BI2-P12-Y1X is a Turck inductive sensor with a NAMUR output to EN 60947-5-6 in an M12 plastic housing, approved for explosion-hazardous areas up to zone 1 (gas) and zone 20 (dust).

• Sensing distance: 2 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: NAMUR, 2-wire; current ≥ 2.1 mA not actuated, ≤ 1.2 mA actuated; switching frequency 5 kHz
• Supply: nominal 8.2 VDC; Ci/Li 150 nF / 150 µH
• Housing: M12 x 1 thread, thread length 30 mm, PA12-GF30 plastic, nut torque up to 1 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: 2 m blue PVC cable (LifYY), 2 x 0.34 mm², Ø 5.2 mm

The sensor may only be connected to certified intrinsically safe (Ex i) circuits, for example an isolating switching amplifier with a NAMUR input. Maximum input values: Ui = 20 V, Ii = 20 mA, Pi = 200 mW. A yellow LED shows the switching state.

Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

Marking Ex II 2 G Ex ia IIC T6 Gb / II 1 D Ex ia IIIC T135 °C Da, certificate KEMA 02 ATEX 1090X. SIL2 (low demand) acc. to IEC 61508 and PL c acc. to ISO 13849-1 with HFT0; SIL3 and PL e in redundant configuration with HFT1. MTTF 6198 years acc. to SN 29500 (40 °C).

BI4-M12-VN6X-H1141 is a Turck inductive sensor in an M12 x 1 chrome-plated brass housing with an increased 4 mm switching distance for flush mounting. Its complementary NPN output switches one NO and one NC signal at the same time.

• Sensing distance: 4 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: NPN, complementary (NO + NC); up to 200 mA; switching frequency 2 kHz
• Supply: 10...30 VDC, 4-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: M12 x 1 thread, chrome-plated brass, PA12-GF30 sensing face, thread length 36 mm, nut torque up to 10 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: M12 x 1 connector, 4-pin

A yellow LED shows the switching state. Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).

NI5U-Q10S-AP6X is a TURCK uprox+ inductive sensor in a flat rectangular housing only 10.2 mm high, with the sensing face on the side. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 5 mm, non-flush; can be mounted flush on up to 4 sides
• Output: PNP, NO, 3-wire, max. 150 mA; short-circuit, wire-break and reverse polarity protection, switching frequency 1 kHz
• Supply: 10...30 VDC, no-load current 15 mA
• Housing: rectangular Q10S, 27.8 x 16 x 10.2 mm, PP-GF20
• Environment: IP68, operating temperature -30...+85 °C
• Connection: 2 m PUR cable, 3 x 0.14 mm², Ø 3 mm, suitable for cable chains

Fits where a cylindrical sensor has no room: grippers, slides and end-of-travel positions on small machines. The cable can be led out to any side, and a yellow LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI2-M12-AP6X-H1141 is a Turck inductive sensor in an M12 x 1 chrome-plated brass housing with a 2 mm switching distance for flush mounting.

• Sensing distance: 2 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, NO; up to 200 mA; switching frequency 2 kHz
• Supply: 10...30 VDC, 3-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: M12 x 1 thread, chrome-plated brass, PA12-GF30 sensing face, thread length 36 mm, nut torque up to 10 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: M12 x 1 connector, 4-pin

A yellow LED shows the switching state. Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).

BI8-M18-LIU is a Turck inductive sensor in an M18 threaded housing with analog output, for flush mounting. Its output signal is proportional to the distance of a metal target and linear across the whole measuring range. The sensor is intended for simple control tasks where the distance matters, not just presence.

• Accuracy: linearity deviation 5 %, repeatability ≤ 1 % of measuring range (0.5 % after 0.5 h warm-up), reproducibility ≤ 40 µm (≤ 20 µm after warm-up), temperature drift ≤ ±0.06 %/K
• Measuring range: 1...5 mm (St37 steel target)
• Outputs: voltage 0...10 V (load ≥ 4.7 kΩ) and current 0...20 mA (load ≤ 0.4 kΩ); measuring frequency 200 Hz
• Supply: 15...30 VDC, 4-wire, no-load current 8 mA
• Protection: short circuit and reverse polarity; no wire-break protection
• Housing: M18 x 1 thread, thread length 55 mm, chrome-plated brass, PA12-GF30 sensing face, nut torque up to 25 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: 2 m PVC cable (LifYY), 4 x 0.34 mm², Ø 5.2 mm

Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 751 years acc. to SN 29500 (40 °C).

Sn = 3 mm, M8×1 metal thread (nickel-plated brass), flush, short barrel, with cable connection (3 m), 10–30V DC, PNP NO (operable as 2-wire PNP/NPN NO), IP67

NI6U-EG08-AP6X is a TURCK uprox+ inductive sensor with an extended 6 mm switching distance in a stainless steel M8 housing. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 200 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 6 mm, non-flush mounting
• Output: PNP, NO, 3-wire, max. 150 mA, switching frequency 1 kHz; short-circuit, wire-break and reverse polarity protection
• Supply: 10...30 VDC, no-load current 15 mA
• Housing: M8 x 1 stainless steel 1.4427 SO, PA12-GF30 sensing face, thread length 35 mm, nut torque max. 5 Nm
• Environment: IP68, operating temperature -30...+85 °C
• Connection: 2 m PUR cable, 3 x 0.25 mm², Ø 4 mm

Integrated protection against predamping, and only a small metal-free zone is needed around the sensing face. A yellow LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI1-EG05-AP6X-V1331 is a Turck inductive sensor in an M5 x 0.5 stainless steel housing with a 1 mm switching distance for flush mounting.

• Sensing distance: 1 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, NO; up to 100 mA; switching frequency 3 kHz
• Supply: 10...30 VDC, 3-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: M5 x 0.5 thread, stainless steel 1.4305 (AISI 303), PA6.6 sensing face, thread length 27.9 mm, nut torque up to 2.5 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: M8 x 1 connector, 3-pin

A yellow LED shows the switching state. Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).

BI50U-Q80-VP4X2-H1141 is a TURCK uprox+ rectangular inductive sensor with a 50 mm switching distance, flush mountable, in a 92 x 80 x 40 mm Q80 housing with the active face on top. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 50 mm, flush mounting
• Output: PNP, complementary (NO + NC), 4-wire, max. 200 mA; short-circuit, wire-break and reverse polarity protection, switching frequency 250 Hz
• Supply: 10...65 VDC, no-load current 15 mA
• Housing: rectangular Q80, 92 x 80 x 40 mm, yellow PBT-GF30-V0, fixing screw torque 4 Nm
• Environment: IP68, operating temperature -25...+70 °C
• Connection: M12 connector, 4-pin

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI8U-EM18WD-AP6X-H1141 is a TURCK uprox+ inductive sensor for the food industry with a 8 mm rated switching distance. The housing is 1.4404 (AISI 316L) stainless steel with an LCP front cap and a double-lip seal, resistant to common acidic and alkaline cleaning agents.

