IM12-DI01-2S-2T-0/24VDC is a 2-channel TURCK isolating switching amplifier in a 12.5 mm housing with two potential-free transistor outputs up to 10 kHz. It runs either as two separate channels or with channel 1 doubled onto both outputs.

• Channels: 2 inputs for NAMUR sensors (EN 60947-5-6) or potential-free contacts
• Outputs: 2 potential-free, short-circuit-proof transistors, ≤30 V DC, 0.1 A, ≤10 kHz
• Supply: 10...30 V DC, ≤0.8 W
• Housing: polycarbonate/ABS, 120 x 12.5 x 117 mm, DIN rail (NS35)
• Connection: removable screw terminals, 0.2...2.5 mm²
• Environment: IP20, -25...+70 °C

DIP switches on the front set the output mode, input circuit monitoring and the operating mode. An input fault makes the red LED flash according to NE44 and blocks the transistor of that channel. Mechanical contacts need either monitoring switched off or the resistor wiring shown in the datasheet.

Approvals: ATEX, cULus; for use in ATEX Zone 2. Usable in safety circuits up to SIL 2 (IEC 61508).

IM12-TI02-2TCURTDR-2I-C0/24VDC is a 2-channel TURCK temperature measuring amplifier for thermocouples, RTDs, resistors and mV signals. It converts the inputs to galvanically isolated 0/4...20 mA outputs; cold junction compensation can be internal, external or a fixed value.

• Inputs: 2 x thermocouple (IEC 60584, DIN 43710), -150...+150 mV, RTD (IEC 60751, DIN 43760) or 0...5 kΩ, 2- or 3-wire
• Outputs: 2 x 0/4...20 mA, source or sink (15...28 V); inputs assignable as E1, E2, E1-E2 or E2-E1
• Configuration: PC via FDT and IODD
• Supply: 10...30 V DC, ≤2.7 W
• Housing: polycarbonate/ABS, 120 x 12.5 x 117 mm, DIN rail (NS35), removable screw terminals
• Environment: IP20, -25...+70 °C

Used where a mix of thermocouples and RTDs from a hazardous area has to reach the control system as current signals. With a 3-wire RTD connection, the lead resistances must be equal. Input faults are indicated according to NE44, and a PC connection is needed for parameterisation.

Approvals: ATEX, cULus; for use in ATEX Zone 2. SIL 2.

PKW4M-2-PSG4M/TXL is a TURCK M8 connection cable with a black PUR jacket rated for drag chains. The female end is angled and the male end is straight, which saves space where the cable leaves the device at a right angle.

• Connectors: M8 x 1 female, angled, and M8 x 1 male, straight, 4-pin each, gold-plated brass (CuZn) contacts, more than 100 mating cycles
• Cable: 2 m, PUR, black, Ø 4.5 mm, 4 x 0.34 mm², PP core insulation, core colours BN, WH, BU, BK
• Ratings: 4 A, 50 V AC/60 V DC
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

TXF705-00VPST is a 5" touch display from the TURCK TXF700 series with TX VisuPro runtime, a metal housing sealed to IP67 all round and a capacitive multi-touch glass front. Power and data come over one PoE Ethernet cable, so it can be mounted on a machine, pipe or wall outside the cabinet.

• Display: 5" TFT, 800 x 480 (WVGA), 16:9, 16M colours, 300 cd/m², capacitive multi-touch with gesture control, dimmable to 0 %
• Communication: 1 x RJ45 PoE Ethernet 10/100 Mbit, 1 x USB host (special cable required)
• Built in: temperature sensor, 3-axis accelerometer, front RGB LED, beeper
• Software: TX VisuPro runtime; ARM Cortex A9, dual core 800 MHz, 1 GB RAM, 4 GB Flash, battery-backed clock
• Supply: PoE IEEE 802.3af, ≤ 6 W
• Housing: metal, 148.3 x 105.1 x 16.5 mm, mounting depth 17 mm
• Environment: IP67, NEMA 1/12/4X; -20...+55 °C, 5...85 % RH non-condensing

The PoE connection is an M22 socket on the device: a TXF M22-to-RJ45 PoE cable and a PoE switch or injector are needed. Pipe, wall, VESA, gooseneck and tabletop mounts are available as accessories.

