Humidity Sensor 0...100%rh, 4...20mA, 10-30VDC, -80...200°C
Humidity-Sensor
for operating temperatures -80...200°C
transmitter box from aluminium-die casting no display
sensor tube high-grade steel 1.4301/special plastics, Ø 15mm
length: aprox. 243 mm
duct mounting
Output 1: relative humidity
Output range 1: 0...100 % rh
Output signal 1: 4...20 mA
Output 2: not
Supply voltage: 10...30 VDC
outputs digital adjustable with push-buttons
operation temperature range transmitter: -40...85°C
operation temperature range sensor tube: -80...200°C please note
the assembly instructions!
Filter: : sintered filter made of high-grade steel, ZE13
Internal Reference:
BKF3.TH.F100.A13.00J