• Switching distance: 8 mm, flush mounting, factor 1 for all metals
• Output: PNP, NO, 3-wire, max. 200 mA; short-circuit, wire-break and reverse polarity protection, switching frequency 1.5 kHz
• Supply: 10...30 VDC, no-load current 25 mA
• Housing: M18 x 1 stainless steel 1.4404, thread length 36 mm, nut torque max. 25 Nm
• Environment: IP68 / IP69K, operating temperature -40...+100 °C
• Connection: M12 connector, 4-pin

Used on washdown lines and filling or packaging machines where the sensor is cleaned in place with high-pressure water and chemicals. A yellow LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

NI5-P12-Y1/S100 is a TURCK intrinsically safe inductive sensor with a 2-wire NAMUR output to EN 60947-5-6, a 5 mm switching distance and an extended temperature range up to +100 °C. It is approved for ATEX zone 1 (gas) and zone 20 (dust, up to +70 °C) and must be connected to an approved Ex i isolating amplifier.

• Switching distance: 5 mm, non-flush mounting
• Output: NAMUR, 2-wire; current ≥ 2.1 mA not actuated, ≤ 1.2 mA actuated; switching frequency 2 kHz
• Supply: nom. 8.2 VDC from the isolating amplifier; Ui 20 V, Ii 60 mA, Pi 200 mW, Ci 150 nF, Li 150 µH
• Housing: M12 x 1 plastic PA12-GF30, thread length 30 mm, nut torque max. 1 Nm
• Environment: IP67, operating temperature -25...+100 °C
• Connection: 2 m PVC cable LifYY-T105, 2 x 0.5 mm², Ø 5.2 mm

Correction factors (St37 = 1): stainless steel 0.7, brass 0.4, aluminium 0.3. For safety functions it reaches SIL2 / PL c as a single channel (HFT0) and SIL3 / PL e in a redundant configuration (HFT1).

ATEX KEMA 02 ATEX 1090X, Ex II 2 G Ex ia IIC T6 Gb / II 1 D Ex ia IIIC T135 °C Da. SIL2 to IEC 61508, PL c to ISO 13849-1. MTTF 6198 years (SN 29500, 40 °C).

NI10-M18E-LIU-H1141 is a Turck inductive sensor in an M18 threaded housing with analog output, for non-flush mounting. Its output signal is proportional to the distance of a metal target and linear across the whole measuring range. The sensor is intended for simple control tasks where the distance matters, not just presence.

• Accuracy: linearity deviation 5 %, repeatability ≤ 1 % of measuring range (0.5 % after 0.5 h warm-up), reproducibility ≤ 60 µm (≤ 30 µm after warm-up), temperature drift ≤ ±0.06 %/K
• Measuring range: 1...7 mm (St37 steel target)
• Outputs: voltage 0...10 V (load ≥ 4.7 kΩ) and current 0...20 mA (load ≤ 0.4 kΩ); measuring frequency 100 Hz
• Supply: 15...30 VDC, 4-wire, no-load current 8 mA
• Protection: short circuit and reverse polarity; no wire-break protection
• Housing: M18 x 1 thread, thread length 46 mm, chrome-plated brass, PA12-GF30 sensing face, nut torque up to 25 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: M12 x 1 connector, 4-pin

Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 751 years acc. to SN 29500 (40 °C).

IR06.D03L-Q40.UA1Z.7SCV is a Baumer miniature inductive distance sensor with a 0...3 mm measuring range and a linearised 0...10 V output. The smooth 6.5 mm stainless steel housing is 40 mm long.

• Accuracy: linearity error ±15 µm (0...2 mm), ±90 µm (0...3 mm); repeatability 0.01 mm; temperature drift ±2 % FS (0...2 mm), ±6 % FS (0...3 mm)
• Measuring range: 0...3 mm, sensitivity 3.33 V/mm, resolution < 0.003 mm static, < 0.009 mm dynamic (0...2 mm)
• Output: voltage 0...10 VDC, linear, load resistance > 4000 Ohm, response time < 2 ms
• Supply: 12...30 VDC, 3-wire, consumption max. 10 mA; short-circuit and reverse polarity protection
• Housing: Ø6.5 mm smooth stainless steel, PBT sensing face, length 40 mm, quasi-flush mounting
• Environment: IP67, operating temperature -25...+75 °C
• Connection: 2 m cable

The best linearity is in the first 2 mm of the range, so mount the sensor so that the working stroke stays within it where accuracy matters.

IR30.P18S-F35.PV1Z.7BCV is a Baumer M30 inductive sensor with enhanced sensing distance (GammaProx): 18 mm for flush mounting in a 35 mm housing. The complementary PNP output gives an NO and an NC signal at the same time; wire colours are brown +Vs, blue 0 V, black NO, white NC.

• Sensing distance: 18 mm, flush mounting; temperature drift ±10 %, hysteresis 3...20 % of Sr
• Output: PNP complementary (NO/NC); output current < 200 mA, voltage drop < 2 VDC; switching frequency 500 Hz
• Supply: 6...36 VDC, 4-wire, current consumption max. 10 mA (no load)
• Protection: short circuit, reverse polarity
• Housing: M30x1.5, nickel-plated brass, length 35 mm, PBT sensing face, red LED, tightening torque max. 140 Nm
• Environment: IP67, operating temperature -25...+75 °C
• Connection: 2 m cable

Correction factors for the target material: mild steel 100 %, stainless steel 70 %, aluminium 40 %. In a steel plate, mount the sensor with the sensing face protruding 1/3 Sn; the sensing distance is then 105 % of Sn. With the face level with the plate the sensor does not work in mild or stainless steel, and in aluminium it reaches 75 % of Sn.

BI5-M18-AZ3X is a Turck inductive sensor in an M18 chrome-plated brass housing with a 2-wire normally open (NO) output. The sensor runs on both AC and DC supply. A red LED shows the switching state.

• Sensing distance: 5 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: 2-wire, NO; up to 400 mA AC / 300 mA DC, minimum load current ≥ 3 mA, surge current ≤ 8 A (≤ 10 ms, max. 5 Hz); switching frequency 20 Hz
• Supply: 20...250 VAC (50...60 Hz) or 10...300 VDC; voltage drop ≤ 6 V, residual current ≤ 1.7 mA
• Housing: M18 x 1 thread, thread length 55 mm, chrome-plated brass, PA12-GF30 sensing face, nut torque up to 25 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: 2 m PVC cable (LifYY), 3 x 0.5 mm², Ø 5.2 mm

Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).

NI3-M08E-AP6X is a Turck inductive sensor in an M8 x 1 nickel-plated brass housing with an increased 3 mm switching distance for non-flush mounting.

• Sensing distance: 3 mm, non-flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, NO; up to 150 mA; switching frequency 2.8 kHz
• Supply: 10...30 VDC, 3-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: M8 x 1 thread, nickel-plated brass, PP-GF20 sensing face, thread length 36 mm, nut torque up to 7 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: 2 m PUR cable (Lif9Y-11Y), 3 x 0.14 mm², Ø 3 mm

A yellow LED shows the switching state. Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).

