Q20KAF200Q7 is a Banner Q20 series photo sensor with adjustable background suppression and a visible red 640 nm beam. Objects up to the set cutoff are detected regardless of colour, while anything beyond it is ignored.

• Sensing range: adjustable cutoff 30...200 mm
• Output: PNP switching output with IO-Link, 50 mA; IO-Link 38400 bit/s, Smart Sensor Profile, 16-bit process data
• Response: 1.7 ms ON, 1.1 ms OFF; repeatability 130 µs
• Supply: 10-30 V DC, < 300 mW
• Housing: ABS front, copolyamide rear, PMMA lenses, 3 mm mounting holes at 25.4 mm spacing
• Environment: IP67, -20...+60 °C
• Connection: integral M8 4-pin male connector

The cutoff is set with a single-turn potentiometer. A green LED indicator shows power; the amber one shows light sensed and flashes at a marginal sensing condition. Two sensors can be mounted close together without crosstalk. All settings are also available through the IODD file.

Q20PAF200 is a Banner Q20 series photo sensor with adjustable background suppression and a visible red 640 nm beam. Objects up to the set cutoff are detected regardless of colour, while anything beyond it is ignored.

• Sensing range: adjustable cutoff 30...200 mm
• Output: complementary PNP, Light Operate and Dark Operate, 50 mA total
• Response: 1.7 ms ON, 1.1 ms OFF; repeatability 130 µs
• Supply: 10-30 V DC, < 300 mW
• Housing: ABS front, copolyamide rear, PMMA lenses, 3 mm mounting holes at 25.4 mm spacing
• Environment: IP67, -20...+60 °C
• Connection: 2 m PVC cable, 4 wires

The cutoff is set with a single-turn potentiometer. A green LED indicator shows power; the amber one shows light sensed and flashes at a marginal sensing condition. Two sensors can be mounted close together without crosstalk.

Q20NAF200 is a Banner Q20 series photo sensor with adjustable background suppression and a visible red 640 nm beam. Objects up to the set cutoff are detected regardless of colour, while anything beyond it is ignored.

• Sensing range: adjustable cutoff 30...200 mm
• Output: complementary NPN, Light Operate and Dark Operate, 50 mA total
• Response: 1.7 ms ON, 1.1 ms OFF; repeatability 130 µs
• Supply: 10-30 V DC, < 300 mW
• Housing: ABS front, copolyamide rear, PMMA lenses, 3 mm mounting holes at 25.4 mm spacing
• Environment: IP67, -20...+60 °C
• Connection: 2 m PVC cable, 4 wires

The cutoff is set with a single-turn potentiometer. A green LED indicator shows power; the amber one shows light sensed and flashes at a marginal sensing condition. Two sensors can be mounted close together without crosstalk.

S18-2VNLPC-Q8 is a Banner S18-2 series polarized retroreflective photo sensor in an 18 mm plastic barrel, with a 6 m range to a BRT-84 reflector. The polarizing filter rejects light returned by shiny objects, so they break the beam instead of acting as a reflector.

• Sensing range: 6 m with a BRT-84 reflector
• Output: complementary NPN, Light Operate (black) and Dark Operate (white), 100 mA total
• Response: 1.5 ms ON, 0.75 ms OFF; repeatability 100 µs
• Supply: 10-30 V DC (10-24 V DC above +55 °C), 16 mA
• Housing: ABS, PMMA window, M18x1 threaded barrel, PBT nuts included
• Environment: IP67, -40...+70 °C
• Connection: integral M12 4-pin male connector

Needs a reflector, ordered separately. Sensitivity is set with a single-turn potentiometer. A green LED shows power and flashes at a marginal signal; the amber LED shows that the black-wire (Light Operate) output is on.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B (75 g operating).

SMBQS12PD is a Banner right-angle bracket that holds the sensor by its threaded nose through a 13 mm hole.

• Sensor hole: Ø13.0 mm
• Mounting: Ø3.5 mm and 3.5 x 10.6 mm slot, 14.0 mm hole centre spacing
• Material: 16-gauge 300 series stainless steel

PIT46U is a Banner pair of individual plastic fibres for opposed mode, one for the emitter and one for the receiver. The tip has an M4 thread stepping down to M2.5.

• Range: DF-G1 820 mm, D10D 1200 mm, D10B 320 mm, D10A 300 mm
• Fibre: Ø1 mm, length 2 m, unterminated; supplied as a pair
• Tip: M2.5 and M4 threaded
• Material: acrylic (PMMA) core, black polyethylene jacket, nickel-plated brass tip
• Bend radius: at least 25 mm
• Temperature: -30...+70 °C

The control ends are unterminated and are cut to length with the PFC-4 cutter supplied with the fibre. The acrylic core is damaged by acids, strong alkalis and solvents; Banner recommends plastic fibres for visible-light sensors only.

BRT-51X51BM is a Banner square acrylic retroreflector with micro-prism geometry, for photo sensors working in retroreflective mode. Two slots let it be screwed on, and optional brackets are available.

• Reflector size: 51 x 51 mm
• Overall size: 51 x 61 x 6.2 mm
• Reflectivity factor: 1.5
• Mounting: 2 slots, Ø4.6 mm
• Temperature: -20...+50 °C

M18-4NAES-Q8 is the emitter of a Banner M18-4 series opposed-mode pair in an M18 stainless steel barrel, with a visible red beam and a 25 m range with an M18-4 receiver. Emitter power is set with a 250° potentiometer.

• Range: 25 m with an M18-4 receiver, effective beam 15.2 mm
• Supply: 10-30 V DC up to +55 °C, 10-24 V DC above; 17 mA
• Housing: M18 316L stainless steel barrel, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C
• Connection: integral M12 4-pin male connector

A green LED indicator shows power.