Approvals: Haz. Loc. Class I, Division 2, Groups A, B, C and D.

RSC8.800T-1/TXL is a TURCK connection cable with a straight M12 male connector (A-coded, 8-pin) on one end and open cores on the other.

• Connector: M12 x 1, male, straight, A-coded, 8-pin, gold-plated brass (CuZn) contacts
• Cable: 1 m, PUR, black, Ø 5.8 mm, 8 x 0.25 mm², core colours WH, BN, GN, YE, GY, PK, BU, RD
• Ratings: 2 A, 30 V, test voltage 2000 V, more than 100 mating cycles
• Housing: black TPU, nickel-plated brass coupling nut
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

Contact assignment follows DIN EN 60947-5-2 (production from CW16/2017).

The PUR jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

TX707FB-P3CV01 is a 7" touch display from the TURCK TX700 series with a built-in CODESYS V3 PLC, TARGET and WEB VISU visualisation. The FB version for the food industry has a stainless steel AISI 316L frame, a food-grade seal and an IP69 front that withstands high-pressure water up to 80 °C, acids and chemicals.

• Display: 7" TFT, 800 x 480 (WVGA), 16:9, 16M colours, 500 cd/m², capacitive glass front with polyester coating, dimmable to 0 %
• Communication: 3 x RJ45 Ethernet 10/100 Mbit, 1 x RS232/RS485/RS422, 2 x USB host (v2.0, max. 500 mA), SD card slot
• Expansion: 2 slots for up to 4 plug-in modules (I/O, CANopen, PROFIBUS DP, RS485, RS232, LTE/Wi-Fi)
• PLC: CODESYS V3.5.12.10, IEC 61131-3 (IL, LD, FBD, SFC, ST), 20000 kB program memory, 63 kB retain memory; ARM Cortex A9, Dual core 800 MHz, 1024 MB RAM, 4 GB Flash, battery-backed clock
• Supply: 24 VDC (10...32 VDC), max. 0.7 A
• Housing: die-cast aluminium, stainless steel AISI 316L frame, polyester front foil, front 217 x 177 x 45 mm, cut-out 176 x 136 mm, mounting depth 45+10 mm
• Environment: IP69 front, IP20 rear, NEMA 12/4X; -20...+60 °C, 5...85 % RH non-condensing

Intended for operator stations in food and beverage production. Built into a cabinet door or control desk. Mounting brackets and the power connector come in the 7" TX700 mounting kit, available as an accessory; I/O and fieldbus modules plug into the expansion slots and are ordered separately.

TX-IO-XX03 is a plug-in I/O module for TURCK TX700 HMI/PLC devices with 20 digital inputs, 12 digital outputs, four universal analogue inputs for voltage, current, RTD and thermocouples, and four analogue outputs for voltage or current.

• Digital inputs: 20 x 24 VDC, PNP, input delay 0.05 ms (S inputs) / 0.0002 ms (E inputs)
• Digital outputs: 12 x 24 VDC, PNP, 0.5 A per channel, simultaneity factor 0.23, short-circuit protected
• Analogue inputs: 4, 12 bit; ±100 mV...±10 V, 0...10 V, 0/4...20 mA, RTD -100...+850 °C (2-, 3-, 4-wire), thermocouple E, J, K, R, S, T; basic error 0.1 % at 25 °C
• Analogue outputs: 4, 12 bit; ±10 V (load > 1 kΩ) or 0...20 mA (load < 470 Ω)
• Supply: 24 VDC (12...30 VDC), I/O optically isolated at 1500 V rms
• Housing: metal, 125.2 x 89.3 x 33.7 mm; pluggable 10-pin spring terminal strips, 3.5 mm pitch
• Environment: IP20, 0...+50 °C, 5...85 % RH non-condensing

Fits the expansion slots of TX700 HMI/PLC devices and the TX700S gateway. The I/O are handled by the CODESYS PLC in the HMI. Thermocouple cold junction compensation is external, through a Pt100 on the compensation input. On the 5" TX705 and the TX700S gateway the module needs the TX-EXTEND adapter.