IPS12-S4PO30-A2P is an XECRO M12 inductive sensor with increased sensing range: 4 mm for flush mounting, with a PNP normally open (NO) output. A switching indicator LED is built into the housing.

• Sensing distance: 4 mm (increased range), flush mounting
• Output: PNP, NO; load up to 200 mA, voltage drop < 1.5 V at 200 mA; switching frequency 1000 Hz
• Supply: 10...30 VDC, 3-wire, current consumption < 8 mA
• Protection: reverse polarity, short circuit (self-resetting)
• Housing: M12x1, brass, PBT sensing face
• Environment: IP67, operating temperature -20...+70 °C
• Connection: 2 m PVC cable (ultra-flex)

Reduction factors for other target metals: aluminium 0.45, brass 0.50, stainless steel 0.85.

BI4-G12K-AP6X is a Turck inductive sensor in an M12 x 1 chrome-plated brass housing with an increased 4 mm switching distance for flush mounting.

• Sensing distance: 4 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, NO; up to 200 mA; switching frequency 2 kHz
• Supply: 10...30 VDC, 3-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: M12 x 1 thread, chrome-plated brass, PA12-GF30 sensing face, thread length 30 mm, nut torque up to 10 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: 2 m PVC cable (LifYY), 3 x 0.34 mm², Ø 5.2 mm

A yellow LED shows the switching state. Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).

NI25-Q20-AP6X2-H1141 is a Turck inductive sensor in a rectangular Q20 plastic housing, 20 mm high, with the sensing face on top.

• Sensing distance: 25 mm, non-flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, NO; up to 200 mA; switching frequency 250 Hz
• Supply: 10...30 VDC, 3-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: Q20, 68 x 40 x 20 mm, PBT-GF30-V0 plastic, sensing face on top
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: M12 x 1 connector, 4-pin

A green LED shows power and a yellow LED the switching state. Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).

BI10-G30-Y1X is a Turck inductive sensor with a NAMUR output to EN 60947-5-6 in an M30 chrome-plated brass housing, approved for explosion-hazardous areas up to zone 0 (gas) and zone 20 (dust).

• Sensing distance: 10 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: NAMUR, 2-wire; current ≥ 2.1 mA not actuated, ≤ 1.2 mA actuated; switching frequency 500 Hz
• Supply: nominal 8.2 VDC; Ci/Li 150 nF / 150 µH
• Housing: M30 x 1.5 thread, thread length 40 mm, chrome-plated brass, PA12-GF30 sensing face, nut torque up to 75 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: 2 m blue PVC cable (LiYY), 2 x 0.5 mm², Ø 5.2 mm

The sensor may only be connected to certified intrinsically safe (Ex i) circuits, for example an isolating switching amplifier with a NAMUR input. Maximum input values: Ui = 20 V, Ii = 20 mA, Pi = 200 mW. A yellow LED shows the switching state.

Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

Marking Ex II 1 G Ex ia IIC T6 Ga / II 1 D Ex ia IIIC T135 °C Da, certificate KEMA 02 ATEX 1090X. SIL2 (low demand) acc. to IEC 61508 and PL c acc. to ISO 13849-1 with HFT0; SIL3 and PL e in redundant configuration with HFT1. MTTF 6198 years acc. to SN 29500 (40 °C).

SMBAMS18RA is a right-angle bracket from the Banner SMBAMS series for barrel sensors with an 18 mm thread.

• Sensor hole: Ø19.0 mm, for 18 mm threaded sensors
• Material: 12-ga (2.6 mm) cold-rolled steel
• Adjustment: articulation slots, rotation beyond 90°
• Included: mounting hardware

BI1U-EG05-AP6X is a Turck uprox3 inductive sensor in an M5 x 0.5 stainless steel housing with a 1 mm switching distance for flush mounting. The switching distance is the same for all metals.

• Sensing distance: 1 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, NO; up to 100 mA; switching frequency 2 kHz
• Supply: 10...30 VDC, 3-wire, no-load current 20 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: M5 x 0.5 thread, thread length 30.2 mm, stainless steel 1.4427 SO, PA12 sensing face, nut torque up to 5 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: 2 m PUR cable (LifY-11Y), 3 x 0.14 mm², Ø 3 mm

The sensor is immune to magnetic DC and AC fields up to 200 mT. A yellow LED shows the switching state. MTTF 874 years acc. to SN 29500 (40 °C).

BI5-M18-LIU is a Turck inductive sensor in an M18 threaded housing with analog output, for flush mounting. Its output signal is proportional to the distance of a metal target and linear across the whole measuring range. The sensor is intended for simple control tasks where the distance matters, not just presence.

• Accuracy: linearity deviation 3 %, repeatability ≤ 1 % of measuring range (0.5 % after 0.5 h warm-up), reproducibility ≤ 20 µm (≤ 10 µm after warm-up), temperature drift ≤ ±0.06 %/K
• Measuring range: 2...4 mm (St37 steel target)
• Outputs: voltage 0...10 V (load ≥ 4.7 kΩ) and current 0...20 mA (load ≤ 0.4 kΩ); measuring frequency 200 Hz
• Supply: 15...30 VDC, 4-wire, no-load current 8 mA
• Protection: short circuit and reverse polarity; no wire-break protection
• Housing: M18 x 1 thread, thread length 55 mm, chrome-plated brass, PA12-GF30 sensing face, nut torque up to 25 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: 2 m PVC cable (LifYY), 4 x 0.34 mm², Ø 5.2 mm

Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 751 years acc. to SN 29500 (40 °C).

BI5U-S18-VP6X-H1141 is a TURCK uprox inductive sensor with a 5 mm switching distance in a flush-mountable M18 plastic housing. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 5 mm, flush mounting
• Output: PNP, complementary (NO + NC), 4-wire, max. 200 mA; short-circuit, wire-break and reverse polarity protection, switching frequency 1.5 kHz
• Supply: 10...30 VDC, no-load current 25 mA
• Housing: M18 x 1 plastic PA12-GF30, thread length 35 mm, nut torque max. 2 Nm
• Environment: IP68, operating temperature -30...+85 °C
• Connection: M12 connector, 4-pin

The plastic housing takes only 2 Nm on the nuts, so it should not be clamped hard into a steel plate.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI2-M08K-AP6X-V1131 is a Turck inductive sensor in an M8 x 1 nickel-plated brass housing with an increased 2 mm switching distance for flush mounting.

• Sensing distance: 2 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, NO; up to 150 mA; switching frequency 2.8 kHz
• Supply: 10...30 VDC, 3-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: M8 x 1 thread, nickel-plated brass, PP-GF20 sensing face, thread length 22 mm, nut torque up to 7 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: M8 x 1 connector, 3-pin

A yellow LED shows the switching state. Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).