Vibration and shock per MIL-STD-202F, methods 201A and 213B. ECOLAB chemical compatibility certified.

M18-4VPRS-Q8 is the receiver of a Banner M18-4 series opposed-mode pair in an M18 stainless steel barrel, with a 25 m range with an M18-4 emitter. Sensitivity is set with a 250° potentiometer.

• Sensing range: 25 m with an M18-4 emitter, effective beam 15.2 mm
• Output: complementary PNP, one NO and one NC, 100 mA total (50 mA above +55 °C)
• Response: 1.5 ms ON, 1.0 ms OFF; repeatability 170 µs
• Supply: 10-30 V DC up to +55 °C, 10-24 V DC above; 8 mA
• Housing: M18 316L stainless steel barrel, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C
• Connection: integral M12 4-pin male connector

A green LED indicator shows power and flashes at a marginal signal; amber LED indicators show the output is conducting.

Vibration and shock per MIL-STD-202F, methods 201A and 213B. ECOLAB chemical compatibility certified.

QS18VP6DVSQ8 is a Banner QS18 series diffuse photo sensor with a small visible red 630 nm light spot. It detects an object by the light the object reflects back to the sensor, and the visible spot shows exactly where it is aimed.

• Sensing range: 250 mm
• Output: complementary PNP, Light Operate and Dark Operate, 100 mA each
• Response: 850 µs ON/OFF; repeatability 90 µs
• Supply: 10-30 V DC, < 25 mA
• Housing: ABS, 18 mm threaded nose or side mounting, 3 mm hardware included
• Environment: IP67, -20...+70 °C
• Connection: integral M12 4-pin male connector

A green LED indicator shows power; the amber one shows light sensed and flashes at marginal excess gain. Sensitivity is set with a single-turn potentiometer.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

Q76E-VP-ZLVC-Q8 is a Banner Q76 series wide-beam retroreflective photo sensor with a visible red 620 nm light band and a 0.4-4 m range. The wide band detects the leading edge of irregular objects and pallets that a single-spot beam could miss.

• Sensing range: 0.4-4 m with a 100 x 100 mm BRT-92X92CB reflector; 3 m with a 40 x 60 mm reflector
• Smallest object: 19 mm standard, 12 mm increased, 8 mm fine-adjusted sensitivity
• Output: complementary PNP, Light Operate and Dark Operate; response 2 ms, 250 Hz
• Supply: 10-30 V DC
• Housing: PC-PBT, PMMA lens cover
• Environment: IP67, IP69, -40...+60 °C, ECOLAB certified
• Connection: integral M12 4-pin male connector

Standard sensitivity switches when 28 % of the band is covered and suits opaque objects; increased sensitivity switches at 18 % for containers with openings, film and transparent objects. Sensitivity and Light/Dark Operate are set with the single teach button. The reflector must be at least 50 mm wide and 30 mm tall.

OR18.GP-PV1T.7BO is a Baumer M18 diffuse photo sensor with background suppression, detecting objects at 20...200 mm and ignoring anything beyond the set distance. The switching distance is taught with qTeach instead of a potentiometer, so the setting is repeatable and cannot drift from vibration. A small PinPoint LED light spot allows detection of small parts.

• Sensing range: 20...200 mm, adjustable 45...200 mm; red PinPoint LED 630 nm
• Output: PNP complementary (NO and NC at the same time), max. 100 mA; response time < 0.49 ms
• Supply: 10...30 V DC, max. 45 mA
• Housing: M18 x 1 threaded, 65 mm long, nickel-plated brass, PA lens
• Environment: IP67; -25...+60 °C
• Connection: M12 4-pin connector

Used for presence detection on conveyors and in assembly stations where a machine frame or wall sits close behind the object. Both outputs are available on one connector (black and white wires), so one sensor gives the controller the light and dark operate signal. A green LED shows power, a yellow LED shows the output state.

Q20NLPQ7 is a Banner Q20 series polarized retroreflective photo sensor with a visible red 645 nm beam and a 4 m range with a BRT-84 reflector. The polarizing filter lets it detect shiny objects that would reflect an unpolarized beam back to the sensor.

• Sensing range: 4 m with BRT-84 reflector
• Output: NPN, complementary Light Operate and Dark Operate outputs, 100 mA
• Response: 850 µs ON/OFF; repeatability 90 µs
• Supply: 10-30 V DC, < 18 mA
• Housing: ABS, PMMA lenses
• Environment: IP67, -20...+60 °C
• Connection: integral M8 4-pin male connector

A green LED indicator shows power; the amber one shows the output state and flashes at marginal excess gain. Sensitivity is set with a single-turn potentiometer.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

T18-2VPDL-Q8 is a Banner T18-2 series diffuse sensor with visible red light that detects objects by the light they reflect back. The right-angle 18 mm threaded housing has epoxy-encapsulated electronics and food-grade plastics, for wet and washdown areas. A single-turn potentiometer sets the sensitivity.

• Sensing range: 750 mm
• Output: complementary PNP (NO and NC), 100 mA total up to +55 °C; response 1.5 ms ON / 0.75 ms OFF
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, 18 mm thread, PBT polyester, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C; ECOLAB chemical compatibility
• Connection: M12 male connector, 4-pin

Vibration per MIL-STD-202G method 201A, shock per method 213B (75 g operating).

QS18VP6R W/30 is the receiver of a Banner QS18 series opposed-mode photo sensor pair. It switches when an object breaks the beam from a separate QS186E emitter up to 20 m away.

