Inductive sensor IGYX 08P17B3/S35L, Sn=2mm, 10-30VDC, PNP NO, flush, M8 connector, L=36mm, IP67

IGYX 08P17B3/S35L is a Baumer inductive proximity sensor in an M8 barrel with a 2 mm nominal sensing distance and a PNP normally open (NO) output. The sensing face is flush mountable and the stainless steel housing is 36 mm long.

• Sensing distance: 2 mm (Sn), assured 1.6 mm (Sa)
• Output: PNP, normally open (NO), 200 mA, with short-circuit and reverse-polarity protection
• Supply: 10...30 V DC, current consumption up to 15 mA with no load
• Housing: M8 thread, stainless steel, PBT sensing face, 36 mm long, flush mountable
• Environment: IP 67, operating temperature -25...+75 °C
• Connection: M8 connector

The Ø 8 mm body and 36 mm length fit the sensor into grippers, indexing tables and other positions where an M12 barrel does not fit. A 3 kHz switching frequency is enough for presence monitoring of fast moving metal parts. Tightening torque on the M8 thread must not exceed 5 Nm, and the switching point drifts by up to ±10 % of Sr across the temperature range, which matters when the target sits close to the 2 mm limit.

Complies with the EMC requirements of EN 60947-5-2:2007.
