T30SP6FF200Q is a Banner T30 series fixed-field photo sensor with a 200 mm cutoff and an infrared beam, in a right-angle housing with a 30 mm threaded lens. Two detectors compare the light returned from near and far, so the sensor detects objects up to 200 mm and ignores backgrounds beyond.

• Sensing range: 200 mm cutoff, fixed
• Output: complementary PNP, Light Operate (black) and Dark Operate (white), 150 mA each
• Response: 3 ms; repeatability 750 µs
• Supply: 10-30 V DC, 35 mA
• Housing: right-angle, M30x1.5 thread, PBT polyester, epoxy-encapsulated, jam nut included
• Environment: IP69K, NEMA 4X, -40...+70 °C
• Connection: integral M12 4-pin male connector

Backgrounds must sit beyond the cutoff; a mirror-like background can still switch the sensor, which is avoided by angling it or using a matte surface. Rotating the sensor 90° stops an object moving across the face beyond the cutoff from triggering it. The white-wire output can be wired as a normally open marginal-signal alarm instead of Dark Operate. There is no sensitivity adjustment.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B (75 g operating). UL, CE and UKCA approved.

SMBQ5XFA is a Banner swivel bracket that fixes a sensor to the T-slot of an extruded aluminium profile. Tilt and pan adjustment lets the beam be aligned after the bracket is fixed.

• Fits: Banner Q5X, QM42, PD45, PD49, QC50
• Adjustment: tilt and pan
• Material: zinc die-cast (Zamak)
• Hardware: 3/8-16 x 4 in socket head cap screw included

Some sensors can also be side-mounted with the 3 mm screws supplied with the sensor.

QS18VP6AFF200Q5 is a Banner QS18 series photo sensor with adjustable foreground suppression and a visible red 640 nm LED beam. It is aimed at a fixed background up to 200 mm away and switches when an object blocks the light coming back from that background, whatever the object's colour or shape.

• Sensing range: cutoff adjustable 30-200 mm, objects detected up to the sensor face
• Output: complementary PNP, Light Operate and Dark Operate, 100 mA total
• Response: 2.8 ms ON/OFF; repeatability 250 µs
• Supply: 10-30 V DC, < 16 mA
• Housing: ABS, acrylic lens
• Environment: IP67, NEMA 6, -20...+55 °C
• Connection: 150 mm PVC cable with M12 4-pin male connector

Typical use is a sensor above a conveyor belt: the belt is the background, and boxes of any colour are detected once they are taller than the minimum separation, more than 10 mm on a black belt at 200 mm. The cutoff is set with a five-turn adjustment screw.

O300.GR-GW1T.72N is a miniature photoelectric sensor from the Baumer O300 series with background suppression and a 30...300 mm switching distance. The sensor detects an object from the angle of the reflected light, so the object's colour and surface gloss do not move the switching point, while everything beyond the taught distance is ignored.

• Switching distance: 30...300 mm, adjustable by qTeach
• Output: push-pull, light / dark operate, 100 mA
• Supply: 10...30 V DC, typical consumption 30 mA
• Housing: rectangular, plastic (ASA, PMMA), PMMA optics, 12.9 x 32.3 x 23 mm
• Environment: IP 67, -30...+60 °C
• Connection: M8 connector, 4 pin

The sensor suits presence and position checks on conveyors, packaging machines and assembly stations where mounting space is tight and the background sits close behind the object. Sensitivity is set with qTeach by holding a ferromagnetic tool against the housing, so there are no buttons and no mechanical adjusters on the body.

OR18.RR-PW1Z.71OV/0010 is a Baumer M18 retro-reflective photo sensor with a polarisation filter and a 3.5 m operating range. The polarisation filter lets the sensor tell the reflector from shiny objects, so glossy packaging or metal parts do not hold the output switched. It has no sensitivity adjustment, so the setting cannot be changed on the machine.

• Operating range: 3.5 m (nominal 4.5 m), red LED 660 nm, fixed sensitivity
• Output: PNP, max. 100 mA, light/dark operate; response time < 1 ms
• Supply: 12...30 V DC, max. 40 mA
• Housing: M18 x 1 threaded, 44.8 mm long, ABS plastic, PMMA lens
• Environment: IP67; -25...+55 °C
• Connection: M12 4-pin connector on a 100 mm flying lead

The short 44.8 mm body with a 100 mm lead fits where there is no room behind the mounting plate for a rear connector and cordset. Pin 2 (white) is a control input. A green LED shows alignment and lens soiling, a yellow LED shows the output state.

T183EQ1 is the emitter of a Banner T18 series AC-powered opposed-mode photo sensor pair, in a right-angle 18 mm housing. Its infrared 950 nm beam reaches a separate T18 AC receiver up to 20 m away; the emitter itself has no output.

• Sensing range: 20 m with a T18 AC receiver
• Output: none (emitter)
• Supply: 20-250 V AC, 50/60 Hz, 20 mA average
• Housing: right-angle, M18x1 thread, PBT polyester, polycarbonate lens, epoxy-encapsulated
• Environment: IP67, NEMA 6P, IP69K, -40...+70 °C
• Connection: integral 1/2"-20UNF Micro 4-pin male connector

The AC supply suits machines without a 24 V DC circuit. The connector is the 1/2" Micro type, not M12, so it needs a matching Micro cordset. A green LED shows power.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B (75 g operating). UL, CE and UKCA approved.

QS30R is the receiver of a Banner QS30 series opposed-mode photo sensor pair. It switches when an object breaks the infrared beam from a separate QS30E emitter up to 60 m away.

• Sensing range: 60 m with a QS30E emitter, effective beam 18 mm
• Output: bipolar, one PNP and one NPN, Light or Dark Operate selected by the grey wire, 100 mA each
• Response: 5 ms ON/OFF
• Supply: 10-30 V DC, < 40 mA
• Housing: ABS, acrylic lens, M30x1.5 threaded barrel or side mounting, 3 mm hardware included
• Environment: IP67, NEMA 6, -20...+70 °C
• Connection: 2 m PVC cable, 5 wires

Grey wire low (0-3 V) gives Light Operate, open or high gives Dark Operate. A large amber LED on the back of the housing shows the output state from a distance; the top LEDs show power and light sensed, and flash at marginal excess gain. Works with a QS30E emitter, ordered separately.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

QS30E is the emitter of a Banner QS30 series opposed-mode photo sensor pair. It sends an infrared 875 nm beam to a separate QS30R receiver up to 60 m away; an object is detected when it breaks the beam.

