Connector FW-D9TLEDKU9PG-W-FC-ME-SH-8.5, Sub-D male angled, 9-pin, PROFIBUS-DP, shieldable, IDC, 6...8mm cable, IP20

FW-D9TLEDKU9PG-W-FC-ME-SH-8.5 is a TURCK field-wireable 9-pin Sub-D male connector for PROFIBUS-DP, with a 90° cable outlet and IDC terminals for 6...8 mm cable.

• Connector: Sub-D, male, 90° cable outlet, 9-pin, gold-plated CuZn contacts, more than 200 mating cycles
• Ratings: 4 A, 12 V
• Bus functions: integrated controller for clock rates up to 12 Mbit/s, switchable terminating resistor, LEDs for bus cable functions, integrated PG diagnostic socket
• Connection: IDC terminals, cable diameter 6...8 mm, shieldable
• Housing: die-cast zinc (GD-Zn) body, black PA contact carrier
• Environment: IP20, pollution degree 1; -20...+75°C fixed

Approval: UL.
