Pressure sensor 26.600G, -1...0 bar, 4-20 mA, G 1/2" DIN 3852 open, spec.
The 26.600 G is a standard OEM pressure transmitter for mechanical and plant engineering as well as general industrial applications. It features a robust ceramic sensor with 0.5% span accuracy according to EN IEC 62828-2 and covers nominal pressure ranges from 0…1 bar up to 0…400 bar. An oil- and grease-free version is available for sensitive applications.
Internal Reference |
26.600G-D025-R-1-5-100-H00-1-582 |
| Brand | BD Sensors |
| Pressure type | Relative pressure |
| Pressure range (new) | -1...0 bar |
| Pressure range | ≤ 0.1 bar |
| Process sensor output | Analog 4-20 mA |
| Process connection | G 1/2" |
| Supply | 12 VDC, 24 VDC |
| Electrical connection | DIN Connector |
| Wiring | 2-wire |
| Media type | Liquids, Gases |
26.600G.pdf
Download