• Sensing range: 60 m with a QS30R receiver, effective beam 18 mm
• Output: none (emitter)
• Supply: 10-30 V DC, < 40 mA
• Housing: ABS, acrylic lens, M30x1.5 threaded barrel or side mounting, 3 mm hardware included
• Environment: IP67, NEMA 6, -20...+70 °C
• Connection: 2 m PVC cable

The emitter has no output and works only with a QS30R receiver, ordered separately. A green LED indicator shows power.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

LX12RQ is the receiver of a Banner LX series part-sensing light curtain with a 295 mm array. Paired with the LX12EQ emitter it detects small parts and flat items passing anywhere through the curtain; the outputs conduct while any beam is blocked.

• Sensing range: 150 mm...2 m between emitter and receiver; 9.5 mm minimum object size
• Output: bipolar, one PNP and one NPN, 125 mA each
• Response: 3.2 ms ON, 8.5 ms OFF including 5 ms OFF-delay
• Supply: 10-30 V DC, < 1 W
• Housing: aluminium, die-cast zinc end caps, acrylic window
• Environment: IP65, -20...+70 °C
• Connection: 150 mm PVC cable with M12 5-pin male connector

Connecting the grey wire to 0-2 V DC switches the pair to reduced range (150...600 mm). The emitter and receiver need no synchronisation wire.

LX12EQ is the emitter of a Banner LX series part-sensing light curtain with a 295 mm array. Paired with the LX12RQ receiver it forms a crosshatched beam pattern that detects small parts and flat items, down to the thickness of an envelope, passing anywhere through it.

• Sensing range: 150 mm...2 m between emitter and receiver; 9.5 mm minimum object size
• Array: 295 mm, infrared beams at 9.5 mm spacing
• Supply: 10-30 V DC, < 1 W
• Housing: aluminium, die-cast zinc end caps, acrylic window
• Environment: IP65, -20...+70 °C
• Connection: 150 mm PVC cable with M12 5-pin male connector

Connecting the grey wire to 0-2 V DC switches the pair to reduced range (150...600 mm). The emitter and receiver need no synchronisation wire.

Q45BB6FQ5 is a Banner Q45BB6 series photo sensor for glass fibre optics, with an infrared 880 nm light source. The fibres carry the light to and from the sensing point, and the high excess gain lets opposed glass fibres work in hostile environments.

• Sensing range: depends on the fibre and sensing mode
• Output: bipolar, one PNP and one NPN, Light or Dark Operate selected by switch, 250 mA each (150 mA at +70 °C)
• Response: 2 ms ON/OFF; repeatability 0.5 ms
• Supply: 10-30 V DC, < 50 mA
• Housing: reinforced thermoplastic polyester, o-ring-sealed polycarbonate cover, acrylic lenses, stainless steel hardware
• Environment: IP67, NEMA 6, -40...+70 °C, built for 1200 psi washdown
• Connection: integral M12 4-pin male connector

Glass fibre optics are ordered separately; with miniature bifurcated fibres from 0.5 mm bundle diameter it also works in diffuse mode. Sensitivity is set with a multi-turn potentiometer under the sealed cover. Indicators: green for power, red for received signal (pulses with signal strength), amber for output. Optional plug-in modules add output timing or a signal strength display.

BR23S is a Banner glass fibre for diffuse mode with an array sensing end: the fibres end in a 9.7 x 0.81 mm row inside a 25.4 x 19.1 mm rectangular tip.

• Type: diffuse, array sensing end 9.7 x 0.81 mm
• Tip: rectangular, 25.4 x 19.1 mm, plastic
• Fibre: glass, core Ø3.2 mm, length 914 mm, minimum bend radius 25 mm
• Sheath: stainless steel monocoil

O500H.SP-GW1J.PVCK is a Baumer O500 series SmartReflect light barrier in a hygienic 1.4404 (V4A) stainless steel housing. Instead of a reflector the sensor uses the background - the machine surface behind the object - and treats every interruption of the beam between itself and the taught background at 60...600 mm as an object, so no reflector and no receiver has to be mounted on the opposite side.

• Background position Sde: 60...600 mm, set by teach-in and over IO-Link
• Output: push-pull, light / dark operate, 100 mA
• Communication: IO-Link V1.1, filter functions, qTeach lock
• Supply: 10...30 V DC, typical consumption 30 mA
• Housing: stainless steel 1.4404 (V4A), PMMA optics, 20.2 x 47.7 x 36.4 mm
• Environment: IP 68/69K and proTect+, -25...+60 °C
• Connection: 2 m cable, 4 cores

The sensor suits presence checks in food and beverage production, where the machine is washed with hot pressurised water and where there is no room for a reflector or a receiver opposite the sensor. The background position is set by magnetic teach or over IO-Link, so there are no adjusters on the housing.

The housing carries Ecolab approval and the hygienic design follows the EHEDG guidelines.

Q20NDLQ7 is a Banner Q20 series long-range diffuse photo sensor with a visible red 624 nm beam. It detects an object by the light the object reflects back to the sensor, so no reflector or separate receiver is needed.

• Sensing range: 800 mm on a 90 % white test card
• Output: NPN, complementary Light Operate and Dark Operate outputs, 100 mA
• Response: 850 µs ON/OFF; repeatability 90 µs
• Supply: 10-30 V DC, < 18 mA
• Housing: ABS, PMMA lenses
• Environment: IP67, -20...+60 °C
• Connection: integral M8 4-pin male connector

A green LED indicator shows power; the amber one shows the output state and flashes at marginal excess gain. Sensitivity is set with a single-turn potentiometer.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

T18-2VNRL-2M is a Banner T18-2 series opposed-mode receiver, used with a T18-2 emitter. The right-angle 18 mm threaded housing has epoxy-encapsulated electronics and food-grade plastics, for wet and washdown areas.

