Connection cable CAM12.A4-11230429, M12 male / M8 female, 4-pin, A-coded, 1m PUR cable

CAM12.A4-11230429 is a Baumer adapter cable from an M12 male to an M8 female connector, both A-coded and 4-pin, for connecting an M8 sensor to an M12 port. The unshielded PUR jacket is rated for drag chains and torsion up to ±180°/m.

• Connectors: M12 male (AF13, 0.6 Nm) and M8 female (AF9, 0.4 Nm), straight, A-coded, 4-pin
• Cable: PUR, black, Ø 4.5 mm, 4 × 0.25 mm² (AWG 24), unshielded, 1 m
• Rating: max. 4 A per contact, max. 50 V AC / 60 V DC
• Flexing: approx. 10 million C-track bending cycles, min. bending radius 10 × Ø when moving
• Protection: IP65, IP66K, IP67
• Temperature: -25...+80 °C moving, -40...+80 °C fixed

Wire colours BN, WH, BU, BK on pins 1-4 at both ends. The cable is halogen-free and flame-retardant to UL 1581 §1090 (H), CSA FT2 and IEC 60332-2-2.
