IM1-22EX-R is a 2-channel TURCK isolating switching amplifier with intrinsically safe input circuits and two relay outputs, each with one NO contact. Six front switches set the output mode (NO/NC) and switch wire-break and short-circuit monitoring on or off separately for each channel.

• Channels: 2 inputs for NAMUR sensors (EN 60947-5-6) or potential-free contacts
• Outputs: 2 relays, 1 NO each, 30 V DC / 250 V AC, ≤2 A, ≤500 VA / 60 W
• Supply: 20...125 V DC / 20...250 V AC (40...70 Hz)
• Housing: polycarbonate/ABS, 104 x 18 x 110 mm, DIN rail (NS35) or panel mounting
• Connection: screw terminals, 1 x 2.5 mm² / 2 x 1.5 mm²
• Environment: IP20, -25...+70 °C

Used to pass NAMUR sensor or contact signals from a hazardous area to a relay input in the control cabinet. With monitoring switched on, an input fault turns the channel LED red and the output relay drops out. Mechanical contacts need either monitoring switched off or the resistor wiring shown in the datasheet.

Approvals: ATEX, IECEx, UL, CFMUS, CSA, TR CU; for use in Zone 2. SIL 2 according to exida FMEDA.

IM12-22EX-R/24VDC is a 2-channel TURCK isolating switching amplifier with intrinsically safe input circuits and two relay outputs, each with one NO contact. Front switches set the output mode (NO/NC) and signal multiplexing, where channel 1 drives both outputs.

• Channels: 2 inputs for NAMUR sensors (EN 60947-5-6) or potential-free contacts
• Outputs: 2 relays, 1 NO each, 30 V DC / 250 V AC, ≤2 A, ≤500 VA / 60 W
• Supply: 10...30 V DC (24 V DC nominal)
• Housing: polycarbonate/ABS, 104 x 18 x 110 mm, DIN rail (NS35) or panel mounting
• Connection: screw terminals, 1 x 2.5 mm² / 2 x 1.5 mm²
• Environment: IP20, -25...+60 °C

Used to pass NAMUR sensor or potential-free contact signals from a hazardous area to a relay input in the control cabinet. A green Pwr LED shows readiness and a yellow LED shows the output switching state.

Approvals: ATEX, CFMUS, TR CU.

TX715FB-P3CV01 is a 7" touch display from the TURCK TX700 series with a built-in CODESYS V3 PLC, TARGET and WEB VISU visualisation. The FB version for the food industry has a stainless steel AISI 316L frame, a food-grade seal and an IP69 front that withstands high-pressure water up to 80 °C, acids and chemicals.

• Display: 7" TFT, 1366 x 768 (HD), 16:9, 16M colours, 400 cd/m², capacitive glass front with polyester coating, dimmable to 0 %
• Communication: 3 x RJ45 Ethernet 10/100 Mbit, 1 x RS232/RS485/RS422, 2 x USB host (v2.0, max. 500 mA), SD card slot
• Expansion: 2 slots for up to 4 plug-in modules (I/O, CANopen, PROFIBUS DP, RS485, RS232, LTE/Wi-Fi)
• PLC: CODESYS V3.5.12.10, IEC 61131-3 (IL, LD, FBD, SFC, ST), 20000 kB program memory, 63 kB retain memory; ARM Cortex A9, Quad core 800 MHz, 2048 MB RAM, 8 GB Flash, battery-backed clock
• Supply: 24 VDC (10...32 VDC), max. 1.2 A
• Housing: die-cast aluminium, stainless steel AISI 316L frame, polyester front foil, mounting depth 56+8 mm
• Environment: IP69 front, IP20 rear, NEMA 12/4X; -20...+60 °C, 5...85 % RH non-condensing

Intended for operator stations in food and beverage production. Built into a cabinet door or control desk. Mounting brackets and the power connector come in the 7" TX700 mounting kit, available as an accessory; I/O and fieldbus modules plug into the expansion slots and are ordered separately.

1-channel

• • Input circuits monitored for wire break and short circuit
  • Complete galvanic isolation
  • HART transparent
  • Removable cage clamp terminals
  • ATEX, IECEx, cULus
  • Use in zone 2
  • SIL 2

IM12-DI01-2S-2T-PR/24VDC is a 2-channel TURCK isolating switching amplifier in a 12.5 mm housing with two potential-free transistor outputs up to 10 kHz. It can be powered through a Power bridge, which also carries a collective fault signal; the connector for the bridge is included.

• Channels: 2 inputs for NAMUR sensors (EN 60947-5-6) or potential-free contacts
• Outputs: 2 potential-free, short-circuit-proof transistors, ≤30 V DC, 0.1 A, ≤10 kHz
• Supply: 10...30 V DC via terminals or Power bridge, ≤0.8 W
• Housing: polycarbonate/ABS, 120 x 12.5 x 117 mm, DIN rail (NS35)
• Connection: removable screw terminals, 0.2...2.5 mm²
• Environment: IP20, -25...+70 °C

DIP switches on the front set the output mode, input circuit monitoring and the operating mode. An input fault makes the red LED flash according to NE44 and blocks the transistor of that channel. Mechanical contacts need either monitoring switched off or the resistor wiring shown in the datasheet.

Approvals: ATEX, cULus; for use in ATEX Zone 2. Usable in safety circuits up to SIL 2 (IEC 61508).