• Sensing range: 25 m with a T18-2 emitter
• Output: complementary NPN (NO and NC), 100 mA total up to +55 °C; response 1.5 ms ON / 1 ms OFF
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, 18 mm thread, PBT polyester, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C; ECOLAB chemical compatibility
• Connection: 2 m PVC cable

Vibration per MIL-STD-202G method 201A, shock per method 213B (75 g operating).

SMB30MM is a Banner right-angle bracket for sensors with a 30 mm thread. Curved mounting slots let the sensor be turned before the screws are tightened.

• Sensor hole: Ø30.1 mm
• Mounting: M6 (¼") hardware, 42.6 x 7 mm slot and Ø6.4 mm hole
• Material: 12-gauge stainless steel

QS18VP6RQ8 is the receiver of a Banner QS18 series opposed-mode photo sensor pair. It switches when an object breaks the beam from a separate QS186E emitter up to 20 m away.

• Sensing range: 20 m with a QS186E emitter, effective beam 13 mm
• Output: complementary PNP, Light Operate and Dark Operate, 100 mA each
• Response: 750 µs ON, 375 µs OFF; repeatability 100 µs
• Supply: 10-30 V DC, < 25 mA
• Housing: ABS, 18 mm threaded nose or side mounting, 3 mm hardware included
• Environment: IP67, -20...+70 °C
• Connection: integral M12 4-pin male connector

Works with a QS186E emitter, ordered separately. A green LED indicator shows power; the amber one shows light sensed and flashes at marginal excess gain.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

O300.RP.T-GW1J.72N is a Baumer O300 series retro-reflective photoelectric sensor for detecting transparent objects - glass and PET bottles, film and clear packaging - at up to 3.5 m. Switching is triggered by the attenuation of the returned signal, and the threshold can be set to 10, 20 or 30 %, so the sensor also responds to an object that weakens the signal only partly.

• Range: 3.5 m actual, 4 m nominal, with polarisation filter
• Signal attenuation threshold: 10 %, 20 % or 30 %
• Output: push-pull, light / dark operate, 100 mA
• Communication: IO-Link V1.1, filter functions, qTeach lock
• Supply: 10...30 V DC, typical consumption 30 mA
• Environment: IP 67, -30...+60 °C
• Connection: M8 connector, 4 pin

The sensor suits checks on empty glass and PET bottles, film and clear packaging on filling and packaging lines. The attenuation threshold and the filter functions can be changed over IO-Link from the control system, while qTeach can be locked so that the settings cannot be overwritten by accident.

T30SN6FF200 is a Banner T30 series fixed-field photo sensor with a 200 mm cutoff and an infrared beam, in a right-angle housing with a 30 mm threaded lens. Two detectors compare the light returned from near and far, so the sensor detects objects up to 200 mm and ignores backgrounds beyond.

• Sensing range: 200 mm cutoff, fixed
• Output: complementary NPN, Light Operate (black) and Dark Operate (white), 150 mA each
• Response: 3 ms; repeatability 750 µs
• Supply: 10-30 V DC, 35 mA
• Housing: right-angle, M30x1.5 thread, PBT polyester, epoxy-encapsulated, jam nut included
• Environment: IP69K, NEMA 4X, -40...+70 °C
• Connection: 2 m PVC cable, 4 wires

Backgrounds must sit beyond the cutoff; a mirror-like background can still switch the sensor, which is avoided by angling it or using a matte surface. Rotating the sensor 90° stops an object moving across the face beyond the cutoff from triggering it. The white-wire output can be wired as a normally open marginal-signal alarm instead of Dark Operate. There is no sensitivity adjustment.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B (75 g operating). UL, CE and UKCA approved.

OR18.SP-GW1B.7BO is a Baumer M18 SmartReflect light barrier that works against a fixed background at 55...300 mm instead of a separate reflector. The sensor is taught to the background position and switches when an object interrupts the beam in front of it, at up to 85-90 % of the background distance. Teaching is done with qTeach on the housing or through the external teach input.

• Background position: 55...300 mm; detection range 85-90 % of the background distance; red PinPoint LED 630 nm
• Output: push-pull, max. 100 mA, light/dark operate; response time < 0.49 ms
• Supply: 10...30 V DC, max. 45 mA
• Housing: M18 x 1 threaded, 65 mm long, nickel-plated brass, PA lens
• Environment: IP67; -25...+60 °C
• Connection: M12 4-pin connector

Suited to positions where a machine part, guide or conveyor belt sits behind the object and no reflector can be mounted. The push-pull output works with both PNP and NPN controller inputs. Pin 2 (white) is the teach input, so the sensor can be re-taught from the controller after a changeover.

O300W.GP-GW1J.PVN is a Baumer O300W series photoelectric sensor with background suppression and a 30...200 mm switching distance in a 1.4404 (V4A) stainless steel housing. The housing meets IP 68/69K and proTect+ and carries Ecolab approval, so the sensor does not have to be removed for washdown cycles.

• Switching distance: 30...200 mm, adjustable by teach-in and over IO-Link
• Output: push-pull, light / dark operate, < 100 mA
• Communication: IO-Link V1.1, filter functions, qTeach lock
• Supply: 10...30 V DC, typical consumption 30 mA
• Housing: stainless steel 1.4404 (V4A), PMMA optics, 16.5 x 34.7 x 28.2 mm
• Environment: IP 68/69K and proTect+, Ecolab, -25...+60 °C
• Connection: M8 connector, 4 pin

The sensor suits checks on bottles, cans and packaging in food and beverage production, where machines are washed regularly with hot pressurised water, foam and disinfectants. The switching distance is set with qTeach or over IO-Link, so there are no adjusters on the housing for dirt to collect in.

OR18.RR-PW1P.71O is a Baumer M18 retro-reflective photo sensor with a polarisation filter and a 3.5 m operating range. The polarisation filter lets the sensor tell the reflector from shiny objects, so glossy packaging or metal parts do not hold the output switched. Sensitivity is set with a 270° potentiometer on the housing.