BI6U-M12-VP6X 7M is a TURCK uprox3 inductive sensor. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 6 mm, flush mounting
• Output: PNP, complementary (NO + NC), 4-wire, max. 200 mA, switching frequency 2 kHz; short-circuit, wire-break and reverse polarity protection
• Supply: 10...30 VDC, no-load current 25 mA
• Housing: M12 x 1 chrome-plated brass, LCP sensing face, thread length 45 mm, nut torque max. 7 Nm
• Environment: IP68, operating temperature -25...+70 °C
• Connection: 7 m PVC cable, 4 x 0.34 mm², Ø 5.2 mm

A yellow LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI20U-CK40-VP4X2-H1141 is a TURCK uprox+ inductive sensor with a 20 mm switching distance in a flush-mountable CK40 rectangular housing. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 20 mm, flush mounting, factor 1 for all metals
• Output: PNP, complementary (NO + NC), 4-wire, max. 200 mA; short-circuit, wire-break and reverse polarity protection, switching frequency 0.25 kHz
• Supply: 10...65 VDC, no-load current 15 mA
• Housing: rectangular CK40, 65 x 40 x 40 mm, PBT-GF20-V0, PA12-GF30 sensing face
• Environment: IP68, operating temperature -30...+85 °C
• Connection: M12 connector, 4-pin

The sensing head turns to 5 positions, and two green and two yellow corner LEDs show power and switching state from any side. The BS1-CK40 mounting part is included.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI2-G12-Y1X 6M is a TURCK intrinsically safe inductive sensor with a 2-wire NAMUR output to EN 60947-5-6 and a 2 mm switching distance. It is approved for ATEX zone 0 (gas) and zone 20 (dust) and must be connected to an approved Ex i isolating amplifier.

• Switching distance: 2 mm, flush mounting
• Output: NAMUR, 2-wire; current ≥ 2.1 mA not actuated, ≤ 1.2 mA actuated; switching frequency 5 kHz
• Supply: nom. 8.2 VDC from the isolating amplifier; Ui 20 V, Ii 20 mA, Pi 200 mW, Ci 150 nF, Li 150 µH
• Housing: M12 x 1 chrome-plated brass, PA12-GF30 sensing face, thread length 30 mm, nut torque max. 10 Nm
• Environment: IP67, operating temperature -25...+70 °C
• Connection: 6 m PVC cable, blue, 2 x 0.34 mm², Ø 5.2 mm

Correction factors (St37 = 1): stainless steel 0.7, brass 0.4, aluminium 0.3. For safety functions it reaches SIL2 / PL c as a single channel (HFT0) and SIL3 / PL e in a redundant configuration (HFT1).

ATEX KEMA 02 ATEX 1090X, Ex II 1 G Ex ia IIC T6 Ga / II 1 D Ex ia IIIC T135 °C Da. SIL2 to IEC 61508, PL c to ISO 13849-1. MTTF 6198 years (SN 29500, 40 °C).

BI5U-S18-AP6X-H1141 is a Turck uprox Factor 1 inductive sensor in an M18 plastic housing with a PNP NO output and an M12 connector.

• Sensing distance: 5 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, NO; up to 200 mA; switching frequency 2.5 kHz
• Supply: 10...30 VDC, 3-wire, no-load current 25 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: M18 x 1 thread, thread length 36 mm, PBT-GF30 plastic, nut torque up to 2 Nm
• Environment: IP68, ambient temperature -30...+85 °C
• Connection: M12 x 1 connector, 4-pin

Factor 1: the switching distance is the same for steel, stainless steel, aluminium and brass, so no correction factor applies when the target metal changes. The sensor is immune to magnetic DC and AC fields up to 300 mT.

A yellow LED shows the switching state. MTTF 874 years acc. to SN 29500 (40 °C).

NI12U-S18-AP6X-H1141 is a TURCK uprox inductive sensor with a 12 mm switching distance in a plastic M18 housing. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 12 mm, non-flush mounting, partially embeddable
• Output: PNP, NO, 3-wire, max. 200 mA, switching frequency 1 kHz; short-circuit, wire-break and reverse polarity protection
• Supply: 10...30 VDC, no-load current 25 mA
• Housing: M18 x 1 plastic, PBT-GF30 housing and sensing face, thread length 36 mm, nut torque max. 2 Nm
• Environment: IP68, operating temperature -30...+85 °C
• Connection: M12 connector, 4-pin

A yellow LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

KJ20-Q40KB-DPU-V2 is a Pulsotronic inductive sensor in a 41 x 41 x 120 mm block housing, with a 20 mm sensing distance for flush mounting and a PNP output that can be switched between NO and NC. Two LEDs show the operating state and the switching state.

• Sensing distance: 20 mm, flush mounting; hysteresis ≤ 20 %, temperature drift ≤ 10 %, repeatability ≤ 5 %
• Output: PNP, NO/NC switchable; load up to 120 mA, voltage drop 2.4 V, leakage current ≤ 10 µA; switching frequency 150 Hz
• Supply: 10...30 VDC, ripple ≤ 10 %, no-load current ≤ 10 mA
• Protection: short circuit, overload, reverse polarity
• Housing: 41 x 41 x 120 mm
• Environment: IP67, operating temperature -25...+70 °C
• Connection: M12 connector, 4-pin

EMC per DIN EN 60947-5-2:2008, utilisation category DC 13.

IFRM 12P13T1/S14L is a Baumer M12 inductive sensor from the outdoor and washdown series, with a 6 mm sensing distance for non-flush mounting and a PNP normally open (NO) output. Three red LEDs on the housing show the switching state.

• Sensing distance: 6 mm, non-flush mounting; hysteresis 2...15 % of Sr
• Output: PNP, NO; output current < 200 mA, voltage drop < 2 VDC; switching frequency 2 kHz
• Supply: 6...30 VDC, 3-wire, current consumption max. 10 mA (no load)
• Protection: short circuit, reverse polarity
• Housing: M12x1, nickel-plated brass, length 60 mm, PBT sensing face, tightening torque max. 15 Nm (front 10 Nm)
• Environment: IP67, operating temperature -40...+80 °C
• Connection: M12 connector

NI8-M18E-LIU-H1141 is a Turck inductive sensor in an M18 threaded housing with analog output, for non-flush mounting. Its output signal is proportional to the distance of a metal target and linear across the whole measuring range. The sensor is intended for simple control tasks where the distance matters, not just presence.

• Accuracy: linearity deviation 3 %, repeatability ≤ 1 % of measuring range (0.5 % after 0.5 h warm-up), reproducibility ≤ 40 µm (≤ 20 µm after warm-up), temperature drift ≤ ±0.06 %/K
• Measuring range: 1...5 mm (St37 steel target)
• Outputs: voltage 0...10 V (load ≥ 4.7 kΩ) and current 0...20 mA (load ≤ 0.4 kΩ); measuring frequency 100 Hz
• Supply: 15...30 VDC, 4-wire, no-load current 8 mA
• Protection: short circuit and reverse polarity; no wire-break protection
• Housing: M18 x 1 thread, thread length 46 mm, chrome-plated brass, PA12-GF30 sensing face, nut torque up to 25 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: M12 x 1 connector, 4-pin

Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 751 years acc. to SN 29500 (40 °C).

