Light curtain - emitter LX3E, 67 mm array, 0.3-2 m, 10-30VDC, 2 m cable, IP65

LX3E is the emitter of a Banner LX series part-sensing light curtain with a 67 mm sensing array. It sends a strobed web of modulated beams to the matching LX receiver for detecting small or flat parts passing anywhere through the screen.

• Sensing range: 300 mm to 2 m with the matching receiver
• Output: none (emitter)
• Supply: 10-30 V DC, < 1 W
• Housing: aluminium, die-cast zinc end caps, acrylic window
• Environment: IP65, -20...+70 °C
• Connection: 2 m PVC cable, 5 wires

Needs the LX receiver of the same array length, ordered separately; no synchronisation wire is needed. Green LED shows power, red LED reduced range or a fault. Not for personnel protection. Best resolution is within the centre 80 % of the sensing range.