• Operating range: 3.5 m (nominal 4.5 m), red LED 660 nm
• Output: PNP, max. 100 mA, light/dark operate; response time < 1 ms
• Supply: 12...30 V DC, max. 40 mA
• Housing: M18 x 1 threaded, 67.2 mm long, ABS plastic, PMMA lens
• Environment: IP67; -25...+55 °C
• Connection: M12 4-pin connector

Used for object detection across conveyors and gates where a reflector can be mounted opposite the sensor. Pin 2 (white) is a control input. A green LED shows alignment and lens soiling, a yellow LED shows the output state.

OR18W.RR-PW1P.9VO is the washdown version of the Baumer OR18 M18 retro-reflective photo sensor: the same 3.5 m range and polarisation filter in a stainless steel 1.4404 (V4A) housing rated IP 67/69K instead of the plastic one.

• Housing: stainless steel 1.4404 (V4A), M18 x 1 thread, 67.2 mm long, PMMA lens
• Environment: IP 67/69K; -25...+55 °C
• Operating range: 3.5 m actual (nominal 4.5 m), pulsed red LED 660 nm, polarisation filter
• Output: PNP, < 100 mA, light/dark operate; response time < 1 ms
• Supply: 12...30 V DC, max. 40 mA
• Connection: M12 4-pin connector

Suited to food, beverage and packaging lines that are washed down at high pressure, where a plastic sensor body would not survive the cleaning cycle. Sensitivity is set with a 270° potentiometer and pin 2 (white) is a control input. A green LED shows alignment against the reflector and lens soiling, a yellow LED the output state.

QS18EP6DQ8 is a Banner QS18E Expert series diffuse photo sensor with an infrared beam and an 800 mm range. The switching threshold is taught with the push button or over the remote wire instead of being set with a potentiometer.

• Sensing range: 800 mm
• Output: one PNP, Light or Dark Operate selectable, 100 mA; selectable 30 ms OFF-delay
• Response: 600 µs ON/OFF; repeatability 75 µs
• Supply: 10-30 V DC, < 35 mA (10-24 V DC above +55 °C)
• Housing: ABS, PMMA lens, 18 mm threaded nose or side mounting
• Environment: IP67, NEMA 6, -20...+70 °C
• Connection: integral M12 4-pin male connector, white wire as remote teach input

Static and dynamic TEACH, Light Set, Dark Set and Window Set are available; the remote input can also lock the push button. A green LED indicator shows power; the amber one shows the output state and flashes at a marginal signal.

LX3EQ is the emitter of the Banner LX series light curtain, with a 67 mm light screen for part sensing. Infrared LEDs are spaced at 9.5 mm and fire in sequence, so together with an LX receiver of the same length they form a crosshatched beam pattern that also detects thin and narrow objects. No synchronisation wire is needed between emitter and receiver.

• Distance between emitter and receiver: 0.3...2 m (Normal), 0.15...0.6 m (Reduced)
• Output: none, the unit is an emitter
• Supply: 10...30 V DC, less than 1 W
• Housing: aluminium profile, die-cast zinc endcaps, acrylic lens; overall length 113.4 mm
• Environment: IP65, -20...+70 °C
• Connection: 150 mm cable with an M12 5-pin male connector

The light curtain is used for part ejection verification and package detection on conveyors, where the object may cross the beam field at any point. The range is selected with the grey wire: 5...30 V DC gives Normal, 0...2 V DC gives Reduced range, and the emitter LED indicators show the selection. The green LED is on when power is applied and the emitter is good; the red LED is on in reduced range. The emitter must be paired with an LX receiver of the same length and range, and the device is not intended for personnel protection.

Meets CE and UKCA requirements; UL listing E71083, Class 2 power, UL Environmental Rating Type 1.

LX3RQ is the receiver of the Banner LX series light curtain, with a 67 mm light screen for part sensing. Photodiodes are spaced at 9.5 mm and recognise each emitter pulse separately, so the crosshatched beam pattern also detects thin objects such as a sheet of paper. In the standard range the smallest detectable object is 9.5 mm in diameter.

• Distance between emitter and receiver: 0.3...2 m (Normal), 0.15...0.6 m (Reduced)
• Output: bipolar, one PNP and one NPN output at the same time, 125 mA each, conducting while the beam is blocked
• Response time: 0.8 ms on, 6 ms off with a 5 ms pulse stretcher
• Supply: 10...30 V DC, less than 1 W
• Housing: aluminium profile, die-cast zinc endcaps, acrylic lens; overall length 113.4 mm
• Environment: IP65, -20...+70 °C
• Connection: 150 mm cable with an M12 5-pin male connector

The receiver is used for part ejection verification and package detection on conveyors, where the object may cross the beam field at any point. The range is selected with the grey wire: 5...30 V DC gives Normal, 0...2 V DC gives Reduced range. The amber LED shows a conducting output, the bicolour LED shows green in Normal and red in Reduced range, and a flashing red light indicates a receiver hardware fault. Resolution is best in the middle 80 % of the beam field, the receiver must be paired with an LX emitter of the same length and range, and the device is not intended for personnel protection.

Meets CE and UKCA requirements; UL listing E71083, Class 2 power, UL Environmental Rating Type 1.

T18-2VPFF100-Q8 is a Banner T18-2 series fixed-field photo sensor with a 100 mm cutoff and a visible red beam, in a right-angle 18 mm housing for washdown areas. It detects objects closer than the cutoff and ignores everything beyond it, so a background just behind the target does not switch the output.

• Sensing range: 100 mm cutoff, fixed
• Output: complementary PNP, Light Operate (black wire) and Dark Operate (white wire), 100 mA total (50 mA above +55 °C)
• Response: 2 ms ON, 2 ms OFF; repeatability 200 µs
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, M18x1 thread, PBT polyester, PMMA window, epoxy-encapsulated electronics
• Environment: IP67, IP68, IP69K, -40...+70 °C
• Connection: integral M12 4-pin male connector

On dark targets the cutoff moves slightly closer: to 95 % of the nominal distance on an 18 % grey card and 90 % on a 6 % black card. There is no sensitivity adjustment. A green LED shows power and flashes at a marginal signal; the amber LED shows that the black-wire output is on.

ECOLAB certified chemical compatibility. Vibration tested to MIL-STD-202G, method 201A; shock to method 213B (75 g operating).

QS18VP6AF350Q5 is a Banner QS18 series photo sensor with adjustable background suppression and a visible red 640 nm LED beam. Objects up to the set cutoff are detected regardless of colour, while anything beyond it is ignored.

