Mounting magnet MAGKIT-M5, for CMVT-QR20 sensors, 2 magnets and M5 x 12 screws

MAGKIT-M5 is the magnetic mounting kit for CMVT-QR20 rectangular-housing sensors. The sensor is screwed to two magnets with the supplied M5 screws, and the magnets hold it on the machine surface without drilling a hole in the equipment.

• Fits: CMVT-QR20 and CMMT-QR20 family sensors
• Supplied: 2 mounting magnets, 2 washers, 2 M5 x 12 screws
• Dimensions: magnet Ø 32 x 7 mm, M5 female thread

Permanent and operationally secure fixing depends on the conditions at the application and must be evaluated by the user.
