0052000NV- 0052000-03 15meters meters

Creates a secure anchor point for cables and suspension wires at the top of a well. Available for 2, 4, and 6 inch wells, this dock is ideal for use with cables and suspension wires.

Humidity, temperature transmitter. T+RH probe from hard anodized duralumin for compressed air up to 25 bars on the cable. Outdoor, indoor use.

Relative humidity, temperature sensors at probe on the cable. Measured values are also converted to other humidity interpretation: dew point temperature, absolute humidity, specific humidity, mixing ratio, specific enthalpy.

The device is supplied with T+RH probe with 1 meter cable.

E2630-LEL-C3H8-230-A Gāzes detektors E2630-LEL-230VAC, 2 x parslēdzošie releji 250VAC/30VDC 6A, skaņas signāls 85dB un LED indikācija, IP65, sensora pašdiagnostika ieslēdzoties un atsevišķi aktivizējot slēdzi, reakcijas laiks 1 sekunde, vides temperatūra -40/+70C

6836579 Spiediena sensors PT250R-2004-U1-H1141 , 0-250Bar, 0-10V, G1/4"

• For effective, permanent control of water and process quality
• Compact, high-quality sensor design prevents failures and unplanned downtime
• Simplify your installation and commissioning processes

Humidity-Sensor for operating temperatures -80...200°C transmitter box from aluminium-die casting no display sensor tube high-grade steel 1.4301/special plastics, Ø 15mm length: aprox. 243 mm duct mounting Output 1: relative humidity Output range 1: 0...100 % rh Output signal 1: 4...20 mA Output 2: not Supply voltage: 10...30 VDC outputs digital adjustable with push-buttons operation temperature range transmitter: -40...85°C operation temperature range sensor tube: -80...200°C please note the assembly instructions! Filter: : sintered filter made of high-grade steel, ZE13

This soft-sided case is ideal for carrying your Multiparameter Sonde and accessories. It includes space for: Aqua TROLL 700 or Aqua TROLL 800 Multiparameter Sonde Aqua TROLL Sensors Rugged Android Tablet Wireless TROLL Com Accessories Two 1L bottles of calibration solution in outside mesh holders.

Pos.10 - Type: [A] NG 8100 Pos.20 - Certificate: [0] CE / UKCA / TR-CU Pos.30 - Process temperature / insulator: [F] -40°C..+150°C (-40°F..302°F) FKM Single line of defense, PEEK Pos.40 - Electronic module: [A] 2-wire 4..20 mA, HART (9.6..35 V DC) Pos.50 - Process connection: [0A] Thread ¾" NPT PN40 taper, ANSI/ ASME B1.20.1 Pos.80 - Version of Probe L: [E] Rod ø8 mm (0.31") Pos.90 - Display and adjustment module: [A] with display and adjustment module, with inspection window in lid Pos.100 - Rigid part L1: [0] without (rod version) Pos.130 - Cable entry: [D] 1x M20x1.5 screwed cable gland PA (ø5-9 mm [0.20-0.35"]) 1x blind plug Pos.140 - Language manual: [2] EN - English Pos.160 - Housing: [A] aluminium single chamber Pos.190 - Dimensions centering weight (diameter / height): [0] without

PFM43-2211.A1421.0 is a Baumer electromagnetic insertion flow meter for pipes from DN 80 to DN 500. It is inserted into the pipe through a G 1 A threaded connection, so a large line does not need a full-bore flow meter. It passes flow velocity on as a pulse or frequency signal, and it is configured with Baumer BCP software.

• Measuring range: flow velocity 0.4...10 m/s, pipes DN 80...DN 500
• Accuracy: ±2 % at ≥ 0.5 m/s, repeatability ±0.5 %
• Output: 2 x pulse/frequency/alarm; analogue 0...20 mA or 4...20 mA output - optional
• Supply: 10...30 V DC, ≤ 1 W
• Housing: AISI 316, L=176 mm; G 1 A connection in AISI 304, Hastelloy C electrodes, PEEK and PTFE seals
• Environment: IP67; process -10...100 °C, up to 100 bar; ambient -10...60 °C
• Connection: M12-A, 5-pin, stainless steel

The medium must have a conductivity above 20 µS/cm, so the meter is not suitable for demineralised water or oils. After power-up it is operational within 30 s, but calibration needs a warm-up of up to 15 min.

PFM43-2211.A2421.0 is a Baumer electromagnetic insertion flow meter for pipes from DN 80 to DN 1000. It is inserted into the pipe through a G 1 A threaded connection, so a large line does not need a full-bore flow meter. It passes flow velocity on as a pulse or frequency signal, and it is configured with Baumer BCP software.

• Measuring range: flow velocity 0.4...10 m/s, pipes DN 80...DN 1000
• Accuracy: ±2 % at ≥ 0.5 m/s, repeatability ±0.5 %
• Output: 2 x pulse/frequency/alarm; analogue 0...20 mA or 4...20 mA output - optional
• Supply: 10...30 V DC, ≤ 1 W
• Housing: AISI 316, L=244 mm; G 1 A connection in AISI 304, Hastelloy C electrodes, PEEK and PTFE seals
• Environment: IP67; process -10...100 °C, up to 100 bar; ambient -10...60 °C
• Connection: M12-A, 5-pin, stainless steel

The medium must have a conductivity above 20 µS/cm, so the meter is not suitable for demineralised water or oils. After power-up it is operational within 30 s, but calibration needs a warm-up of up to 15 min.

PFM43-2211.A3421.0 is a Baumer electromagnetic insertion flow meter for pipes from DN 80 to DN 2000. It is inserted into the pipe through a G 1 A threaded connection, so a large line does not need a full-bore flow meter. It passes flow velocity on as a pulse or frequency signal, and it is configured with Baumer BCP software.

• Measuring range: flow velocity 0.4...10 m/s, pipes DN 80...DN 2000
• Accuracy: ±2 % at ≥ 0.5 m/s, repeatability ±0.5 %
• Output: 2 x pulse/frequency/alarm; analogue 0...20 mA or 4...20 mA output - optional
• Supply: 10...30 V DC, ≤ 1 W
• Housing: AISI 316, L=462 mm; G 1 A connection in AISI 304, Hastelloy C electrodes, PEEK and PTFE seals
• Environment: IP67; process -10...100 °C, up to 100 bar; ambient -10...60 °C
• Connection: M12-A, 5-pin, stainless steel

The medium must have a conductivity above 20 µS/cm, so the meter is not suitable for demineralised water or oils. After power-up it is operational within 30 s, but calibration needs a warm-up of up to 15 min.

Pressure switch with intuitive switch point setting PK6522 PK-100-SFG14-HCPKG/US/ /W

Pressure switch with intuitive switch point setting PK6520 PK-400-SFG14-HCPKG/US/ /W
