LED indicator S15LGYPQ, PNP, green/yellow, M12 4-pin

S15LGYPQ is a Banner S15L series two-color status indicator that screws in between a sensor and its cordset. Green is on while the sensor has power, and yellow replaces it when the sensor's PNP output is active.

• Colors: green - power, yellow - sensor output active
• Input: PNP, pin 4 (black wire)
• Supply: 10...30 V DC, up to 15 mA
• Housing: Ø15 × 57.8 mm, nickel-plated brass coupling, translucent white PVC
• Environment: IP65, IP67, IP68, -40...+40 °C
• Connection: integral 4-pin M12 male and female

The indicator is fitted where the sensor's own LEDs cannot be seen, for example inside a machine or behind a guard. All four pins pass straight through from male to female, so an IO-Link sensor can also be connected through it. The input responds to PNP signals only.

Meets CE, UKCA and UL/CSA requirements, enclosure rating UL Type 1.
