Laser distance sensor Q4XTULAF300-Q8, 25-300mm, 0-10V, 12-30VDC, M18 stainless steel, IP69K, M12 5-pin

Q4XTULAF300-Q8 is a Banner Q4X series Class 1 laser distance sensor in an M18 stainless steel housing that outputs the measured distance over 25...300 mm as a 0...10 V signal. The analog span is taught with two points or one point, and the 4-digit display shows either the output value or the distance in millimetres.

• Resolution: < 0.3 mm at 25...100 mm, < 1 mm at 100...300 mm; linearity follows the accuracy curve in the manual
• Measuring range: 25...300 mm
• Output: analog 0...10 V, min. load 2.5 kΩ; response time 0.5...2560 ms depending on measurement rate and averaging
• Supply: 12...30 V DC, < 675 mW; protected against reverse polarity and transient overvoltage
• Housing: M18x1 threaded barrel, 316L stainless steel, PMMA lens cover, polysulfone display window; nose mounting torque up to 20 N·m
• Environment: IP67, IP68, IP69K, -10...+50 °C
• Connection: integral M12 male connector, 5-pin; remote input for TEACH

The housing materials are ECOLAB certified for acidic and caustic cleaning and disinfecting agents and are compatible with cutting and lubricating fluids, so the sensor can stay in place on washdown lines in food processing and inside machining centres. Allow 10 minutes of warm-up for full performance.

CE, UKCA and UL listed (Industrial Control Equipment). Vibration per MIL-STD-202G method 201A, shock per MIL-STD-202G method 213B (100 G).
