range, a push-pull switching output and an IO-Link interface. A multiplex version lets several sensors run side by side without mutual interference.

• Accuracy: repeatability 0.5 mm; hysteresis typ. 4 % Sde; temperature drift < 2 % Sde; power-up drift compensated after 15 min
• Sensing distance: 20...1000 mm; response time < 40 ms; sonic frequency 200 kHz
• Outputs: push-pull (works as PNP or NPN), up to 100 mA; IO-Link V1.1, COM 2 (38.4 kBaud), cycle time ≥ 12 ms, port type Class A, also transmits distance
• Supply: 12...30 V DC, typical consumption 35 mA; short-circuit and reverse-polarity protected
• Housing: rectangular, ASA/PMMA plastic, PEEK-coated sensor face, 18 x 45 x 32 mm
• Environment: IP67, operating temperature -25...+65 °C
• Connection: M12 connector, 5-pin

Suited to presence and level detection up to 1 m regardless of colour and transparency. The switching point is set by qTeach, Line-Teach or over IO-Link, which also configures output logic, time filters, beam forming and the function of pin 5.

O300.RP-PV1T.72CU is a miniature photoelectric sensor from the Baumer O300 series working against a reflector over a 5 m range. A polarisation filter lets the sensor respond only to the light returned by the reflector, so shiny metal or film in the object's place is not read as a reflector.

• Range: 5 m actual, 6 m nominal, with polarisation filter
• Output: PNP complementary, NO and NC at the same time, light / dark operate, < 100 mA
• Supply: 10...30 V DC, typical consumption 25 mA
• Housing: rectangular, plastic (ASA, PMMA), PMMA optics, 12.9 x 32.3 x 23 mm
• Environment: IP 67, -25...+60 °C
• Connection: 2 m cable, 4 cores

The sensor suits counting and presence checks on conveyors and packaging lines where the sensor and the reflector can face each other. Sensitivity is set with qTeach by holding a ferromagnetic tool against the housing, and mutual interference between sensors mounted side by side is suppressed.

SME312D is a Banner MINI-BEAM Expert diffuse-mode photo sensor with an infrared 880 nm beam and 380 mm range. Sensitivity is set by TEACH instead of a potentiometer.

• Sensing: diffuse, range 380 mm, infrared 880 nm
• Outputs: bipolar, 1x PNP and 1x NPN, 150 mA each (100 mA at 70 °C); response 500 µs, repeatability 100 µs
• Supply: 10-30VDC, below 45 mA
• Housing: MINI-BEAM, reinforced thermoplastic polyester, encapsulated, M18x1 nose thread with nut
• Environment: IP67, -20...+70 °C
• Connection: 2 m PVC cable, 5 conductors

Set with the push button or the gray remote TEACH wire: the first condition taught becomes Output ON, so Light or Dark Operate is not selected separately. The green indicator flashes when the signal approaches the switching threshold.

SLO30VB6Q is a Banner SLO series slot sensor: an infrared 890 nm opposed-mode emitter and receiver across a 30 mm slot, 45 mm deep, in one U-shaped housing. The 2 mm effective beam suits hole, gear-tooth and edge detection without any alignment.

• Slot: 30 mm wide, 45 mm deep; beam 10 mm from the outer edge
• Output: bipolar, one PNP and one NPN, Light or Dark Operate selected by the grey wire, 150 mA each
• Response: 1 ms; repeatability 250 µs
• Supply: 10-30 V DC, 30 mA
• Housing: ABS and polycarbonate, acrylic lenses
• Environment: IP67, NEMA 6, -40...+70 °C
• Connection: integral M12 5-pin male connector

Grey wire to +V gives Dark Operate, to 0 V or open gives Light Operate. There is no sensitivity adjustment. A green LED shows power; the amber LED shows light sensed and flashes at marginal excess gain.

T30SP6FF100Q is a Banner T30 series fixed-field photo sensor with a 100 mm cutoff and an infrared beam, in a right-angle housing with a 30 mm threaded lens. The sensor detects objects up to 100 mm and ignores backgrounds beyond.