• Sensing range: cutoff adjustable 30-350 mm
• Output: complementary PNP, Light Operate and Dark Operate, 100 mA total
• Response: 2.8 ms ON/OFF; repeatability 250 µs
• Supply: 10-30 V DC, < 16 mA
• Housing: ABS, acrylic lens
• Environment: IP67, -20...+55 °C
• Connection: 150 mm PVC cable with M12 4-pin male connector

The cutoff distance is set with a five-turn adjustment screw. A crosstalk algorithm lets two sensors work close to each other. A green LED indicator shows power; the amber one shows light sensed and flashes at a marginal condition.

QS30FF200Q is a Banner QS30 series fixed-field photo sensor with a visible red 680 nm beam and a 200 mm cutoff. It compares the light returned to a near and a far detector, so it detects low-reflectivity objects in front of the cutoff and ignores the background behind it.

• Sensing range: 200 mm cutoff, tolerance ±5 %; spot 7 mm at cutoff
• Output: bipolar, one PNP and one NPN, Light or Dark Operate selected by the grey wire, 100 mA each
• Response: 2 ms; repeatability 500 µs
• Supply: 10-30 V DC, < 40 mA
• Housing: ABS, acrylic lens, M30x1.5 threaded barrel or side mounting, 3 mm hardware included
• Environment: IP67, NEMA 6, -20...+70 °C
• Connection: integral M12 5-pin male connector

The cutoff is fixed, so the sensor needs no sensitivity adjustment; backgrounds must sit beyond 200 mm, and mirror-like backgrounds can cause false switching. Grey wire open or high gives Light Operate, low gives Dark Operate. A large amber LED on the back shows the output state.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

SM312WQD is a Banner MINI-BEAM divergent diffuse photo sensor with an infrared 880 nm beam and a 130 mm range. The wide beam detects objects by the light they reflect back, without precise aiming at the target.

• Sensing range: 130 mm
• Output: bipolar, one PNP and one NPN, Light or Dark Operate selected by switch, 150 mA each (100 mA at +70 °C)
• Response: 1 ms; repeatability 0.3 ms
• Supply: 10-30 V DC, < 25 mA
• Housing: reinforced thermoplastic polyester, fully encapsulated, o-ring sealed, acrylic lens
• Environment: IP67, -20...+70 °C
• Connection: integral M12 4-pin male connector

Sensitivity is set with a 15-turn potentiometer and the LO/DO switch, both under a gasketed clear cover on the rear panel. The rear AID LED pulses faster as the received signal gets stronger, which helps when setting up.

PVS28D100QP is a Banner PVS28 parts verification sensor and multicolour indicator in one 28 mm wide, 100 mm long housing. Two infrared beams detect a hand or object up to a set distance and ignore everything beyond it, so a bin can be confirmed touchlessly.

• Sensing range: 20...500 mm, up to 1000 mm in retroreflective mode
• Output: PNP or NPN, 150 mA
• Response: 120 ms (240 ms in retroreflective mode)
• Supply: 12-30 V DC, 35 mA typical at 24 V DC
• Housing: polycarbonate, ABS end caps, 2 beams at 50 mm spacing
• Environment: IP54, -20...+50 °C
• Connection: 150 mm PVC cable with M12 5-pin male connector

The switch point is taught through the grey remote-input wire. Colours, flash patterns and output behaviour (latching, ON or OFF delay) are set with Banner Pro Editor software and the Pro Converter Cable, ordered separately.

Vibration per IEC 60068-2-6, shock per IEC 60068-2-27.

QS30EXSH2OQ5 is the super high-power emitter of a Banner QS30H2O opposed-mode water sensor pair, used with a QS30ARXSH2O or QS30RRXSH2O receiver over up to 8 m. The 1450 nm infrared beam is tuned to an absorption band of water: it passes through many plastic and glass containers but is attenuated by water-based liquids, so the pair sees whether a container is filled.

• Sensing range: 8 m with a super high-power receiver, 13 mm effective beam
• Output: none (emitter); beam inhibit input on the white wire
• Supply: 10-30 V DC, < 80 mA
• Housing: PC/ABS, PMMA window, M30x1.5 threaded barrel or side mounting
• Environment: IP67, NEMA 6, 1200 psi washdown per NEMA PW12, -20...+60 °C
• Connection: 150 mm PVC cable with M12 5-pin male connector

Works only with the super high-power QS30ARXSH2O (light operate) or QS30RRXSH2O (dark operate) receiver, ordered separately. Pulling the white wire low switches the beam off, so the receiver can be checked before the machine starts. Modulation frequency A or B is chosen with the grey wire and must match on emitter and receiver, so neighbouring pairs do not interfere.

QS30ARXSH2OQ5 is the super high-power receiver of a Banner QS30H2O opposed-mode water sensor pair, used with a QS30EXSH2O emitter over up to 8 m. The 1450 nm infrared beam is tuned to an absorption band of water: it passes through many plastic and glass containers but is attenuated by water-based liquids, so the pair sees whether a container is filled.

• Sensing range: 8 m with a QS30EXSH2O emitter
• Output: bipolar, one PNP and one NPN, Light Operate, 100 mA
• Response: 10 ms ON/OFF, repeatability 5 ms at 10x excess gain or more; 30 ms and 25 ms at 2-10x
• Supply: 10-30 V DC, < 65 mA
• Housing: PC/ABS, PMMA window, M30x1.5 threaded barrel or side mounting
• Environment: IP67, NEMA 6, 1200 psi washdown per NEMA PW12, -20...+60 °C
• Connection: 150 mm PVC cable with M12 5-pin male connector

The super high-power pair is meant for thick or opaque containers that need the most burn-through power, at a slower response than the standard models. It works only with a super high-power QS30EXSH2O emitter, ordered separately. The output is on while the beam is not blocked. Modulation frequency A or B is chosen with the grey wire and must match on emitter and receiver, so neighbouring pairs do not interfere. An amber AID indicator flashes faster as more light is received.

QS18VN6RQ8 is the receiver of a Banner QS18 series opposed-mode photo sensor pair. It switches when an object breaks the beam from a separate QS186E emitter up to 20 m away.

