S15LPRGB7Q is a Banner S15L Pro series RGB status indicator with four discrete inputs that screws into an M12 cable run. Three inputs select seven colors in combination, and the fourth input (gray wire) switches on 1 Hz flashing.

• Colors: 7 by default (red, yellow, green, cyan, blue, magenta, white), 14 selectable in total
• Inputs: 4, PNP/NPN, 12...30 V DC, response time up to 250 ms
• Configuration: Banner Pro Editor - colors, intensity, flash pattern, animations
• Supply: 12...30 V DC, up to 60 mA at 12 V DC, typically 35 mA at 24 V DC
• Housing: Ø15 × 58 mm, nickel-plated brass coupling, diffuse white PVC
• Environment: IP65, IP67, IP68, -40...+45 °C
• Connection: integral 5-pin M12 male and female

The indicator is driven directly by PLC or sensor outputs and shows machine status where a separate stack light would not fit. Without any setup it works from the factory color table. Changing the settings in Pro Editor requires a Banner Pro Converter cable, ordered separately.

Meets CE and UKCA requirements, enclosure rating UL Type 1. Vibration and shock resistance tested to IEC 60068-2-6 and IEC 60068-2-27.

S15LPSQ is a Banner S15L Pro series RGB status indicator controlled over a Modbus RTU network that screws into a cable run with 4-pin M12 connectors. Color, intensity, flash pattern and speed are set by writing Modbus registers, so no separate wire is needed per color.

• Colors: 14 selectable, with flash, two-color flash and color sweep
• Communication: Modbus RTU, RS-485 (pins 2 and 4)
• Supply: 12...30 V DC, up to 60 mA at 12 V DC, typically 35 mA at 24 V DC
• Housing: Ø15 × 58 mm, nickel-plated brass coupling, diffuse white PVC
• Environment: IP65, IP67, IP68, -40...+45 °C
• Connection: integral 4-pin M12 male and female

The indicator is used on machines where the PLC already communicates over Modbus RTU, and it connects anywhere on the RS-485 line. It needs a Modbus RTU master, such as a PLC, to operate. Normal-mode settings are not stored in the indicator, so the controller must write them again after a power loss.

Meets CE and UKCA requirements, enclosure rating UL Type 1. Vibration and shock resistance tested to IEC 60068-2-6 and IEC 60068-2-27.

Without packaging

The Banner SD50 Wireless Communication Kit enables fast, clear messaging across industrial facilities without complex wiring. This starter kit includes one DXMR90 controller, one R70SR radio, and one SD50 display. Additional SD50 displays can be added to expand the system to multiple locations.

DXMR90-X1E Industrial Controller - Network hub supporting EtherNet/IP, Modbus TCP, Modbus RTU, PROFINET, and MQTT/Sparkplug B protocols. IP67/IP68 rated with dual M12 Ethernet ports. 12-30V DC power supply.

R70SR2MQ Serial Data Radio - 2.4 GHz multihop wireless radio with 65mW output. RS-485 interface, internal antenna, IP65 rated. Supports point-to-point, point-to-multipoint, star, and tree topologies.

SD50P300WSR2QP Wireless Status Display - 300mm white LED display (8×96 pixels) with RGB indicators. Configure wirelessly via Pro Editor software without coding. IP65 polycarbonate housing. 12-30V DC.

Configuration Options:

• Discrete models: Configure via Pro Editor - define text, colors, animations without coding or PLC programming
• IO-Link models: Integrate with IO-Link networks for remote diagnostics and standardized connectivity
• Wireless models: Configure through Modbus registers, update messages as conditions change

Expandable System: Add multiple SD50 displays to communicate across different zones, production lines, or departments using the same controller and radio infrastructure.

K30LGXXPQ is a single-colour green LED indicator from the Banner EZ-LIGHT K30L series. It is driven directly from the discrete PNP output of a 3-wire or 4-wire sensor or from a PLC output, without a relay and without an amplifier.

• Indication: single colour - green, the whole dome emits light
• Input: PNP, on and off response time up to 1 ms
• Supply: 10...30 V DC, up to 25 mA
• Housing: polycarbonate base with M22x1.5 thread, translucent polycarbonate dome, Ø30 mm, height 58 mm, fully encapsulated electronics
• Environment: IP67 and IP69K per DIN 40050-9, -40...+50 °C
• Connection: integral M12 male connector, 4-pin

The indicator mounts in a 22 mm hole and shows machine or process status at the workplace - at a conveyor, a packaging machine station or a control desk. The QD version needs a separately ordered M12 cordset, as one is not included.

CE compliant, K30L models are cULus Listed.

S15LGYPQ is a Banner S15L series two-color status indicator that screws in between a sensor and its cordset. Green is on while the sensor has power, and yellow replaces it when the sensor's PNP output is active.

• Colors: green - power, yellow - sensor output active
• Input: PNP, pin 4 (black wire)
• Supply: 10...30 V DC, up to 15 mA
• Housing: Ø15 × 57.8 mm, nickel-plated brass coupling, translucent white PVC
• Environment: IP65, IP67, IP68, -40...+40 °C
• Connection: integral 4-pin M12 male and female

The indicator is fitted where the sensor's own LEDs cannot be seen, for example inside a machine or behind a guard. All four pins pass straight through from male to female, so an IO-Link sensor can also be connected through it. The input responds to PNP signals only.

Meets CE, UKCA and UL/CSA requirements, enclosure rating UL Type 1.