• Sensing range: 20 m with a QS186E emitter, effective beam 13 mm
• Output: complementary PNP, Light Operate and Dark Operate, 100 mA each
• Response: 750 µs ON, 375 µs OFF; repeatability 100 µs
• Supply: 10-30 V DC, < 25 mA
• Housing: ABS, 18 mm threaded nose or side mounting, 3 mm hardware included
• Environment: IP67, -20...+70 °C
• Connection: 9 m PVC cable, 4 wires

Works with a QS186E emitter, ordered separately. A green LED indicator shows power; the amber one shows light sensed and flashes at marginal excess gain.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

QS186E W/30 is the emitter of a Banner QS18 series opposed-mode photo sensor pair. It sends an infrared 940 nm beam to a separate QS18 receiver up to 20 m away; an object is detected when it breaks the beam.

• Sensing range: 20 m with a QS18 receiver, effective beam 13 mm
• Output: none (emitter)
• Supply: 10-30 V DC, < 25 mA
• Housing: ABS, 18 mm threaded nose or side mounting, 3 mm hardware included
• Environment: IP67, -20...+70 °C
• Connection: 9 m PVC cable, 2 wires

The emitter has no output and works only with a QS18VP6R or QS18VN6R receiver, ordered separately. A green LED indicator shows power.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

T18-2NAES-Q8 is a Banner T18-2 series opposed-mode emitter with visible red light, used with a T18-2 receiver. The right-angle 18 mm threaded housing has epoxy-encapsulated electronics and food-grade plastics, for wet and washdown areas. A single-turn potentiometer sets the sensitivity.

• Sensing range: 25 m with a T18-2 receiver
• Light source: visible red LED
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, 18 mm thread, PBT polyester, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C; ECOLAB chemical compatibility
• Connection: M12 male connector, 4-pin

Vibration per MIL-STD-202G method 201A, shock per method 213B (75 g operating).

OR18W.TI-ZZZP.9VO is the emitter half of the Baumer OR18W through-beam pair, in a washdown stainless steel 1.4404 (V4A) housing rated IP 67/69K. It carries no switching output - it only sends the infrared beam, and the matching OR18W receiver does the detecting.

• Housing: stainless steel 1.4404 (V4A), M18 x 1 thread, 67.2 mm long, PMMA lens
• Environment: IP 67/69K; -25...+55 °C
• Operating range: 13 m actual (nominal 20 m), pulsed infrared diode 880 nm
• Emission power: adjustable, 270° potentiometer
• Supply: 12...30 V DC, max. 40 mA
• Connection: M12 4-pin connector

Pins 2 and 4 (white and black) are the ON/OFF inputs, so the beam can be switched off from the controller without cutting the supply - useful when two pairs face each other and have to be run alternately. A green LED shows that the emitter is powered. The receiver is ordered separately.

OR18W.EI-PW1P.9VO is the receiver half of the Baumer OR18W through-beam pair, in a washdown stainless steel 1.4404 (V4A) housing rated IP 67/69K. It switches when the beam from the matching OR18W emitter is interrupted, so the emitter has to be ordered with it.

• Housing: stainless steel 1.4404 (V4A), M18 x 1 thread, 67.2 mm long, PMMA lens
• Environment: IP 67/69K; -25...+55 °C
• Operating range: 13 m actual (nominal 20 m)
• Output: PNP, < 100 mA, light/dark operate; response time < 2 ms
• Supply: 12...30 V DC, max. 40 mA
• Connection: M12 4-pin connector

A through-beam pair holds its range on wet, dark or poorly reflecting objects, which is what makes it the choice on washdown lines where a reflector would be fouled by the cleaning water. Sensitivity is set on the receiver with a 270° potentiometer and pin 2 (white) is a control input. A green LED shows beam alignment and lens soiling, a yellow LED the output state.

T18-2NAEL-2M is a Banner T18-2 series opposed-mode emitter with visible red light, used with a T18-2 receiver. The right-angle 18 mm threaded housing has epoxy-encapsulated electronics and food-grade plastics, for wet and washdown areas.

• Sensing range: 25 m with a T18-2 receiver
• Light source: visible red LED
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, 18 mm thread, PBT polyester, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C; ECOLAB chemical compatibility
• Connection: 2 m PVC cable

Vibration per MIL-STD-202G method 201A, shock per method 213B (75 g operating).

T18-2VPRL-2M is a Banner T18-2 series opposed-mode receiver, used with a T18-2 emitter. The right-angle 18 mm threaded housing has epoxy-encapsulated electronics and food-grade plastics, for wet and washdown areas.

• Sensing range: 25 m with a T18-2 emitter
• Output: complementary PNP (NO and NC), 100 mA total up to +55 °C; response 1.5 ms ON / 1 ms OFF
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, 18 mm thread, PBT polyester, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C; ECOLAB chemical compatibility
• Connection: 2 m PVC cable

Vibration per MIL-STD-202G method 201A, shock per method 213B (75 g operating).

T18-2NAEL-Q8 is a Banner T18-2 series opposed-mode emitter with visible red light, used with a T18-2 receiver. The right-angle 18 mm threaded housing has epoxy-encapsulated electronics and food-grade plastics, for wet and washdown areas.

• Sensing range: 25 m with a T18-2 receiver
• Light source: visible red LED
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, 18 mm thread, PBT polyester, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C; ECOLAB chemical compatibility
• Connection: M12 male connector, 4-pin

Vibration per MIL-STD-202G method 201A, shock per method 213B (75 g operating).

OT500.GL-PLPVB.72F is a background suppression photo sensor from the Baumer OT500 series, measuring by time of flight over a 150...2500 mm switching range. A red laser diode (680 nm, laser class 1) forms a point beam focused at 1500 mm, and switching follows the measured distance rather than the amount of reflected light.

