CSB-M1250M1250-T is a Banner M12 T splitter listed among the power cordsets for Sure Cross wireless devices. It passes the supply and signal lines in parallel to both branches.

• Connectors: M12x1, straight
• Wiring: brown 1, white 2, blue 3, black 4, in parallel
• Size: 62.7 x 43.0 mm
• Ratings: 4 A, IP67, -40...+105 °C

K50PSLRGB7Q is a Banner K50 Pro Select series 50 mm programmable RGB dome indicator with seven default colors. Colors, animations and input logic are reprogrammed with Banner Pro Editor software.

• Colors: green, red, yellow, blue, white, cyan, magenta (default)
• Inputs: bimodal PNP/NPN; gray wire - 1.5 Hz flash; response time 250 ms
• Configuration: Pro Editor, Discrete Control (up to 15 states) and Pulse Control (up to 16 states by frequency on the white wire)
• Supply: 10...30 V DC, 220 mA at 10 V, 115 mA at 24 V
• Housing: polycarbonate, M30x1.5 threaded base, 50 x 69 mm
• Environment: IP66, IP67, IP69K, UL 4X and 13, -40...+50 °C
• Connection: integral 5-pin M12 male connector

Changing the settings requires a Pro Converter cable to connect to a PC. The Pro ID function takes the code of another K50 model and applies its colors and input logic, so one indicator can stand in for several standard K50 models.

CE and UL compliant. Vibration per IEC 60068-2-6, shock per IEC 60068-2-27 (30 G, 11 ms).

TTR558APSB6T-2.0Q3-061 is a Banner Through the Roller sensor: an aluminium bar with six diffuse infrared beams that sits in the gap between conveyor rollers and detects the leading edge of letters, thin packages, poly bags, totes and boxes. All six beams switch one common output.

• Sensing range: 0...≥120 mm on 90% white card, 0...≥50 mm on 18% grey, ≤3...≥30 mm on 6% black
• Beams: 6, spacing 93.1 mm, first beam 61 mm from the cable end cap; infrared 940 nm
• Output: PNP, Light Operate, 100 mA; response 1 ms
• Supply: 18-30VDC, 45 mA
• Housing: aluminium, 558 mm between frames, end cap style T for T-slot mounting
• Environment: IP50, -10...+55 °C
• Connection: 2 m cable with M8 4-pin snap connector

On the T-slot the sensor is 6 mm shorter than the stated between-frame distance, and the bracket and hardware are supplied by the customer. Keep at least 12 mm clearance to any fixed barrier in the beam path.

Vibration per IEC 60068-2-6, IEC 60947-5-2 and MIL-STD-202F, Method 201A; shock per IEC 60068-2-27.

RKC4.4T-5-RSC4.4T/TXL is a TURCK extension cable with a straight M12 female connector on one end and a straight M12 male connector on the other (4-pin). The PUR jacket is rated for moving installation, including drag chains.

• Connectors: M12 x 1 female and M12 x 1 male, both straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PUR, black, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

RKC4.5T-1-RSC4.5T/TEL is a TURCK extension cable with a straight M12 female connector on one end and a straight M12 male connector on the other (5-pin). The cable has a black PVC jacket.

• Connectors: M12 x 1 female and M12 x 1 male, both straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 1 m, PVC, black, Ø 5 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

RKC4.5T-2-RSC4.5T/TEL is a TURCK extension cable with a straight M12 female connector on one end and a straight M12 male connector on the other (5-pin). The cable has a black PVC jacket.

• Connectors: M12 x 1 female and M12 x 1 male, both straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 2 m, PVC, black, Ø 5 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

QM30VT3-SS-MQP is a Banner QM30VT3 3-axis vibration and temperature sensor for condition monitoring of motors, pumps, fans and other rotating machines. It works as a Modbus RTU server on RS-485 and delivers pre-processed values such as RMS velocity, high-frequency RMS acceleration and peak velocity per axis.