Approvals: CE, cULus, Class I Div. 2, DNV-GL.

TX-IO-DX06 is a plug-in I/O module for TURCK TX700 HMI/PLC devices with eight PNP digital inputs, six PNP digital outputs and one relay output, optically isolated at 1500 V rms.

• Inputs: 8 x DI, 24 VDC, PNP, input delay < 0.05 ms
• Outputs: 6 x DO, 24 VDC, PNP, 0.5 A per channel, simultaneity factor 0.46, short-circuit protected; 1 x relay, NO contact
• Supply: 24 VDC (12...30 VDC), actuator supply fed externally
• Connection: 2 pluggable 10-pin spring terminal strips, 3.5 mm pitch (Weidmüller Omnimate BLZF 3.5/180F); supply on a cage-clamp strip
• Housing: metal, 41.2 x 89.3 x 33.7 mm
• Environment: IP20, 0...+50 °C, 5...85 % RH non-condensing

Fits the expansion slots of TX700 HMI/PLC devices and the TX700S gateway. The I/O are handled by the CODESYS PLC in the HMI.

Approvals: CE, cULus, DNV GL.

TX700S-P3WV01 is a TURCK TX700 series IoT gateway without a display: a single-core CODESYS V3 PLC with WEB VISU, so the visualisation is opened in a web browser. It has two separate Ethernet ports and one expansion slot for plug-in modules.

• Communication: 2 x RJ45 Ethernet 10/100 Mbit (separate), 1 x RS232/RS485/RS422, 1 x USB host, SD card slot
• Expansion: 1 slot for up to 2 plug-in modules (I/O, CANopen, PROFIBUS DP, RS485, RS232, LTE/Wi-Fi)
• PLC: CODESYS V3.5.12.10, IEC 61131-3 (IL, LD, FBD, SFC, ST), 20000 kB program memory, 63 kB retain memory, programmed over Ethernet
• Controller: ARM Cortex A8, 1 GHz, 512 MB RAM, 4 GB Flash, battery-backed clock
• Supply: 24 VDC (10...32 VDC), max. 0.35 A
• Housing: 134 x 45 x 102 mm
• Environment: IP20, -20...+60 °C, 5...85 % RH non-condensing

The TX-PSC power connector and plug-in modules are available as accessories; the TX-IO-XX03 module needs the TX-EXTEND adapter in this housing.

WKH4.4-2/TFE is a TURCK hygienic connection cable with an angled M12 female connector (4-pin) on one end and open cores on the other, for sensors and actuators in food and beverage plants.

• Connector: M12 female, angled, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 2 m, PVC, grey RAL 7040, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: grey PP, stainless steel (V4A) coupling nut, FPM/FKM seal
• Environment: IP65, IP67, IP68, IP69 (only when screwed in); -25...+80°C fixed, 0...+80°C mobile

Designed for food and beverage areas: the grey PVC jacket (RAL 7040) resists acids, alkalis, oils and chemicals and is flame retardant per DIN EN 60332-1-2 and 60332-2-2. RoHS and REACH compliant. Approvals: GOST, Ecolab.

TXF-M22W-RJ45-5M is a TURCK PoE connection cable for the TXF700 HMI series, with an angled M22 connector on the device end and an RJ45 plug on the other.

