Accessories
Mounting bracket SMB30A, right-angle, 30 mm hole, stainless steel
In stock: 5 pcs
11.00 €

SMB30A is a Banner right-angle bracket for sensors with a 30 mm housing. The curved slot lets the sensor be turned before the screws are tightened.

  • Sensor hole: Ø30.5 mm
  • Mounting: M6 (¼") hardware, 40 mm hole centre spacing
  • Material: 12-gauge stainless steel
Accessories
Test module TB3-CP80, for PNP/NPN and NAMUR sensors, M12 and M8, battery-powered
In stock: 2 pcs
79.40 €

TB3-CP80 is a TURCK test box for checking inductive, magnetic field, capacitive and photoelectric sensors on site or in the workshop, without dismounting the sensor. It runs on two 9 V E-block batteries and shows the switching state on two LEDs and with an acoustic signal.

  • Sensors: 2-wire DC, 3-/4-wire DC (PNP/NPN), NAMUR to DIN EN 60947-5-6
  • Connection: spring-type terminals, cable with M12 x 1 female connector, cable with M8 x 1 female connector
  • Supply: 18 VDC from 2 × 9 V E-block batteries
  • Display: 2 LEDs, green (PLUS) / blue (MINUS); acoustic signal via pin 4
  • Housing: PBT-GF30-V0, 80 x 80 x 40.5 mm

NAMUR sensors must not be operated in the hazardous area together with the test box. Testing in the non-hazardous area is allowed, and the sensor's EN 60079-0 and -11 approval stays valid after connecting it to the box.

Accessories
Test module TB4, for analog and PNP/NPN sensors, battery or 24VDC
In stock: 1 pcs
440.40 €

TB4 is a TURCK test box for testing and setting up sensors with analog or switching outputs on the machine, without connecting them to the machine supply. The sensor output is shown on an illuminated display and the analog value also as a bar graph.

  • Sensors: analog current/voltage output, 3-wire DC (PNP/NPN)
  • Supply: 18 VDC from 2 × 9 V E-block batteries, or external 24 VDC (>250 mA)
  • Connection: connector
  • Dimensions: 122 x 78.5 x 32 mm

The connector is switched between voltage and current output values by push button. Teachable sensors are set via the set button, which bridges pin 5 and pin 3. Hold the menu button for about 3 s to switch the box on or off.

Accessories
Mounting set E20719, M18 clamp, M10 bolt mounting, stainless steel fixture
Out of stock
9.20 €

E20719 is an ifm mounting set for position sensors: a M18 clamp on a fixture for M10 bolt mounting.

  • Fits: M18 threaded sensors
  • Mounting: M10 bolt mounting
  • Material: diecast zinc clamp, stainless steel fixture, galvanised steel screw, washers and nuts
  • Included: 1 × M10 x 45 mm cylinder screw, 2 × Ø 10.5 mm washers, 2 × M10 nuts
  • Weight: 168 g
Accessories
Mounting bracket BST-18B, M18, PA6, with dead-stop
Out of stock
13.00 €

BST-18B is a TURCK PA6 mounting bracket for M18 threaded sensors. The built-in dead-stop fixes the sensor position in the bracket.

  • Fits: M18 threaded barrel sensors
  • Material: PA6, black
  • Dimensions: 30 x 40 x 24 mm
  • Housing nut torque: max. 1 Nm
  • Design: with dead-stop
Accessories
Mounting bracket BSS-12, M12, polypropylene
Out of stock
6.22 €

BSS-12 is a TURCK polypropylene mounting bracket for M12 threaded sensors. It consists of two half-shells clamped together with two Allen screws.

  • Fits: M12 x 1 threaded barrel sensors
  • Material: polypropylene (PP), green
  • Dimensions: 30 x 34 x 26.5 mm
  • Housing nut torque: max. 0.5 Nm
  • Included: 2 × M6 Allen screws

For DIN rail mounting, the BSS-TSM rail nut is ordered separately.

Accessories
Mounting bracket BST-08B, M8, PA6, with dead-stop
Out of stock
9.79 €

BST-08B is a TURCK PA6 mounting bracket for M8 threaded sensors. The built-in dead-stop fixes the sensor position in the bracket.

  • Fits: M8 threaded barrel sensors
  • Material: PA6
  • Dimensions: 16 x 20 x 12 mm
  • Design: with dead-stop
Showing 8 of 8 results