• Sensing range: 100 mm cutoff, fixed
• Output: PNP, Light/Dark Operate
• Response: 3 ms; repeatability 750 µs
• Supply: 10-30 V DC
• Housing: right-angle, 30 mm thread, thermoplastic, acrylic lens, encapsulated
• Environment: IP69K, NEMA 4X, -40...+70 °C
• Connection: integral M12 4-pin male connector

There is no sensitivity adjustment.

UL, CE and UKCA approved.

Q12AB6R is the receiver of a Banner Q12 series opposed-mode pair and works with a Q12 emitter with a visible red 640 nm beam.

• Sensing range: 2 m with a Q12 emitter, effective beam 5.7 mm
• Output: bipolar, one PNP and one NPN, Light Operate, 50 mA
• Response: 1.3 ms ON, 900 µs OFF; repeatability 125 µs
• Supply: 10-30 V DC, < 20 mA
• Housing: polyamide, polycarbonate lens, 8 mm thick
• Environment: IP67, -20...+55 °C
• Connection: 2 m PVC cable, 4 wires

A green LED indicator shows power; the amber one shows the received signal and flashes when the signal is marginal.

T30UIPAQ is a Banner T30U series ultrasonic sensor with a 4-20 mA analog output and a PNP discrete output. Both can be taught together or separately, and the analog slope is set by the order in which the limits are taught.

• Accuracy: analog linearity ±0.5 % of full scale; resolution and repeatability ±0.25 % of distance; 10 x 10 cm aluminium target, 25 °C
• Measuring range: 150 mm...1 m, 228 kHz; minimum window 10 mm
• Outputs: analog 4-20 mA; discrete PNP, 100 mA; response 48 ms
• Supply: 12...24 V DC, 90 mA
• Housing: M30 thread, reinforced thermoplastic polyester (PBT)
• Environment: IP67, -20...+70 °C
• Connection: integral M12 5-pin male

Window limits are taught with the push buttons on the sensor or through the remote teach wire. Objects closer than 150 mm can cause a false response.

Vibration per MIL-STD-202F method 201A, shock per IEC 60947-5-2 (30 g, 11 ms). CE and UKCA.

Q20NLP is a Banner Q20 series polarized retroreflective photo sensor with a visible red 645 nm beam and a 4 m range with a BRT-84 reflector. The polarizing filter lets it detect shiny objects that would reflect an unpolarized beam back to the sensor.

• Sensing range: 4 m with BRT-84 reflector
• Output: NPN, complementary Light Operate and Dark Operate outputs, 100 mA
• Response: 850 µs ON/OFF; repeatability 90 µs
• Supply: 10-30 V DC, < 18 mA
• Housing: ABS, PMMA lenses
• Environment: IP67, -20...+60 °C
• Connection: 2 m PVC cable, 4 wires

A green LED indicator shows power; the amber one shows the output state and flashes at marginal excess gain. Sensitivity is set with a single-turn potentiometer.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

O330.GP-GLZZB.72N/H006 is a miniature photoelectric sensor from the Baumer O330 series with background suppression and a 20...350 mm switching distance. The switching distance is set with qTeach or by an external teach signal over the connection cable, so the sensor can be re-taught from the control system without physical access.

• Switching distance: 20...350 mm, adjustable by qTeach or an external teach signal
• Output: push-pull, light / dark operate, 100 mA
• Supply: 10...30 V DC, typical consumption 25 mA
• Housing: rectangular, plastic (ABS, ASA, PMMA), M3 brass threaded sleeves, 11 x 32 x 21 mm
• Environment: IP 67, -30...+55 °C
• Connection: M8 connector, 4 pin

The sensor suits presence checks on conveyors, assembly stations and packaging machines where mounting space is tight and the unit is swapped without rewiring. The M3 threaded sleeves allow the sensor to be fixed directly, without a separate bracket.

Vibration resistance tested to IEC 60068-2-6:2008 (10 g, 10-2000 Hz) and shock resistance to IEC 60068-2-27:2009 (50 g, 11 ms).

S30SP6FF600Q is a Banner S30 series fixed-field photo sensor with an infrared 880 nm beam and a 600 mm cutoff. It compares the light returned to a near and a far detector, so it detects objects in front of the cutoff and ignores the background behind it.