• Accuracy: vibration ±5 % at 25 °C; temperature ±3 °C
• Measuring range: vibration ±16 g, 0...65.5 mm/s RMS, 6 Hz...5.3 kHz; temperature -40...+105 °C, resolution 1 °C
• Output: RS-485, Modbus RTU, 9.6/19.2/38.4 kbaud
• Supply: 10...30 V DC, 9 mA at 30 V DC
• Housing: stainless steel 316L, 30 mm; mounting by M4 screw, epoxy, thermal tape or magnet
• Environment: IP69K, -40...+105 °C
• Connection: 150 mm cable with M12 5-pin male connector

High-frequency enveloping mode is available for bearing fault diagnostics, and the FMax setting (325...5300 Hz) trades bandwidth against frequency resolution. Configuration and firmware updates are done with the SNAP SIGNAL software and the BWA-UCT-900 USB adapter cable.

Shock per MIL-STD-202G, method 213B (100 g). FCC Part 15 Class B, ICES-003(B); CE and UKCA declaration of conformity.

QM30VT3-MQP is a Banner QM30VT3 3-axis vibration and temperature sensor for condition monitoring of motors, pumps, fans and other rotating machines. It works as a Modbus RTU server on RS-485 and delivers pre-processed values such as RMS velocity, high-frequency RMS acceleration and peak velocity per axis.

• Accuracy: vibration ±5 % at 25 °C; temperature ±3 °C
• Measuring range: vibration ±16 g, 0...65.5 mm/s RMS, 6 Hz...5.3 kHz; temperature -40...+105 °C, resolution 1 °C
• Output: RS-485, Modbus RTU, 9.6/19.2/38.4 kbaud
• Supply: 10...30 V DC, 9 mA at 30 V DC
• Housing: aluminium, 30 mm; mounting by M4 screw, epoxy, thermal tape or magnet
• Environment: IP67, -40...+105 °C
• Connection: 150 mm cable with M12 5-pin male connector

High-frequency enveloping mode is available for bearing fault diagnostics, and the FMax setting (325...5300 Hz) trades bandwidth against frequency resolution. Configuration and firmware updates are done with the SNAP SIGNAL software and the BWA-UCT-900 USB adapter cable.

Shock per MIL-STD-202G, method 213B (100 g). FCC Part 15 Class B, ICES-003(B); CE and UKCA declaration of conformity.

IM12-22EX-R/24VDC is a 2-channel TURCK isolating switching amplifier with intrinsically safe input circuits and two relay outputs, each with one NO contact. Front switches set the output mode (NO/NC) and signal multiplexing, where channel 1 drives both outputs.

• Channels: 2 inputs for NAMUR sensors (EN 60947-5-6) or potential-free contacts
• Outputs: 2 relays, 1 NO each, 30 V DC / 250 V AC, ≤2 A, ≤500 VA / 60 W
• Supply: 10...30 V DC (24 V DC nominal)
• Housing: polycarbonate/ABS, 104 x 18 x 110 mm, DIN rail (NS35) or panel mounting
• Connection: screw terminals, 1 x 2.5 mm² / 2 x 1.5 mm²
• Environment: IP20, -25...+60 °C

Used to pass NAMUR sensor or potential-free contact signals from a hazardous area to a relay input in the control cabinet. A green Pwr LED shows readiness and a yellow LED shows the output switching state.

Approvals: ATEX, CFMUS, TR CU.

Camera + Bell + Siren + App

Keep your front door secure with our 4-in-1 video doorbell & chime kit. Install in minutes and get a video system that streams live 2K video. Or, choose an Arlo Secure Subscription (sold separately) to save video clips in the cloud and look back at them via the app. Recieve a video call when the bell is pressed and speak in real-time to visitors with two-way audio. Plug in the chime to hear notifications in your home when someone presses your doorbell or when motion is detected. Plus, take instant action and scare away trespassers with the built-in intruder alarm. *Battery not removable, charge your video doorbell inside or hardwire it for continuous power.