NI15U-M18M-VP6X-H1141 is a TURCK uprox+ inductive sensor with an extended 15 mm switching distance in an M18 housing. It detects all metals at the same distance and has integrated protection against predamping by surrounding metal.

• Switching distance: 15 mm, non-flush mounting, factor 1 for all metals
• Output: PNP, complementary (NO + NC), 4-wire, max. 200 mA; short-circuit, wire-break and reverse polarity protection, switching frequency 1 kHz
• Supply: 10...30 VDC, no-load current 15 mA
• Housing: M18 x 1 chrome-plated brass, LCP sensing face, thread length 36 mm, nut torque max. 25 Nm
• Environment: IP68, operating temperature -30...+85 °C, magnetic field immunity 300 mT
• Connection: M12 connector, 4-pin

It can be screwed in up to the top of the thread, with the switching distance then reduced by 20 %. In an aperture plate keep a distance of 70 mm.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI15U-CK40-AP6X2-H1141 is a TURCK uprox inductive sensor with a 15 mm switching distance in a flush-mountable CK40 rectangular housing. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 15 mm, flush mounting, factor 1 for all metals
• Output: PNP, NO, 3-wire, max. 200 mA; short-circuit, wire-break and reverse polarity protection, switching frequency 0.25 kHz
• Supply: 10...30 VDC, no-load current 15 mA
• Housing: rectangular CK40, 65 x 40 x 40 mm, PBT-GF20-V0, PA12-GF30 sensing face
• Environment: IP68, operating temperature -30...+85 °C
• Connection: M12 connector, 4-pin

The sensing head turns to 5 positions, and two green and two yellow corner LEDs show power and switching state from any side. The BS1-CK40 mounting part is included.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

NI8U-M12EE-AP6X-H1141 is a TURCK uprox inductive sensor in an extra long M12 housing. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 8 mm, non-flush mounting
• Output: PNP, NO, 3-wire, max. 200 mA, switching frequency 2 kHz; short-circuit, wire-break and reverse polarity protection
• Supply: 10...30 VDC, no-load current 25 mA
• Housing: M12 x 1 chrome-plated brass, LCP sensing face, thread length 46 mm, nut torque max. 10 Nm
• Environment: IP68, operating temperature -30...+85 °C
• Connection: M12 connector, 4-pin

A yellow LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI8-M18-VN6X-H1141 is a Turck inductive sensor in an M18 x 1 chrome-plated brass housing with an increased 8 mm switching distance for flush mounting. Its complementary NPN output switches one NO and one NC signal at the same time.

• Sensing distance: 8 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: NPN, complementary (NO + NC); up to 200 mA; switching frequency 500 Hz
• Supply: 10...30 VDC, 4-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: M18 x 1 thread, chrome-plated brass, PA12-GF30 sensing face, thread length 36 mm, nut torque up to 25 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: M12 x 1 connector, 4-pin

A yellow LED shows the switching state. Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).

BI5U-Q12-AP6X2 is a Turck uprox+ inductive sensor in a rectangular Q12 plastic housing, 12 mm high, with the sensing face on the side. It has an extended 5 mm switching distance, the same for all metals, and can be mounted on metal.

• Sensing distance: 5 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, NO; up to 200 mA; switching frequency 1 kHz
• Supply: 10...30 VDC, 3-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: Q12, 40 x 26 x 12 mm, PA12-GF30 plastic, lateral sensing face
• Environment: IP68, ambient temperature -25...+70 °C
• Connection: 2 m PUR cable (LifYY-11Y), 3 x 0.25 mm², Ø 4 mm

Two sensors can be mounted directly side by side only when one of them is the version with a staggered oscillator frequency (/F2). The sensor is immune to magnetic DC and AC fields up to 300 mT. A green LED shows power and a yellow LED the switching state.

MTTF 874 years acc. to SN 29500 (40 °C).

BI5U-Q12-AP6X2-V1131 is a Turck uprox+ inductive sensor in a rectangular Q12 plastic housing, 12 mm high, with the sensing face on the side. It has an extended 5 mm switching distance, the same for all metals, and can be mounted on metal.

• Sensing distance: 5 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, NO; up to 200 mA; switching frequency 1 kHz
• Supply: 10...30 VDC, 3-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: Q12, 40 x 26 x 12 mm, PA12-GF30 plastic, lateral sensing face
• Environment: IP68, ambient temperature -25...+70 °C
• Connection: M8 x 1 connector, 3-pin

Two sensors can be mounted directly side by side only when one of them is the version with a staggered oscillator frequency (/F2). The sensor is immune to magnetic DC and AC fields up to 300 mT. A green LED shows power and a yellow LED the switching state.

MTTF 874 years acc. to SN 29500 (40 °C).

NI6U-EG08-AP6X-V1131 is a TURCK uprox+ inductive sensor with an extended 6 mm switching distance in a stainless steel M8 housing. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 200 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 6 mm, non-flush mounting
• Output: PNP, NO, 3-wire, max. 150 mA, switching frequency 1 kHz; short-circuit, wire-break and reverse polarity protection
• Supply: 10...30 VDC, no-load current 15 mA
• Housing: M8 x 1 stainless steel 1.4427 SO, PA12-GF30 sensing face, thread length 35 mm, nut torque max. 5 Nm
• Environment: IP68, operating temperature -30...+85 °C
• Connection: M8 connector, 3-pin

Integrated protection against predamping, and only a small metal-free zone is needed around the sensing face. A yellow LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI2-M08E-AP6X-V1131 is a Turck inductive sensor in an M8 x 1 nickel-plated brass housing with an increased 2 mm switching distance for flush mounting.

• Sensing distance: 2 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, NO; up to 150 mA; switching frequency 2.8 kHz
• Supply: 10...30 VDC, 3-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: M8 x 1 thread, nickel-plated brass, PP-GF20 sensing face, thread length 40 mm, nut torque up to 7 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: M8 x 1 connector, 3-pin

A yellow LED shows the switching state. Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).

IPS30-N15PO79-A12 is an XECRO M30 inductive sensor for non-flush mounting with a 15 mm standard sensing distance and a PNP normally open (NO) output. A switching indicator is built into the housing.

• Sensing distance: 15 mm, non-flush mounting; repeatability < 1 % of Sn, hysteresis 3...15 %
• Output: PNP, NO; load up to 200 mA, voltage drop < 1.5 V at 200 mA; switching frequency 150 Hz
• Supply: 10...30 VDC, 3-wire, current consumption < 8 mA
• Protection: reverse polarity, short circuit (self-resetting)
• Housing: M30, nickel-plated brass, length 79 mm, PBT sensing face, tightening torque max. 75 Nm
• Environment: IP67, operating temperature -20...+70 °C
• Connection: M12 connector

The sensing distance applies to steel. For other metals multiply it by the reduction factor: aluminium 0.45, brass 0.50, stainless steel 0.85.