• Switching range: 150...2500 mm (Tw), set by qTeach or an external teach wire
• Output: PNP, complementary (Light operate), output current 50 mA
• Repeat accuracy: ≤ 1200...4300 µm, linearity error ± 10 mm
• Supply: 12...30 V DC, consumption max. 60 mA
• Housing: plastic (ASA, PMMA), 18 x 45 x 32 mm, PMMA optics window
• Environment: IP 67, -20...+50 °C
• Connection: M12 connector, 5 pin

The complementary output gives an NO and an NC signal at the same time, so the operating mode need not be chosen before installation. Teaching is done either with qTeach on the housing or through an external wire, which allows the switching distance to be re-taught from the control cabinet. Suppression of reciprocal influence allows several sensors to be mounted side by side.

Vibration and shock resistance tested to IEC 60068-2-6:2008 (10 g, 10...2000 Hz) and IEC 60068-2-27:2009 (50 g / 11 ms).

PRO-KIT is a Banner kit for configuring Pro series lights and selected sensors from a PC with the Pro Editor software. It is needed for initial configuration only, not for the device's operation in the machine.

• Included: converter cable, splitter and power supply
• Software: Banner Pro Editor
• Fits: Banner Pro series lights and selected sensors

CE and UKCA compliant.

OT300.GL-GLZZJ.72N is a background suppression photo sensor from the Baumer OT300 series in a miniature housing, measuring by time of flight over a 100...1800 mm switching range. A red laser diode (680 nm, laser class 1) focused at 700 mm forms a narrow point beam, and the measured distance value is available over IO-Link.

• Switching range: 100...1800 mm (Tw), set by teach-in or IO-Link
• Output: push-pull (PNP/NPN) and IO-Link V1.1.3, Class A, Light operate, switchable
• Repeat accuracy: ≤ 1400...5500 µm, linearity error ± 10 mm
• Supply: 12...30 V DC, consumption max. 60 mA
• Housing: plastic (ASA, PMMA), 12.9 x 32.3 x 23 mm
• Environment: IP 67, -20...+50 °C
• Connection: M8 connector, 4 pin

Response time is selected over IO-Link: < 4 ms in High Speed, < 8 ms in Standard and < 50 ms in Long Range mode, so the same sensor suits both a fast sorting line and a longer distance with weak remission. Operating hours, operating cycles, supply voltage and device temperature are also readable over IO-Link.

Vibration and shock resistance tested to IEC 60068-2-6:2008 (10 g, 10...2000 Hz) and IEC 60068-2-27:2009 (50 g / 11 ms).

O200.SL.T-GW1J.72NV/F160_H006 is a Baumer O200 miniature SmartReflect light barrier tuned for transparent objects. It forms the barrier between itself and a fixed machine surface, so no reflector is mounted opposite, and an object is detected by the 5% signal attenuation that even a clear bottle or film produces.

• Background position Sde: 15...180 mm, teachable; scanning range 90%...85% Sde
• Detection: minimum signal attenuation 5%, focus at 160 mm
• Output: push-pull, light/dark operate, 50 mA
• Communication: IO-Link V1.1, port class A, 230.4 kBaud, cycle ≥ 0.6 ms
• Supply: 10...30 VDC, typ. 10 mA at 24 VDC; response time < 0.25 ms in High Speed mode
• Housing: rectangular 8 x 25.1 x 15.8 mm, ASA plastic, PMMA optics, M3 stainless steel threaded sleeves; laser class 1, 680 nm
• Environment: IP 67, -20...+50 °C; connection M8 4-pin flylead connector, 200 mm

It is used on filling and labelling lines for PET bottles, glass containers, clear film and blister packs, and wherever there is no room or no mounting point for a reflector on the far side. Background tracking compensates for lens contamination and slow changes in the reference surface, so the threshold stays usable between cleaning intervals; the compensation and the switching point are also readable and settable over IO-Link.

O200.GL-GW1J.72NV/F040_H006 is a Baumer O200 miniature background suppression sensor with a focused laser beam converging at 40 mm, where it resolves objects down to 0.05 mm. Switching point, hysteresis, time filters and counter are set by qTeach, line teach or over IO-Link V1.1, and the same interface returns a 16-bit distance measurement, excess gain, quality and alarm bits.

• Sensing distance Tw: 20...120 mm, teachable; sensing range Tb 3...132 mm
• Output: push-pull, light/dark operate, 50 mA
• Communication: IO-Link V1.1, port class A, 230.4 kBaud, cycle ≥ 0.6 ms
• Supply: 10...30 VDC, typ. 10 mA at 24 VDC
• Response time: ≤ 0.25 ms in High Speed mode, jitter ≤ 0.06 ms
• Housing: rectangular 8 x 25.1 x 15.8 mm, ASA plastic, PMMA optics, M3 stainless steel threaded sleeves; laser class 1, 680 nm
• Environment: IP 67, -20...+50 °C; connection M8 4-pin flylead connector, 200 mm

The focused beam suits small targets and narrow gaps - wire ends, thin edges, holes in a moving strip, or the boundary between stacked sheets. The distance value returned over IO-Link lets a controller follow signal drift long before the switching output starts to fail.

O200.GR.F-PV1Z.72NV/H006_BX15 is a Baumer O200 miniature background suppression sensor with a fixed 15 mm switching distance and V-optics, in which the emitted and received beams cross on the object itself. That geometry gives a repeatable switching point on shiny and transparent surfaces, where coaxial optics read the specular reflection instead of the object.