• Sensing range: 600 mm cutoff
• Output: PNP, SPDT - NO (Light Operate) and NC (Dark Operate), 150 mA each
• Response: 3 ms ON/OFF; repeatability 750 µs
• Supply: 10-30 V DC, 35 mA
• Housing: PBT polyester, acrylic lens, fully epoxy-encapsulated, M30x1.5 threaded barrel
• Environment: IP69K, NEMA 6P, -40...+70 °C
• Connection: integral M12 4-pin male connector

The cutoff is fixed and there is nothing to adjust. Excess gain peaks at about 40 mm from the lens, which is where low-reflectivity targets are detected most reliably; backgrounds belong well beyond 600 mm, and mirror-like ones can cause false switching. A yellow LED shows the NO output on and flashes at marginal excess gain.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B (75 g operating).

T18-2VPRS-Q8 is a Banner T18-2 series opposed-mode receiver, used with a T18-2 emitter. The right-angle 18 mm threaded housing has epoxy-encapsulated electronics and food-grade plastics, for wet and washdown areas. A single-turn potentiometer sets the sensitivity.

• Sensing range: 25 m with a T18-2 emitter
• Output: complementary PNP (NO and NC), 100 mA total up to +55 °C; response 1.5 ms ON / 1 ms OFF
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, 18 mm thread, PBT polyester, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C; ECOLAB chemical compatibility
• Connection: M12 male connector, 4-pin

Vibration per MIL-STD-202G method 201A, shock per method 213B (75 g operating).

IGYX 30P17B3/S14L is a Baumer inductive proximity sensor in an M30 barrel with a 15 mm nominal sensing distance and a PNP normally open (NO) output. The sensing face is flush mountable and the nickel-plated brass housing is 60 mm long.

• Sensing distance: 15 mm (Sn), assured 12 mm (Sa)
• Output: PNP, normally open (NO), 200 mA, with short-circuit and reverse-polarity protection
• Supply: 10...30 V DC, current consumption up to 15 mA with no load
• Housing: M30 thread, nickel-plated brass, PBT sensing face, 60 mm long, flush mountable
• Environment: IP 67, operating temperature -25...+75 °C
• Connection: M12 connector

The 15 mm sensing distance keeps the sensor clear of the moving part - end-position monitoring on hydraulic and pneumatic cylinders, gates and pallets. Switching frequency is 400 Hz, so this model is not suited to counting the teeth of a fast rotating gear. Tightening torque on the M30 thread must not exceed 60 Nm, and the switching point drifts by up to ±10 % of Sr across the temperature range, which matters when the target sits close to the 15 mm limit.

Complies with the EMC requirements of EN 60947-5-2:2007.

Q126E is the emitter of a Banner Q12 series opposed-mode pair and works with a Q12 receiver.

• Range: 2 m with a Q12 receiver
• Light source: visible red 640 nm
• Supply: 10-30 V DC, < 20 mA
• Housing: polyamide, polycarbonate lens, 8 mm thick
• Environment: IP67, -20...+55 °C
• Connection: 2 m PVC cable, 4 wires

A green LED indicator shows power.

LT3PUQ-79783 is a Banner L-GAGE LT3 time-of-flight laser sensor with a 0-10 V analog output and a PNP discrete output, each with its own taught window. The analog signal is scaled across the programmed window, so a short window still uses the full 0-10 V.

• Accuracy: linearity ±30 mm (0.3...1.5 m), ±20 mm (1.5...5 m) at 24 V DC, 22 °C, white card; temperature effect < 2 mm/°C
• Measuring range: 0.3...5 m (90 % white), 0.3...3 m (18 % grey), 0.3...2 m (6 % black); minimum window 20 mm
• Outputs: analog 0-10 V; discrete PNP, 100 mA; response 1, 10 or 100 ms
• Supply: 12...24 V DC, max. 108 mA at 24 V DC; protected against reverse polarity
• Housing: ABS, acrylic window; Class 2 red laser 658 nm, beam Ø 6 mm
• Environment: IP67, NEMA 6, 0...+50 °C
• Connection: M12 8-pin swivel connector

Window limits are taught with the push buttons or the remote wire, and the red wire enables or disables the laser. Allow 30 minutes of warm-up before programming.

