PT250R-2004-U1-H1141 is a TURCK PT-2000 series relative pressure transmitter with a fully welded metal measuring cell and a 0...10 V voltage output in 3-wire technology. It has no display: the measured value goes straight to the analogue input of a PLC or controller.

• Accuracy: ±0.3 % FS typical, max. 0.5 % FS (linearity, hysteresis, repeatability); temperature coefficient ±0.2 % FS/10 K; long-term stability 0.25 % FS per IEC EN 60770-1; reference conditions 15...25°C, 24 VDC
• Measuring range: 0...250 bar relative (0...25 MPa); overpressure ≤ 750 bar, burst pressure ≥ 1500 bar; resolution ±0.1 % FS
• Output: analogue 0...10 V, 3-wire, load ≤ 100 nF / > 10 kΩ; response time < 2 ms, typ. 1 ms
• Supply: 12...33 VDC, consumption ≤ 7 mA; protected against short circuit, wire break and reverse polarity
• Housing: stainless steel 1.4404 (AISI 316L) and polyarylamide 50 % GF (UL 94 V-0), stainless steel 1.4435 (AISI 316L) cell; G 1/4" male thread, back sealing per DIN EN ISO 1179-2 with FPM profile seal; wrench size 24, nut torque max. 20 Nm
• Environment: IP67, ambient -30...+85°C, medium -40...+135°C
• Connection: M12 x 1 connector

One FKM profile seal is included in the delivery.

Approval: cULus (UL E302799). Shock 100 g (11 ms) per IEC 68-2-27, vibration 20 g (15...2000 Hz) per IEC 68-2-6. MTTF 1238 years per SN 29500 (40°C).

• For effective, permanent control of water and process quality
• Compact, high-quality sensor design prevents failures and unplanned downtime
• Simplify your installation and commissioning processes

Humidity-Sensor for operating temperatures -80...200°C transmitter box from aluminium-die casting no display sensor tube high-grade steel 1.4301/special plastics, Ø 15mm length: aprox. 243 mm duct mounting Output 1: relative humidity Output range 1: 0...100 % rh Output signal 1: 4...20 mA Output 2: not Supply voltage: 10...30 VDC outputs digital adjustable with push-buttons operation temperature range transmitter: -40...85°C operation temperature range sensor tube: -80...200°C please note the assembly instructions! Filter: : sintered filter made of high-grade steel, ZE13

PKW4M-P7X2-10/TEL is a TURCK connection cable with an angled M8 female connector (4-pin) on one end and open cores on the other. A two-colour LED is built into the connector.

• Connector: M8 x 1, female, angled, 4-pin, gold-plated brass (CuZn) contacts
• Indication: two-colour LED (PNP) – green shows supply, yellow shows switching state
• Cable: 10 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 30 VDC, more than 100 mating cycles
• Housing: translucent TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

RKC4.5T-20/TXL is a TURCK connection cable with a straight M12 female connector (5-pin) on one end and open cores on the other. The PUR jacket is rated for moving installation, including drag chains.

• Connector: M12 x 1, female, straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 20 m, PUR, black, Ø 4.8 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

RKS4.5T-30/TXL is a TURCK shielded connection cable with a straight M12 female connector (5-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 30 m, PUR, black, Ø 5.7 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

Measurement range: -55°C to +125°C; Accuracy up to 0.5°C in the -10°C to +85°C range and up to 2°C in the -55°C to -125°C range; default probe length: 1m- different probe lengh on request; different probe tip- on request; default IP30 protection; IP67 on request

Measurement range: - 200 °C to +200 °C; Accuracy: up to 0.5 °C in the +200 °C and 1,3°C in the -200°C; default probe length: 1m- different probe lengh on request; IP30 protection; IP67 on request

Temperature: -55 to +125°C, accuracy: up to 0.5°C in the range from -10°C to +85°C and up to 2°C in the range -55 to -125°C. 1 m long external probe. Battery ensures up to 5 years. Measurement period: 1 minute – 10 days (configurable by the user) User configurable alarm thresholds. The device stores 40,000 measurements in its memory, when the memory is full, the oldest measurements are overwritten Sensor's configuration can be changed remotely from the cloud or with a mobile application over Bluetooth Low Energy.

Temperature: -55 to +125°C, accuracy: up to 0.5°C in the range from -10°C to +85°C and up to 2°C in the range -55 to -125°C. 1 m long external probe. Battery ensures up to 5 years. Measurement period: 1 minute – 10 days (configurable by the user) User configurable alarm thresholds. The device stores 40,000 measurements in its memory, when the memory is full, the oldest measurements are overwritten Sensor's configuration can be changed remotely from the cloud or with a mobile application over Bluetooth Low Energy.

