Process Temperature: max. +250°C (482°F)
Process Overpressure: max. 0.8 bar (11.60 psi)
Power Supply: 230 V AC, 50-60 Hz, 4 VA
Process Connection: Thread G 1½", DIN 228
Material of Process Connection: Stainless steel
Length of Extension L: Special length 400 mm
Material of Extension L: Stainless steel
Measuring Vane: Hinged vane, 98 x 200 mm (3.86 x 7.87"), double-sided (L = 10 mm [0.39"] longer)
Local Certificates: Without
Bearing at Tube End: Without (Note: For RN 3004, bearing at tube end is factory mounted)
Extension / Flange Welded: Without
