PRO-KIT is a Banner kit for configuring Pro series lights and selected sensors from a PC with the Pro Editor software. It is needed for initial configuration only, not for the device's operation in the machine.

• Included: converter cable, splitter and power supply
• Software: Banner Pro Editor
• Fits: Banner Pro series lights and selected sensors

CE and UKCA compliant.

M18TUP8Q is a Banner M18T T-GAGE non-contact temperature sensor. A thermopile detector measures the infrared energy emitted by the object and outputs a 0-10 V signal proportional to its temperature, with a integrated lens giving a 8:1 distance-to-spot ratio.

• Accuracy: linearity ±2 °C (0...+50 °C), ±1 °C or ±1 % (+50...+300 °C); repeatability ±1 % or ±1 °C
• Measuring range: -20...+300 °C, minimum taught span 10 °C; wavelength 8...14 µm
• Outputs: analog 0-10 V; PNP alarm output, active at full-scale signal; response 75 ms
• Supply: 12...30 V DC, < 35 mA; short-circuit protected outputs
• Housing: M18 threaded barrel, 304 stainless steel
• Environment: IP67, -20...+70 °C
• Connection: integral M12 5-pin connector

Used for hot part detection, ejection checks on injection moulding machines, flame and hot glue verification and cold product detection; the object does not need to move. The span is taught with the push button or remote wire, and the teach order sets a positive or negative slope. Allow 5 minutes of warm-up.

FCC Part 15 Class A, ICES-003(A); UL, CE and UKCA.

Temperatūras sensors TE2-1.4.7020.0080.0 Art: 11180504 G 1/2 A hygienic (A03) L=80mm D=6mm