• Sensing distance Tw: 15 mm, fixed, no adjustment; sensing range Tb 3...15 mm
• Detection: smallest object typ. 0.05 mm at 10 mm
• Output: PNP complementary, light/dark operate, 50 mA
• Supply: 10...30 VDC, typ. 16 mA at 24 VDC; response time < 1 ms
• Housing: rectangular 8 x 25.1 x 14.1 mm, ASA plastic, PMMA optics, M3 stainless steel threaded sleeves; red LED 644 nm
• Environment: IP 67, -30...+50 °C
• Connection: M8 4-pin flylead connector, 200 mm

The fixed preset means commissioning is mounting and wiring only - there is nothing to teach and nothing that can be turned later. It is used at short fixed distances against glass, film, foil and polished metal: edge detection on packaging film, presence of a vial or ampoule, label and blister checks.

O200.GP-GW1J.72NV/E022_H006 is a Baumer O200 miniature background suppression sensor whose PinPoint LED light is shaped into a line beam. The line covers the full width of an irregular or perforated object, so a part with holes, slots or a ragged edge gives one switching signal instead of a burst of short pulses.

• Sensing distance Tw: 20...120 mm, teachable; sensing range Tb 3...132 mm
• Detection: line beam, smallest object typ. 8 mm at 60 mm
• Output: push-pull, light/dark operate, 50 mA
• Communication: IO-Link V1.1, port class A, 230.4 kBaud, cycle ≥ 0.6 ms
• Supply: 10...30 VDC, typ. 16 mA at 24 VDC; response time < 0.25 ms in High Speed mode
• Housing: rectangular 8 x 25.1 x 15.8 mm, ASA plastic, PMMA optics, M3 stainless steel threaded sleeves; 644 nm
• Environment: IP 67, -30...+50 °C; connection M8 4-pin flylead connector, 200 mm

Typical positions are perforated trays, mesh baskets, crates with gaps and bottle cases on a conveyor, where a point beam would drop out each time it passes an opening. Teach-in is by qTeach or line teach and every parameter is also reachable over IO-Link, so a format change can be loaded from the controller instead of being set by hand at the machine.

O300.RP-PV1T.72CU is a miniature photoelectric sensor from the Baumer O300 series working against a reflector over a 5 m range. A polarisation filter lets the sensor respond only to the light returned by the reflector, so shiny metal or film in the object's place is not read as a reflector.

• Range: 5 m actual, 6 m nominal, with polarisation filter
• Output: PNP complementary, NO and NC at the same time, light / dark operate, < 100 mA
• Supply: 10...30 V DC, typical consumption 25 mA
• Housing: rectangular, plastic (ASA, PMMA), PMMA optics, 12.9 x 32.3 x 23 mm
• Environment: IP 67, -25...+60 °C
• Connection: 2 m cable, 4 cores

The sensor suits counting and presence checks on conveyors and packaging lines where the sensor and the reflector can face each other. Sensitivity is set with qTeach by holding a ferromagnetic tool against the housing, and mutual interference between sensors mounted side by side is suppressed.

SME312D is a Banner MINI-BEAM Expert diffuse-mode photo sensor with an infrared 880 nm beam and 380 mm range. Sensitivity is set by TEACH instead of a potentiometer.

• Sensing: diffuse, range 380 mm, infrared 880 nm
• Outputs: bipolar, 1x PNP and 1x NPN, 150 mA each (100 mA at 70 °C); response 500 µs, repeatability 100 µs
• Supply: 10-30VDC, below 45 mA
• Housing: MINI-BEAM, reinforced thermoplastic polyester, encapsulated, M18x1 nose thread with nut
• Environment: IP67, -20...+70 °C
• Connection: 2 m PVC cable, 5 conductors

Set with the push button or the gray remote TEACH wire: the first condition taught becomes Output ON, so Light or Dark Operate is not selected separately. The green indicator flashes when the signal approaches the switching threshold.

SLO30VB6Q is a Banner SLO series slot sensor: an infrared 890 nm opposed-mode emitter and receiver across a 30 mm slot, 45 mm deep, in one U-shaped housing. The 2 mm effective beam suits hole, gear-tooth and edge detection without any alignment.

• Slot: 30 mm wide, 45 mm deep; beam 10 mm from the outer edge
• Output: bipolar, one PNP and one NPN, Light or Dark Operate selected by the grey wire, 150 mA each
• Response: 1 ms; repeatability 250 µs
• Supply: 10-30 V DC, 30 mA
• Housing: ABS and polycarbonate, acrylic lenses
• Environment: IP67, NEMA 6, -40...+70 °C
• Connection: integral M12 5-pin male connector

Grey wire to +V gives Dark Operate, to 0 V or open gives Light Operate. There is no sensitivity adjustment. A green LED shows power; the amber LED shows light sensed and flashes at marginal excess gain.

T30SP6FF100Q is a Banner T30 series fixed-field photo sensor with a 100 mm cutoff and an infrared beam, in a right-angle housing with a 30 mm threaded lens. The sensor detects objects up to 100 mm and ignores backgrounds beyond.

• Sensing range: 100 mm cutoff, fixed
• Output: PNP, Light/Dark Operate
• Response: 3 ms; repeatability 750 µs
• Supply: 10-30 V DC
• Housing: right-angle, 30 mm thread, thermoplastic, acrylic lens, encapsulated
• Environment: IP69K, NEMA 4X, -40...+70 °C
• Connection: integral M12 4-pin male connector

There is no sensitivity adjustment.

UL, CE and UKCA approved.

Q12AB6R is the receiver of a Banner Q12 series opposed-mode pair and works with a Q12 emitter with a visible red 640 nm beam.

• Sensing range: 2 m with a Q12 emitter, effective beam 5.7 mm
• Output: bipolar, one PNP and one NPN, Light Operate, 50 mA
• Response: 1.3 ms ON, 900 µs OFF; repeatability 125 µs
• Supply: 10-30 V DC, < 20 mA
• Housing: polyamide, polycarbonate lens, 8 mm thick
• Environment: IP67, -20...+55 °C
• Connection: 2 m PVC cable, 4 wires

A green LED indicator shows power; the amber one shows the received signal and flashes when the signal is marginal.