BI8-Q10-VP6X2 is a Turck inductive sensor in a flat rectangular Q10 plastic housing with a 8 mm switching distance for flush mounting. Its complementary PNP output switches one NO and one NC signal at the same time.

• Sensing distance: 8 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, complementary (NO + NC); up to 200 mA; switching frequency 1 kHz
• Supply: 10...30 VDC, 4-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: Q10, 42 x 25 x 10.8 mm, sensing face on top, PBT-GF30-V0 plastic, PBT-GF30-V0 sensing face
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: 2 m PVC cable (LifYY), 4 x 0.25 mm², Ø 4 mm

A green LED shows power and a yellow LED the switching state. Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).

NI30U-EM30WD-VP6X-H1141 is a TURCK uprox+ inductive sensor for the food industry with a 30 mm rated switching distance. The housing is 1.4404 (AISI 316L) stainless steel with an LCP front cap and a double-lip seal, resistant to common acidic and alkaline cleaning agents.

• Switching distance: 30 mm, non-flush mounting, factor 1 for all metals
• Output: PNP, complementary (NO + NC), 4-wire, max. 200 mA; short-circuit, wire-break and reverse polarity protection, switching frequency 1 kHz
• Supply: 10...30 VDC, no-load current 25 mA
• Housing: M30 x 1.5 stainless steel 1.4404, thread length 31 mm, LCP front cap rated to 10 bar, nut torque max. 75 Nm
• Environment: IP68 / IP69K, operating temperature -40...+100 °C
• Connection: M12 connector, 4-pin, PP connector housing

Used on washdown lines and filling or packaging machines where the sensor is cleaned in place with high-pressure water and chemicals. It can be screwed in up to the top of the thread, with the switching distance then reduced by 20 %.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI20U-M30-AP6X-H1141 is a TURCK uprox3 inductive sensor with an extended 20 mm switching distance in an M30 housing. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 20 mm, flush mounting
• Output: PNP, NO, 3-wire, max. 200 mA, switching frequency 1 kHz; short-circuit, wire-break and reverse polarity protection
• Supply: 10...30 VDC, no-load current 25 mA
• Housing: M30 x 1.5 chrome-plated brass, LCP sensing face, thread length 46 mm, nut torque max. 50 Nm
• Environment: IP68, operating temperature -25...+70 °C
• Connection: M12 connector, 4-pin

A yellow LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

NI75U-CP80-AP6X2/S97 is a TURCK uprox+ inductive sensor with a 75 mm switching distance in an 80 x 80 mm housing. The S97 version works down to -40 °C. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 75 mm, non-flush mounting
• Output: PNP, NO, 3-wire, max. 200 mA; short-circuit, wire-break and reverse polarity protection, switching frequency 0.25 kHz
• Supply: 10...30 VDC, no-load current 15 mA
• Housing: rectangular CP80, 80 x 80 x 41 mm, PBT-GF30-V0
• Environment: IP67, operating temperature -40...+70 °C
• Connection: terminal chamber, conductors up to 2.5 mm²

Used outdoors and in cold stores, cranes and port equipment, where large metal parts are detected at a distance. A green LED shows power and a second LED the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI2-G12-Y1 is a Turck inductive sensor with a NAMUR output to EN 60947-5-6 in an M12 chrome-plated brass housing, approved for explosion-hazardous areas up to zone 0 (gas) and zone 20 (dust).

• Sensing distance: 2 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: NAMUR, 2-wire; current ≥ 2.1 mA not actuated, ≤ 1.2 mA actuated; switching frequency 5 kHz
• Supply: nominal 8.2 VDC; Ci/Li 150 nF / 150 µH
• Housing: M12 x 1 thread, thread length 30 mm, chrome-plated brass, PA12-GF30 sensing face, nut torque up to 10 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: 2 m blue PVC cable (LifYY), 2 x 0.34 mm², Ø 5.2 mm

The sensor may only be connected to certified intrinsically safe (Ex i) circuits, for example an isolating switching amplifier with a NAMUR input. Maximum input values: Ui = 20 V, Ii = 60 mA, Pi = 200 mW.

Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

Marking Ex II 1 G Ex ia IIC T6 Ga / II 1 D Ex ia IIIC T135 °C Da, certificate KEMA 02 ATEX 1090X. SIL2 (low demand) acc. to IEC 61508 and PL c acc. to ISO 13849-1 with HFT0; SIL3 and PL e in redundant configuration with HFT1. MTTF 6198 years acc. to SN 29500 (40 °C).

NI8-M18-AP6X/S120 is a Turck inductive sensor in an M18 x 1 chrome-plated brass housing with a 8 mm switching distance for non-flush mounting. The S120 version and its silicone cable are rated for ambient temperatures up to +120 °C.

• Temperature: ambient up to +120 °C (special version S120), range -25...+120 °C; IP67
• Sensing distance: 8 mm, non-flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, NO; up to 200 mA; switching frequency 100 Hz
• Supply: 10...30 VDC, 3-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: M18 x 1 thread, chrome-plated brass, PA12-GF30 sensing face, thread length 60 mm, nut torque up to 25 Nm
• Connection: 2 m silicone cable (SiHSi), 3 x 0.5 mm², Ø 5.2 mm

The permissible output current falls at higher ambient temperatures - see the derating curve in the datasheet.

A yellow LED shows the switching state. Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

NI14-M18-AN6X-H1141 is a Turck inductive sensor in an M18 x 1 chrome-plated brass housing with an increased 14 mm switching distance for non-flush mounting.

• Sensing distance: 14 mm, non-flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: NPN, NO; up to 200 mA; switching frequency 500 Hz
• Supply: 10...30 VDC, 3-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: M18 x 1 thread, chrome-plated brass, PA12-GF30 sensing face, housing length 52 mm, nut torque up to 25 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: M12 x 1 connector, 4-pin

A yellow LED shows the switching state. Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).

NI15U-EM18E-AP6X-H1141 is a TURCK uprox inductive sensor with an extended 15 mm switching distance in a stainless steel M18 housing. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 15 mm, non-flush mounting
• Output: PNP, NO, 3-wire, max. 200 mA, switching frequency 1 kHz; short-circuit, wire-break and reverse polarity protection
• Supply: 10...30 VDC, no-load current 25 mA
• Housing: M18 x 1 stainless steel 1.4301, LCP sensing face, thread length 46 mm, nut torque max. 25 Nm
• Environment: IP68, operating temperature -30...+85 °C
• Connection: M12 connector, 4-pin

A yellow LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI10U-M18E-AP6X-H1141 is a TURCK uprox3 inductive sensor with an extended 10 mm switching distance in a long M18 housing. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 10 mm, flush mounting
• Output: PNP, NO, 3-wire, max. 200 mA, switching frequency 1.5 kHz; short-circuit, wire-break and reverse polarity protection
• Supply: 10...30 VDC, no-load current 25 mA
• Housing: M18 x 1 chrome-plated brass, LCP sensing face, thread length 56 mm, nut torque max. 10 Nm
• Environment: IP68, operating temperature -25...+70 °C
• Connection: M12 connector, 4-pin

