Fibre optic amplifier QS18VP6FPQ8, plastic fibre, PNP, 10-30VDC, M12 4-pin

QS18VP6FPQ8 is a Banner QS18 series fibre optic amplifier for plastic fibres with a visible red 660 nm light source. The sensing range depends on the fibre and sensing mode used; gain is set with a single-turn potentiometer.

• Output: complementary PNP (SPDT), 100 mA per output
• Response: 600 µs ON/OFF, repeatability 150 µs
• Supply: 10-30 V DC, < 25 mA
• Housing: ABS, 3 mm mounting hardware included
• Environment: IP67, -20...+70 °C
• Connection: M12 4-pin male connector

A green LED indicator shows power; the amber one shows light sensed and flashes at marginal excess gain (1 to 1.5 times).

Vibration per MIL-STD-202F, Method 201A; shock per IEC 60947-5-2 (30 G, 11 ms).