Q20NLP is a Banner Q20 series polarized retroreflective photo sensor with a visible red 645 nm beam and a 4 m range with a BRT-84 reflector. The polarizing filter lets it detect shiny objects that would reflect an unpolarized beam back to the sensor.

• Sensing range: 4 m with BRT-84 reflector
• Output: NPN, complementary Light Operate and Dark Operate outputs, 100 mA
• Response: 850 µs ON/OFF; repeatability 90 µs
• Supply: 10-30 V DC, < 18 mA
• Housing: ABS, PMMA lenses
• Environment: IP67, -20...+60 °C
• Connection: 2 m PVC cable, 4 wires

A green LED indicator shows power; the amber one shows the output state and flashes at marginal excess gain. Sensitivity is set with a single-turn potentiometer.

Vibration tested to MIL-STD-202F, method 201A; shock to IEC 60947-5-2.

O330.GP-GLZZB.72N/H006 is a miniature photoelectric sensor from the Baumer O330 series with background suppression and a 20...350 mm switching distance. The switching distance is set with qTeach or by an external teach signal over the connection cable, so the sensor can be re-taught from the control system without physical access.

• Switching distance: 20...350 mm, adjustable by qTeach or an external teach signal
• Output: push-pull, light / dark operate, 100 mA
• Supply: 10...30 V DC, typical consumption 25 mA
• Housing: rectangular, plastic (ABS, ASA, PMMA), M3 brass threaded sleeves, 11 x 32 x 21 mm
• Environment: IP 67, -30...+55 °C
• Connection: M8 connector, 4 pin

The sensor suits presence checks on conveyors, assembly stations and packaging machines where mounting space is tight and the unit is swapped without rewiring. The M3 threaded sleeves allow the sensor to be fixed directly, without a separate bracket.

Vibration resistance tested to IEC 60068-2-6:2008 (10 g, 10-2000 Hz) and shock resistance to IEC 60068-2-27:2009 (50 g, 11 ms).

S30SP6FF600Q is a Banner S30 series fixed-field photo sensor with an infrared 880 nm beam and a 600 mm cutoff. It compares the light returned to a near and a far detector, so it detects objects in front of the cutoff and ignores the background behind it.

• Sensing range: 600 mm cutoff
• Output: PNP, SPDT - NO (Light Operate) and NC (Dark Operate), 150 mA each
• Response: 3 ms ON/OFF; repeatability 750 µs
• Supply: 10-30 V DC, 35 mA
• Housing: PBT polyester, acrylic lens, fully epoxy-encapsulated, M30x1.5 threaded barrel
• Environment: IP69K, NEMA 6P, -40...+70 °C
• Connection: integral M12 4-pin male connector

The cutoff is fixed and there is nothing to adjust. Excess gain peaks at about 40 mm from the lens, which is where low-reflectivity targets are detected most reliably; backgrounds belong well beyond 600 mm, and mirror-like ones can cause false switching. A yellow LED shows the NO output on and flashes at marginal excess gain.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B (75 g operating).

T18-2VPRS-Q8 is a Banner T18-2 series opposed-mode receiver, used with a T18-2 emitter. The right-angle 18 mm threaded housing has epoxy-encapsulated electronics and food-grade plastics, for wet and washdown areas. A single-turn potentiometer sets the sensitivity.

• Sensing range: 25 m with a T18-2 emitter
• Output: complementary PNP (NO and NC), 100 mA total up to +55 °C; response 1.5 ms ON / 1 ms OFF
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, 18 mm thread, PBT polyester, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C; ECOLAB chemical compatibility
• Connection: M12 male connector, 4-pin

Vibration per MIL-STD-202G method 201A, shock per method 213B (75 g operating).

Q126E is the emitter of a Banner Q12 series opposed-mode pair and works with a Q12 receiver.

• Range: 2 m with a Q12 receiver
• Light source: visible red 640 nm
• Supply: 10-30 V DC, < 20 mA
• Housing: polyamide, polycarbonate lens, 8 mm thick
• Environment: IP67, -20...+55 °C
• Connection: 2 m PVC cable, 4 wires

A green LED indicator shows power.

T18-2VNRL-Q8 is a Banner T18-2 series opposed-mode receiver, used with a T18-2 emitter. The right-angle 18 mm threaded housing has epoxy-encapsulated electronics and food-grade plastics, for wet and washdown areas.

• Sensing range: 25 m with a T18-2 emitter
• Output: complementary NPN (NO and NC), 100 mA total up to +55 °C; response 1.5 ms ON / 1 ms OFF
• Supply: 10-30 V DC (10-24 V DC above +55 °C), < 16 mA
• Housing: right-angle, 18 mm thread, PBT polyester, PMMA window
• Environment: IP67, IP68, IP69K, -40...+70 °C; ECOLAB chemical compatibility
• Connection: M12 male connector, 4-pin

Vibration per MIL-STD-202G method 201A, shock per method 213B (75 g operating).

T30SP6RQ is the receiver of a Banner T30 series opposed-mode photo sensor pair, in a right-angle housing with a 30 mm threaded lens. It switches when an object breaks the infrared beam from a separate T30 emitter up to 60 m away.

• Sensing range: 60 m with a T30 emitter
• Output: complementary PNP, Light Operate (black) and Dark Operate (white), 150 mA each
• Response: 3 ms ON, 1.5 ms OFF; repeatability 375 µs
• Supply: 10-30 V DC, 20 mA
• Housing: right-angle, M30x1.5 thread, PBT polyester, epoxy-encapsulated, jam nut included
• Environment: IP69K, NEMA 4X, -40...+70 °C
• Connection: integral M12 4-pin male connector

Needs a T30 emitter, ordered separately. The white-wire output can be wired as a normally open marginal-signal alarm instead of Dark Operate. A green LED shows power and flashes on output overload; the amber LED shows the NO output is on and flashes at marginal excess gain.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B (75 g operating). UL, CE and UKCA approved.