• Sensing range: 20 m with a QS186E emitter, effective beam 13 mm
• Output: complementary NPN, Light Operate and Dark Operate, 100 mA each
• Response: 750 µs ON, 375 µs OFF; repeatability 100 µs
• Supply: 10-30 V DC, < 25 mA
• Housing: ABS, 18 mm threaded nose or side mounting, 3 mm hardware included
• Environment: IP67, -20...+70 °C
• Connection: integral M12 4-pin male connector

Works with a QS186E emitter, ordered separately. A green LED indicator shows power; the amber one shows light sensed and flashes at marginal excess gain.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

QS186E is the emitter of a Banner QS18 series opposed-mode photo sensor pair. It sends an infrared 940 nm beam to a separate QS18 receiver up to 20 m away; an object is detected when it breaks the beam.

• Sensing range: 20 m with a QS18 receiver, effective beam 13 mm
• Output: none (emitter)
• Supply: 10-30 V DC, < 25 mA
• Housing: ABS, 18 mm threaded nose or side mounting, 3 mm hardware included
• Environment: IP67, -20...+70 °C
• Connection: 2 m PVC cable, 2 wires

The emitter has no output and works only with a QS18VP6R or QS18VN6R receiver, ordered separately. A green LED indicator shows power.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

O200.ER-PV1Z.72CV/H006 is the receiver half of a Baumer O200 miniature through-beam pair with a 6 m nominal range. It carries no sensitivity adjustment - the switching threshold is preset at the factory, so the pair is aligned and left alone.

• Range: actual 5 m, nominal 6 m; smallest detectable object 5 mm (0.5 mm with aperture)
• Output: PNP complementary, light/dark operate, < 50 mA
• Supply: 10...30 VDC, typ. 16 mA at 24 VDC
• Response time: < 0.5 ms
• Housing: rectangular 8 x 25.1 x 14.1 mm, ASA plastic, PMMA optics, M3 stainless steel threaded sleeves
• Environment: IP 67, -25...+50 °C
• Connection: 2 m PVC cable, 4-wire

The fixed threshold suits series machines where the same gap is checked on every unit and commissioning should not include a sensitivity setting that can drift or be turned. A flashing output indicator reports weak signal margin or a soiled lens, and reciprocal influence is suppressed so several pairs can work side by side.

O200.TR-ZZZX.72CV/H006 is the emitter half of a Baumer O200 miniature through-beam pair, with a pulsed red LED at 644 nm and a 6 m nominal range. A test input switches the transmitter diode off, so the receiver channel can be verified from the controller without anyone reaching into the machine.

• Range: actual 5 m, nominal 6 m
• Light source: pulsed red LED, 644 nm
• Alignment: optical axis deviation < 1.5°, green power-on indicator
• Supply: 10...30 VDC, typ. 16 mA at 24 VDC
• Housing: rectangular 8 x 25.1 x 14.1 mm, ASA plastic, PMMA optics, M3 stainless steel threaded sleeves
• Environment: IP 67, -25...+50 °C
• Connection: 2 m PVC cable, 4-wire

A visible red beam is aligned by eye, which is the practical difference from the laser emitters in the same series over long spans. The emitter is used with an O200 through-beam receiver, which carries the switching output - the emitter has none of its own.

T18-2VPFF30-Q5 is a Banner T18-2 series fixed-field photo sensor with a 30 mm cutoff and a small visible red spot, in a right-angle 18 mm housing for washdown areas. It detects objects closer than 30 mm and ignores everything beyond, so a conveyor or machine part just behind the target does not switch the output.

• Sensing range: 30 mm cutoff, fixed
• Output: complementary PNP, Light Operate and Dark Operate
• Light source: visible red LED, 624 nm
• Supply: 10-30 V DC
• Housing: right-angle, 18 mm thread, thermoplastic, acrylic lens, encapsulated
• Environment: IP67, IP68, IP69K, NEMA 4X, -40...+70 °C
• Connection: 150 mm cable with M12 4-pin male connector

The short pigtail puts the M12 connector away from the sensor body, which helps where the right-angle housing sits in a tight spot. There is no sensitivity adjustment.

UL and CE approved.

Q406E is the emitter of a Banner EZ-BEAM Q40 series opposed-mode photo sensor pair. It sends an infrared beam to a separate Q40 receiver up to 60 m away; an object is detected when it breaks the beam.

• Sensing range: 60 m with a Q40 receiver
• Output: none (emitter)
• Supply: 10-30 V DC, reverse-polarity protected
• Housing: thermoplastic, polycarbonate lens, M30 mounting nut included
• Environment: IP67, -40...+70 °C
• Connection: 2 m cable, 2 wires

The emitter has no output and needs a Q40 receiver such as the Q40SP6R, ordered separately.

Q40SP6R is the receiver of a Banner EZ-BEAM Q40 series opposed-mode photo sensor pair. It switches when an object breaks the infrared beam from a separate Q40 emitter up to 60 m away.

• Sensing range: 60 m with a Q406E emitter
• Output: PNP, complementary Light Operate and Dark Operate outputs, 150 mA
• Response: 3 ms ON, 1.5 ms OFF
• Supply: 10-30 V DC, reverse-polarity and short-circuit protected
• Housing: thermoplastic, polycarbonate lens, M30 mounting nut included
• Environment: IP67, -40...+70 °C
• Connection: 2 m cable, 4 wires

Works with a Q406E emitter, ordered separately. A green LED indicator shows power and a yellow one the output state.

FHDK 10P5101/S35A is a Baumer miniature photo sensor with background suppression. It compares where the reflected beam lands on its internal detector, so an object is detected regardless of its colour or surface reflectivity while everything beyond the set distance is ignored. A 35...45 mm focus zone with a 4 mm beam diameter allows small objects to be detected.

• Switching distance: 20...120 mm, adjustable by a 5-turn mechanical potentiometer
• Output: PNP, Light/Dark Operate, < 100 mA
• Supply: 10...30 V DC, typical consumption 20 mA
• Housing: rectangular, 10.4 x 27 x 14 mm, plastic (ASA), PMMA optics
• Environment: IP 67, -25...+65 °C
• Connection: M8 connector, 4-pin

The sensor suits presence and position control in packaging, assembly and sorting machines where the background sits close to the object and dark or glossy surfaces give a standard diffuse sensor a false reading. A flashing light indicator shows insufficient signal margin or a soiled lens, so alignment and maintenance need no instruments. Reciprocal influence is suppressed, so several sensors can be mounted side by side.