T18-2VNRL-Q8 is a Banner T18-2 series opposed-mode receiver, used with a T18-2 emitter. The right-angle 18 mm threaded housing has epoxy-encapsulated electronics and food-grade plastics, for wet and washdown areas.

• Sensing range: 25 m with a T18-2 emitter
• Output: complementary NPN (NO and NC), 100 mA total up to +55 °C; response 1.5 ms ON / 1 ms OFF
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, 18 mm thread, PBT polyester, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C; ECOLAB chemical compatibility
• Connection: M12 male connector, 4-pin

Vibration per MIL-STD-202G method 201A, shock per method 213B (75 g operating).

T30SP6RQ is the receiver of a Banner T30 series opposed-mode photo sensor pair, in a right-angle housing with a 30 mm threaded lens. It switches when an object breaks the infrared beam from a separate T30 emitter up to 60 m away.

• Sensing range: 60 m with a T30 emitter
• Output: complementary PNP, Light Operate (black) and Dark Operate (white), 150 mA each
• Response: 3 ms ON, 1.5 ms OFF; repeatability 375 µs
• Supply: 10-30 V DC, 20 mA
• Housing: right-angle, M30x1.5 thread, PBT polyester, epoxy-encapsulated, jam nut included
• Environment: IP69K, NEMA 4X, -40...+70 °C
• Connection: integral M12 4-pin male connector

Needs a T30 emitter, ordered separately. The white-wire output can be wired as a normally open marginal-signal alarm instead of Dark Operate. A green LED shows power and flashes on output overload; the amber LED shows the NO output is on and flashes at marginal excess gain.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B (75 g operating). UL, CE and UKCA approved.

T30UXUBQ8 is a Banner T30UX series ultrasonic sensor with a 0-10 V analog output scaled across a taught window and built-in temperature compensation. Fast or slow response, output slope and push-button lock are set from the sensor.

• Accuracy: linearity 0.25 % of distance; resolution 0.1 % of distance (1 mm min.); temperature effect 0.02 % of distance/°C
• Measuring range: 200 mm...2 m, 174 kHz; minimum window 10 mm
• Output: analog 0-10 V, min. load 2.5 kΩ; response 92 ms or 222 ms
• Supply: 10...30 V DC, 40 mA; full 10 V output from 12 V DC
• Housing: M30 x 1.5 thread, PBT
• Environment: IP67, -40...+70 °C
• Connection: integral M12 4-pin male

On loss of signal the output drops to 0 V, which the controller can read as a fault.

PTL110S-FF200L-QP150 is a Banner PTL110 series pick-to-light device with an RGB indicator and a 200 mm fixed-field infrared sensor, controlled over RS-485 Modbus RTU with PICK-IQ. The indicator shows the operator which bin to pick from, and the sensor confirms the hand reaching into it.

• Indicator: RGB, up to 14 colours; pick, acknowledge, mis-pick and job lights programmable
• Sensor: 200 mm fixed field, infrared 870 nm
• Communication: RS-485 Modbus RTU, PICK-IQ
• Supply: 10-30 V DC, 50 mA at 24 V DC, 1.35 W maximum
• Housing: ABS, polycarbonate indicator, acrylic lens, 110 x 35 x 33.1 mm
• Environment: IP54, -40...+50 °C
• Connection: two 150 mm PVC cables, M12 4-pin male and M12 4-pin female

The male and female pigtails let devices be daisy-chained along a picking shelf on one RS-485 line. The device needs a Modbus RTU host with PICK-IQ to set colours and read the sensor; it has no touch button and no display.

UL, CE and UKCA approved; FCC Part 15 Class B.

T306EQ is the emitter of a Banner T30 series opposed-mode photo sensor pair, in a right-angle housing with a 30 mm threaded lens. Its infrared 950 nm beam reaches a separate T30 receiver up to 60 m away, so the pair can span wide conveyors and doorways.