PTL110S-FF200L-QP150 is a Banner PTL110 series pick-to-light device with an RGB indicator and a 200 mm fixed-field infrared sensor, controlled over RS-485 Modbus RTU with PICK-IQ. The indicator shows the operator which bin to pick from, and the sensor confirms the hand reaching into it.

• Indicator: RGB, up to 14 colours; pick, acknowledge, mis-pick and job lights programmable
• Sensor: 200 mm fixed field, infrared 870 nm
• Communication: RS-485 Modbus RTU, PICK-IQ
• Supply: 10-30 V DC, 50 mA at 24 V DC, 1.35 W maximum
• Housing: ABS, polycarbonate indicator, acrylic lens, 110 x 35 x 33.1 mm
• Environment: IP54, -40...+50 °C
• Connection: two 150 mm PVC cables, M12 4-pin male and M12 4-pin female

The male and female pigtails let devices be daisy-chained along a picking shelf on one RS-485 line. The device needs a Modbus RTU host with PICK-IQ to set colours and read the sensor; it has no touch button and no display.

UL, CE and UKCA approved; FCC Part 15 Class B.

T306EQ is the emitter of a Banner T30 series opposed-mode photo sensor pair, in a right-angle housing with a 30 mm threaded lens. Its infrared 950 nm beam reaches a separate T30 receiver up to 60 m away, so the pair can span wide conveyors and doorways.

• Sensing range: 60 m with a T30 receiver
• Output: none (emitter)
• Supply: 10-30 V DC, 25 mA
• Housing: right-angle, M30x1.5 thread, PBT polyester, epoxy-encapsulated, jam nut included
• Environment: IP69K, NEMA 4X, -40...+70 °C
• Connection: integral M12 4-pin male connector

The emitter uses only the brown and blue wires; pins 2 and 4 are not connected. A green LED shows power.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B (75 g operating). UL, CE and UKCA approved.

FHDK 14P5101/S35A is a Baumer standard-size photo sensor with background suppression. It compares where the reflected beam lands on its internal detector, so an object is detected regardless of its colour or surface reflectivity while everything beyond the set distance is ignored.

• Switching distance: 20...350 mm, adjustable by a 10-turn mechanical potentiometer
• Output: PNP, Light/Dark Operate, < 100 mA
• Supply: 10...30 V DC, typical consumption 25 mA
• Housing: rectangular, 14.8 x 43 x 31 mm, plastic (ASA, MABS), PMMA optics
• Environment: IP 67, -25...+65 °C
• Connection: M8 connector, 4-pin

The sensor suits presence and position control in packaging, assembly and sorting machines where the background sits close to the object and dark or glossy surfaces give a standard diffuse sensor a false reading. A flashing light indicator shows insufficient signal margin or a soiled lens, so alignment and maintenance need no instruments. Reciprocal influence is suppressed, so several sensors can be mounted side by side.

Q25S2P6RQ is the receiver of a Banner EZ-BEAM Q25 series opposed-mode photo sensor pair, in the S2 version for sensor bus junctions. Besides the sensing output it has a second PNP output that warns when the received signal becomes marginal.

• Sensing range: 20 m with a Q256EQ emitter
• Output: PNP Light Operate sensing output and PNP NO alarm output, 150 mA total
• Response: 3 ms ON, 1.5 ms OFF; repeatability 375 µs
• Supply: 10-30 V DC, 20 mA
• Housing: PBT polyester, polycarbonate lens, epoxy-encapsulated electronics
• Environment: IP67, NEMA 6P, -40...+70 °C
• Connection: integral M12 4-pin male connector

The alarm output (white wire) conducts when excess gain falls to 1-1.5x in the light condition, so the bus system sees a dirty lens or misalignment before the sensor stops switching. Using it needs a junction with two channels per input. No adjustments are needed. Works with a Q256EQ emitter, ordered separately.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B.

Q256EQ is the emitter of a Banner EZ-BEAM Q25 series opposed-mode photo sensor pair. It sends an infrared 950 nm beam to a separate Q25 receiver up to 20 m away; an object is detected when it breaks the beam.

• Sensing range: 20 m with a Q25 receiver
• Output: none (emitter)
• Supply: 10-30 V DC, 25 mA
• Housing: PBT polyester, polycarbonate lens, epoxy-encapsulated electronics
• Environment: IP69K, NEMA 6P, -40...+70 °C
• Connection: integral M12 4-pin male connector

The emitter has no output and needs a Q25 receiver, ordered separately.

Vibration tested to MIL-STD-202F, method 201A; shock to method 213B.

SLM50P6Q is a Banner SLM series slot sensor: an opposed-mode emitter and receiver facing each other across a 50 mm slot in one U-shaped die-cast housing. There is nothing to align; molded-in arrows show where the visible red beam crosses the slot.

• Slot width: 50 mm; beam 5 mm from the outer edge
• Output: one PNP, Light or Dark Operate selected by switch, 100 mA
• Response: 500 µs; repeatability 95 µs
• Supply: 10-30 V DC, < 25 mA
• Housing: nickel-plated die-cast zinc, ABS end caps, acrylic windows
• Environment: IP67, -20...+60 °C
• Connection: integral M8 3-pin male connector

Used for counting, gear-tooth and edge detection, and part sensing on conveyor rails, with the object passing midway through the slot. Sensitivity is set with a single-turn potentiometer, turned down from maximum until the object is detected reliably. Green and amber LEDs show power and output.