S18-2VNDS-Q8 is a Banner S18-2 series diffuse photo sensor in an 18 mm plastic barrel. It detects objects by the visible red light they reflect back, up to 300 mm from the sensor.

• Sensing range: 300 mm on a 90 % white test card
• Output: complementary NPN, Light Operate (black) and Dark Operate (white), 100 mA total
• Response: 1.5 ms ON, 0.75 ms OFF; repeatability 100 µs
• Supply: 10-30 V DC (10-24 V DC above +55 °C), 16 mA
• Housing: ABS, PMMA window, M18x1 threaded barrel, PBT nuts included
• Environment: IP67, -40...+70 °C
• Connection: integral M12 4-pin male connector

The range applies to a white card; darker objects are detected at a shorter distance. Sensitivity is set with a single-turn potentiometer. A green LED shows power and flashes at a marginal signal; the amber LED shows that the black-wire (Light Operate) output is on.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B (75 g operating).

QS186EQ5 is the emitter of a Banner QS18 series opposed-mode photo sensor pair. It sends an infrared 940 nm beam to a separate QS18 receiver up to 20 m away; an object is detected when it breaks the beam.

• Sensing range: 20 m with a QS18 receiver, effective beam 13 mm
• Output: none (emitter)
• Supply: 10-30 V DC, < 25 mA
• Housing: ABS, 18 mm threaded nose or side mounting, 3 mm hardware included
• Environment: IP67, -20...+70 °C
• Connection: 150 mm PVC cable with M12 4-pin male connector

The emitter has no output and works only with a QS18VP6R or QS18VN6R receiver, ordered separately. A green LED indicator shows power.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

QS18VN6RQ5 is the receiver of a Banner QS18 series opposed-mode photo sensor pair. It switches when an object breaks the beam from a separate QS186E emitter up to 20 m away.

• Sensing range: 20 m with a QS186E emitter, effective beam 13 mm
• Output: complementary NPN, Light Operate and Dark Operate, 100 mA each
• Response: 750 µs ON, 375 µs OFF; repeatability 100 µs
• Supply: 10-30 V DC, < 25 mA
• Housing: ABS, 18 mm threaded nose or side mounting, 3 mm hardware included
• Environment: IP67, -20...+70 °C
• Connection: 150 mm PVC cable with M12 4-pin male connector

Works with a QS186E emitter, ordered separately. A green LED indicator shows power; the amber one shows light sensed and flashes at marginal excess gain.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

Transmitter LT110LTB58J

T18-2VPDLIR-Q8 is a Banner T18-2 series diffuse photo sensor with an infrared 850 nm beam, in a right-angle 18 mm housing for washdown areas. It detects objects by the light they reflect back, up to 750 mm from the sensor.

• Sensing range: 750 mm, adjustable
• Output: complementary PNP, Light Operate (black wire) and Dark Operate (white wire), 100 mA total (50 mA above +55 °C)
• Response: 1.5 ms ON, 0.75 ms OFF; repeatability 100 µs
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, M18x1 thread, PBT polyester, PMMA window, epoxy-encapsulated electronics
• Environment: IP67, IP68, IP69K, -40...+70 °C
• Connection: integral M12 4-pin male connector

Sensitivity is set with a single-turn potentiometer. A green LED shows power and flashes at a marginal signal; the amber LED shows that the black-wire output is on.

ECOLAB certified chemical compatibility. Vibration tested to MIL-STD-202G, method 201A; shock to method 213B (75 g operating).

ABR72L16-RDE2 is a Banner ABR 7000 imager-based barcode reader for 1D and 2D codes, including direct part marked (DPM) codes. It has a 2 MP global-shutter sensor, a 16 mm liquid-lens autofocus and red diffused lighting in two software-configurable sectors.

• Imager: 1600 x 1200 px CMOS, global shutter, 45 fps; 16 mm liquid lens autofocus
• Lighting: red diffused DPM, central/peripheral sectors; working distance 40...450 mm
• Inputs and outputs: 2 opto-isolated inputs; 3 outputs NPN/PNP/push-pull, 100 mA
• Communication: RS232 or RS422 main + RS232 auxiliary; Ethernet 10/100 with TCP/IP, EtherNet/IP, Modbus TCP, SLMP, PROFINET-compatible
• Configuration: Barcode Manager software, Smart Teach button, embedded web server
• Supply: 10-30VDC, 0.7 A at 10 VDC to 0.2 A at 30 VDC
• Housing and environment: aluminium, 238 g, IP67 with sealed cables, 0...+45 °C; M12 17-pin male + M12 D-coded 4-pin female

Factory focus is 240 mm with a horizontal field of view of 112 mm; other distances are set with the autofocus. Power and I/O need a 17-pin M12 cordset, and the Ethernet port a D-coded M12 cable. Two class 2 laser pointers aim the reader, and green/red spots and a beeper show good read and no read.

Vibration per EN 60068-2-6, shock per EN 60068-2-27, bump per EN 60068-2-29. Laser class 2 per IEC 60825-1.

950551020 Pastiprinātājs šķiedru optikai S7-5-E-N

SMBZMXMP is a Banner stainless steel plate for flush mounting a sensor of the 3DTOF series. Besides the M4 holes for the sensor it carries a 1/4-20 thread, so the plate can also be fixed to an articulated (Bogen-type) arm.

• Fits: Banner 3DTOF series
• Material: stainless steel
• Hardware: M4 x 0.7 screws included
• Extra mounting: 1/4-20 thread

Q4XTULAF500-Q8 is a Banner Q4X series laser distance sensor with a Class 1 visible red 655 nm laser and a 0-10 V analog output over 25-500 mm. It measures dark and shiny targets alike and shows the reading in volts or millimetres on its four-digit display.