• Sensing range: 60 m with a T30 receiver
• Output: none (emitter)
• Supply: 10-30 V DC, 25 mA
• Housing: right-angle, M30x1.5 thread, PBT polyester, epoxy-encapsulated, jam nut included
• Environment: IP69K, NEMA 4X, -40...+70 °C
• Connection: integral M12 4-pin male connector

The emitter uses only the brown and blue wires; pins 2 and 4 are not connected. A green LED shows power.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B (75 g operating). UL, CE and UKCA approved.

FHDK 14P5101/S35A is a Baumer standard-size photo sensor with background suppression. It compares where the reflected beam lands on its internal detector, so an object is detected regardless of its colour or surface reflectivity while everything beyond the set distance is ignored.

• Switching distance: 20...350 mm, adjustable by a 10-turn mechanical potentiometer
• Output: PNP, Light/Dark Operate, < 100 mA
• Supply: 10...30 V DC, typical consumption 25 mA
• Housing: rectangular, 14.8 x 43 x 31 mm, plastic (ASA, MABS), PMMA optics
• Environment: IP 67, -25...+65 °C
• Connection: M8 connector, 4-pin

The sensor suits presence and position control in packaging, assembly and sorting machines where the background sits close to the object and dark or glossy surfaces give a standard diffuse sensor a false reading. A flashing light indicator shows insufficient signal margin or a soiled lens, so alignment and maintenance need no instruments. Reciprocal influence is suppressed, so several sensors can be mounted side by side.

Q25S2P6RQ is the receiver of a Banner EZ-BEAM Q25 series opposed-mode photo sensor pair, in the S2 version for sensor bus junctions. Besides the sensing output it has a second PNP output that warns when the received signal becomes marginal.

• Sensing range: 20 m with a Q256EQ emitter
• Output: PNP Light Operate sensing output and PNP NO alarm output, 150 mA total
• Response: 3 ms ON, 1.5 ms OFF; repeatability 375 µs
• Supply: 10-30 V DC, 20 mA
• Housing: PBT polyester, polycarbonate lens, epoxy-encapsulated electronics
• Environment: IP67, NEMA 6P, -40...+70 °C
• Connection: integral M12 4-pin male connector

The alarm output (white wire) conducts when excess gain falls to 1-1.5x in the light condition, so the bus system sees a dirty lens or misalignment before the sensor stops switching. Using it needs a junction with two channels per input. No adjustments are needed. Works with a Q256EQ emitter, ordered separately.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B.

Q256EQ is the emitter of a Banner EZ-BEAM Q25 series opposed-mode photo sensor pair. It sends an infrared 950 nm beam to a separate Q25 receiver up to 20 m away; an object is detected when it breaks the beam.

• Sensing range: 20 m with a Q25 receiver
• Output: none (emitter)
• Supply: 10-30 V DC, 25 mA
• Housing: PBT polyester, polycarbonate lens, epoxy-encapsulated electronics
• Environment: IP69K, NEMA 6P, -40...+70 °C
• Connection: integral M12 4-pin male connector

The emitter has no output and needs a Q25 receiver, ordered separately.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B.

SLM50P6Q is a Banner SLM series slot sensor: an opposed-mode emitter and receiver facing each other across a 50 mm slot in one U-shaped die-cast housing. There is nothing to align; molded-in arrows show where the visible red beam crosses the slot.

• Slot width: 50 mm; beam 5 mm from the outer edge
• Output: one PNP, Light or Dark Operate selected by switch, 100 mA
• Response: 500 µs; repeatability 95 µs
• Supply: 10-30 V DC, < 25 mA
• Housing: nickel-plated die-cast zinc, ABS end caps, acrylic windows
• Environment: IP67, -20...+60 °C
• Connection: integral M8 3-pin male connector

Used for counting, gear-tooth and edge detection, and part sensing on conveyor rails, with the object passing midway through the slot. Sensitivity is set with a single-turn potentiometer, turned down from maximum until the object is detected reliably. Green and amber LEDs show power and output.

Q5XKLAF10000-Q8 is a Banner Q5X series Class 2 laser measurement sensor with a 50...10000 mm range and two independent switching outputs. It detects black targets below 6 % reflectance, also against a black or shiny metal background, and shows the measured distance on its display; settings are made with the buttons or over IO-Link.