A yellow LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI5U-M18-AP6X is a TURCK uprox inductive sensor. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 5 mm, flush mounting
• Output: PNP, NO, 3-wire, max. 200 mA, switching frequency 1.5 kHz; short-circuit, wire-break and reverse polarity protection
• Supply: 10...30 VDC, no-load current 25 mA
• Housing: M18 x 1 chrome-plated brass, PBT sensing face, thread length 45 mm, nut torque max. 25 Nm
• Environment: IP68, operating temperature -30...+85 °C
• Connection: 2 m PVC cable, 3 x 0.34 mm², Ø 5.2 mm

A yellow LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

NI12U-M18-ADZ30X2 is a TURCK uprox Factor 1 inductive sensor in 2-wire AC/DC technology, so the same part runs on 20...250 VAC or 10...300 VDC. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 12 mm, non-flush mounting
• Output: 2-wire, NO, max. 400 mA AC / 300 mA DC, min. load current 3 mA, residual current 1.7 mA, voltage drop ≤ 6 V, switching frequency 0.01 kHz
• Supply: 20...250 VAC (50...60 Hz) or 10...300 VDC; short-circuit protection (latching), reverse polarity protection
• Housing: M18 x 1 chrome-plated brass, PBT sensing face, thread length 45 mm, nut torque max. 25 Nm
• Environment: IP68, operating temperature -30...+85 °C
• Connection: 2 m PVC cable, 3 x 0.5 mm², Ø 5.2 mm

Being a 2-wire device, it is wired in series with the load like a mechanical switch, which suits replacing limit switches on AC control circuits. The residual and minimum load currents above decide whether a given relay or PLC input will work with it. A green LED shows power and a yellow LED the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

NI75U-Q80-VP4X2-H1141 is a TURCK uprox+ inductive sensor with a 75 mm switching distance in a Q80 rectangular housing. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 75 mm, non-flush, partially embeddable
• Output: PNP, complementary (NO + NC), 4-wire, max. 200 mA; short-circuit, wire-break and reverse polarity protection, switching frequency 0.25 kHz
• Supply: 10...65 VDC, no-load current 15 mA
• Housing: rectangular Q80, 92 x 80 x 40 mm, PBT-GF30-V0
• Environment: IP68, operating temperature -25...+70 °C
• Connection: M12 connector, 4-pin

Used on cranes, lifting gear and steel handling, where large parts are detected at a distance. Four LEDs show power and switching state from any side.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI1U-S12-AP6X/S1132 is a TURCK uprox+ inductive sensor in a plastic M12 housing with a very short hysteresis of 0.03...0.1 mm. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 1 mm, flush mounting
• Output: PNP, NO, 3-wire, max. 200 mA, switching frequency 2 kHz; short-circuit, wire-break and reverse polarity protection
• Supply: 10...30 VDC, no-load current 25 mA
• Housing: M12 x 1 plastic, PA6-GK15 housing, PA12-GF30 sensing face, thread length 45 mm, nut torque max. 1 Nm
• Environment: IP68, operating temperature -25...+100 °C
• Connection: 2 m PVC cable, 3 x 0.5 mm², Ø 5.2 mm

The short hysteresis means the output switches back at almost the same point, which suits end positions and stops where a few tenths of a millimetre matter. The sensor can be mounted recessed. Above +70 °C the load current is reduced according to the derating curve in the datasheet. A yellow LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI4U-S18-AP6X/S1132 is a TURCK uprox+ inductive sensor in a plastic M18 housing with a very short hysteresis of 0.12...0.4 mm. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 4 mm, flush mounting
• Output: PNP, NO, 3-wire, max. 200 mA, switching frequency 2.5 kHz; short-circuit, wire-break and reverse polarity protection
• Supply: 10...30 VDC, no-load current 25 mA
• Housing: M18 x 1 plastic, PA12-GF30 housing and sensing face, thread length 50 mm, nut torque max. 2 Nm
• Environment: IP68, operating temperature -25...+100 °C
• Connection: 2 m PVC cable, 3 x 0.5 mm², Ø 5.2 mm

The short hysteresis means the output switches back at almost the same point, which suits end positions and stops where a few tenths of a millimetre matter. The sensor can be mounted recessed. Above +70 °C the load current is reduced according to the derating curve in the datasheet. A red LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI2-Q4.7-AP6X is a Turck miniature inductive sensor in a 16 x 8 x 4.7 mm die-cast zinc housing with the sensing face on top.

• Sensing distance: 2 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, NO; up to 100 mA; switching frequency 1 kHz
• Supply: 10...30 VDC, 3-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: Q4.7, 16 x 8 x 4.7 mm, GD-ZnAl zinc alloy, PA12 sensing face, fixing screw torque 0.5 Nm
• Environment: IP67, ambient temperature 0...+85 °C
• Connection: 2 m PUR cable (LifY-11Y), 3 x 0.14 mm², Ø 3 mm

A yellow LED shows the switching state. Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).

BI5-P18-Y1X is a Turck inductive sensor with a NAMUR output to EN 60947-5-6 in an M18 plastic housing, approved for explosion-hazardous areas up to zone 1 (gas) and zone 20 (dust).

• Sensing distance: 5 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: NAMUR, 2-wire; current ≥ 2.1 mA not actuated, ≤ 1.2 mA actuated; switching frequency 1 kHz
• Supply: nominal 8.2 VDC; Ci/Li 150 nF / 150 µH
• Housing: M18 x 1 thread, thread length 30 mm, PA12-GF30 plastic, nut torque up to 2 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: 2 m blue PVC cable (LifYY), 2 x 0.34 mm², Ø 5.2 mm

The sensor may only be connected to certified intrinsically safe (Ex i) circuits, for example an isolating switching amplifier with a NAMUR input. Maximum input values: Ui = 20 V, Ii = 20 mA, Pi = 200 mW. A yellow LED shows the switching state.

Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

Marking Ex II 2 G Ex ia IIC T6 Gb / II 1 D Ex ia IIIC T135 °C Da, certificate KEMA 02 ATEX 1090X. SIL2 (low demand) acc. to IEC 61508 and PL c acc. to ISO 13849-1 with HFT0; SIL3 and PL e in redundant configuration with HFT1. MTTF 6198 years acc. to SN 29500 (40 °C).

BI10U-CA25-AP6X2-H1141 is a Turck uprox Factor 1 inductive sensor in a 40 x 25 x 25 mm die-cast brass housing with a duroplast front cap. The sensing face can be turned to point in 5 directions and the M12 connector moved to 4 positions, so one part covers several mounting layouts.

• Sensing distance: 10 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: PNP, NO; up to 200 mA; switching frequency 250 Hz
• Supply: 10...30 VDC, 3-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: CA25, 40 x 25 x 25 mm, GD-CuZn 12 die-cast brass, black duroplast front cap
• Environment: IP67, ambient temperature -30...+85 °C
• Connection: M12 x 1 connector, 4-pin

Factor 1: the switching distance is the same for steel, stainless steel, aluminium and brass, so no correction factor applies when the target metal changes. The sensor is immune to magnetic DC and AC fields up to 300 mT.