• VARIETY OF TRACKERS: A selection of tiles that allow you to track keys, wallet, remote controls & more. Keep an eye on more for less money with our multipacks or give them a tracker to your loved ones
• Find your stuff: let your misplaced Tile ring or track them in the free app
• Find your phone: is the phone hidden under a pillow? Let it ring with your Tile - even when it's muted
• Stay safe with SOS - Unobtrusively trigger an SOS notification to your loved ones in uncertain situations.
• USE WITH LIFE360 - Add your Tiles to Life360, a top-notch app for family connections and security, to see everything and everyone on the same map
• Works with iOS and Android: the free Tile app is suitable for all households and individuals
• Specifications: 105m Bluetooth range Up to 3 years of battery life. Waterproof (IP68 certified)
• GIVE THE GIFT TO FIND: Tile is a simple and functional gift for family and friends

• VARIETY OF TRACKERS: A selection of tiles that allow you to track keys, wallet, remote controls & more. Keep an eye on more for less money with our multipacks or give them a tracker to your loved ones
• Find your stuff: let your misplaced Tile ring or track them in the free app
• Find your phone: is the phone hidden under a pillow? Let it ring with your Tile - even when it's muted
• Stay safe with SOS - Unobtrusively trigger an SOS notification to your loved ones in uncertain situations.
• USE WITH LIFE360 - Add your Tiles to Life360, a top-notch app for family connections and security, to see everything and everyone on the same map
• Works with iOS and Android: the free Tile app is suitable for all households and individuals
• Specifications: 105m Bluetooth range Up to 3 years of battery life. Waterproof (IP68 certified)
• GIVE THE GIFT TO FIND: Tile is a simple and functional gift for family and friends

PKG4M-5/TEL is a TURCK connection cable with a straight M8 female connector (4-pin) on one end and open cores on the other.

• Connector: M8 x 1, female, straight, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 50 VAC / 60 VDC, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

BS6-0 is a TURCK field-wireable M16 x 0.75 male connector, straight, 6-pin, for 6...8 mm cable.

• Connector: M16 x 0.75, male, straight, 6-pin, silver-plated bronze (CuSn) contacts, more than 500 mating cycles
• Ratings: 5 A, 60 V, contact resistance ≤5 mΩ
• Connection: conductors up to 0.75 mm², cable diameter 6...8 mm, PG9 screw-in thread
• Housing: black PA body, black PBT (UL 94 V0) contact carrier, nickel-plated die-cast zinc (GD-Zn) coupling nut
• Environment: -40...+95°C fixed

PKG4M-0.3-PSG4M/TEL is a TURCK M8 connection cable with straight female and male connectors, 4-pin, and a black PVC jacket.

• Connectors: M8 x 1 female and M8 x 1 male, both straight, 4-pin each, gold-plated brass (CuZn) contacts, more than 100 mating cycles
• Cable: 0.3 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², PVC core insulation, core colours BN, WH, BU, BK
• Ratings: 4 A, 50 V AC/60 V DC
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

RKC8T-15/TEL is a TURCK connection cable with a straight M12 female connector (8-pin) on one end and open cores on the other. The cable has a black PVC jacket.

• Connector: M12 x 1, female, straight, A-coded, 8-pin, gold-plated brass (CuZn) contacts
• Cable: 15 m, PVC, black, Ø 5.7 mm, 8 x 0.25 mm², core colours BN, WH, BU, BK, GY, PK, VT, OG
• Ratings: 2 A, 30 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

TL50BGYRAOSQ is a Banner TL50 series 50 mm LED tower light with 4 colour segments: blue, green, yellow, red, from the bottom up, topped by a sealed omnidirectional audible alarm. Each colour has its own input wire and the inputs are bimodal, so the tower can be driven from either PNP or NPN controller outputs.

• Colours: blue 470 nm, green 528 nm, yellow 590 nm, red 625 nm
• Audible: continuous tone, 2.1 kHz, up to 99 dB at 1 m
• Inputs: bimodal (PNP or NPN), one per colour, response 10 ms
• Supply: 18-30 V DC or 24 V AC 50/60 Hz, up to 45 mA per colour, alarm 45 mA
• Housing: Ø50 x 278.7 mm, ABS base and covers, polycarbonate light segments, black, M30x1.5 base mount
• Environment: IP67, -20...+50 °C
• Connection: integral M12 male connector, 8-pin

The tower connects through a separately ordered 8-pin M12 female cordset. The omnidirectional alarm sounds at a fixed 99 dB with no intensity adjustment.

Vibration tested to IEC 60068-2-6, shock to IEC 60068-2-27 (30 g, 11 ms).