O330.GP-NLNVT.72ZV/T003 is a miniature photoelectric sensor from the Baumer O330 series with background suppression and a 20...350 mm switching distance. The PinPoint LED produces a small, even light spot with sharp edges, so the sensor also detects small objects and objects close to their edge.

• Switching distance: 20...350 mm, adjustable by qTeach or 1-Step teach-in
• Output: NPN complementary, NO and NC at the same time, light / dark operate, 100 mA
• Supply: 10...30 V DC, typical consumption 25 mA
• Housing: rectangular, plastic (ABS, ASA, PMMA), brass sleeves in the mounting holes, 11 x 32 x 21 mm
• Environment: IP 67, -25...+55 °C
• Connection: 2 m PVC cable, 4 x 0.14 mm²

The sensor suits presence checks on conveyors, assembly stations and packaging machines where mounting space is tight. The brass sleeves in the mounting holes let the screws be tightened without crushing the plastic housing.

Vibration resistance tested to IEC 60068-2-6:2008 (10 g, 10-2000 Hz) and shock resistance to IEC 60068-2-27:2009 (50 g, 11 ms).

Q26PLUMQ5 is a Banner Q26 luminescence sensor: a 375 nm UV LED makes the target glow and the sensor detects that glow, so luminescent plastics, coatings, lubricants and marks are found on even or uneven surfaces regardless of their colour under normal light.

• Sensing range: 10...30 mm, beam Ø2 mm at 15 mm, UV 375 nm
• Output: PNP, 100 mA; response 250 µs or 1 ms, 2 kHz or 500 Hz, depending on sensitivity
• Supply: 12-30VDC, 30 mA
• Housing: ABS, 14 x 25 x 42 mm, glass window, max 0.8 Nm mounting torque
• Environment: IP67, -10...+55 °C
• Connection: 150 mm PVC pigtail with M12 4-pin connector

Light Operate or Dark Operate is selected with a rotary switch. The threshold is taught with the button or the remote wire by Light SET, Two-Point TEACH or Dark SET.

Vibration per EN 60068-2-6, shock per EN 60068-2-27.

QS30RRXH2OQ5-83044 is the high-gain dark operate receiver of a Banner QS30H2O opposed-mode water sensor pair, used with a standard QS30EXH2O emitter over up to 4 m. The 1450 nm infrared beam is tuned to an absorption band of water: it passes through many plastic and glass containers but is attenuated by water-based liquids, so the pair sees whether a container is filled.

• Sensing range: 4 m with a QS30EXH2O emitter
• Output: bipolar, one PNP and one NPN, Dark Operate, 100 mA
• Response: 1 ms ON/OFF, repeatability 500 µs at 10x excess gain or more; 3 ms and 2.5 ms at 2-10x
• Supply: 10-30 V DC, < 65 mA
• Housing: PC/ABS, PMMA window, M30x1.5 threaded barrel or side mounting
• Environment: IP67, NEMA 6, 1200 psi washdown per NEMA PW12, -20...+60 °C
• Connection: 150 mm PVC cable with M12 5-pin male connector

The high-gain receiver suits translucent containers and thick liquid layers, such as HDPE milk containers or coloured PET bottles. The output is on while the beam is blocked. Works with a standard QS30EXH2O emitter, ordered separately. Modulation frequency A or B is chosen with the grey wire and must match on emitter and receiver, so neighbouring pairs do not interfere.

QS30EXH2OQ5-83043 is the standard emitter of a Banner QS30H2O opposed-mode water sensor pair, supplied with a stainless steel mounting nut. The 1450 nm infrared beam is tuned to an absorption band of water: it passes through many plastic and glass containers but is attenuated by water-based liquids, so the pair sees whether a container is filled.

• Sensing range: 2 m with a low-gain receiver, 4 m with a high-gain receiver
• Output: none (emitter); beam inhibit input on the white wire
• Supply: 10-30 V DC, < 80 mA
• Housing: PC/ABS, PMMA window, M30x1.5 threaded barrel with stainless steel nut, or side mounting
• Environment: IP67, NEMA 6, 1200 psi washdown per NEMA PW12, -20...+60 °C
• Connection: 150 mm PVC cable with M12 5-pin male connector

Works only with standard QS30H2O receivers, ordered separately: the low-gain models suit clear bottles and test tubes, the high-gain models translucent containers such as HDPE or coloured PET. Pulling the white wire low switches the beam off for a receiver check. Modulation frequency A or B is chosen with the grey wire and must match on emitter and receiver, so neighbouring pairs do not interfere.

Q12RB6RQ5 is the Dark Operate receiver of a Banner Q12 series opposed-mode pair and works with a Q12 emitter with a visible red 640 nm beam.

• Sensing range: 2 m with a Q12 emitter, effective beam 5.7 mm
• Output: bipolar, one PNP and one NPN, Dark Operate, 50 mA
• Response: 1.3 ms ON, 900 µs OFF; repeatability 125 µs
• Supply: 10-30 V DC, < 20 mA
• Housing: polyamide, polycarbonate lens, 8 mm thick
• Environment: IP67, -20...+55 °C
• Connection: 150 mm PVC cable with M12 4-pin male connector

A green LED indicator shows power; the amber one shows the received signal and flashes when the signal is marginal.

Q126EQ5 is the emitter of a Banner Q12 series opposed-mode pair and works with a Q12 receiver.

• Range: 2 m with a Q12 receiver
• Light source: visible red 640 nm
• Supply: 10-30 V DC, < 20 mA
• Housing: polyamide, polycarbonate lens, 8 mm thick
• Environment: IP67, -20...+55 °C
• Connection: 150 mm PVC cable with M12 4-pin male connector

A green LED indicator shows power.