• Connectors: M22, angled / RJ45
• Cable: 5 m
• Function: Power over Ethernet (PoE) for TXF700 HMI

RKC8T-10/TEL is a TURCK connection cable with a straight M12 female connector (8-pin) on one end and open cores on the other. The cable has a black PVC jacket.

• Connector: M12 x 1, female, straight, A-coded, 8-pin, gold-plated brass (CuZn) contacts
• Cable: 10 m, PVC, black, Ø 5.7 mm, 8 x 0.25 mm², core colours BN, WH, BU, BK, GY, PK, VT, OG
• Ratings: 2 A, 30 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

RKC8T-5/TEL is a TURCK connection cable with a straight M12 female connector (8-pin) on one end and open cores on the other. The cable has a black PVC jacket.

• Connector: M12 x 1, female, straight, A-coded, 8-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PVC, black, Ø 5.7 mm, 8 x 0.25 mm², core colours BN, WH, BU, BK, GY, PK, VT, OG
• Ratings: 2 A, 30 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

M12, 100 pcs. per bag

PKG3M-15/TXL is a TURCK connection cable with a straight M8 female connector (3-pin) on one end and open cores on the other. The PUR jacket is rated for moving installation, including drag chains.

• Connector: M8 x 1, female, straight, 3-pin, gold-plated brass (CuZn) contacts
• Cable: 15 m, PUR, black, Ø 4.1 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 50 VAC / 60 VDC, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

PKG3M-20/TEL is a TURCK connection cable with a straight M8 female connector (3-pin) on one end and open cores on the other.

• Connector: M8 x 1, female, straight, 3-pin, gold-plated brass (CuZn) contacts
• Cable: 20 m, PVC, black, Ø 4.3 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 50 VAC / 60 VDC, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

BS 4151-0/16 is a TURCK field-wireable 7/8" male connector, straight, 5-pin, for 12...14 mm cable with screw-clamp terminals.

• Connector: 7/8", male, straight, 5-pin, gold-plated brass (CuZn) contacts, more than 50 mating cycles
• Ratings: 9 A, 600 V
• Connection: screw-clamp terminals, conductors 16 AWG, cable diameter 12...14 mm
• Housing: black PBT body, nylon or TPU contact carrier, nickel-plated metal coupling nut
• Environment: IP67; -25...+85°C fixed

Approval: UL.

RKC4.4T-1-RSC4.4T/TEL is a TURCK extension cable with a straight M12 female connector on one end and a straight M12 male connector on the other (4-pin). The cable has a black PVC jacket.

• Connectors: M12 x 1 female and M12 x 1 male, both straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 1 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

PKG3M-5-RSC4T/TEL is a TURCK adapter cable from a straight M8 female connector to a straight M12 male connector (A-coded), 3-pin, with a black PVC jacket. It connects an M8 sensor to an M12 port.

• Connectors: M8 x 1 female, straight, and M12 x 1 male, straight, A-coded, 3-pin each, gold-plated brass (CuZn) contacts, more than 100 mating cycles
• Cable: 5 m, PVC, black, Ø 4.3 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 50 V AC/60 V DC
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

PKG3M-40/TXL is a TURCK connection cable with a straight M8 female connector (3-pin) on one end and open cores on the other. The PUR jacket is rated for moving installation, including drag chains.

• Connector: M8 x 1, female, straight, 3-pin, gold-plated brass (CuZn) contacts
• Cable: 40 m, PUR, black, Ø 4.1 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 50 VAC / 60 VDC, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

RKC4.4T-20/TXL is a TURCK connection cable with a straight M12 female connector (4-pin) on one end and open cores on the other. The PUR jacket is rated for moving installation, including drag chains.

• Connector: M12 x 1, female, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 20 m, PUR, black, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

RKC4.4T-25/TXL is a TURCK connection cable with a straight M12 female connector (4-pin) on one end and open cores on the other. The PUR jacket is rated for moving installation, including drag chains.