A green LED shows power and a yellow LED the switching state. MTTF 874 years acc. to SN 29500 (40 °C).

BI8U-M18-AP6X-H1141 is a TURCK uprox inductive sensor with an extended 8 mm switching distance in an M18 housing. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 8 mm, flush mounting
• Output: PNP, NO, 3-wire, max. 200 mA, switching frequency 1.5 kHz; short-circuit, wire-break and reverse polarity protection
• Supply: 10...30 VDC, no-load current 25 mA
• Housing: M18 x 1 chrome-plated brass, LCP sensing face, thread length 36 mm, nut torque max. 25 Nm
• Environment: IP68, operating temperature -30...+85 °C
• Connection: M12 connector, 4-pin

A yellow LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

BI8U-M18-AN6X-H1141 is a TURCK uprox inductive sensor with an extended 8 mm switching distance in an M18 housing. Correction factor 1 for all metals and immune to magnetic AC and DC fields up to 300 mT, so steel, stainless steel, aluminium and brass are detected at the same distance.

• Switching distance: 8 mm, flush mounting
• Output: NPN, NO, 3-wire, max. 200 mA, switching frequency 1.5 kHz; short-circuit, wire-break and reverse polarity protection
• Supply: 10...30 VDC, no-load current 25 mA
• Housing: M18 x 1 chrome-plated brass, LCP sensing face, thread length 36 mm, nut torque max. 25 Nm
• Environment: IP68, operating temperature -30...+85 °C
• Connection: M12 connector, 4-pin

A yellow LED shows the switching state.

MTTF 874 years (SN 29500, 40 °C). Shock 30 g (11 ms), vibration 55 Hz (1 mm).

NI8-M12-VN6X-H1141 is a Turck inductive sensor in an M12 x 1 chrome-plated brass housing with an increased 8 mm switching distance for non-flush mounting. Its complementary NPN output switches one NO and one NC signal at the same time.

• Sensing distance: 8 mm, non-flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: NPN, complementary (NO + NC); up to 200 mA; switching frequency 2 kHz
• Supply: 10...30 VDC, 4-wire, no-load current 15 mA, voltage drop ≤ 1.8 V
• Protection: short circuit, wire break and reverse polarity
• Housing: M12 x 1 thread, chrome-plated brass, PA12-GF30 sensing face, thread length 26 mm, nut torque up to 10 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: M12 x 1 connector, 4-pin

A yellow LED shows the switching state. Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).

IPS40-S15PCOL-PG13 is an XECRO inductive sensor in a 40 x 40 mm PBT housing with a standard 15 mm sensing distance for flush mounting. The PNP output has a normally open and a normally closed contact at the same time; the wires go to terminals through a PG13.5 cable gland.

• Sensing distance: 15 mm (standard range), flush mounting
• Output: PNP, NO + NC; load up to 200 mA, voltage drop < 2 V at 200 mA; switching frequency 120 Hz
• Supply: 10...30 VDC, current consumption < 11 mA
• Protection: reverse polarity, short circuit (self-resetting)
• Housing: 40 x 40 mm, PBT, PBT sensing face
• Environment: IP67, operating temperature -20...+70 °C
• Connection: terminals, PG13.5 cable gland

Reduction factors for other target metals: aluminium 0.45, brass 0.50, stainless steel 0.85.

IPS8-N6PO60-A8 is an XECRO M8 inductive sensor with extended sensing range: 6 mm for non-flush mounting, with a PNP normally open (NO) output. The 60 mm housing is stainless steel 1.4301, and a switching indicator is built in.

• Sensing distance: 6 mm (extended range), non-flush mounting; repeatability < 1 % of Sn, hysteresis 3...15 %
• Output: PNP, NO; load up to 200 mA, voltage drop < 1.5 V at 200 mA; switching frequency 500 Hz
• Supply: 10...30 VDC, 3-wire, current consumption < 8 mA
• Protection: reverse polarity, short circuit (self-resetting)
• Housing: M8, stainless steel 1.4301, length 60 mm, PBT sensing face, tightening torque max. 8 Nm
• Environment: IP67, operating temperature -20...+70 °C
• Connection: M8 connector

Reduction factors for other target metals: aluminium 0.45, brass 0.50, stainless steel 0.85.

NI10-G18-Y1X is a Turck inductive sensor with a NAMUR output to EN 60947-5-6 in an M18 chrome-plated brass housing, approved for explosion-hazardous areas up to zone 0 (gas) and zone 20 (dust).

• Sensing distance: 10 mm, non-flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: NAMUR, 2-wire; current ≥ 2.1 mA not actuated, ≤ 1.2 mA actuated; switching frequency 500 Hz
• Supply: nominal 8.2 VDC; Ci/Li 150 nF / 150 µH
• Housing: M18 x 1 thread, thread length 20 mm, chrome-plated brass, PA12-GF30 sensing face, nut torque up to 25 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: 2 m blue PVC cable (LifYY), 2 x 0.34 mm², Ø 5.2 mm

The sensor may only be connected to certified intrinsically safe (Ex i) circuits, for example an isolating switching amplifier with a NAMUR input. Maximum input values: Ui = 20 V, Ii = 20 mA, Pi = 200 mW. A yellow LED shows the switching state.

Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

Marking Ex II 1 G Ex ia IIC T6 Ga / II 1 D Ex ia IIIC T135 °C Da, certificate KEMA 02 ATEX 1090X. SIL2 (low demand) acc. to IEC 61508 and PL c acc. to ISO 13849-1 with HFT0; SIL3 and PL e in redundant configuration with HFT1. MTTF 6198 years acc. to SN 29500 (40 °C).

BI10-M30-ADZ3X is a Turck inductive sensor in an M30 chrome-plated brass housing with a 2-wire normally open (NO) output. The sensor runs on both AC and DC supply. A red LED shows the switching state.

• Sensing distance: 10 mm, flush mounting; secured operating distance ≤ 0.81 × Sn
• Output: 2-wire, NO; up to 400 mA AC / 300 mA DC, minimum load current ≥ 3 mA, surge current ≤ 8 A (≤ 10 ms, max. 5 Hz); switching frequency 20 Hz
• Supply: 20...250 VAC (50...60 Hz) or 10...300 VDC; voltage drop ≤ 6 V, residual current ≤ 1.7 mA
• Protection: short circuit (latching), reverse polarity and wire break
• Housing: M30 x 1.5 thread, thread length 55 mm, chrome-plated brass, PA12-GF30 sensing face, nut torque up to 75 Nm
• Environment: IP67, ambient temperature -25...+70 °C
• Connection: 2 m PVC cable (LifYY), 3 x 0.5 mm², Ø 5.2 mm

Correction factors for other target metals (St37 steel = 1): aluminium 0.3, brass 0.4, stainless steel 0.7.

MTTF 2283 years acc. to SN 29500 (40 °C).
