Photo sensor - emitter Q456EQ5, 60 m, infrared, 10-30VDC, M12 4-pin

Q456EQ5 is the emitter of a Banner Q45BB6 series opposed-mode photo sensor pair. It sends an infrared 880 nm beam to a separate Q45BB6 receiver up to 60 m away; an object is detected when it breaks the beam.

• Sensing range: 60 m with a Q45BB6 receiver
• Output: none (emitter)
• Supply: 10-30 V DC
• Housing: reinforced thermoplastic polyester, o-ring-sealed polycarbonate cover, acrylic lenses, stainless steel hardware
• Environment: IP67, NEMA 6, -40...+70 °C, built for 1200 psi washdown
• Connection: integral M12 4-pin male connector

The emitter has no output and works with a Q45BB6RQ5 receiver, ordered separately. The high excess gain of the pair makes it suited to long distances and dusty or dirty areas.