• Connector: M12 x 1, female, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 25 m, PUR, black, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

WSC4.4T-5/TXL is a TURCK connection cable with an angled M12 male connector (4-pin) on one end and open cores on the other.

• Connector: M12 x 1, male, angled, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PUR, black, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The PUR jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

RSS4.4T-2/TXL is a TURCK shielded connection cable with a straight M12 male connector (4-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, male, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 2 m, PUR, black, Ø 5.3 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

BK7-0 is a TURCK field-wireable M16 x 0.75 female connector, straight, 7-pin, for 6...8 mm cable.

• Connector: M16 x 0.75, female, straight, 7-pin, silver-plated bronze (CuSn) contacts, more than 500 mating cycles
• Ratings: 5 A, 60 V
• Connection: conductors up to 0.75 mm², cable diameter 6...8 mm, PG9 screw-in thread
• Housing: black PA body, PBT (UL 94 V0) contact carrier, nickel-plated die-cast zinc (GD-Zn) coupling nut
• Environment: -40...+95°C fixed

HT-WWAK4-2/S2430 is a TURCK high-temperature connection cable with an angled M12 female connector (4-pin) on one end and open cores on the other.

• Connector: M12 x 1, female, angled, 4-pin, gold-plated brass (CuZn) contacts, more than 100 mating cycles
• Cable: 2 m, PTFE, white, Ø 3.8 mm, 4 x 0.34 mm², PTFE core insulation, core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V
• Housing: black glass-fibre reinforced PBT, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP65 (only when screwed in); -20...+150°C fixed

The PTFE cable itself is rated for -190...+260°C. The jacket stays flexible in cold and heat, resists welding sparks, chemicals, UV radiation, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and LABS free. RoHS compliant.

VC-AC21-11.024-K is a TURCK field-wireable design A valve connector, 2+PE, with screw-clamp terminals for 6...8 mm cable, a yellow switching-state LED and varistor protective circuitry.

• Connector: valve connector design A, 2+PE, metal contacts, more than 50 plug cycles
• Ratings: 10 A, 24 V
• Connection: screw-clamp terminals, conductors up to 1 mm² (3 x 1 mm²), cable diameter 6...8 mm, M20 x 1.5 screw-in thread, M3 x 33.5 central screw
• Housing: transparent PA6-I body, black PA6 GF30 contact carrier, NBR seal
• Environment: IP65 (mounted); -25...+80°C fixed

Supplied with the central screw, pressure screw, seal, sealing ring and pressure ring.

VB2-FSM5-2FKM5 is a TURCK Y-splitter without cable with one M12 male connector (5-pin) and two M12 female connectors (5-pin). The two female connectors are wired in parallel.

• Connectors: M12 male, 5-pin / 2 x M12 female, 5-pin, straight, gold-plated brass (CuZn) contacts, more than 100 mating cycles
• Ratings: 4 A, 60 V, contact resistance ≤5 mΩ, insulation resistance ≥10⁸ Ω
• Housing: black TPU, nickel-plated brass coupling nuts
• Environment: IP67 (only when screwed in); -30...+90°C

RoHS compliant.

PT250R-2004-U1-H1141 is a TURCK PT-2000 series relative pressure transmitter with a fully welded metal measuring cell and a 0...10 V voltage output in 3-wire technology. It has no display: the measured value goes straight to the analogue input of a PLC or controller.