• Sensing range: 50...10000 mm; laser alignment tolerance ±172 mm at 10000 mm
• Output 1: IO-Link, push/pull or PNP/NPN switching, 50 mA
• Output 2: PNP/NPN switching, pulse frequency output or remote input, 50 mA; response time 2, 5, 15, 50 or 250 ms
• IO-Link: v1.1, 38.4 kbit/s, Smart Sensor Profile, min. cycle time 3.6 ms
• Supply: 10...30 V DC, < 1.4 W; protected against reverse polarity and transient overvoltage
• Housing: ABS, PMMA lens cover; side mounting
• Environment: IP67, -10...+50 °C
• Connection: integral M12 male connector, 4-pin, rotatable through 270°

Black gain mode raises excess gain about three times for low-reflectivity targets, and shiny gain mode lowers it to about one third for highly reflective ones. The sensor reaches full performance after 20 minutes of warm-up.

CE, UKCA and UL listed (Industrial Control Equipment). Vibration per MIL-STD-202G method 201A, shock per MIL-STD-202G method 213B (100 G).

O330.GP-NLNVT.72ZV/T003 is a miniature photoelectric sensor from the Baumer O330 series with background suppression and a 20...350 mm switching distance. The PinPoint LED produces a small, even light spot with sharp edges, so the sensor also detects small objects and objects close to their edge.

• Switching distance: 20...350 mm, adjustable by qTeach or 1-Step teach-in
• Output: NPN complementary, NO and NC at the same time, light / dark operate, 100 mA
• Supply: 10...30 V DC, typical consumption 25 mA
• Housing: rectangular, plastic (ABS, ASA, PMMA), brass sleeves in the mounting holes, 11 x 32 x 21 mm
• Environment: IP 67, -25...+55 °C
• Connection: 2 m PVC cable, 4 x 0.14 mm²

The sensor suits presence checks on conveyors, assembly stations and packaging machines where mounting space is tight. The brass sleeves in the mounting holes let the screws be tightened without crushing the plastic housing.

Vibration resistance tested to IEC 60068-2-6:2008 (10 g, 10-2000 Hz) and shock resistance to IEC 60068-2-27:2009 (50 g, 11 ms).

IGYX 12P17B3/S14L is a Baumer inductive proximity sensor in an M12 barrel with a 4 mm nominal sensing distance and a PNP normally open (NO) output. The sensing face is flush mountable and the nickel-plated brass housing is 50 mm long.

• Sensing distance: 4 mm (Sn), assured 3.2 mm (Sa)
• Output: PNP, normally open (NO), 200 mA, with short-circuit and reverse-polarity protection
• Supply: 10...30 V DC, current consumption up to 15 mA with no load
• Housing: M12 thread, nickel-plated brass, PBT sensing face, 50 mm long, flush mountable
• Environment: IP 67, operating temperature -25...+75 °C
• Connection: M12 connector

The sensor is intended for presence and end-position monitoring of metal parts on conveyors, pneumatic cylinders and indexing mechanisms. Switching frequency is 1.5 kHz. Tightening torque on the M12 thread must not exceed 10 Nm, and the switching point drifts by up to ±10 % of Sr across the temperature range, which matters when the target sits close to the 4 mm limit.

Complies with the EMC requirements of EN 60947-5-2:2007.

Q26PLUMQ5 is a Banner Q26 luminescence sensor: a 375 nm UV LED makes the target glow and the sensor detects that glow, so luminescent plastics, coatings, lubricants and marks are found on even or uneven surfaces regardless of their colour under normal light.

• Sensing range: 10...30 mm, beam Ø2 mm at 15 mm, UV 375 nm
• Output: PNP, 100 mA; response 250 µs or 1 ms, 2 kHz or 500 Hz, depending on sensitivity
• Supply: 12-30VDC, 30 mA
• Housing: ABS, 14 x 25 x 42 mm, glass window, max 0.8 Nm mounting torque
• Environment: IP67, -10...+55 °C
• Connection: 150 mm PVC pigtail with M12 4-pin connector

Light Operate or Dark Operate is selected with a rotary switch. The threshold is taught with the button or the remote wire by Light SET, Two-Point TEACH or Dark SET.

Vibration per EN 60068-2-6, shock per EN 60068-2-27.