IM12-AI01-1I-2IU-HPR/24VDC/CC is a 1-channel TURCK isolating transducer for HART 2-wire transmitters. The 4...20 mA input is passed 1:1 to two isolated outputs (splitter), and HART communication runs bidirectionally through output O1.

• Channels: 1 input, 4...20 mA, transmitter supply 17 V / 20 mA
• Outputs: 2 x 4...20 mA (source or sink) or 1...5 V; HART on O1 only
• Accuracy: ≤0.05 % of full scale
• Supply: 10...30 V DC via terminals or Power bridge, ≤3.8 W
• Housing: polycarbonate/ABS, 120 x 12.5 x 128 mm, DIN rail (NS35), removable spring-type terminals
• Environment: IP20, -25...+70 °C

Used where one transmitter signal from a hazardous area is needed by two systems, for example a control system and a separate safety system. Wire break (< 3.5 mA) and short circuit (> 22 mA) are passed to the outputs as < 3.5 mA or < 0.875 V. The Power bridge also carries a collective fault signal; its connector is included.

Approvals: ATEX, cULus; for use in ATEX Zone 2. SIL 2.

- Working temperature: 0 to 70 °C

IM12-DI03-1S-2T-S/24VDC/CC is a 1-channel TURCK isolating switching amplifier in a 12.5 mm housing with two potential-free transistor outputs up to 10 kHz. The second output works either as a copy of the signal or as an alarm output for input faults.

• Channels: 1 input for NAMUR sensors (EN 60947-5-6) or potential-free contacts
• Outputs: 2 potential-free, short-circuit-proof transistors, ≤30 V DC, 0.1 A, ≤10 kHz
• Supply: 10...30 V DC, ≤1.03 W typical dissipation
• Housing: polycarbonate/ABS, 120 x 12.5 x 128 mm, DIN rail (NS35)
• Connection: removable spring-type terminals, 0.2...2.5 mm²
• Environment: IP20, -25...+70 °C

DIP switches on the front set the output mode, input circuit monitoring and the operating mode. An input fault makes the red LED flash according to NE44 and blocks the transistor of that channel. Mechanical contacts need either monitoring switched off or the resistor wiring shown in the datasheet.

Approvals: ATEX, cULus; for use in ATEX Zone 2. Usable in safety circuits up to SIL 2 (IEC 61508).

S100PTVD2WAD2Q is a Banner S100 Pro series touch operator display that combines status indication, text and operator input in a single M30 threaded housing. This version works without an industrial network: the PLC switches states through discrete inputs, while text, colours and animations are loaded into the unit beforehand with Banner Pro Editor.

• Display: two-row white dot-matrix display, 13 characters per line, 16 RGB LED ring and audible alert
• Control: 5 capacitive touch zones with vibration feedback, response time max. 300 ms
• Control signals: discrete inputs, output max. 150 mA
• Supply: 12-30 V DC
• Housing: black polycarbonate with tinted window, Ø100 mm, M30x1.5 threaded base, IP66/IP69K, -40...+50°C
• Connection: integral M12 male connector, 5-pin

The display mounts in a Ø30 mm hole at the machine station - pick-to-light positions, takt timer, counter and step confirmation. The configuration is loaded with Pro Editor before installation, so changing text or colours means disconnecting the unit and connecting it to a PC.

CE marked and cULus listed, housing rated UL Type 4X.

S100PTVD2WAKQ is a Banner S100 Pro series touch operator display that combines status indication, text and operator input in a single M30 threaded housing. Over IO-Link it connects to a standard master port, carrying process data and parameters on the same unshielded cable, so a replacement unit is re-parameterised by the master rather than by hand.

• Display: two-row white dot-matrix display, 13 characters per line, 16 RGB LED ring and audible alert
• Control: 5 capacitive touch zones with vibration feedback, response time max. 300 ms
• Communication: IO-Link
• Supply: 18-30 V DC, 280 mA at 18 V DC, 210 mA at 24 V DC
• Housing: black polycarbonate with tinted window, Ø100 mm, M30x1.5 threaded base, IP66/IP69K, -40...+50°C
• Connection: integral M12 male connector, 4-pin

The display mounts in a Ø30 mm hole at the machine station - pick-to-light positions, takt timer, counter and step confirmation. Note that this version starts at 18 V DC, not 12 V DC as the other S100 Pro versions.

CE marked and cULus listed, housing rated UL Type 4X.

S100PTVD2WASQ is a Banner S100 Pro series touch operator display that combines status indication, text and operator input in a single M30 threaded housing. The controller changes text, colours and the meaning of each touch zone at runtime over Modbus RTU, so one unit serves several machine modes without reconfiguration.

• Display: two-row white dot-matrix display, 13 characters per line, 16 RGB LED ring and audible alert
• Control: 5 capacitive touch zones with vibration feedback, response time max. 300 ms
• Communication: Modbus RTU over RS-485, 9600, 19200 and 38400 bit/s
• Supply: 12-30 V DC, 415 mA at 12 V DC, 210 mA at 24 V DC
• Housing: black polycarbonate with tinted window, Ø100 mm, M30x1.5 threaded base, IP66/IP69K, -40...+50°C
• Connection: integral M12 male connector, 4-pin

The display mounts in a Ø30 mm hole at the machine station - pick-to-light positions, takt timer, counter and step confirmation. Prepared modes run without programming, while Modbus registers let the PLC drive each row, colour and the audible alert separately.

CE marked and cULus listed, housing rated UL Type 4X.