• Accuracy: ±0.3 % FS typical, max. 0.5 % FS (linearity, hysteresis, repeatability); temperature coefficient ±0.2 % FS/10 K; long-term stability 0.25 % FS per IEC EN 60770-1; reference conditions 15...25°C, 24 VDC
• Measuring range: 0...250 bar relative (0...25 MPa); overpressure ≤ 750 bar, burst pressure ≥ 1500 bar; resolution ±0.1 % FS
• Output: analogue 0...10 V, 3-wire, load ≤ 100 nF / > 10 kΩ; response time < 2 ms, typ. 1 ms
• Supply: 12...33 VDC, consumption ≤ 7 mA; protected against short circuit, wire break and reverse polarity
• Housing: stainless steel 1.4404 (AISI 316L) and polyarylamide 50 % GF (UL 94 V-0), stainless steel 1.4435 (AISI 316L) cell; G 1/4" male thread, back sealing per DIN EN ISO 1179-2 with FPM profile seal; wrench size 24, nut torque max. 20 Nm
• Environment: IP67, ambient -30...+85°C, medium -40...+135°C
• Connection: M12 x 1 connector

One FKM profile seal is included in the delivery.

Approval: cULus (UL E302799). Shock 100 g (11 ms) per IEC 68-2-27, vibration 20 g (15...2000 Hz) per IEC 68-2-6. MTTF 1238 years per SN 29500 (40°C).

PKW4M-P7X2-10/TEL is a TURCK connection cable with an angled M8 female connector (4-pin) on one end and open cores on the other. A two-colour LED is built into the connector.

• Connector: M8 x 1, female, angled, 4-pin, gold-plated brass (CuZn) contacts
• Indication: two-colour LED (PNP) – green shows supply, yellow shows switching state
• Cable: 10 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 30 VDC, more than 100 mating cycles
• Housing: translucent TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

RKC4.5T-20/TXL is a TURCK connection cable with a straight M12 female connector (5-pin) on one end and open cores on the other. The PUR jacket is rated for moving installation, including drag chains.

• Connector: M12 x 1, female, straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 20 m, PUR, black, Ø 4.8 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

RKS4.5T-30/TXL is a TURCK shielded connection cable with a straight M12 female connector (5-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 30 m, PUR, black, Ø 5.7 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

TX-RS485 is a plug-in module for TURCK TX700 HMI/PLC devices that adds a galvanically isolated RS485/RS422 interface on a 9-pin SUB-D female connector.

• Interface: RS485/RS422, 9.6...115.2 kbps, galvanically isolated
• Connector: 1 x 9-pin SUB-D, female
• Supply: from the HMI
• Housing: metal, 41.2 x 90.3 x 23.8 mm
• Environment: IP20, -20...+60 °C, 5...85 % RH non-condensing

Fits the expansion slots of TX700 HMI/PLC devices and the TX700S gateway; powered from the HMI, no separate supply. The module has a plug-in extension port.

Approvals: CE.

RKS4.5T-20/TEL is a TURCK shielded connection cable with a straight M12 female connector (5-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 20 m, PVC, black, Ø 6.1 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, 0...+80°C mobile

The PVC jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS.

Approval: cULus.

 Sn = 3 mm, M8×1 metal thread (nickel-plated brass), flush, extended barrel, with connector M8 (4-pin), 10–30V DC, PNP NO/NC (changeover), with increased switching distance

PKW4M-10/TEL is a TURCK connection cable with an angled M8 female connector (4-pin) on one end and open cores on the other.

• Connector: M8 x 1, female, angled, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 10 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 50 VAC / 60 VDC, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

RSC4.4T-1/TXL is a TURCK connection cable with a straight M12 male connector (A-coded, 4-pin) on one end and open cores on the other.

• Connector: M12 x 1, male, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 1 m, PUR, black, Ø 4.5 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, test voltage 2000 V, more than 100 mating cycles
• Housing: black TPU, nickel-plated brass coupling nut
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The PUR jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

RKC5.501T-30/TXL is a TURCK connection cable with a straight M12 female connector (4-pin) on one end and open cores on the other. The PUR jacket is rated for moving installation, including drag chains.

• Connector: M12 x 1, female, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 30 m, PUR, black, shielded, Ø 5.3 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

The jacket resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS. Approval: cULus.