• Resolution: < 0.3 mm at 25-100 mm, < 1 mm at 100-300 mm, < 1.75 mm at 300-500 mm; linearity follows the accuracy curve in the manual
• Measuring range: 25-500 mm
• Output: analog 0-10 V, min. load 2.5 kOhm; response 0.5...2560 ms depending on averaging
• Supply: 12-30 V DC, < 675 mW
• Housing: 316L stainless steel, M18 threaded barrel, PMMA lens cover
• Environment: IP67, IP68, IP69K, -10...+50 °C, ECOLAB certified
• Connection: integral M12 5-pin male connector

The analog span is taught with the push buttons or the remote input, with one-point and two-point teach. The housing withstands aggressive cleaning and typical cutting and lubricating fluids, so it fits washdown food lines and machining centres. Allow 10 minutes of warm-up for best accuracy.

Shock to MIL-STD-202G, method 213B; vibration to MIL-STD-202G, method 201A. Class 1 laser product.

FHDK 10P5101 is a Baumer miniature photo sensor with background suppression. It compares where the reflected beam lands on its internal detector, so an object is detected regardless of its colour or surface reflectivity while everything beyond the set distance is ignored. A 35...45 mm focus zone with a 4 mm beam diameter allows small objects to be detected.

• Switching distance: 20...120 mm, adjustable by a 5-turn mechanical potentiometer
• Output: PNP, Light/Dark Operate, < 100 mA
• Supply: 10...30 V DC, typical consumption 20 mA
• Housing: rectangular, 10.4 x 27 x 14 mm, plastic (ASA), PMMA optics
• Environment: IP 65, -25...+65 °C
• Connection: cable 2 m, 4-wire

The sensor suits presence and position control in packaging, assembly and sorting machines where the background sits close to the object and dark or glossy surfaces give a standard diffuse sensor a false reading. A flashing light indicator shows insufficient signal margin or a soiled lens, so alignment and maintenance need no instruments. Reciprocal influence is suppressed, so several sensors can be mounted side by side.

Receiver SMR3215TBJ

LMB30LP is a Banner low-profile flat bracket with a 30 mm mounting hole.

• Mounting hole: Ø30.5 mm
• Mounting: 2x Ø5.5 mm holes
• Dimensions: 65 x 50 mm
• Material: 300 series stainless steel

LMBS15SP is a Banner snap clip that holds a device in the S15 housing. It is fixed with the supplied thread-forming screws or with M5 or No. 10 hardware.

• Fits: Banner S15 housing
• Material: white polypropylene
• Mounting: clearance for M5 or No. 10 hardware
• Included: pack of 5, with thread-forming hardware

PIRS1X166UMPMAL is a Banner plastic fibre-optic array for opposed mode: the rectangular sensing head carries 16 fibre cores of Ø0.25 mm side by side along 33.5 mm, so a small object anywhere along the array interrupts the light. The beam exits from the side of the head.

• Range: DF-G1 680 mm, D10D 1000 mm, D10B 300 mm, D10A 260 mm
• Array: 33.5 mm, 16 x Ø0.25 mm cores, side view, rectangular head
• Fibre: length 2 m, unterminated; supplied as a pair
• Material: acrylic (PMMA) core, polyethylene jacket and head
• Temperature: -30...+70 °C

The control ends are unterminated and are cut to length with the PFC-4 cutter supplied with the fibre. The acrylic core is damaged by acids, strong alkalis and solvents; Banner recommends plastic fibres for visible-light sensors only.

SMBAMS18RA is a right-angle bracket from the Banner SMBAMS series for barrel sensors with an 18 mm thread.

• Sensor hole: Ø19.0 mm, for 18 mm threaded sensors
• Material: 12-ga (2.6 mm) cold-rolled steel
• Adjustment: articulation slots, rotation beyond 90°
• Included: mounting hardware

T18-2VPLPC-Q8 is a Banner T18-2 series polarized retroreflective sensor, which works with a reflector and ignores light returned by shiny objects. The right-angle 18 mm threaded housing has epoxy-encapsulated electronics and food-grade plastics, for wet and washdown areas. A single-turn potentiometer sets the sensitivity.

• Sensing range: 6 m with a BRT-84 reflector
• Output: complementary PNP (NO and NC), 100 mA total up to +55 °C; response 1.5 ms ON / 0.75 ms OFF
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, 18 mm thread, PBT polyester, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C; ECOLAB chemical compatibility
• Connection: M12 male connector, 4-pin

Vibration per MIL-STD-202G method 201A, shock per method 213B (75 g operating).

S18-2VNDS-2M is a Banner S18-2 series diffuse photo sensor in an 18 mm plastic barrel. It detects objects by the visible red light they reflect back, up to 300 mm from the sensor.

• Sensing range: 300 mm on a 90 % white test card
• Output: complementary NPN, Light Operate (black) and Dark Operate (white), 100 mA total
• Response: 1.5 ms ON, 0.75 ms OFF; repeatability 100 µs
• Supply: 10-30 V DC (10-24 V DC above +55 °C), 16 mA
• Housing: ABS, PMMA window, M18x1 threaded barrel, PBT nuts included
• Environment: IP67, -40...+70 °C
• Connection: 2 m PVC cable

The range applies to a white card; darker objects are detected at a shorter distance. Sensitivity is set with a single-turn potentiometer. A green LED shows power and flashes at a marginal signal; the amber LED shows that the black-wire (Light Operate) output is on.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B (75 g operating).

QS30LPQPMA25 is a Banner QS30 series polarized retroreflective photo sensor with a visible red 630 nm beam and an 8 m range with a BRT-84 reflector. Sensitivity is set with a single-turn potentiometer.

• Sensing range: 8 m with BRT-84 reflector
• Output: PNP, 100 mA, Light/Dark Operate
• Response: 2 ms, repeatability 500 µs
• Supply: 10-30 V DC, < 40 mA
• Housing: rectangular ABS with M30 mount, acrylic lens
• Environment: IP67, -20...+70 °C
• Connection: 150 mm PUR cable with M12 4-pin male connector

Green LED indicator: power on, flashing on output overload. Amber: light sensed, flashing at marginal excess gain. A yellow LED on the back of the sensor shows the output is conducting.

Vibration per MIL-STD-202F, Method 201A; shock per IEC 60947-5-2 (30 G, 11 ms).
