Level sensor LRS510-10-69-LI2UPN8-H1141/EU
Radar Sensor, Level Control
■ Insensitive to harsh
environmental conditions
■ Distance, level and volume
measurement in a single unit
■ Simple sensor data visualization
and configuration via Turck’s
IO-Link masters
■ Foreign object suppression
via distance and signal
intensity filter
Operating voltage 17…33 VDC,
Max. range 10000 mm,
Range: 10 m,
Blind zone: 35 cm,
Resolution: 1 mm,
Cone angle of the radar beam: ±3°,
Distance, level, volume or % output,
Approved according to ETSI 305550-2,
Approved according to FCC/CFR. 47 Part 15.,
Male connector, M12 × 1, 4-pin,
Operating voltage 18…33 VDC,
Switching output switchable between PNP/NPN,
Analog output switchable between 4…20 mA/0…10 V,
Automatic current/voltage detection, IO-Link, 4-digit, 2-colored, 14-segment display, Housing is rotatable by 180° after mounting the process connection,
Process connection G1",
Pressure resistance -1…16 bar rel.
Internal Reference |
100048852 |
| Brand | TURCK |
| Electrical connection | M12 |
| Process sensor output | Analog 4-20 mA, Analog 0-10 V, Transistor |
| Communication | IO-Link |
| Process connection | G 1" |
Datu lapa_100048852.pdf
Download