RKS4.4T-40/TXL is a TURCK shielded connection cable with a straight M12 female connector (4-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 40 m, PUR, black, Ø 5.3 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

RKS4.4T-50/TXL is a TURCK shielded connection cable with a straight M12 female connector (4-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 50 m, PUR, black, Ø 5.3 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.

VBRS4.4-2RKC4T-2/2/TXL is a TURCK Y-splitter with a straight M12 male connector (4-pin) and two straight M12 female connectors (3-pin) on 2 m PUR cable branches. Pin 4 of the male connector is wired to pin 4 of the first branch (BK1), pin 2 to pin 4 of the second branch (BK2), and the supply (pin 1 +, pin 3 -) is shared by both branches.

• Connectors: M12 x 1 male, 4-pin / 2 x M12 x 1 female, 3-pin, all straight, gold-plated brass (CuZn) contacts
• Cable: 2 x 2 m, PUR, black, Ø 4.3 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nuts, FPM/FKM seal; tightening torque 0.8...1 Nm
• Environment: IP67 (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

Two sensors switching on pin 4 therefore share one two-channel M12 port.

The PUR jacket is rated for drag chains: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m. It resists chemicals, UV radiation, oils and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

RoHS compliant.

VBRS4.4-2WKC4.324T-5/5/TXL is a TURCK Y-splitter with a straight M12 male connector and two angled M12 female connectors on 5 m PUR cable branches. Pin 4 of the male connector is wired to pins 2 and 4 of the first branch, pin 2 to pins 2 and 4 of the second branch, and the supply (pin 1 +, pin 3 -) is shared by both branches.

• Connectors: M12 x 1 male, straight / 2 x M12 x 1 female, angled; all 4-pin, gold-plated brass (CuZn) contacts
• Cable: 2 x 5 m, PUR, black, Ø 4.3 mm, 3 x 0.34 mm², core colours BN, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nuts, FPM/FKM seal; tightening torque 0.8...1 Nm
• Environment: IP67 (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain
• Drag chain: at least 5 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø, torsion ±180°/m

Two sensors therefore share one two-channel M12 port. The PUR jacket resists chemicals, UV radiation, oils and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

RoHS compliant.

WKC4.4T-15/TEL is a TURCK connection cable with an angled M12 female connector (4-pin) on one end and open cores on the other.

• Connector: M12 x 1, female, angled, A-coded, 4-pin, gold-plated brass (CuZn) contacts
• Cable: 15 m, PVC, black, Ø 4.6 mm, 4 x 0.34 mm², core colours BN, WH, BU, BK
• Ratings: 4 A, 250 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -40...+105°C fixed, -5...+80°C mobile

The PVC jacket resists chemicals, oils, acids, alkaline solutions, microbes and hydrolysis, is flame retardant and free from LABS. Approval: cULus.

RKS4.5T-5/TXL is a TURCK shielded connection cable with a straight M12 female connector (5-pin) on one end and open cores on the other. The cable shield is connected to the coupling nut.

• Connector: M12 x 1, female, straight, A-coded, 5-pin, gold-plated brass (CuZn) contacts
• Cable: 5 m, PUR, black, Ø 5.7 mm, 5 x 0.34 mm², core colours BN, WH, BU, BK, GY
• Shield: aluminium foil and tinned copper wire
• Ratings: 4 A, 60 V, more than 100 mating cycles
• Housing: TPU, nickel-plated brass coupling nut, FPM/FKM seal
• Environment: IP67, IP69K (only when screwed in); -50...+80°C fixed, -25...+80°C mobile, -25...+60°C in a drag chain

The PUR jacket is rated for drag chains: at least 2 million bending cycles, up to 3.3 m/s and 5 m/s², bending radius ≥10 x Ø. It resists chemicals, UV radiation, oils, welding sparks and abrasion, is flame retardant (FT2 per UL 1581, IEC 60332-2-2) and free from halogen, silicone, PVC and LABS.

Approval: cULus.
