Duct mount CO2 concentration t-line WebSensor.

Transmitter with built-in concentration CO2, temperature, relative humidity sensor for duct mount.

A multiple point CO2 and temperature adjustment procedure leads to excellent CO2 measurement accuracy over the entire temperature working range; this is a must for process control and outdoor applications. The dual wavelength NDIR CO2 sensing procedure compensates automatically for ageing effects. The CO2 module is highly resistant to pollution and offers maintenance free operation and outstanding long term stability.

Green LED shines - CO2 concentration 0 to 1000 ppm

Yellow LED shines - CO2 concentration 1001 to 1200 ppm

Red LED shines - CO2 concentration 1201 ppm and more

Extended measuring range available for an additional charge

• Measuring range: 0 to 10 000 ppm
• Accuracy: 100 ppm + 5% of the measured value at 25 °C and 1013 hPa