Temperature: -55 to +125°C, accuracy: up to 0.5°C in the range from -10°C to +85°C and up to 2°C in the range -55 to -125°C. 1 m long external probe. Battery ensures up to 5 years. Measurement period: 1 minute – 10 days (configurable by the user) User configurable alarm thresholds. The device stores 40,000 measurements in its memory, when the memory is full, the oldest measurements are overwritten Sensor's configuration can be changed remotely from the cloud or with a mobile application over Bluetooth Low Energy.

Temperature: -55 to +125°C, accuracy: up to 0.5°C in the range from -10°C to +85°C and up to 2°C in the range -55 to -125°C. 1 m long external probe. Battery ensures up to 5 years. Measurement period: 1 minute – 10 days (configurable by the user) User configurable alarm thresholds. The device stores 40,000 measurements in its memory, when the memory is full, the oldest measurements are overwritten Sensor's configuration can be changed remotely from the cloud or with a mobile application over Bluetooth Low Energy.

Temperature: -55 to +125°C, accuracy: up to 0.5°C in the range from -10°C to +85°C and up to 2°C in the range -55 to -125°C. 1 m long external probe. Battery ensures up to 5 years. Measurement period: 1 minute – 10 days (configurable by the user) User configurable alarm thresholds. The device stores 40,000 measurements in its memory, when the memory is full, the oldest measurements are overwritten Sensor's configuration can be changed remotely from the cloud or with a mobile application over Bluetooth Low Energy.

- IP30 protection

Temperature: -55 to +125°C, accuracy: up to 0.5°C in the range from -10°C to +85°C and up to 2°C in the range -55 to -125°C. 1 m long external probe. Battery ensures up to 5 years. Measurement period: 1 minute – 10 days (configurable by the user) User configurable alarm thresholds. The device stores 40,000 measurements in its memory, when the memory is full, the oldest measurements are overwritten Sensor's configuration can be changed remotely from the cloud or with a mobile application over Bluetooth Low Energy.

Temperature: -55 to +125°C, accuracy: up to 0.5°C in the range from -10°C to +85°C and up to 2°C in the range -55 to -125°C. 1 m long external probe. Battery ensures up to 5 years. Measurement period: 1 minute – 10 days (configurable by the user), storeable 40,000 measurements.

- Equipped with an external Watermark soil moisture probe 3 m long and a temperature probe – 3 m (to correct the results depending on the soil temperature). - Measurement range: 0 - 200 Centibar (kPa) - Accuracy: up to 0.5°C in the range from -10°C to +85°C - Default IP67 protection (old no: 5906660327783)

- Min duration pulse: 5 millisecond - Max duration pulse: 500 millisecond - Supported counters: NO (Pull-up 3.6V) - default 3 active channles, (more/less chanles on request) - default IP30 protection-

TX-RS485 is a plug-in module for TURCK TX700 HMI/PLC devices that adds a galvanically isolated RS485/RS422 interface on a 9-pin SUB-D female connector.

• Interface: RS485/RS422, 9.6...115.2 kbps, galvanically isolated
• Connector: 1 x 9-pin SUB-D, female
• Supply: from the HMI
• Housing: metal, 41.2 x 90.3 x 23.8 mm
• Environment: IP20, -20...+60 °C, 5...85 % RH non-condensing

Fits the expansion slots of TX700 HMI/PLC devices and the TX700S gateway; powered from the HMI, no separate supply. The module has a plug-in extension port.

Approvals: CE.

Measurement range: -55°C to +125°C; Accuracy up to 0.5°C in the -10°C to +85°C range and up to 2°C in the -55°C to -125°C range; default probe length: 2x 1m- different probe lengh on request; IP30 protection; IP67 on request

Resolution: 1600 x 1200 px; Lens: 16 mm Autofocus; Light: Red; Diffused, Ethernet & Serial Communications; 1D + 2D Code

This soft-sided case is ideal for carrying your Multiparameter Sonde and accessories. It includes space for: Aqua TROLL 700 or Aqua TROLL 800 Multiparameter Sonde Aqua TROLL Sensors Rugged Android Tablet Wireless TROLL Com Accessories Two 1L bottles of calibration solution in outside mesh holders.

RKS4.5T-20/TEL is a TURCK shielded connection cable with a straight M12 female connector (5-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 20 m, PVC, black, Ø 6.1 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, 0...+80°C mobile

The PVC jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS.

Approval: cULus.

 Sn = 3 mm, M8×1 metal thread (nickel-plated brass), flush, extended barrel, with connector M8 (4-pin), 10–30V DC, PNP NO/NC (changeover), with increased switching distance

PKW4M-10/TEL is a TURCK connection cable with an angled M8 female connector (4-pin) on one end and open cores on the other.

• Connector: M8 x 1, female, angled, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 10 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 50 VAC / 60 VDC, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.
